SCAN 1005 Series User guide

1005/1006
UK SCAN
ASSEMBLY AND INSTRUCTION MANUAL SCAN 1005/1006
UK - ASSEMBLY AND INSTRUCTIONS MANUAL
SCAN 1005/1006

1005/1006
2
You have purchased a product by one of Europe’s leading manufacturers of wood-bur-
ning stoves, and we are sure that you will have years of pleasure from your purchase.
To make the best possible use of your stove, it is important that you follow our advice
and instructions. Read through this Assembly and Instruction Manual carefully before
you start to assemble your stove.
UK SCAN
CONGRATULATIONS
ON YOUR NEW SCAN
BUILT-IN STOVE
SCAN 1005 BB SCAN 1005 WC SCAN 1005 BS
SCAN 1006 WC SCAN 1006 BSSCAN 1006 BB

3
CONTENTS
¬¬ TECHNICAL DATA 4
Installation 4
Safety 4
Technical data and dimensions 5
Dimension sketch Scan 1005 6
Dimension sketch Scan 1006 7
Type plate 8
Product registrationumber 9
¬¬ ASSEMBLY 10
Tools needed for mounting of the insert 10
Loose parts 10
Additional accessories 10
Disposal of packaging 10
Load-bearing foundation 10
Floor plate 11
Convection air 11
Existing chimney and pre-fabricated element chimney 11
Connection between built-in stove and steel chimney 11
Requirements for chimney 11
Internal installation in non-flammable material 11
Trims and doors 12
Gasket 12
Distance to furniture 12
Safety distance 12
Building into flammable material with fire wall 13
Operating the door 16
Remove packaging 16
Fitting the flue connection piece 18
Fresh air intake 18
Closed combustion system 18
Mounting of external air supply 19
Fitting without the convection connection pieces 21
Fitting the convection connection pieces 21
Fitting the cassette 22
Mount the insert in the cassette 25
Mounting of the trim 26
Mounting of convection grate 27
Mounting of combustion chamber 28
Adjustment of the door 30
¬¬ INSTRUCTIONS FOR USE 31
CB-technology (Clean Burn) 31
Baffle plate 31
Primary air 31
Secondary air 31
¬¬ INSTRUCTIONS FOR HEATING 32
Environmentally friendly operation 32
Lighting 32
Continuous operation 33
Warning about over-firing 33
Using the stove in various weather conditions 33
Firing in the spring or autumn 33
General notes 33
The function of the chimney 34
Chimney fire 34
¬¬ HANDLING OF THE FUEL 35
Selecting wood/fuel 35
Preparation 35
Storing 35
Moisture 35
Use of the following as fuel is illegal 35
Calorific value of the wood 35
¬¬ MAINTENANCE 36
Sweeping the chimney and cleaning the stove 36
Checking the stove 36
Servicing 36
Combustion chamber lining 36
Gaskets 36
Painted surfaces 36
Cleaning the glass 37
Baffle plates and combustion chamber lining 37
Disposal of stove parts 37
¬¬ TROUBLESHOOTING 38
¬¬ WARRANTY 39

4
YOU GET THE BEST USE OF
THE STOVE BY USING
A TOP-DOWN
LIGHTING METHOD
SEE
"INSTRUCTIONS FOR HEATING"
PLEASE NOTE!
TECHNICAL DATA
INSTALLATION
¬ The house owner is responsible for ensuring that installation and assembly are in accordance with national and local
building regulations as well as the information provided in this Assembly and Instructions Manual.
¬ When you install any kind of fireplace or stove, you must inform the local building and housing authorities. In addition
you are obliged to have the installation inspected and approved by a local chimney sweep prior to commissioning.
¬ To ensure best-possible functionality and safety for your installation, we advise you to call a professional fitter. Your Scan
dealer will be able to recommend a qualified fitter in your area. For information on Scan Dealers, please go to www.scan.dk.
SAFETY
Any changes made to the product by the dealer, fitter or user could result in the product and safety functions not functioning as
intended. The same applies to the fitting of accessories or extra equipment not supplied by Scan A/S. This could also be the case
if parts that are necessary for the operation and safety of the stove are dismantled or removed.

