Scag Power Equipment GC-STWC-61V User manual

MODEL GC-STWC-61V
THISMANUALCONTAINSTHEOPERATING
INSTRUCTIONS AND SAFETY INFORMA-
TIONFORYOURSCAGACCESSORY. READ-
ING THIS MANUAL WILL PROVIDE YOU
WITH MAINTENANCE AND ADJUSTMENT
PROCEDURESTO KEEPYOURACCESSORY
PERFORMING TO MAXIMUM EFFICIENCY.
THE SPECIFIC MODELS THAT THIS BOOK
COVERSARE CONTAINED ON THE INSIDE
COVER. BEFORE OPERATING YOUR MA-
CHINE,PLEASE READ ALL THE INFORMA-
TION ENCLOSED.
PART NUMBER 03179
OPERATOR’S MANUALOPERATOR’S MANUAL OPERATOR’S MANUALOPERATOR’S MANUAL
OPERATOR’S MANUAL

FAILURE TO FOLLOW SAFE OPERATING PRACTICES
MAY RESULT IN SERIOUS INJURY.
* Keep all safety shields in place.
* Beforeperforminganymaintenance or service, stop themachineand
remove the spark plug wire.
* Ifamechanism becomes clogged, stopthe engine before cleaning.
* Keephands,feetandclothing away from power-driven parts.
* Readthismanualcompletelyaswell as the Operator's Manual that came
withyourmower.
* Keepothersoff the tractor (onlyoneperson at a time).
REMEMBER - YOUR MOWER IS ONLY AS SAFE AS THE OPERATOR!
Hazard control and accident prevention are dependent upon the awareness,
concern, prudence, and proper training of the personnel involved in the
operation, transport, maintenance, and storage of the equipment.
WARNING
Thismanualcovers the operating instructions
andillustratedpartslist for:
GC-STWC-61V with a serial number of B8400001 to B8499999

1
1.1 INTRODUCTION
This manual has been prepared to provide the
information you need to correctly assemble, operate,
and maintain this grass catcher. Read it carefully and
keep it for future reference.
The replacement of any part on this product by other
than the manufacturer's authorized replacement part
may adversely affect the performance, durability or
safety of this product.
USE OF OTHER THAN ORIGINAL SCAG
REPLACEMENT PARTS WILL VOID THE
WARRANTY.
If additional information or service is needed that is
not outlined in this manual, please contact your Scag
Power Equipment dealer. Scag dealers are trained in
the latest service methods and carry a full line of Scag
replacementparts.
When ordering parts, always provide the complete
model number of your catcher.
All information provided in this manual is based upon
information available at the time of printing. Scag
Power Equipment reserves the right to make changes
at any time without notice or obligation.
A replacement manual is available from your
authorized Scag Service Dealer or by contacting:
Scag Power Equipment, Service Department at P.O.
Box 152, Mayville, WI 53050. You may also contact
us through our website at www.scag.com. The
manual for this grass catcher can be downloaded by
using the model and serial number or use the contact
form to make your request. Please indicate the
complete model and serial number of your Scag
product when requesting replacement manuals.
1.2 DIRECTION REFERENCE
The "Right" and "Left", "Front" and "Rear" of the
machine are referenced from the normal operating
position.
2. Before removing the grass bags, disengage the
mower, stop the engine and wait for all
movement to stop.
3. ALWAYS turn the engine OFF, remove the key
and wait for all movement to stop before
servicing or cleaning the mower or the grass
catcher.
4. Do not modify or alter any component of the
grass catcher attachment or mower.
5. Do not allow any passengers to ride on the grass
catcher attachment or on the mower.
WARNING
WARNING
DO NOT OPERATE WITHOUT DISCHARGE CHUTE, MULCHING
KIT, OR ENTIRE GRASS CATCHER INSTALLED
2.1 SAFETY AND OPERATING
INSTRUCTIONS
-NOTE-
To avoid personal injury, it is imperative that all
safety instructions be observed.
1. Readthisoperator's manual andthe
operator'smanualthatis suppliedwiththe
machinethisattachmentisusedon.
DANGER
DANGER
ROTATING BLOWER
BLADES
STOP ENGINE BEFORE
ENTERING CHUTE
CONTACT CAN INJURE

