SC&T Power Rack Series User manual

Smart Cabling & Transmission Corp.
V1.0
Power Rack Series
User Manual
Model : PR1008-5R
10AMP 8PORT DC5V Power Supply support multiple HKM02B,
VDKM02B

1
User Manual
PR1008-5R
Introduction
PR1008-5R is a power supply in a 19” standard 1U rack, which can transform AC120 or 230V to 10 ports of
regulated DC10V 0.5A output. It's a perfect power supply for numbers of cameras, housing, pan tilt turning
devices or other surveillance equipment in a security center...
Features
Built-in NFB to avoid current overload.
Built-in PTC fuse for overcurrent and resettable protection on each port...
.
Panel View
Caution for Operation
1. The power center has built-in auto reset able fuse on each port. The device will open while it is in
short condition. Please check the system to find out what caused short and solve it. The device
will auto reset after the problem has been solved.
2. Caution: connect only one device to one port, never connect one device to two different ports, or it
will lose protection. (See below drawing)

2
User Manual
PR1008-5R
Specification
ITEM NO.
PR1008-5R
Support
Output Voltage
DC5V (Regulated)
Output Current
0.5A/ Port
Output Trip Current
2A/ Port
Short Cut Time
0.2 sec/ Port
Cut Current / Time
2.5A/ 4 sec
Resettable Output/ Time
Auto/ 1 sec (Min)
Total Output Current
10 A (Max)
Ports & Interfaces
Power Input
1 x Power Core
Power Output
8 x 2-pin Terminal Block
Ambient Temperature
Operation
-10 to 45℃
Storage
-30 to 70℃
Humidity
up to 95%
Physical Characteristics
Dimensions
437 x 170 x 44mm
Weight
2500g
