Schaller humimeter FSG User manual

78,0°F | 6,16% | 456kg/m
3
| -27,3td | 0,64aw | 51,9%r.H. | 14,8%abs | 100,4g/m
2
| 09m/s | 4,90Ugl | 1
Operating Manual
Always read this operating manual before using the humimeter FSG!
humimeter FSG
Moisture meter for measuring the moisture content
of food
Moisture meter
Version 2.0

humimeter FSG Operating Manual
Page 2
Your humimeter FSG at a glance
The main unit
No. Name
1 Measuring chamber
2 Display
3 Keypad
4 USB port (optional)
5 Battery compartment
1
2
3
4
5

Page 3
The display
No. Name
1 Product type
2 Moisture content in % ("6.2 How moisture
content is defined")
3 Display symbols
4 Temperature display
The display symbols
Symbol Name Symbol Name
Enter No
Up Change input
level
Down OK
Back Change menu
Enter numbers Enter data
Enter letters View measurements
Continue / go right Delete measurements
Left On/off button, display
light
Yes Save measured value
1
2
4
3

humimeter FSG Operating Manual
Page 4
The menus
The device has three different menus: product selection, Data Log and main menu:
Product selection menu
No. Name
1 Change menu
2 Display illumination / device on/off
3 For changing the product type
Data Log menu
No. Name
1 Change menu
2 Display illumination / device on/off
3 Save measured value
4 Show the last recorded values
21 3
21 3 4

Page 5
Main menu
The main menu comprises the following menu items:
• Edit Logs:
Manual Logs, Clear Logs
• Print Logs:
Last Log, All Logs, Clear Logs
• Send Logs:
Manual Logs, Clear Logs
• Options:
Bluetooth, Date/Time, Language, Unlock, °C/°F, BL On Time, Auto Off Time,
Materialcalibration, Online Send, Online Print, Password, Reset
• Status

humimeter FSG Operating Manual
Page 6
Table of contents
Your humimeter FSG at a glance ������������������������������������������������� 2
The main unit ..........................................................................................................2
The display ...............................................................................................................3
The display symbols .................................................................................................3
The menus ...............................................................................................................4
1� Introduction �������������������������������������������������������������������� 9
1.1 Information about this operating manual ................................................9
1.2 Limitation of liability ................................................................................ 9
1.3 Symbols used in this manual .................................................................10
1.4 Customer service .................................................................................. 10
2� For your safety �������������������������������������������������������������� 11
2.1 Proper use ............................................................................................11
2.2 Improper use ........................................................................................11
2.3 User qualications ................................................................................. 11
2.4 General safety information .................................................................... 12
2.5 Warranty .............................................................................................. 12
3� On receipt of your device �������������������������������������������� 12
3.1 Taking the device out of its packaging ...................................................12
3.2 Making sure that all of the components have been included .................13
3.3 Inserting batteries .................................................................................13
4� Using the device - Basics ���������������������������������������������� 14
4.1 Switching the device on ........................................................................14
4.2 Automatic calibration ............................................................................ 14
4.3 Selecting the product type ....................................................................15
4.4 Taking a measurement ..........................................................................15
4.5 Switching the device off ........................................................................ 15
5� The measuring process ������������������������������������������������� 16

Page 7
5.1 Preparing a measurement ..................................................................... 16
5.2 Taking a measurement ..........................................................................17
5.3 Saving individual readings .....................................................................18
5.4 Saving several readings (a measurement series) at the same time .......... 19
5.5 Viewing individual readings ................................................................... 21
5.6 Viewing individual readings from a series of measurements ................... 21
5.7 Deleting all measured values (data log) ................................................. 22
5.8 Deleting individual measurement series ................................................. 22
5.9 Deleting individual values from a single series of measurements ............ 23
6� Product types ���������������������������������������������������������������� 24
6.1 Pictures of product types ....................................................................... 25
6.2 How moisture content is dened .......................................................... 26
7� Using the LogMemorizer program ������������������������������ 27
7.1 Installing / opening the program ...........................................................27
7.2 Exporting measured values to a computer ............................................. 27
8� Checking the device's status ���������������������������������������� 30
9. Conguringthedevice������������������������������������������������� 31
9.1 Turning on Bluetooth ............................................................................31
9.2 Adjust the date/time ............................................................................31
9.3 Selecting a language ............................................................................. 32
9.4 Activating options ................................................................................. 32
9.5 Deactivating options .............................................................................33
9.6 Selecting °C/°F ......................................................................................33
9.7 Reducing the device's power consumption ............................................ 33
9.7.1 Conguring the display illumination time ..............................................33
9.7.2 Conguring automatic switch-off ......................................................... 34
9.8 Conguring the material calibration function ........................................35
9.9 Online functions ................................................................................... 35
9.9.1 Online Send .......................................................................................... 35