2
3.1 ASSEMBLY INSTRUCTIONS FOR 61"
CUTTER DECK
-NOTE-
Use the illustrated parts list as a part number
reference when following the assembly
instructions.
1. Remove all packaging materials. Lay out the
mounting hardware and the catcher assembly
parts for easy access. Prepare the work area
making sure that it is a clean, safe environment.
2. Remove the discharge chute from the cutter
deck. See Figure 3-1.
-NOTE-
Do not discard the discharge chute or
mounting hardware. The discharge chute
MUST be reinstalled anytime the grass
catcher has been removed from the machine.
3. Remove the right side belt cover to gain access to
the spindle assembly. Remove the front u-nut
from the cutter deck bracket. See Figure 3-1.
FIGURE 3-1
-NOTE-
Retain the original belt cover. This cover
MUST be reinstalled anytime the
complete catcher system is removed.
4. Install the grass catcher pulley onto the spindle
assembly. Apply loctite to both pulley setscrews
and tighten. See Figure 3-1.
5. Remove the "Custom-Cut" and "Turbo" baffles
from the cutter deck. Using the original
hardware, install the new "Front" and "Turbo"
baffles. See Figure 3-2.
WARNING
WARNING
DO NOT OPERATE WITHOUT DISCHARGE CHUTE, MULCHING
KIT, OR ENTIRE GRASS CATCHER INSTALLED
RIGHT SIDE OF
CUTTER DECK SHOWN
(Note: Some parts not shown for viewing purposes.)
REMOVE DISCHARGE
CHUTE AND
HARDWARE
REMOVE EXISTING
RT. SIDE BELT
COVER
INSTALL PULLEY
ON RH SPINDLE SHAFT -
ON TOP OF EXISTING
SPINDLE DRIVE
PULLEY
Figure 1- GC-STC-V install art
REMOVE U-NUT
FIGURE 3-2
-NOTE-
Do not discard the original "Custom-Cut"
or "Turbo" baffles. These baffles may be
reinstalled anytime the grass catcher has
been removed from the machine.
6. Install the blower mounting bracket to the deck
using carriage bolts (p/n 04003-11), lockwashers,
and nuts. Do not fully tighten the hardware at
this time. See Figure 3-3.
ELASTIC STOP
NUT
FLATWASHER
CARRIAGE BOLT
FIGURE 3-3
UNDER SIDE OF
VELOCITY-PLUS
CUTTER DECK SHOWN
Front Baffle
61V - 424403
Turbo Baffle
61V - 424212

3
12. Install the hopper mounting brackets to the
outside of the frame on the rear of the machine.
See Figure 3-6.
FIGURE 3-6
13. Attach the hood assembly to the machine by
installingthemountingpostintothehopper
mounting brackets. Secure with the ring pins
and tighten the locking bolts. See Figure 3-7.
FIGURE 3-7
14. Install the hose from the blower assembly
adapter to the hopper hood and secure using the
8-1/2"clamps.
15. Install the bag assemblies.
7. Install the blower assembly to the mounting
bracket and secure with the mounting pin.
See Figure 3-4.
8. Align the blower assembly with the discharge
opening of the cutter deck. Tighten the
hardware for the mounting bracket. See Figure
3-4.
9. Install the quick pin through the rear hole in the
discharge chute mounting bracket. See Figure 3-
4.
FRONT SIDE
IDLER PULLEY
BACK SIDE
IDLER PULLEY BLOWER
PULLEY
SPINDLE
PULLEY
10. Install the belt to the spindle pulley. When
replacing the belt, see figure 3-5 below.
FIGURE 3-4
11. Install the new belt covers and secure. See
items number 1 and number 21 on page 10 of the
Blower Mounting Components section in the
Illustrated Parts List for proper installation.
Figure 4 A GC-STT Install Art
Hopper
Mounting
Brackets
Rear Frame
Ring Pins
Ring Pins
Locking
Bolts
Locking
Bolts
FIGURE 3-5
16. Using the weight support bar as a guide, identify
the four corresponding mounting holes, and the
existing hardware that will need to be removed in
order to secure the weight support bar to the
front of the machine as shown. See Figure 3-8,
Page 4.
RIGHT SIDE OF
CUTTER DECK SHOWN
(Note: Some parts not shown for viewing purposes.)
2006 GC-STC-V install art 3
BLOWER
ASSEMBLY
MOUNTING
BRACKET
MOUNTING PIN
TIGHTEN MOUNTING
BRACKET HARDWARE
HAIR
PIN
QUICK
PIN