5
TECHNICAL DATA AND DIMENSIONS
* Intermittent operation in this context means normal use of a
wood-burning stove. In other words, you should let the fire die
down until only the embers are left before refuelling.
Scan 1005-1006 is produced in accordance with type approv-
al for the product, which also covers the product’s Assembly
and Instruction Manual.
The Declaration of Performance (DoP) is available from www.
scan.dk
EN 13229 was carried out on the installation shown on page 13.
Scan 1005 – Test in compliance with EN 13229
Combustion chamber Ceramic
stone
Vermi-
culite
CO Emission at 13% O20,07 0,07 %
CO Emission at 13% O2887 861 mg/Nm3
Dust @ 13% O219 25 mg/Nm3
Nox@ 13% O295 103 mg/Nm3
Efficiency 82 84 %
Energy efficiency index 109,9 112,8
Energy efficiency class A+ A+
Nominel output 6 6 kW
Chimney temperature
EN 13229 227 202 °C
Temperature in flue conn.
piece 272 242 °C
Amount of smoke 5,6 5,3 g/sec
Sub-pressure EN 13229 12 12 Pa
Recommended sub-pressure
in connecting piece 18-20 18-20 Pa
Required combustion air supply 18 15 m3/h
Fuel Wood Wood
Fuel consumption 1,9 1,8 kg/h
Amount of fuel required to light 1,5 1,5 kg
Amount of fuel, max. 2,5 2,5 kg
Scan 1006 – Test in compliance with EN 13229
Combustion chamber Ceramic
stone
Vermi-
culite
CO Emission at 13% O20,07 0,07 %
CO Emission at 13% O2887 905 mg/Nm3
Dust @ 13% O219 18 mg/Nm3
Nox@ 13% O295 95 mg/Nm3
Efficiency 82 82 %
Energy efficiency index 109,9 109,9
Energy efficiency class A+ A+
Nominel output 6 7 kW
Chimney temperature
EN 13229 227 224 °C
Temperature in flue conn.
piece 272 269 °C
Amount of smoke 5,6 6,6 g/sec
Sub-pressure EN 13229 12 12 Pa
Recommended sub-pressure
in connecting piece 18-20 18-20 Pa
Required combustion air supply 18 18 m3/h
Fuel Wood Wood
Fuel consumption 1,9 2,2 kg/h
Amount of fuel required to light 1,5 1,8 kg
Amount of fuel, max. 2,5 3 kg
Materials
Steel plate
Galvanised sheet
Ceramic stone/vermiculite
Chamotte
Robax glass
Surface treatment Senotherm
Max. wood length Scan 1005 50 cm
Max. wood length Scan 1006 65 cm
Weight Scan 1005 (Ceramic stone) ca. 113kg
Weight Scan 1005 (Vermiculite) ca. 99 kg
Weight Scan 1006 (Ceramic stone) ca. 132 kg
Weight Scan 1006 (Vermiculite) ca. 116 kg
Connecting piece internal diameter 144 mm
Connecting piece external diameter 148 mm
Approval type Intermittent
fuelling*

NAVN:
STI:
M3 NR.:
MATERIALE: DATO: SIGN:
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1005\91005001_stregtegning.idw
91005001_stregtegning
Målskitse
03-05-2018 pcj
Scan 1005
VÆGT:
AREAL:
N/A
N/A
DIM.: Scan A/S
523
688
325
105
466
106
438
650
470
389
470
463
92
125
130
333
Min490
Min 670
Min
450
D
A
B
C
6
DIMENSION SKETCH SCAN 1005
ATop outlet
BRear outlet
CCentre external air supply, rear side
DCentre of external air supply, bottom
All measures are in mm

