SCAN-LINK Mobile Tag Health Tester User manual

BEFORE UNPACKING
READ THIS GUIDE!
This Quick Start Guide 1_1 will show you how to use
the SCAN~LINK Mobile Tag Health Tester v.05
CONTENTS/REQUIREMENTS
PACKAGE CONTENTS
PAGE 2
USAGE INSTRUCTIONS
PAGE 3
TROUBLESHOOTING
PAGE 7
SPECIFICATIONS
PAGE 8
LIMITED WARRANTY
PAGE 9

2
Tag Health Tester Mobile Quick Start Guide 1_1
PACKAGE CONTENTS:
SCAN~LINK
Mobile Tag Health Tester
with 5V 4A Power Supply
and Touchscreen Tablet
EQUIPMENT/
MATERIALS REQUIRED:
A 120VAC wall outlet
SERIAL NUMBERS (MACs)
Write these down now before installing:
Mobile THT
00 : 1C : 2C : XX : XX : XX : XX : XX

3
Tag Health Tester Mobile Quick Start Guide 1_1
USAGE INSTRUCTIONS
POWER UP
Open the case with the handle on the bottom half. The power
adapter is stored inside.
Plug in the power adapter to the wall, and insert the barrel
connector in to the base of the Tester, located between the
hinges on the rear of the case.
TURN ON THE TOUCHSCREEN TABLET
If the Tag Health Tester has been provided power, you should
see a small orange light flashing in the top-left face of the
tablet.
Press and hold the power button, located on the top edge of
the tablet on the left, for three seconds.
The tablet takes approximately thirty seconds to fully start.
The Touchscreen will, after booting, show this:

4
Tag Health Tester Mobile Quick Start Guide 1_1
SETTINGS
By tapping on the gears in the bottom-
right corner you will see a settings
page. Ensure that both sliders are all
the way to the top (set to 63); this
should be default. The COM port
shown at the top may differ from the
one shown in the image to the right.
Click the arrow in the bottom left
corner to close this screen. You are
now ready to test some apparel!
USAGE
First, select the type of apparel you wish to test –yellow vest,
orange vest, or hard hat –by clicking on the apparel type icon
at the top of the screen.
Place the apparel on the Tester in the circular target on the left
side of the case. Tap the ‘Start’ button. The timer will begin to
count down, and the health tester will approach 100% as tags
are detected. Scan time is typically under five seconds.

5
Tag Health Tester Mobile Quick Start Guide 1_1
When the scan is complete, and if all tags are okay, you should
see this:
The output screen will indicate the MAC address of the
apparel, and how many tags were detected.
A piece of apparel will pass if more than 90% of the tags are
present.
If there are damaged tags, the scan will time out after twenty
seconds, and you’ll get a screen like this:

6
Tag Health Tester Mobile Quick Start Guide 1_1
This means that (in this case) only 9 of the 14 (64%) tags in the
vest are functioning properly, and the vest should not be used.
Ensure to re-test a piece of apparel before discarding it, as
poor positioning of the apparel can cause erroneous readings.
You may move the apparel while scanning to ensure all the
tags are within the detection zone above the Tag Health Tester.
EXITING
Press the quit button (the power icon) in the bottom-left of the
window. A confirmation dialog will appear:
Tap ‘Shut Down’ to turn off the touchscreen. When the orange
light in the top-left face of the tablet returns to flashing, it is
safe to disconnect the Power Adapter.

7
Tag Health Tester Mobile Quick Start Guide 1_1
TROUBLESHOOTING
ERR: Communications timeout
Ensure that the channels are both set to 63 in the settings
section.
Apparel works fine in the field but the tester
doesn’t pass
A SCAN~LINK Armour system alarms for the detection of even
a single tag. We include many tags (up to fifteen in an orange
Surveyor’s vest) to improve redundancy and to cover all angles
for optimal detection –as the RFID scan won’t pass through a
human body.
A vest that is detected in one direction may not be detected in
another –for instance, a worker sitting or kneeling facing away
from a machine may not be detected if the tags on the back or
top of the garment are broken.

8
Tag Health Tester Mobile Quick Start Guide 1_1
SPECIFICATIONS
Item
Value
Notes
Input Voltage
5V DC
Input Current
3.5A
Power
Consumption
20W
Temperature
Range
-20°C to +50°C
Ambient
RFID Sensor Radio
Frequency
902.3 –927.7 MHz
North American unlicensed band
Industry Canada
ID
9283A-SLAU270NB
Registered under SCAN-LINK
Technologies Inc.
FCC ID
YUU-SLAU270NB
Registered under SCAN-LINK
Technologies Inc.
Ingress
Protection
Designed for IP-65
Do NOT immerse
RoHS Compliant
Yes