4
17. Install one 7/16-14 x 1-3/4" hex head bolt into
each of the four mounting holes in the weight
support bar, and through the matching holes in
the caster support weldment. Secure this
assembly to the front of the machine using the
7/16 - 1/2" x 1-1/4" x .083" flatwashers, and the
7/16-14 elastic stop nuts. Torque hardware to
59 ft. lbs. See Figure 3-8.
FIGURE 3-8
18. Operate and test.
FIGURE 4-2
6. With help from an assistant, remove the hood
assembly.
Remove Pins
Remove Pins
Loosen
Locking
Bolts
Loosen
Locking
Bolts
4.1 GRASS CATCHER REMOVAL
INSTRUCTIONS
1. Prepare the machine so there is easy and safe
access to the work area. Remove the key and
maintain all safety related work procedures.
Always wear eye and hand protection.
2. Remove the bag assemblies from the grass
catcher.
3. Remove the rubber strap holding the adapter to
the blower assembly and the large quick pin
securing the blower to the discharge mounting
bracket. See Figure 4-1.
4. Remove the belt, pin, hair pin and large quick pin
securing the blower assembly to the cutter deck
and remove the blower assembly. See Figure 4-
1.
FIGURE 4-1
5. Loosen the locking bolts and remove the two (2)
pinsholding thehoodassemblytothemounting
posts on the rear of the machine. See Figure
4-2.
BLOWER
ASSEMBLY
MOUNTING
BRACKET
PIN & HAIR PIN
ADAPTER
RIGHT SIDE OF
CUTTER DECK SHOWN
(Note: Some parts not shown for viewing purposes.)
2006 GC-STC-V removal art 1
QUICK PIN

5
WARNING
WARNING
DO NOT OPERATE WITHOUT DISCHARGE CHUTE, MULCHING
KIT, OR ENTIRE GRASS CATCHER INSTALLED
7. Re-install the side discharge chute to the opening
on the cutter deck. Replace the two outside
mounting bolts on the discharge chute with the
clevis pins (p/n 04064-15) and rue cotter pins
(p/n 04069-03). See Figure 4-3.
8. Re-install the cutter deck belt cover.
FIGURE 4-3
CLEVIS PIN
P/N 04064-15
CLEVIS PIN
P/N 04064-1
5
RUE COTTER PIN
P/N 04069-03
DISCHARGE
CHUTE
GC-STC-V removal art 3

6
5.1 MAINTENANCECHART - RECOMMENDEDSERVICE INTERVALS
* Perform these maintenance procedures more frequently under extreme dusty or dirty conditions.
MAINTENANCE
HOURS
Break-In 8 20 40 100 200 500 Procedure Comments
(First 10)
X Check all hardware for tightness
X Inspect hose and adapter
X Check belt for proper alignment
X Inspect fabric bags
X *Check screen in hopper Remove debris from screen
X Inspect hose and adapter
X Inspect fabric bags
X Check condition of blower
X *Apply grease to blower bearings See figure below
X Check belt for proper alignment
GREASE FITTING
ON BEARING HOUSING
GREASE FITTING
ON BEARING HOUSING
BEHIND PULLEY

7
NOTES

8
GC-STWC-61V BLOWER HOUSING ASSEMBLY
2006 GC-STWC-61V Blower Assembly
35
35
35
4
7
8
9
9
10
10
11
11
12
12
13
14
14
14
14
15
15
16
17
18
19
20 21
22
23
24
24
27
27
28
30
31
32
33
34
35
35
37
38
39
40
41
41
42
43
44
10
46
34
29
11
14
17
45
36
25
ROTATINGBLADESANDBLOWER
DANGER
DO NOT OPERATE MOWER
UNLESS GRASS CATCHER OR
DISCHARGE GUARD IS INSTALLED
Stop engine before cleaning or removing
DANGER
ROTATINGBLOWER
BLADES
STOPENGINEBEFORE
ENTERINGCHUTE
CONTACTCANINJURE
6
DANGER
ROTATINGBLOWER
BLADES
STOPENGINEBEFORE
ENTERINGCHUTE
CONTACTCANINJURE
5
DANGER
DANGER
47
11
14
WARNING
INSTALLBELTCOVERBEFORE
OPERATINGMACHINE
READ OPERATOR'S MANUAL
26
14
1
17
2
48
3
31
35