NAVN:
STI:
M3 NR.:
MATERIALE: DATO: SIGN:
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1006\91006001_stregtegning.idw
91006001_stregtegning
Målskitse
03-05-2018 pcj
Scan 1006
VÆGT:
AREAL:
N/A
N/A
DIM.: Scan A/S
463
470
389
105
400
523
838
800
200
130
438
106
470
466
92
333
Min 820
Min490
Min
450
D
A
B
C
7
DIMENSION SKETCH SCAN 1006
ATop outlet
BRear outlet
CCentre external air supply, rear side
DCentre of external air supply, bottom
All measures are in mm

Scan 1006 CS
Insert fired by solid fuel
Standard:
Fuel type:
Operation type:
Reaction to fire: A1
Country
EN 13229 EC no. 91006601
Wood
Intermittent
EUR
Classification
Intermittent
Certificate/Standard
EN 13229
Approved by
DTI NB.no. 1235
Dust at 13% O2: 19 mg/Nm³
Flue gas temperature: 227°C
Nominal heat output: 6 kW
Efficiency: 82%
Scan A/S DK 5492 Vissenbjerg
Minimum distance to combustible materials:
See assembly- and instructions manual
CO emission at 13% O2:
Follow assembly- and instructions manual.
Use only recommended fuels.
The appliance can be operated in a shared flue.
Montage- und Bedienungsanleitung beachten.
Verwenden Sie nur empfohlene Brennstoffe.
1000 18
0,07% 887 mg/Nm³
Germany Stufe 2 1. BlmSchV DTI NB.no. 1235
Scan 1006 VE
Insert fired by solid fuel
Standard:
Fuel type:
Operation type:
Reaction to fire: A1
Country
EN 13229 EC no. 91006600
Wood
Intermittent
EUR
Norway
Classification
Intermittent
Klasse 2
Certificate/Standard
EN 13229
NS 3058
Approved by
DTI NB.no. 1235
DTI NB.no. 1235
Dust at 13% O2: 18 mg/Nm³
Flue gas temperature: 224°C
Nominal heat output: 7 kW
Efficiency: 82%
Scan A/S DK 5492 Vissenbjerg
Minimum distance to combustible materials:
See assembly- and instructions manual
CO emission at 13% O2:
Follow assembly- and instructions manual.
Use only recommended fuels.
The appliance can be operated in a shared flue.
Montage- und Bedienungsanleitung beachten.
Verwenden Sie nur empfohlene Brennstoffe.
1000 18
0,07% 905 mg/Nm³
Germany Stufe 2 1. BlmSchV DTI NB.no. 1235
8
TYPE PLATE
All Scan built-in stoves are fitted with a type plate that specifies the approval standards and the distance to flammable materials.
The type plate (Vermiculite) is located on top of the stove.
The type plate (Ceramic stone) is in the box with the ceramic stones and must be stuck on top of the existing type plate.
Type plate Scan 1005 (Ceramic stone) Type plate Scan 1005 (Vermiculite)
Type plate Scan 1006 (Ceramic stone) Type plate Scan 1006 (Vermiculite)
Scan 1005 CS
Insert fired by solid fuel
Standard:
Fuel type:
Operation type:
Reaction to fire: A1
Country
EN 13229 EC no. 91005601
Wood
Intermittent
EUR
Classification
Intermittent
Certificate/Standard
EN 13229
Approved by
DTI NB.no. 1235
Dust at 13% O2: 19 mg/Nm³
Flue gas temperature: 227°C
Nominal heat output: 6 kW
Efficiency: 82%
Scan A/S DK 5492 Vissenbjerg
Minimum distance to combustible materials:
See assembly- and instructions manual
CO emission at 13% O2:
Follow assembly- and instructions manual.
Use only recommended fuels.
The appliance can be operated in a shared flue.
Montage- und Bedienungsanleitung beachten.
Verwenden Sie nur empfohlene Brennstoffe.
1000 18
0,07% 887 mg/Nm³
Germany Stufe 2 1. BlmSchV DTI NB.no. 1235
Scan 1005 VE
Insert fired by solid fuel
Standard:
Fuel type:
Operation type:
Reaction to fire: A1
Country
EN 13229 EC no. 91005600
Wood
Intermittent
EUR
Norway
Classification
Intermittent
Klasse 2
Certificate/Standard
EN 13229
NS 3058
Approved by
DTI NB.no. 1235
DTI NB.no. 1235
Dust at 13% O2: 25 mg/Nm³
Flue gas temperature: 202°C
Nominal heat output: 6 kW
Efficiency: 84%
Scan A/S DK 5492 Vissenbjerg
Minimum distance to combustible materials:
See assembly- and instructions manual
CO emission at 13% O2:
Follow assembly- and instructions manual.
Use only recommended fuels.
The appliance can be operated in a shared flue.
Montage- und Bedienungsanleitung beachten.
Verwenden Sie nur empfohlene Brennstoffe.
1000 18
0,07% 861 mg/Nm³
Germany Stufe 2 1. BlmSchV DTI NB.no. 1235