humimeter FSG Operating Manual
Page 8
9.9.2 Online Print ........................................................................................... 35
9.10 Changing the password ........................................................................ 36
9.11 Resetting the device to its factory settings ............................................. 37
10� Cleaning and maintenance ������������������������������������������ 37
10.1 Changing the batteries ......................................................................... 37
10.2 Cleaning the device .............................................................................. 38
11� Faults ����������������������������������������������������������������������������� 39
12� Storage and disposal ���������������������������������������������������� 40
12.1 Storing the device ................................................................................. 40
12.2 Disposing of the device ......................................................................... 40
13� Device information ������������������������������������������������������� 41
13.1 Technical data ....................................................................................... 41
14� Notes ����������������������������������������������������������������������������� 42

Page 9
1. Introduction
1.1 Information about this operating manual
This operating manual is designed to enable you to use the humimeter FSG safely and
effectively. It is part of the device, has to be stored nearby and must be easily acces-
sible to users at all times.
All users are required to carefully read and make sure that they have understood this
operating manual before using the humimeter FSG. All of the safety and operating
instructions detailed in this manual have to be observed to ensure the safety of the
device.
1.2 Limitation of liability
All of the information and instructions provided in this operating manual have been
compiled on the basis of the current standards and regulations, the state of the art,
and the extensive expertise and experience of Schaller GmbH.
Schaller GmbH does not accept any liability for damage associated with the following,
which also voids the warranty:
• Non-observance of this operating manual
• Improper use
• Inadequately qualified users
• Unauthorised modifications
• Technical changes
• Use of unapproved spare parts
This fast measuring procedure can be affected by a range of different factors. For this
reason, we recommend periodically checking the device’s measurements with a stand-
ardised oven-drying method.
We, as the manufacturer, do not accept any liability for any incorrect measurements
and associated consequential damage.

humimeter FSG Operating Manual
Page 10
1.3 Symbols used in this manual
All of the safety information provided in this manual is shown with a corresponding
symbol.
ATTENTION
It is essential to observe this warning. Non-compliance can lead to damage to
property or equipment.
iInformation
This symbol indicates important information that enables users to use the de-
vice more efficiently and cost effectively.
1.4 Customer service
For technical advice, please contact our customer service department at
Schaller GmbH
Max-Schaller-Straße 99
A - 8181 St.Ruprecht an der Raab
Telephone: [phone]
Fax: [phone] - 901
E-mail: [e-mail]
Internet: www.humimeter.com
© Schaller GmbH 2019

Page 11
2. For your safety
The device complies with the following European directives:
• Restriction of Hazardous Substances in Electrical and Electronic Equipment
(RoHS)
• Electromagnetic compatibility (EMC)
The device corresponds to state-of-the-art technology. However, it is still associated
with a number of residual hazards.
These hazards can be avoided through strict observance of our safety information.
2.1 Proper use
• Easy to use device for quickly measuring the moisture content of food
• The device must only be used for taking measurements on the products defined
in the following sections of this manual (see "6. Product types").
2.2 Improper use
• The device is not suitable for measuring mouldy material.
• The device must not be used in ATEX.
• The device is not waterproof and must be protected from water and fine dust.
2.3 User qualifications
The device must only be operated by people who can be expected to reliably take the
measurements. The device must not be operated by people whose reaction times may
be slowed due to, e.g. the use of drugs, alcohol or medication.
All persons using this device must have read, understood and follow the instructions
provided in the operating manual.