9
Tag Health Tester Mobile Quick Start Guide 1_1
LIMITED WARRANTY
Manufacturer Limited Warranty and Limitation of
Liability
Warranty Coverage
1. SCAN~LINK Technologies Inc. (“SCAN~LINK”) warrants to the original end-user
purchaser (“Purchaser”) of this SCAN~LINK device (“Device”) that the Device
will be free from defects in materials and workmanship and will operate
without mechanical failures under normal use, as defined in this Limited
Warranty, for a period that commences on the date that the Device was
delivered to the vendor who sold the Device (“Dealer”) or delivered to the
Purchaser, whichever date occurs first, and continues for twelve (12) months
thereafter (“Warranty Period”).
2. The warranty provided in this Limited Warranty is the only warranty
SCAN~LINK provides for the Device. SCAN~LINK gives no other guarantee,
warranty or condition, express, statutory, implied or collateral. No one else
may give any guarantee, warranty, or condition on SCAN~LINK’s behalf.
3. This Limited Warranty is not transferrable and is limited to the first Purchaser
of the Device only.
4. If SCAN~LINK repairs or replaces the Device during the Warranty Period, the
Warranty Period for the repaired or replaced Device will expire upon the
expiration of the original Warranty Period. Moreover, the time taken for
transit, repair and/or replacement whether under the Limited Warranty or
otherwise shall not be excluded from the Warranty Period.
5. Warranty repairs must be carried out by SCAN~LINK or its authorized agents.
This Limited Warranty will be void if repairs are attempted by any
unauthorized party, including the Purchaser.
6. Warranty service or support provided by or on behalf of SCAN~LINK under
this Limited Warranty is conditional on the Purchaser reporting any
problem(s) with the Device to the Dealer within the Warranty Period.
7. The Dealer and SCAN~LINK working in conjunction will initially attempt to
troubleshoot the Purchaser’s concerns onsite with the Purchaser.
8. If SCAN~LINK determines that the Device qualifies for mail-in service,
SCAN~LINK will issue a Return Merchandise Authorization (“RMA”) authorizing
shipping of the Device to SCAN~LINK.
9. Any Device shipped to SCAN~LINK is to be mailed in accordance with
SCAN~LINK’s instructions. SCAN~LINK bears no responsibility for any Device
not shipped in accordance with its instructions.

10
Tag Health Tester Mobile Quick Start Guide 1_1
10. After receiving the Device, if SCAN~LINK determines that the Device is
defective and covered under this Limited Warranty, SCAN~LINK may at its
absolute and sole discretion:
i. Repair the defective portion of the Device without charge to the
Purchaser with new or reconditioned parts;
ii. Replace the defective Device without charge to the Purchaser with a
comparable new or refurbished device; or
iii. Refund to the Purchaser the purchase price paid for the Device.
11. If SCAN~LINK determines that the Device is not covered by this Limited
Warranty or that the Limited Warranty has been rendered void, SCAN~LINK
will charge a fee for its efforts to diagnose and service any problems with the
Device, reflecting its time, the cost of parts, and return shipping fees.
12. Service options, parts availability and response times may vary.
13. If SCAN~LINK provides a replacement Device, the returned Device becomes
the property of SCAN~LINK and the replacement Device becomes the
property of the Purchaser.
Warranty Exclusions and Limitations
14. As determined solely by SCAN~LINK, the Limited Warranty does not apply in
situations where damage, malfunction, or defect to the Device is caused by or
results from:
i. misuse, alteration, modification, proximity or exposure to heat, accident,
act of God, abuse, neglect or misapplication;
ii. use of the Device in conjunction with accessories, products, services,
software, applications, or ancillary or peripheral equipment not
expressly approved or provided by SCAN~LINK specifically for use with
the Device;
iii. improper installation or operation not consistent with the Maintenance
Procedures set out in the Manufacturer’s Installation and Operating
Instructions; or
iv. failure to maintain the Device in accordance with the Maintenance
Procedures set out in the Manufacturer’s Installation and Operating
Instructions.
Limitation of Liability
15. Except to the extent that SCAN~LINK is expressly prohibited by law from
limiting or excluding remedies in relation to the Device, this Limited Warranty
sets out the Purchaser’s exclusive remedies for the Device and any other
warranties, conditions, representations, or guarantees of any kind, either
express or implied, including but not limited to implied warranties of

11
Tag Health Tester Mobile Quick Start Guide 1_1
merchantability, satisfactory quality and/or fitness for a particular purpose are
hereby disclaimed and shall not apply or have any affect.
16. SCAN~LINK is not responsible for any indirect, incidental, special or
consequential damages (including without limitation damages for loss of
profits, business interruption, or other pecuniary loss) arising out of the use
or inability to use the Device. These exclusions apply even if SCAN~LINK has
been advised of the possibility of these damages and even if any remedy fails
of its essential purpose. This limitation is intended to apply and does apply
without regard to whether such damages are claimed, asserted or brought in
an action or claim in tort, contract, on the warranty, or under any other legal
theory. The liability of SCAN~LINK and anyone acting on behalf or with
SCAN~LINK for loss or damage arising under this Limited Warranty shall not
exceed in aggregate the price paid by the Purchaser for the Device or the cost
of replacing the Device, whichever is greater.
Governing Law
17. This Limited Warranty is governed by the laws of Ontario and the laws of
Canada applicable therein.
Miscellaneous
18. All claims made under the Limited Warranty are governed by the terms set
out herein. If there is any conflict between this Limited Warranty and any
other warranty provided to the Purchaser, the provisions of this Limited
Warranty shall be applied to SCAN~LINK to the extent of such conflict.
19. If any term, provision or subsection of this Limited Warranty is held to be void,
illegal or unenforceable, the validity or enforceability of the remainder of such
term, provision or subsection and this Limited Warranty will not be affected.
This document is copyright SCAN~LINK Technologies Inc., 2016.
All trademarks property of their respective owners.
Current as of August, 2016. SCAN~LINK may have updated documentation which can
be located on our website,
www.scan-link.com.
