NOTE: Whilewehavenoreasontobelievethatthegluingoptionmightnegatively
aectanyhelmet,Cardodoesnotassumeanyresponsibilitytothataect,irrespective
ofitsnatureandcircumstances.TheGluePlateisoeredasafreeoptionthatyoumay
choose to use at your own risk and subject to renouncement of any future claims.
Caution: This process can be done only once!
1. Use the enclosed Allen Wrench to remove both Allen screws
and release the Helmet Clamp’s back plate.
2. Determine the location on the helmet where the
Helmet Clamp must be attached.
3. Adjust the Helmet Clamp’s location on the Helmet so that
the microphone is located opposite your mouth. You
may need to reposition the Clamp repeatedly until you
identify the best spot. The microphone must be
positioned vertically and not horizontally (Be sure to clean
the selected area prior to the gluing process).
4. Use the pre-moistened Towelette to clean the helmet area where you
want to install the Glue Plate. Allow to dry thoroughly.
5. Peel the foil cover from the Glue Plates’ adhesive pad.
6. Place the Glue Plate into position according to #3. Press rmly 15 sec-
onds on all 3 parts of the Glue Plate.
7. The adhesive pad bonds to full strength over the next 24 hours. There-
fore it is recommended to not use the headset during this 24 hour
period.
8. Fasten the Clamp to the Glue Plate using the Allen screws that were
previously removed.
SPEAKERS AND MICROPHONE POSITIONING
The microphone must be positioned vertically, not
horizontally, in front of the center of the mouth.
Attach the speakers to the Velcro inside your
helmet opposite your ears (short speaker cord for
Speaker A
Speaker B
4Audio & Microphone Kit
