SCAN&GO UPLIFT 500 User manual

USER MANUAL
SCAN&GO srl
Via della Tecnica 34 A/B - 41051
Castelnuovo Rangone (MO) - Italy
Cell. [phone]
[email protected]u
July 2022

STEEL TELESCOPIC LIFTER
Uplift500
UPLIFT500 is a telescopic lifter made in painted steel, with manual lifter composed of 4 sections.
The best solution for using the laser scanner at maximum height of 5.00 mt.
Combines stability with great sturdiness.
All metallic components guarantee maximum durability and strength
It is equipped with:
double safety locking system by means of safety-bolt
pressure knob
non-slip rubber feet
wind bracing kit
braking wheels
L'UPLIFT500 IS PERFECT FOR ALL LASER SCANNERS
WITH MAX. WEIGHT 10 kg
Technical data
• Min.height when opened 160 cm
• Max.height when opened 500 cm
• Basic diameter when opened 170 cm
• Section 4
• Max.load 10 kg
• Weight 16 kg
• Dimensions when closed 145x20x20 cm
UpLift500
can be used with FARO, TRIMBLE X7
LEICA BLK360 and RTC360
ATTENTION !!!!
READ CAREFULLY THE PRESENT INSTRUCTION
MANUAL BEFORE USING THE EQUIPMENT

DETAILS AND ACCESSORIES
1
5/8’’ STANDARD CONNECTION
2COLUMN
3DOUBLE SAFETY LOCKING SYSTEM
4DOUBLE COLUMN BLOCK
51 TELESCOPIC LEG
6RUBBER FEET
7BRAKING WHEELS
8WIND BRACING KIT
1
5
6
4
2
ACCESSORIES INCLUDED
3
7
8
ADAPTERS TO BE ORDERED SEPARATELY
ADP38 ADAPTER 3/8” FOR BLK360
TRIPOD ADAPTER
ASOFT BAG FOR ACCESSORIES
BWIND BRACING KIT
CBRAKING WHEELS
DRUBBER FEET
EBUBBLE LEVEL
A
B
C
D
E

WHEELS INSTALLATION
OPENING
Place the elevator on a solid surface and loosen the locking
screws
Lower the crossbar to the maxi-
mum opening of the legs.
Use the telescopic leg to level
the elevator
Connect the wind bracing ropes
to the top-head and
the legs of tripod
IT IS STRICTLY FORBIDDEN TO
EXCEED THE MAXIMUM PAY-
LOAD SPECIFIED IN TECHNICAL
DETAILS
Instal the tool
INSTALLATION AND USE INSTRUCTIONS

Loosen the thumb-screw
of first extension
Lift the extension up to
the stop hole
Insert the pin into the ho-
le and tighten the knob
Carry out the same operation for all the other extensions
COMPLETE WITH THE TENSIONING OF
THE BRACES BEING CAREFUL NOT TO
OVERDO WITH THE TENSION FORCE
PAY EXTREME ATTENTION TO SUSPENDED
ELECTRIC CABLES, DO NOT APPROACH
THE TOP OF THE POLE WITHIN 3 METERS
THE USE OF THE EQUIPMENT IS STRICTLY
FORBIDDEN TO MINORS UNDER THE AGE
OF 18
INSTALLATION AND USE INSTRUCTIONS