9
GC-STWC-61V BLOWER HOUSING ASSEMBLY
Ref. Part
No. Number Description
27 04019-04 Nut, Serr. Flange 3/8-16
28 04001-136 Bolt, Hex Head 3/8-16 x 1-1/2 Gr. 8
29 483037 Decal, Danger
30 461931 Blower Housing Weldment
31 04003-12 Bolt, Carr. 5/16-18 x 3/4" Gr. 5
32 04063-06 Key, 1/4 x 1/4 x 1-1/2"
33 461796 Fan Weldment
34 483034 Bearing Assembly
35 04019-03 Nut, Serr. Flange 5/16-18
36 461930 Blower Housing Assembly, GC-STT
37 421319 Cover, Blower Housing
38 48136-02 Clamp, 8-5/8" Max Dia.
39 48135-14 Hose, 8.00" Dia. x 60.50" Long
40 482298 Pulley, 4-3/4" O.D. - 1" Bore
41 04012-04 Set Screw, 5/16-18 x 3/8"
42 461932 Frame, Blower Mount
43 481522 Spring, Main Drive
44 43212 Spacer
45 04062-04 Hair Pin Cotter, .177 x 3-1/4"
46 461723 Adapter w/Strap
47 451821 Receiver Weldment, Mounting Post
48 424367 Dust Shield
Ref. Part
No. Number Description
1 04067-10 Pin, Ring 2-1/4" Long
2 481547 Lanyard, Deck Height Pin
3 04066-04 Quick Pin, 5/16" Dia.
4 04001-21 Bolt, Hex Head 3/8-16 x 1-3/4"
5 481377 Decal, Blower
6 482080 Decal, Rotating Blower
7 481428 Grip, Blower Lever
8 483223 Cap, Square
9 04024-02 Nut, Push On 3/8 Thread
10 04021-05 Lock Nut, 3/8-16
11 04041-07 Flatwasher, 3/8-.391 x .938 x .105
12 43277 Spacer
13 483209 Pulley, Idler 4" Dia.
14 04021-09 Nut, Elastic Stop 3/8-16
15 04030-04 Lockwasher, 3/8-16
16 424361 Plate, Catcher Mounting
17 04003-05 Bolt, Carr. 3/8-16 x 1-1/2"
18 04001-46 Bolt, Hex Head 3/8-16 x 2-1/4"
19 04001-81 Bolt, Hex Head 3/8-16 x 3-1/2"
20 04001-21 Bolt, Hex Head 3/8-16 x 1-3/4"
21 461928 Idler Arm Assembly
22 483182 Belt, GC-STC
23 483189 Pulley, 3-1/2" O.D., GC-STC
24 04043-04 Washer, 3/8 Hardened
25 43575 Pivot, Idler
26 482871 Decal, Belt Cover

10
GC-STWC-61V" BLOWER MOUNTING COMPONENTS
UNDER SIDE OF
VELOCITY-PLUS
CUTTER DECK SHOWN
23
23
28
24
24
25
25
26
26
16
16
25
27
1
2
3
4
5
6
6
7
8
9
10
10
11
12 13
14 15
15
16
17
18
19
20
2006 GC-STC-V BMC
21
22
RIGHT SIDE OF
CUTTER DECK SHOWN

11
GC-STWC-61V" BLOWER MOUNTING COMPONENTS
Ref. Part
No. Number Description
1 483227 Belt Cover, GC-61V
2 04029-04 Wingnut, Plastic 3/8" Small
3 483223 Cap, Square Vinyl
4 04021-08 Nut, Elastic Stop 1/4-20
5 461723 Adapter, Blower GC-STC, includes item #7
6 04040-14 Flatwasher, 1/4-.312 x .750 x .065
7 48137-04 Rubber Strap 7-3/4"
8 04001-59 Bolt, Hex Head 1/4-20 x 1-1/4"
9 481625-01 Knob W/Stud, 3/8-16 x 1-1/4"
10 04064-15 Clevis Pin, 5/16 x 1-1/2"
11 04069-03 Pin, Rue Cotter 5/16 Dia.
12 04067-10 Pin, Ring 1/2 x 2-1/4"
13 481547 Lanyard
14 482377 Pulley, 5-1/2" Dia. 1.125 Bore
15 04012-04 Setscrew, 5/16-18 x 3/8"
16 04021-09 Nut, Elastic Stop 3/8-16
17 04030-04 Lockwasher, 3/8"
18 04041-07 Flatwasher, 3/8-.391 x .938 x .105
19 04003-11 Bolt, Carr. 3/8-16 x 1-1/4" Grade 5
20 461894 Mounting Post Weldment, Blower
21 424328 Belt Cover, GC-61V
22 04110-03 U-Nut
23 04003-23 Bolt, Carriage 3/8-16 x 1"
24 04001-09 Bolt, Hex Head 5/16-18 x 1"
25 04040-15 Flatwasher, 5/16-.375 x .875 x .083
26 04021-10 Nut, Elastic Stop 5/16-18
27 424403 Baffle, Front 61" Deck
28 424212 Baffle, Turbo 61" Deck

