SAYFA KATT RL429T User manual

THIS PROPERTY REMAINS THE PROPERTY OF SAYFA GROUP AND MAY NOT BE CHANGED WITHOUT WRITTEN
PERMISSIONFOR FURTHER INFORMATION REFER TO OUR WEBSITE AT sayfa.com.au
1029 MOUNTAIN HWY BORONIA VIC 3155
T [phone]
E [email protected]
F [phone]
E sayfa.com.au
DRG No.
DATE
Code
REV
DESCRIPTION
RL429T - LADDER HEAD CANTILEVER
PLATFORM INSTALL DETAILS
D9369
28/9/2022
RL429T
3 (RL update)
3200
1800
687
8 x 75mm SCREW BOLT
OR 10mm TRU-BOLT
2 PER BRACKET
PURLIN/CLADDING INSTALLATION
CONCRETE INSTALLATION
SUPPORT BRACKET
(MAY BE CUT DOWN TO SUIT)

THIS PROPERTY REMAINS THE PROPERTY OF SAYFA GROUP AND MAY NOT BE CHANGED WITHOUT WRITTEN
PERMISSIONFOR FURTHER INFORMATION REFER TO OUR WEBSITE AT sayfa.com.au
1029 MOUNTAIN HWY BORONIA VIC 3155
T [phone]
E [email protected]
F [phone]
E sayfa.com.au
DRG No.
DATE
Code
REV
DESCRIPTION
RL429T - LADDER HEAD CANTILEVER
PLATFORM INSTALL DETAILS
D9369
28/9/2022
RL429T
3 (RL update)
Allow 750mm
for ladder
GUTTER
3200
400 MAX
PLATFORM SUPPORT CHANNELS
PLATFORM
STEP 1 - POSITION AND FIX PLATFORM SUPPORT CHANNELS TO ROOF DECK
EPDM SEAL UNDER
QTY 4 x 8mm BULB TYPE
RIVETS PER BATTEN
EPDM SEAL
GUIDE FOR POSITIONING OF CHANNELS

THIS PROPERTY REMAINS THE PROPERTY OF SAYFA GROUP AND MAY NOT BE CHANGED WITHOUT WRITTEN
PERMISSIONFOR FURTHER INFORMATION REFER TO OUR WEBSITE AT sayfa.com.au
1029 MOUNTAIN HWY BORONIA VIC 3155
T [phone]
E [email protected]
F [phone]
E sayfa.com.au
DRG No.
DATE
Code
REV
DESCRIPTION
RL429T - LADDER HEAD CANTILEVER
PLATFORM INSTALL DETAILS
D9369
28/9/2022
RL429T
3 (RL update)
STEP 2 - ASSEMBLE KOMBI PLATFORM FRAME
KOMBI 80 EXTRUSION
KOMBI PLATFORM CROSS SUPPORT
KOMBI 80 ANGLE BRACKET
650
KOMBI T-BOLTS
300mm WIDE
NARROW MESH
30mm TEK SCREW &
WALKWAY DISC
WALKWAY EDGE BAR
REFER TO KOMBI INSTALLATION DETAILS
https://kombiaccess.com/wp-
content/uploads/2018/10/KOMBI_Stair_and_
Platform_Install_Manual.pdf

THIS PROPERTY REMAINS THE PROPERTY OF SAYFA GROUP AND MAY NOT BE CHANGED WITHOUT WRITTEN
PERMISSIONFOR FURTHER INFORMATION REFER TO OUR WEBSITE AT sayfa.com.au
1029 MOUNTAIN HWY BORONIA VIC 3155
T [phone]
E [email protected]
F [phone]
E sayfa.com.au
DRG No.
DATE
Code
REV
DESCRIPTION
RL429T - LADDER HEAD CANTILEVER
PLATFORM INSTALL DETAILS
D9369
28/9/2022
RL429T
3 (RL update)
ADJUST PLATFORM HEIGHT THEN
FIX OFF WITH TEK 20mm SCREWS
KOMBI T-BOLT
20mm TEK SCREWS INTO BATTEN
STEP 3 - POSITION AND FIX PLATFORM
INSERT SPLICE INTO POST
STEP 1
STEP 2
STEP 3

THIS PROPERTY REMAINS THE PROPERTY OF SAYFA GROUP AND MAY NOT BE CHANGED WITHOUT WRITTEN
PERMISSIONFOR FURTHER INFORMATION REFER TO OUR WEBSITE AT sayfa.com.au
1029 MOUNTAIN HWY BORONIA VIC 3155
T [phone]
E [email protected]
F [phone]
E sayfa.com.au
DRG No.
DATE
Code
REV
DESCRIPTION
RL429T - LADDER HEAD CANTILEVER
PLATFORM INSTALL DETAILS
D9369
28/9/2022
RL429T
3 (RL update)
KOMBI T-BOLTS
KOMBI 60 BRACE
BRACE SUPPORT
AL732 - 100 x 50 x 6 ANGLE
KB017 - KOMBI BRACE PLATE
M10 x 75 BOLT
QTY 4 x 14G TEK SCREW INTO PURLIN
(2 AT THE TOP & 2 AT THE BOTTOM)
STEP 4 - ATTACH ANGLE SUPPORTS AND BRACES
SUPPORT MAY BE BOLTED
ANYWHERE ON ANGLE
MIN 45°
14G TEK

THIS PROPERTY REMAINS THE PROPERTY OF SAYFA GROUP AND MAY NOT BE CHANGED WITHOUT WRITTEN
PERMISSIONFOR FURTHER INFORMATION REFER TO OUR WEBSITE AT sayfa.com.au
1029 MOUNTAIN HWY BORONIA VIC 3155
T [phone]
E [email protected]
F [phone]
E sayfa.com.au
DRG No.
DATE
Code
REV
DESCRIPTION
RL429T - LADDER HEAD CANTILEVER
PLATFORM INSTALL DETAILS
D9369
28/9/2022
RL429T
3 (RL update)
STEP 5
ATTACH HANDRAIL, KNEERAIL AND TOEBOARD AND
LADDER BRACKET
CONNECT KNEERAIL TO
SIDE OF LADDER STILE
ENSURE NO GAPS
GREATER THAN 100mm
ATTACH HANDRAIL KNEERAIL AND TOEBOARD
AS PER SENTRY INSTRUCTION MANUAL
JOINER BAR
T-BOLT

THIS PROPERTY REMAINS THE PROPERTY OF SAYFA GROUP AND MAY NOT BE CHANGED WITHOUT WRITTEN
PERMISSIONFOR FURTHER INFORMATION REFER TO OUR WEBSITE AT sayfa.com.au
1029 MOUNTAIN HWY BORONIA VIC 3155
T [phone]
E [email protected]
F [phone]
E sayfa.com.au
DRG No.
DATE
Code
REV
DESCRIPTION
RL429T - LADDER HEAD CANTILEVER
PLATFORM INSTALL DETAILS
D9369
28/9/2022
RL429T
3 (RL update)
300
290
VERTICAL
HEIGHT
MAX 6000
5800
DISTANCE BETWEEN LANDINGS
MUST BE IN INCREMENTS OF 290mm
GUIDE FOR DISTANCE BETWEEN LANDINGS
75°
80°
295
PREFERRED ANGLE