humimeter FSG Operating Manual
Page 12
2.4 General safety information
The following safety information has to be observed at all times to avoid damage to
objects and injury to people:
• Remove the batteries if the device is not used for a prolonged period of time
(4 weeks).
• In case of damages or loose parts on the device, remove the batteries and con-
tact Schaller GmbH or your dealer.
All of the device’s technical features have been inspected and tested before delivery.
Every device has a serial number. Do not remove the tag with the serial number.
2.5 Warranty
The warranty does not apply to:
• Damage resulting from non-observance of the operating manual
• Damage resulting from third-party interventions
• Products that have been used improperly or modified without authorisation
• Products with missing or damaged warranty seals
• Damage resulting from force majeure, natural disasters, etc.
• Damage from improper cleaning
• Damage due to leaking batteries
3. On receipt of your device
3.1 Taking the device out of its packaging
• Take the device out of its packaging.
• Next, make sure that it is not damaged and that no parts are missing.

Page 13
3.2 Making sure that all of the components have been included
Make sure that all of the components have been included by checking the package
contents against the following list:
• humimeter FSG
• 4 pieces of AA Alkaline batteries
• Digital scale 2,200 grams
• Measuring bucket 2.5 liter
• Operating manual
Optional accessories:
• humimeter USB data interface module - USB stick with software and USB cable
• Battery operated portable thermal printer (only possible together with humimeter
USB data interface module) - Described in a separate operating manual
• Bluetooth module (only possible together with humimeter USB data interface
module) - Described in a separate operating manual
3.3 Inserting batteries
1. Remove both screws on either side of the black battery
cover (figure 1, screws 1 and 2) and then take the bat-
tery cover off of the battery compartment.
2. Insert the batteries with negative and positive terminals
matching those indicated on the battery compartment.
Press down the batteries so that they lay flat on the bot-
tom of the housing (figure 2) and the battery cover lays
flat on the battery compartment.
»As soon as all batteries have been inserted, the device
switches on automatically.
3. Place the battery cover onto the battery compartment
and tighten the screws on both sides again (figure 3).
1
2
3

humimeter FSG Operating Manual
Page 14
4. Using the device - Basics
4.1 Switching the device on
• Press the button for 3 seconds.
»The display will then show the status indicator
(figure4).
»After inserting the batteries, the device switches on
automatically.
4.2 Automatic calibration
»The display will show the message Adjust?
(figure 5).
1. Make sure that the measuring chamber of the de-
vice is empty and place the device on a level table.
2. Confirm by pressing .
»The display will now appear as shown in figure 6.
»The bar will run upwards. During this period, the
device must remain on the table without external
influence,
»which only takes a couple of seconds to complete.
»Once completed, the device will show the measuring window (see "Product selec-
tion menu" page 4).
4
5
6

Page 15
4.3 Selecting the product type
To do so: The device has to be in the product selection menu (figure ).
For an overview of the different product types and the criteria for selecting them,
please refer to "6. Product types".
1. Press the or button to move from one
product type to the next Or
2. Press the or button for 3 seconds to open
the product type overview (figure 8).
3. Use the arrow keys to move from one product type
to the next
4. and keep any of them pressed to scroll through the
types.
5. Confirm your selection by pressing .
»The product type you selected will now be shown at the top of the display.
4.4 Taking a measurement
• For information on how to take a measurement, see section "5. The measuring
process".
4.5 Switching the device off
To do so: The device has to be in the product selection or Data Log menu. It is not pos-
sible to switch off the device when it is in the main menu.
• Press the button for 3 seconds.
7
8

humimeter FSG Operating Manual
Page 16
5. The measuring process
5.1 Preparing a measurement
To do so: The device has to have nearly the same temperature than the product being
measured. It is recommended to let your humimeter device adjust to the surrounding
temperature of the material being measured for at least 30 minutes.
1. Place the empty and clean measuring bucket (2.5 liter) on
the switched-off scale. Then switch on the scale.
»The scale must display 0 g with the empty measuring cup
on it (figure 9). The measuring cup must not be weighed.
2. Check whether the measuring chamber of the device is
empty. When the device is switched on, there must not
be any material in it.
»Empty the device and clean the measuring chamber if
necessary (see "10.2 Cleaning the device").
3. Switch on the device (see "4.1 Switching the device
on").
4. Effect the automatic calibration (see "4.2 Automatic
calibration").
5. Select the required product type (see "6. Product
types") by pressing the or button (see "4.3
Selecting the product type").
9
10
11