B
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1005\91005002.idw
91005002
Ovn påpalle
13-03-2018 KEN
Scan 1005
VÆGT:
AREAL:
N/A
N/A
100500000 100600000
A
B
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1005\91005002.idw
91005002
Ovn påpalle
13-03-2018 KEN
Scan 1005
VÆGT:
AREAL:
N/A
N/A
9
Product registration number Scan 1005 Product registration number Scan 1006
Product registration number
Type plates
PRODUCT REGISTRATIONUMBER
All Scan built-in stoves are provided with a product registration number. Please make a note of this number at the rear page of
this manual; you will always need to quote it when contacting your dealer or Scan A/S.

10
ASSEMBLY
TOOLS NEEDED FOR MOUNTING OF THE INSERT
¬ Spirit level ¬ Cutting nippers
¬ Cross tip screwdriver ¬ Flat head screwdriver
¬ Ø10 wall drill ¬ Open-end spanner
LOOSE PARTS
The trim is delivered on the wood pallet together with the insert.
In the insert’s combustion chamber you will find the following loose parts
¬ Bricks for the bottom of the burn chamber ¬ Log guard
¬ Glove
¬Bag containing loose parts:
4 x self-tapping screws 4.2 x 6.5 mm 8 x 3 mm black self-adhesive gasket (2 m)
(for fastening the sleeve Ø100 mm) (Ø100 mm sleeve, connecting piece and cassette)
4 x rawlplugs10 x 50 mm (for fastening the cassette) 4 x torx screws M6 x 50 (for fastening the cassette)
4 x discs Ø6.5 / Ø16 x 1.1 (for fastening the cassette) Torx key T30
Ø100 mm sleeve with flange
Combustion chamber package contains:
¬ Baffle plates ¬ Burn chamber plates (side and rear)
¬ 3 pins Ø6 x 40 mm
ADDITIONAL ACCESSORIES
¬ Convection adaptors Ø149 mm (see page 21)
¬ Convection grates (See page 27)
DISPOSAL OF PACKAGING
Your Scan built-in stove may come supplied with the following packaging:
Wood packaging The wood packaging can be reused and after final use can be incinerated as a CO2neutral
product or sent for recycling.
Polystyrene top Send for recycling or waste disposal.
Foam Send for recycling or waste disposal.
Plastic bags Send for recycling or waste disposal.
Stretch/plastic film Send for recycling or waste disposal.
LOAD-BEARING FOUNDATION
All items in our product range come under the category of lightweight fireplaces and stoves and do not normally require any
reinforcement of the beam structure. They can be positioned on ordinary beams/floor.
You should of course make sure that the foundation on which the stove is positioned can indeed support the weight of the stove
and, where applicable, a steel chimney, if you have opted for this solution. In case of doubt about the carrying capacity of the
floor, please consult a building expert.

