Schefenacker Telescopic Trailer Tow Mirror User manual

WARNING
Please readALL the instructions and warnings thoroughly before installing the
replacement parts.Ensure that the fitting instructions are followed exactly,
as failure to do so may result in incorrect installation,and may also result in
the driver,passengers and vehicle being placed in hazardous conditions.
take a really good look
TelescopicTrailerTow Mirror by
Takeareallygoodlook
ReplacementComponentInstallationInstructions
For technical support,contact yourTelescopicTrailerTow Mirror dealer or visit www.ttt-mirror.com
SchefenackerVision SystemsAustralia Pty Ltd warrants thatthiscomponentisfreefromdefectsinmaterial
andworkmanship under normal use for a period of 12 months from the date ofpurchase.
Important Information
SchefenackerWarranty–Terms&Conditions
Allillustrationsaredrawntoshowdriver’ssidecomponent.
Existing cover removal.
Make sure you have the required tools:
• flashlight
• slotted screwdriver (with at least a 5”shaft)
• 3/16”(5mm) hex head socket and driver
Approximate installation time:15minutes.
Preparation and STEP 1 LIGHT MODULE REPLACEMENT (part # 9000 - 9001)
Vertical slot
Hex-head Screw
Horizontal slot
Figure 1a
Figure 1b
1. Pull the top edge of the main glass as far forward
as practical.It may make a clicking sound as it moves
- this is normal.(See Figure 1a)
Using a flashlight,locate the vertical rectangular slot
on the vehicle side of the main glass opening.It will be
alongside a hex-headscrew and another rectangular
slot - horizontal.(See Figure 1b)
Continued over page…

2. Insert your screwdriver through the vertical slot
until you feel the tip pressing against a spring
loaded clip.(see Figure 2 opposite)
Push the screwdriver gently against the clip
– very little force is needed.
For technical support,contact yourTelescopicTrailerTow Mirror dealer or visit www.ttt-mirror.com
4. Remove the 3/16”(5mm) hex head screw and
pull the light module up and forward to free it from
the main body of the mirror assembly.
(see Figure 4 opposite)
STEPS 2,3 & 4 LIGHT MODULE REPLACEMENT
Figure 2
Figure 4
3/16”(5mm) hex head screw
3. At the same time,slide the mirror cover
towards the vehicle door.(see Figure 3 opposite)
The cover should slide away from the main body
of the mirror.
Figure 3

5. Remove the wiring connector from the
original connector,and refit the wiring connector
to the replacement light module.
(see Figure 5 opposite)
For technical support,contact yourTelescopicTrailerTow Mirror dealer or visit www.ttt-mirror.com
7. To refit the cover,simply position the cover
over the main body of the mirror,locate the two
hook-like tags in the slots at the top edge of the
mirror body,place the cover flat against the body
of the mirror and slide the cover away from the
vehicle door.
(see Figure 7 opposite)
You should hear a definite“click”as the cover
locates itself.
Check for an even and secure fit of the cover.
STEPS 5,6 & 7 LIGHT MODULE REPLACEMENT
Figure 5
Figure 7
6. Relocate the replacement light module,
ensuring the tabs on the lower and main glass side
of the module locate securely inside the body of
the mirror’s case.
(see Figure 6 opposite)
Refit the hex head screw.
Test your lights to ensure that the light module is
correctly connected.
Figure 6
Locating tabs