SAFETY MEASURES
IT IS COMPULSORY TO SECURE THE ELEVATOR AGAINST SUDDEN WIND ACTIONS, IF USED OUTDOORS. POSSIBLY,
WEIGHTS CAN BE USED TO BE POSITIONED ON THE FEET OF THE ELEVATOR.
DO NOT PLACE STAIRS ON THE ELEVATOR.
DO NOT STAND UNDER THE ELEVATOR WHEN THE LOAD IS LIFTED.
DO NOT MOVE THE LIFT WHEN IT IS FULLY LIFTED.
THE ELEVATOR IS NOT APPROVED FOR LIFTING HUMAN BEINGS.
ALWAYS BLOCK THE EXHAUST PIPE WITH THE APPROPRIATE SCREW AND WITH THE SAFETY LOCK WHEN THE
LOAD IS LIFTED.
IF YOU USE THE ELEVATOR IN THE PRESENCE OF OTHER PEOPLE, CROSSENNAR IT.
LIMITS OF USE
MAXIMUM LOAD (see the technical data) refers to the weight that can be installed on the top of the mast to ensure its safe
use. All loading condions that exceed the limit will be considered as dangerous and will result in an immediate end of any form
of warranty.
The STRENGHT OF THE WIND must be considered. If there is a strong wind, the manufacturer is not responsible for damages
that may be caused by the inappropriate use of the equipment
RISKS RELATED TO THE USE
The two main sources of risk are :
1.RISK OF FALLING of the equipment extended in height, resulng from the acon of wind that has not been evaluated adequa-
tely.
2. CONTACT WITH ELECTRICAL CABLES, avoiding the risks is possible if the product is used properly by paying aenon to the
possible sources of danger present in the area. Please, remember that the electrical cables for high voltage, may dene the
electric discharge to the ground simply approaching and not necessarily touching the conductor.
It is therefore recommended to limit, as far as possible, the inuence of the above risks, both for the operaonal sta and for
strangers, in the following way:
* prohibit the transit and parking space surrounding the Upli500
* maintain the eciency of the equipment
Prohibited the use of the plaorm in the installer mode dierent from the original conguraon and delivery processes
other than those provided by the manufacturer.
Prohibited the use of the plaorm in presence of funconal anomalies and discrepancies in the rules of use and safety in-
strucons given in this manual. If needed, please ask and wait for intervenon of the sta in charge.
RE
INSTRUCTIONS FOR DEMOLITION
The demolion of the pole must be done by qualied personnel in such acvies and provided with adequate experse.
The disassembled components must be separated according to the nature of the materials they are made in compliance with
the applicable laws of "dierent waste".
QUIREMENTS
REQUIREMENTS

The use in the presence of funconal anomalies and discrepancies in the terms of use and safety instrucons described in
this manual. If something happens, request and wait for assistance from the personnel.
• The instrucons, drawings and documentaon contained in this document are of condenal technical nature, of pro-
perty of the manufacturer and may not be reproduced in any manner, either wholly, or in part.
• The manufacturer reserves the right to make changes and improvements at any me, without any modicaon to this
manual, and without prior noce.
• This document must be kept for future reference, unl the scrapping of the machine and must be made available to
the operators.
• If the unit is sold or leased, both the person who rents and the one who oer the service, is obliged to give the manual
to the new owner or user.
• The original instrucons are provided by the manufacturer in the Italian language.
• This document assumes that in the places where the equipment is sold, users respect the safety standards in force in
the country.
• If the manual is lost or damaged, you can request a copy to the dealer, providing the data of the model, serial number
and year of construcon.
• Do not use the manual for any purpose other than the use and maintenance of the product
WARRANTY
The product warranty is of 12 months from the date of the Invoice.
• SCAN & GO S.r.l. will support, at its discreon, the repairment and / or replacement of parts with manufacturing defe-
cts or damages during the warranty period, aer having evaluated the fail-ure.
• The shipping cost of the damaged/defecve parts during the warranty period, and the labour for its removal and re-
placement , are not included in the warranty, and may be approved only aer prior wrien request and conse-quent
authorizaon.
• The warranty does not cover cases of normal wear and tear, negligence in use, improper mainte-nance and im-proper
use.
• The warranty lapses in case the ‘machine’ is equipped with non-original accessories or parts.
• In no event SCAN & GO srl will cover the expenses, for loss or damage of any kind resulng from the use more or less
correct or from the paral or total malfunconing of the equipment.
• The goods travel at the risk of the recipient, any damage incurred during the shipment must be claimed at the delivery
by the courier in charge.
The manufacturer is deemed non-responsible in the case of:
1) inappropriate use of the UPLIFT
2) use of the equipment, against to any other applicable naonal regulaons;
3) serious lack of aenon in the maintenance;
4) intervenons or unauthorized modicaons;
5) use of non-original parts or replacing parts;
6) failure to comply, in whole or in part, of the instrucons;
7) exceponal events.
