SC&T DS02 User manual

DVI Switcher Series
ITEM NO.: DS02, DS02A, DS02D, DS04, DS04A, DS04D
Our smart DVI switch allows two or four different digital video with stereo, digital (SPDIF/
optical) audio sources to share one video display. Manage multiple video sources manually or
remotely with this convenient unit. They are fully HDCP compliant and compatible with most
of the computer and HDTV related hardware.
DS022 Input 1 Output DVI Switcher
Switch easily between any two DVI sources.
Extends the range of DVI compliant device by equalizing and reclocking the DVI signal
Pre-emphasized outputs.
Supports high resolution input:
PC: VGA, SVGA, XGA, SXGA, UXGA, WUXGA (1920 x 1200)
HDTV: 480i, 576i, 480p, 576p, 720p, 1080i and 1080p @60Hz.
Supports 250 Mbps to 1.65 Gbps data rates
Supports 25 MHz to 165 MHz pixel clocks
HDMI pass-through
HDCP pass-through
IR remote control included.
DS02A 2 Input 1 Output DVI Switcher With Stereo Audio
Identical to DS02, but with stereo audio.
DS02D 2 Input 1 Input DVI Switcher With Digital Audio
Identical to DS02, but with digital audio instead of stereo.
Digital Audio: Coax or Optical option.
DS04 4 Input 1 Output DVI Switcher
Switch easily between any four DVI sources.
Extends the range of DVI compliant device by equalizing and reclocking the DVI signal
Pre-emphasized outputs.
Supports high resolution input:
PC: VGA, SVGA, XGA, SXGA, UXGA, WUXGA (1920 x 1200)
HDTV: 480i, 576i, 480p, 576p, 720p, 1080i and 1080p @60Hz.
Supports 250 Mbps to 1.65 Gbps data rates
Supports 25 MHz to 165 MHz pixel clocks
HDMI pass-through
HDCP pass-through
IR remote control included.
DS04A 4 Input 1 Output DVI Switcher With Stereo Audio
Identical to DS04, but with stereo audio.
DS04D 4 Input 1 Output DVI Switcher With Digital Audio
Identical to DS04, but with digital audio.
Digital Audio: Coax or Optical option.
Installation view: DS02

2
DS02A DS02D
DS04
DS04A DS04D
Specification:
ITEM NO. DS02 DS02A DS02D
DVI Input
DVI-I x 2 (29 Pin)
DVI-I x 2 (29 Pin)
DVI-I x 2 (29 Pin)
DVI Output
DVI-I x 1 (29 Pin)
DVI-I x 1 (29 Pin)
DVI-I x 1 (29 Pin)
Audio Input X 3.5mm Phone Jack x 2
Coaxial RCA x 2 (75Ω)
，
Optical x 2
Audio Output X 3.5mm Phone Jack x 1
Coaxial RCA x 1 (75Ω)
，
Optical x 1
Frequency Bandwidth
1.65 GHz
Supports Resolution
480i
，
576i
，
480p
，
720p
，
1080i
，
1080p
Temperature
Operation: -10 to 45
℃
, Storage: -30 to 70
℃
, Humidity: up to 95%
Power Consumption
300mA
Power Supply
DC 5V 1A
Dimension mm
145 x 96 x 37
145 x 96 x 37
145 x 96 x 37
Weight g
320
360
365
ITEM NO. DS04 DS04A DS04D
DVI Input
DVI-I x 4 (29 Pin)
DVI-I x 4 (29 Pin)
DVI-I x 4 (29 Pin)
DVI Output
DVI-I x 1 (29 Pin)
DVI-I x 1 (29 Pin)
DVI-I x 1 (29 Pin)
Audio Input X 3.5mm Phone Jack x 4
Coaxial RCA x 4 (75Ω)
，
Optical x 4
Audio Output X 3.5mm Phone Jack x 1 Coaxial RCA x 1 (75Ω)，
Optical x 1
Frequency Bandwidth
1.65 GHz
Supports Resolution
480i
，
576i
，
480p
，
720p
，
1080i
，
1080p
Temperature
Operation: -10 to 45
℃
, Storage: -30 to 70
℃
, Humidity: up to 95%
Power Consumption
400mA
Power Supply
DC 5V 1A
Dimension mm
225 x 166 x 40
225 x 166 x 40
225 x 166 x 40
Weight g
860
930
925
Rev.B