11
FLOOR PLATE
If you are placing the stove on a flammable floor, you must comply with the national and local regulations on the size of any
non-flammable subsurface required to cover the floor around the stove.
Your local Scan dealer can advise you on regulations concerning protection of flammable materials in the vicinity of your stove.
The floor plate’s function is to protect the floor and flammable material against any sparks that may occur.
CONVECTION AIR
The covering must contain holes for convection air. Convection means that there is an air circulation ensuring that the heat is
equally distributed in the room. It is important that the demands concerning convection areas are observed.
¬ Min. area for ingoing convection air: 350 cm2 ¬ Min. area for outgoing convection air: 500 cm2
If there is not enough convection air, the covering may be damaged. Do not obstruct the convection holes.
Convection air grids are available as an accessory.
EXISTING CHIMNEY AND PRE-FABRICATED ELEMENT CHIMNEY
If you intend to connect your stove to an existing chimney, it makes sense to contact an authorised Scan dealer, or a local chim-
ney sweep, for advice. These experts will also let you know if your chimney needs renovating.
¬ When connecting a pre-fabricated element chimney, follow the manufacturer’s connection instructions for the
relevant chimney type.
CONNECTION BETWEEN BUILT-IN STOVE AND STEEL CHIMNEY
Your Scan dealer, or local chimney sweep, can advise you on choosing a make and type of steel chimney. This ensures that the
chimney will match your wood-burning stove.
REQUIREMENTS FOR CHIMNEY
The chimney must have a diameter of min. 148 mm and be labelled T400 and G for soot testing. The length must be min. 4 me-
tres.
If you opt to connect the bulit-in stove with an elbow pipe, you should use a curved elbow, as this gives a better draught.
If you connect the stove with a sharp elbow pipe, the cleansing lid must be placed in the vertical part so that the
horizontal part can be cleaned through here.
The requirements to the chimney and the flue pipe in terms of safety distances must be met.
¬ Choosing the wrong length or diameter of chimney could impair functionality
¬ Always comply exactly with the instructions provided by the chimney supplier
INTERNAL INSTALLATION IN NON-FLAMMABLE MATERIAL
When building or fitting into structures that do not contain flammable materials, a minimum distance of 10 mm must be main-
tained between the brickwork and the convection hood. This is to prevent cracks in the brickwork caused by the expansion of the
metal while the stove is heating. This construction does not require convection grates except for the convection air produced by
the convection box of the insert. However, please note that without convection grates, the effect of the insert will be lower.
(BY BUILDING INTO FLAMMABLE MATERIAL WITH FIRE WALL)
/ EXISTING BRICKWORK

NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1001\91001036.idw
91001036
Pakning påsvøb
11-05-12 BC
Scan 1001
VÆGT:
AREAL:
N/A
N/A
12
TRIMS AND DOORS
Trims and doors are fitted when the surfaces of the surround have been treated.
GASKET
Gasket 0,75 m is mounted on the inside of the cassette as shown.
DISTANCE TO FURNITURE
Distance to furniture from glass: 1500 mm.
You should however assess whether furniture or other items might become excessively dry due to being too close to the stove.
The stove is NOT to be built into flammable materials without the use of a fire wall!
SAFETY DISTANCE
European, national and local regulations concerning safety distances for wood-burning stoves and flue pipes must be complied
with.
Gasket

NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1005\91005013.idw
91005013
Uisoleret skorsten
23-04-2018 KEN
Scan 1005
VÆGT:
AREAL:
N/A
N/A
710
420300
500
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1005\91005029.idw
91005029
Uisoleret røgrør
23-01-2019 KEN
Scan 1005
VÆGT:
AREAL:
N/A
N/A
175
100
75
15
450
200
1500
800
Min. 350 cm2
Min. 500 cm2
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:
EMNE:
C:\Working Folder\Designs\Scan 1001\91001029.idw
91001029
Lille glasgulvplade
02-05-12 BC
Scan 1001
VÆGT:
AREAL:
N/A
N/A
* *
*
*
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1005\91005029.idw
91005029
Uisoleret røgrør
23-01-2019 KEN
Scan 1005
VÆGT:
AREAL:
N/A
N/A
175
100
75
15
450
200
1500
800
13
BUILDING INTO FLAMMABLE MATERIAL WITH FIRE WALL
Cavities are not to be
filled out with
insulation material!
Installation with an un-insulated elbow pipe
Lower
convection
opening
Upper
convection
opening
These cover plates must be
removed when installing into
flammable material protected
by insulation
Flammable materials
Floor plate
Distance to furniture from glass Floor
Ceiling
Flammable material
Fire wall, e.g. 50 mm Jøtul Firewall, 110 mm brick
or other material with corresponding fireproof and
insulating abilities
All distances are in mm.
All distances are minimum distances
* Applies for all installations
Chimney
(Ceramic stone)
(Vermiculite)
(Ceramic stone) (Vermiculite)

NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1005\91005008.idw
91005008
Konstruktion/omramning mod loft
23-04-2018 KEN
Scan 1005
VÆGT:
AREAL:
N/A
N/A
400
420300
Min. 350 cm2
Min. 500 cm2
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1005\91005030.idw
91005030
Isoleret røgrør
23-01-2019 KEN
Scan 1005/1006
VÆGT:
AREAL:
N/A
N/A
75
40
75
15
75
15
Stove:
Path:
Articlenumber:
Material:
Date:
Constructed/Changed by:
SCAN A/S
DK-5492 Vissenbjerg©
Drawing
number:
Name:
C:\Working Folder\Designs\Scan 80\90580001.idw
90580001
Opstillingsafstand, hjørne, Scan 1008 03-03-2017
sr
Scan 80
Weight: Area:
N/A N/A
350mm
25 mm
25mm
Møbleringsafstand: 800 mm.
Brandbart materiale
Brandmur
F.eks. 50 mm. Jøtul firewall
14
BUILDING INTO FLAMMABLE MATERIAL WITH FIRE WALL
Cavities are not to
be filled out with
insulation material!
Installation with an insulated, vertical flue pipe
- structure/surround to ceiling
Lower
convection
opening
Upper
convection
opening
The distance to fire wall (brick) depends on the use of
an insulated flue pipe all the way down to the insert
Floor
Ceiling
Flammable material
Fire wall, e.g. 50 mm Jøtul Firewall, 110 mm brick
or other material with corresponding fireproof and
insulating abilities
All distances are in mm
All distances are minimum distances
(Ceramic stone)
(Vermiculite)
(Ceramic stone) (Vermiculite)
Tighten the space,
for example with a
glass-gasket

NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1005\91005007.idw
91005007
Indbygning i åben omramning
23-01-2019 KEN
Scan 1005/1006
VÆGT:
AREAL:
N/A
N/A
500
400
420
900
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Scan A/S
DK-5492 Vissenbjerg©
TG.NR:
EMNE:
C:\Working Folder\Designs\Scan 1001\91001050.iam
91001050Åben indbygning Scan 1001
15-11-12 BC
Scan 1001
VÆGT:
AREAL:
N/A
N/A
Min. 350 cm2
Stove:
Path:
Articlenumber:
Material:
Date:
Constructed/Changed by:
SCAN A/S
DK-5492 Vissenbjerg©
Drawing
number:
Name:
C:\Working Folder\Designs\Scan 80\90580001.idw
90580001
Opstillingsafstand, hjørne, Scan 1008 03-03-2017
sr
Scan 80
Weight: Area:
N/A N/A
350mm
25 mm
25mm
Møbleringsafstand: 800 mm.
Brandbart materiale
Brandmur
F.eks. 50 mm. Jøtul firewall
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1005\91005030.idw
91005030
Isoleret røgrør
23-01-2019 KEN
Scan 1005/1006
VÆGT:
AREAL:
N/A
N/A
75
40
75
15
75
15
15
BUILDING INTO FLAMMABLE MATERIAL WITH FIRE WALL
Flammable material
Fire wall, e.g. 50 mm Jøtul Firewall, 110 mm brick
or other material with corresponding fireproof and
insulating abilities
All distances are in mm
All distances are minimum distances
When building or fitting into a structure/sur-
round that is open at the top, the convection
holes can be omitted. However, you should
note that no top plate must be placed on the
structure
Installation with an insulated, vertical flue pipe
- open structure/surround
Lower
convection
opening
Floor
Ceiling
(Ceramic stone)
(Vermiculite)
(Ceramic stone) (Vermiculite)
Convection
opening