Page 17
5.2 Taking a measurement
To do so: The device has to have nearly the same temperature
than the product being measured.
1. Fill the measuring bucket with the filling quantity dis-
played in the product type name (+/- 3 g) (figure 12) (see
"6. Product types").
2. Now slowly and evenly fill the measuring chamber of the
device with the material being measured (figure 13).
»For the filling, no funnel or similar device may be used.
3. The device will now display the moisture content
(figure 14).
»The displayed value flashes when the moisture content
exceeds the measuring range of the selected product
type (figure 15). A flashing value signals a decreasing
accuracy of the measurement. The measuring range is
dependent on the product type (see "6. Product types").
»Once the reading has been taken, it can be saved on the
device (see "5.3 Saving individual readings" or "5.4
Saving several readings (a measurement series) at
the same time").
4. Empty the device and make sure that there are no
residues in the measuring chamber.
»Clean the measuring chamber if necessary (see
"10.2 Cleaning the device").
iInformation - Measuring accuracy
This rapid and non-destructive measuring procedure allows you to quickly
take several moisture readings of the same sample material. When saving the
individual readings, the device will automatically calculate the readings’ average
(see "5.4 Saving several readings (a measurement series) at the same time").
iInformation - Incorrect readings
Always make sure to select the correct product type and the correct filling
quantity for the material you are measuring. This prevents taking incorrect rea-
dings (see "11. Faults").
12
13
14
15

humimeter FSG Operating Manual
Page 18
5.3 Saving individual readings
The device is configured in such a way that the device will save a reading every time a
button is pressed.
To do so: The device has to be in the Data Log menu (see "Data Log menu" page 4).
1. Press .
»The display will now appear as in figure 17 and the
disc symbol will be preceded by the digit one.
2. Press to enter a name for the saved reading
and to finish the measuring process.
»The display will now appear as shown in figure 18.
3. The data you have inputted can be overwritten at
any time.
4. Inputting letters:
Press and hold to quickly scroll to the
required letter and either press it for 3 seconds or
press to confirm the selected letter (figure 19).
5. Inputting numbers:
Press and hold to quickly scroll to the
required number and either press it for 3 seconds
or press to confirm the selected number.
6. Moving forward/back:
Press to switch to another input level. Press
or to move forward or back.
7. Confirm your entry by pressing .
»The data you entered has been saved.
16
17
18
19

Page 19
5.4 Saving several readings (a measurement series) at the same time
To do so: The device has to be in the Data Log menu (see "Data Log menu" page 4).
1. Take several measurements of the same sample material (see "5. The measuring
process").
2. To save a reading, press as soon as the reading
has been taken.
3. The display will now appear as shown in figure 20.
The marked number shows the number of rea-
dings that have already been saved.
4. Press to enter a name for the saved series
of measurements and to finish the measuring
process.
5. The display will now appear as shown in figure 21.
6. The data you have inputted can be overwritten at
any time.
7. Inputting letters:
Press and hold to quickly scroll to the
required letter and either press it for 3 seconds or
press to confirm the selected letter (figure 22).
8. Inputting numbers:
Press and hold to quickly scroll to the required number and either press it
for 3 seconds or press to confirm the selected number.
9. Moving forward/back:
Press to switch to another input level. Press or to move forward or
back.
10. Confirm your entry by pressing .
»The data you entered has been saved.
»The device automatically determines the average moisture content of the saved
measuring values.
20
21
22

humimeter FSG Operating Manual
Page 20
»The display will show the following information:
No. Name
1 Name of the measurement series (editable)
2 Temperature (average)
3 Date & start time of the measurement series
4 Date & end time of the measurement series
5 Number of saved readings
6 Product type
7 Device name
8 Moisture content (average)
1
54
3
2
6
7
8