12
GC-STWC-61V BUCKET SUPPORT COMPONENTS (UPPER)
1
2
3
4
4
6
8
5
59
9
9
9
5
11
516
16
16
16
16
16
18
18
13
13
19
20
14
21
21
22
23
23
24
31
11
5
32
33
33
26
27
28
29
30 32
3
36
37
35
25
31
35
38
17
15
9
34
4
5
7
12
10
39
40

13
GC-STWC-61V BUCKET SUPPORT COMPONENTS (UPPER)
Ref. Part
No. Number Description
1 423302 Screen, Catcher Hood
2 04090-02 Pop Rivet, 3/16 x .652
3 04041-19 Flatwasher, 3/16-.196 x .469 x .048
4 04001-32 Bolt, Hex Head 3/8-16 x 1-1/4"
5 04041-01 Flatwasher, 3/8-.391 x .938 x .105
6 461408 Hood Assembly, GC-STT (includes items 1, 2 & 3 and items 2 & 15 on page 15)
7 04001-117 Bolt, Hex Head 7/16-14 x 1-3/4"
8 423258 Hinge, Upper LH
9 04021-09 Nut, Elastic Stop 3/8-16
10 04040-11 Flatwasher, 7/16-.500 x 1-1/4"
11 04001-46 Bolt, Hex Head 3/8-16 x 2-1/4"
12 04021-11 Nut, Elastic Stop 7/16-14
13 04001-20 Bolt, Hex Head 3/8-16 x 1-1/2"
14 04001-135 Bolt, Hex Head 3/8-16 x 1-3/4" Grade 8
15 451674 Support Weldment, Bag Frame
16 04019-04 Nut, Serrated Flange 3/8-16
17 04090-03 Rivot, 3/16 x .402 POP
18 43546 Bushing, Hopper Pivot
19 482304 Spring, Hood Hinge
20 423436 Hinge, Lower LH
21 43212 Spacer
22 04021-05 Locknut, 3/8-16
23 43277 Spacer
24 423259 Hinge, Upper RH
25 423261 Hinge, Lower RH
26 48135-14 Hose, 8" Dia. x 60-1/2"
27 48136-02 Clamp, 8-5/8" Max Dia.
28 482422 Tube, Filler
29 482421 Elbow
30 04001-10 Bolt, Hex Head 5/16-18 x 1-1/4"
31 04021-10 Nut, Elastic Stop 5/16-18
32 04040-15 Flatwasher, 5/16-.375 x .875 x .083
33 04041-11 Flatwasher, 3/8- .406 x 1-1/2" x .179
34 04030-04 Lockwasher, 3/8" Spring
35 482409 Latch
36 04010-25 Screw, #10-32 x 3/4"
37 04021-01 Nut, Elastic Stop #10-32
38 04001-08 Bolt, Hex Head 5/16-18 x 3/4"
39 451517 Support Weldment, Weights
40 461097 Weight Assembly

14
GC-STWC-61V BUCKET SUPPORT COMPONENTS (LOWER)
STC 2002 BSC
1
2
11
14
15
16
17
18
19
20
21
22
23
24
4
13
5
4
6
7
8
4
3
8
12
6
7
4
4
5
FRAME
9
4
5
10
10A
"A"
TO "A"
3
6
6
9

15
GC-STWC-61 BUCKET SUPPORT COMPONENTS (LOWER)
Ref. Part
No. Number Description
1 04090-02 Pop Rivet, 3/16 x .652
2 482321 Seal, Hood
3 423262 Tube, Upright
4 04041-07 Flatwasher, 3/8-.391 x .938 x .105
5 04021-09 Nut, Elastic Stop 3/8-16
6 04020-04 Nut, 3/8-16
7 04021-05 Hex Lock Nut, 3/8-16
8 04067-07 Pin, Ring 1/2 x 2-1/4"
9 04001-19 Bolt, Hex Head 3/8-16 x 1"
10 451726 Mounting Bracket Weldment RH
10A 451725 Mounting Bracket Weldment LH
11 04021-02 Lock Nut, 1/4-20 Center
12 04001-46 Bolt, Hex Head 3/8-16 x 2-1/4"
13 04001-31 Bolt, Hex Head 3/8-16 x 2-1/2"
14 482569 Bag Assembly, GC-STT
15 423312 Retainer, Seal
16 451674 Support, Bag Frame
17 04003-02 Bolt, Carr. 1/4-20 x 3/4"
18 04001-08 Bolt, Hex Head 5/16-18 x 3/4"
19 423198 Mount, Bag Frame Tube
20 04003-12 Bolt, Carr. 5/16-18 x 3/4"
21 423197 Tube, Bag Support
22 04019-03 Nut, Serr. Flange 5/16-18
23 04040-15 Flatwasher, 5/16-.375 x .875 x .083
24 04021-10 Nut, Elastic Stop 5/16-18