C
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1005\91005003.idw
91005003
Afmontage låge
13-03-2018 KEN
Scan 1005
VÆGT:
AREAL:
N/A
N/A
C
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1005\91005003.idw
91005003
Afmontage låge
13-03-2018 KEN
Scan 1005
VÆGT:
AREAL:
N/A
N/A
1
16
OPERATING THE DOOR
REMOVE PACKAGING
Check that the built-in stove is not damaged before installing it.
Scan 1005/1006 is delivered secured to the pallet. It is recommended that you remove the door and take all loose parts out of
the combustion chamber before unscrewing the stove from the pallet; this will facilitate the mounting of the insert.
Dismount the combustion air box. This box is only needed, if the insert is to be connected with external air supply, see page 19.
2The door should be banged shut, as on a car.
Grip the handle (hold in a horizontal position)
and bang the door shut
1Push down the handle and the door will open
Combustion air box
Pointed screw
Screw
and
spring
To remove the door:
Loosen the pointed screw,
remove the screw and the
spring and lift off the door

B
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1005\91005006.idw
91005006
Afmontage skruer fra palle
12-04-2018 KEN
Scan 1005
VÆGT:
AREAL:
N/A
N/A
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1005\91005004.idw
91005004
Afmontage røgstuds
13-03-2018 KEN
Scan 1005
VÆGT:
AREAL:
N/A
N/A
4
2
3
B
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1005\91005006.idw
91005006
Afmontage skruer fra palle
12-04-2018 KEN
Scan 1005
VÆGT:
AREAL:
N/A
N/A
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1005\91005005.idw
91005005
Afmontage ovn fra svøb
13-03-2018 KEN
Scan 1005
VÆGT:
AREAL:
N/A
N/A
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1005\91005012.idw
91005012
Brændkammerforing, eksploderet
23-04-2018 KEN
Scan 1005
VÆGT:
AREAL:
N/A
N/A
17
REMOVE PACKAGING
Remove the two screws securing
the cassette to the pallet
Lift the insert free from the grip holes in
the front and pull it out of the cassette
Dismount the connecting piece:
Remove the baffle plate from the stove
before the connecting piece is removed.
Loosen (not dismount) the flange nuts
holding the connecting piece inside the
stove. Push the connecting piece in the
direction of the arrow and remove it
Baffle plate

NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:
EMNE:
C:\Working Folder\Designs\Scan 1001\91001025.idw
91001025
Montage røgstuds
26-04-12 BC
Scan 1001
VÆGT:
AREAL:
N/A
N/A
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:
EMNE:
C:\Working Folder\Designs\Scan 1001\91001025.idw
91001025
Montage røgstuds
26-04-12 BC
Scan 1001
VÆGT:
AREAL:
N/A
N/A
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1005\91005028.idw
91005028
Montage røgstuds
16-11-2018 KEN
Scan 1005
VÆGT:
AREAL:
N/A
N/A
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1005\91005028.idw
91005028
Montage røgstuds
16-11-2018 KEN
Scan 1005
VÆGT:
AREAL:
N/A
N/A
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1005\91005028.idw
91005028
Montage røgstuds
16-11-2018 KEN
Scan 1005
VÆGT:
AREAL:
N/A
N/A
18
4 x flange nuts M6
Mount the gasket 3 x 8 mm at the edge of the flange of the connecting piece. Fasten the connecting piece with the flanged nuts
Gasket
FRESH AIR INTAKE
In a well-insulated house, the air used up by the burning process has to be replaced. This particularly applies to houses with
mechanical ventilation. There are different ways of making sure that an air exchange takes place. The most important thing is to
ensure that there is a supply of air to the room where the wood stove is located. The external wall vent must be located as close
to the wood stove as possible, and you must be able to close it when you are not using the wood stove.
National and local building regulations must be followed with regard to the connection of fresh-air intake.
CLOSED COMBUSTION SYSTEM
You should use the closed combustion system for the wood-burning stove if you live in a newly-built, airtight home.
External combustion air is connected through a ventilation pipe via the wall or floor.
We recommend mounting a valve in the ventilation pipe in order to avoid condensate in the stove and the pipe system, which can
be closed when the oven is not in use. It can also be an advantage to insulate the ventilation pipe.
Minimum Ø 100 mm ventilation pipe, maximum length: 6 metres with a maximum of 3 bends. We recommend smooth steel pipes.
NOTE: If the stove has a fresh air connexion or closed combustion, the ventilation pipe must be open, when the stove
is in use!
FITTING THE FLUE CONNECTION PIECE
The insert is prepared for a top flue outlet from the factory, but the connection piece can be turned around for a rear outlet.
Mount the connecting piece on the insert, after it has been placed in the cassette.
If the radiation plate was removed before the mounting, remember to put it back in place before putting the burn chamber back
into the cassette.
Radiation plate

NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1005\91005010.idw
91005010
Montage forbrændingsluftkasse
15-03-2018 KEN
Scan 1005
VÆGT:
AREAL:
N/A
N/A
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1005\91005009.idw
91005009
Kassette
15-03-2018 KEN
Scan 1005
VÆGT:
AREAL:
N/A
N/A
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1001\91001037.idw
91001037
Ekstern forbrænding bag påsvøb
15-05-12 BC
Scan 1001
VÆGT:
AREAL:
N/A
N/A
1
2
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1001\91001032.idw
91001032
Frisklufttilførsel bund af ovn
07-05-2012 BC
Scan 1001
VÆGT:
AREAL:
N/A
N/A
19
MOUNTING OF EXTERNAL AIR SUPPLY
To dismount the cover plates for the Ø100 mm sleeve, use an ordinary screwdriver as shown below. Tilt the screwdriver and
loosen the cover plates.
External air supply on
the rear of the cassette
MOUNTING OF EXTERNAL AIR SUPPLY
External combustion air on
the bottom of the cassette
4 x self-tapping screws 4.2 x 6.5 mm
Mount the Ø100 sleeve
Hitch the combustion air box on the
rear plate of the cassette.
This box must always be mounted
when connecting the insert with
external air supply.
IMPORTANT: Only use for connection
with external air supply!
Mount the insert in the cassette
(see page 22)
ON THE REAR OF THE CASSETTE

NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1005\91005010.idw
91005010
Montage forbrændingsluftkasse
15-03-2018 KEN
Scan 1005
VÆGT:
AREAL:
N/A
N/A
A
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1001\91001033.idw
91001033
Pakning friskluft bund
08-05-2012 BC
Scan 1001
VÆGT:
AREAL:
N/A
N/A
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1001\91001032.idw
91001032
Frisklufttilførsel bund af ovn
07-05-2012 BC
Scan 1001
VÆGT:
AREAL:
N/A
N/A
1
2
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 1001\91001032.idw
91001032
Frisklufttilførsel bund af ovn
07-05-2012 BC
Scan 1001
VÆGT:
AREAL:
N/A
N/A
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:
EMNE:
C:\Working Folder\Designs\Scan 1001\91001034.idw
91001034
Friskluftdæksel under ovn
08-05-2012 BC
Scan 1001
VÆGT:
AREAL:
N/A
N/A
NAVN:
STI:
DIMENSION:
MATERIALE: DATO: SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg©
TG.NR:
EMNE:
C:\Working Folder\Designs\Scan 1001\91001034.idw
91001034
Friskluftdæksel under ovn
08-05-2012 BC
Scan 1001
VÆGT:
AREAL:
N/A
N/A
3
4
20
MOUNTING OF EXTERNAL AIR SUPPLY THROUGH THE BOTTOM OF THE CASSETTE
Mount 0.5 m gasket round the
flange of the sleeve Ø 100 mm
Turn the insert over and remove the cover plate at the bottom.
Mount the insert in the cassette (see page 22)
Cover plate
4 x self-tapping screws 4.2 x 6.5 mm
Mount the Ø100 sleeve
Hitch the combustion air box on the
rear plate of the cassette.
This box must always be mounted
when connecting the insert with
external air supply.
IMPORTANT: Only use for connection
with external air supply!
