SC&T TPP016VPD User manual

Smart Cabling & Transmission Corp. V1.0
C
Twisted Pair Passive Series
User Manual
Model : TPP016VPD
16 Port HD-TVI/AHD/HDCVI/CVBS Video,AC24V Power, Data
Hub in 1U Rack

1
User Manual
TPP016HD
Introduction
TPP016VPD is a 16 port video hub that sends video, power, and data over a single Ethernet cable, with a
transmission distance of up to 300 meters. The video hub can pair with different video transceivers for a
variety of CCTV applications.
Features
Supports HD-TVI, AHD, HDCVI, CVBS video formats.
Supports AC 24V power
Supports RS485 signal transmission
Built-in 1.1A PTC fuse for overcurrent protection.
Built-in NFB for overcurrent protection
Installation View
Caution: to avoid any damage, TPP016VPD cabling is not able to connect any Ethernet or PoE network
with outside plant routing.
HD-TVI/AHD/HDCVI Twisted Pair Transmission Distance Chart
Transmitter
Receiver
HD-TVI
AHD
HDCVI
CVBS
TTP111HDP
TTP111HDP-L
TTP111HDPD-RJ45
TPP016VPD
1080P 250M
1080P 300M
1080P 300M
300M

2
User Manual
TPP016HD
AC24V Power Distance Chart over UTP CAT5 cable:
CAT5 Cable (24AWG)
Actual Voltage camera at 21V
Power
2 Pairs/AC24V
3 Pairs/AC24V
100 mA
300 Meters
300 Meters
300 mA
100 Meters
225 Meters
1 Amp
30 Meters
45 Meters
Optional Model: Work with HDTVI/AHD//HDCVI Analog Camera
TTP111HDP HD-TVI/AHD/HDCVI HD Video & Power Balun
Transmit HD-TVI/AHD/HDCVI video and power over one CAT5e cable.
Video (one pair) and remote power (3pairs) transmission over one 4pairs CAT5 cable.
TTP111HDPD-RJ45 HD-TVI/AHD/HDCVI Video Power Data Balun
HD-TVI/AHD/HDCVI video, low voltage camera power, Data (RS485) transmission over one Cat5e
cable.

3
User Manual
TPP016HD
Panel View
TPP016VPD
Switch Setting
3 pairs power work with TTP111VP3/TTP111HDP/TTP111HDP-L or TTP111VPC
2 pairs power & data work with TTP111VPD-RJ45/TTP111HDPD-RJ45
2 pairs power work with TTP111VP
TTP111HDP
Front Rear
RJ-45 Jack Pin Define
Rack Mount Installation
Package includes the two mounting brackets and eight screws.
Place the mounting brackets unto the side of the left and right side of rack enclosure. Use two screws to
secure mounting brackets.

4
User Manual
TPP016HD
Specification
ITEM NO.
TPP016VPD
Support
Video Format
Composite Video, HD-TVI, AHD, HDCVI
Max. Transmission Distance
300M over CAT5 or greater (4 Pairs, 24 AWG)
Ports & Interfaces
Video, Power Input
16 x RJ45
Data Input
1 x Terminal Block
Video Output
16 x BNC (1Vp-p, 75 ohms)
Power
Power Output
AC24V, 10 A, 1.1A/ port, Max 10A/ port
Ambient Temperature
Operation
-30 to 70℃
Storage
-10 to 45℃
Humidity
Up to 95%
Physical Characteristics
Dimensions
480 x 290 x 44mm
Weight
5700g