16
GC-STC DECALS
482871
482275
481327
483037
481377
482080
483044
482080
482871
MANUFACTURED UNDER ONE OR MORE
OF THE FOLLOWING PATENTS:
4,487,006 4,885,903 4,920,733 4,967,543
4,991,382 4,998,948 5,042,239 5,118,617
5,133,176 5,826,416 5,832,708 5,865,018
6,192,666 6,766,633 6,892,519
PATENTS PENDING

LIMITED WARRANTY- COMMERCIAL ACCESSORY
AnypartoftheScagcommercialaccessorymanufacturedbyScagandfound,inthereasonablejudgmentofScag,
tobedefectiveinmaterialorworkmanship,willberepairedorreplacedbyanAuthorizedScagServiceDealerwithout
chargeforpartsandlabor.
TheScagaccessory, includingany defectivepart,mustbe returned toanAuthorizedScag ServiceDealerwithin
thewarrantyperiod. The expense of delivering the accessory to the dealer for warranty work and the expense of
returningitbacktotheownerafterrepairorreplacementwillbepaidforbytheowner. Scag’sresponsibilityinrespect
toclaimsislimitedtomakingtherequiredrepairsorreplacements,andnoclaimofbreachofwarrantyshallbecause
forcancellationorrescissionofthecontractofsaleofanyScagmachine. Proofofpurchasewillberequiredbythe
dealer to substantiate any warranty claim. All warranty work must be performed by an Authorized Scag Service
Dealer.
Thiswarrantyislimited to90daysfromthe dateoforiginalretailpurchase foranyScagaccessorythat isusedfor
commercialpurposes, oranyotherincome-producing purposeincludingrentaluse.
Thiswarrantydoes not coveranyaccessorythat hasbeensubjectto misuse,neglect,negligence,or accident, or
thathasbeenoperatedinanywaycontrarytotheoperating instructionsasspecifiedintheOperator'sManual. The
warranty does not apply to any damage to the accessory that is the result of improper maintenance, or to any
accessory or parts that have not been assembled or installed as specified in the Operator's Manual.
Thewarrantydoesnotcoveranyaccessory that has been altered or modified. In addition, the warranty does not
extendtorepairsmadenecessarybynormalwear,orby the use of parts or accessories which, inthereasonable
judgment of Scag, are either incompatible with the Scag mower or adversely affect its operation, performance or
durability. This warranty does not cover engines and electric starters, which are warranted separately by their
manufacturer.
ScagPowerEquipmentreservestherighttochangeorimprovethedesignofanyaccessorywithoutassumingany
obligation to modify any accessory previously manufactured.
All other implied warranties are limited in duration to the 90 day warranty period. Accordingly, any such implied
warrantiesincludingmerchantability, fitness foraparticularpurpose, orotherwise,aredisclaimed in theirentirety
aftertheexpirationof theappropriateninetyday warrantyperiod. Scag’s obligationunderthiswarrantyis strictly
andexclusivelylimitedtotherepairorreplacementofdefectivepartsandScagdoesnotassumeorauthorizeanyone
toassumeforthemanyotherobligation. Somestatesdonotallowlimitationsonhowlonganimpliedwarrantylasts,
so the above limitation may not apply to you.
Scagassumesnoresponsibilityforincidental,consequentialorotherdamagesincluding,butnotlimitedto,expense
forgasoline,oil,expenseofdeliveringthemachinetoanAuthorizedScagServiceDealerandexpenseofreturning
itbacktotheowner,mechanic’straveltime,telephoneortelegramcharges,rentalofalikeproductduringthetime
warrantyrepairsarebeingperformed,travel,lossordamagetopersonalproperty,lossofrevenue,lossofuseof
the mower, loss of time, or inconvenience. Some states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

PART NO. 03179
PRINTED 8-2005
PRINTED IN USA
©2005
SCAG POWER EQUIPMENT
DIVISION OF METALCRAFT OF MAYVILLE, INC.
WWW.SCAG.COM
