Schiit MODI+ User manual

D/A CONVERTER

1
2
34
CONNECTIONS
1 Connect the two RCA jacks to your amp,
preamp, or receiver.
2 Connect a USB source using a USB A-C
cable (supplied). If you’re using a USB
source, this may be the only input you need.
3 (Optional) Connect a coaxial digital
source to the coaxial input, using an RCA
cable, 75 ohm preferred.
4 (Optional) Connect an optical source
to the optical input jack, using a Toslink
cable.
5 (Optional) Connect a 5V power source
to the power input if you need external
power—see below.
If you’re using Modi+ as a USB only DAC, you don’t
need Power Input. Just connect it to your computer
and you’re set.
If you’re using the other digital inputs, and you’re
NOT using USB, you need Power Input. Connect the
USB wall-wart with the supplied USB A-C cable to
provide power for the other inputs.
5

12 3
USING MODI+
1Select input by pressing the input button.
This selects from three inputs—USB, optical,
and coaxial. Keep pressing and it will cycle
back around thru the inputs.
2When lit, the Unison USB™ input is
selected. This is good for computers,
tablets, streamers, and phones.
3 When lit, the Optical (Toslink style) input
is selected. Typically used with TVs.
4 When lit, the Coaxial input is selected.
Used with some CD players and transports.
TROUBLESHOOTING
“Draws too much power” error? Disconnect
Modi+ from USB, then connect the wall-wart
to the Power Input. Modi+ will then report as
a 0mA USB device. You’ll need another USB
cable to connect to your source.
No sound? Make sure you have the correct
output device selected on your device. For
computers, you may need to select Modi+
in both Control Panel (Windows) or System
Prefs (Mac) AND in your player software or
streaming service interface.
4

Schiit Audio warrants to the original purchaser that this product shall be free from defects in material and workmanship for two (2) years
from the date of purchase. If a defect covered by this warranty occurs during this period, Schiit Audio will repair the defective product, free
of charge. Date of purchase will be based on customer receipts, otherwise date of manufacturing will be used.
If you believe you need warranty service, contact us rst. Schiit Audio products sent back to us without a Return Authorization (RA) will
be returned to the sender without repair. To contact us and obtain an RA, email [email protected].
Warranty Limitations. This warranty shall not apply if a product: (a) is modied or tampered with; (b) is damaged by negligence, accident,
unreasonable use, or other causes unrelated to defective materials or workmanship, or (c) has had the serial number altered or removed.
Any implied warranties, including warranties of merchantability and tness for a particular purpose, are hereby limited in duration to the
warranty period of 2 years. In no event shall Schiit Audio be liable for consequential or incidental damages resulting from the breach of any
implied or expressed warranties. Some states do not allow these limitations, so they may not apply to you. You may also have other rights
which vary from state to state or province to province.
WARRANTY
SCHIIT.COM
[email protected]
1. If you don’t know how to install audio devices, get a qualied professional to help.
2. Never use this device near water, do not expose to rain or moisture, and clean only
with a dry cloth.
3. Assure adequate ventilation, do not block ventilation openings, or place near heat sources.
4. Use only the supplied wall-wart or suitable replacement. Route cords away from trac areas and
protect them from being pinched. Unplug the wall-wart from the outlet if the apparatus is unused
for a long period of time.
5. To prevent electric shock, do not use the plug with an extension cord, receptacle, or outlet unless
blades can be fully inserted.
6. Refer all servicing to qualied service personnel. Service is required when the device has been
damaged, including cord or plug damage, liquid has been spilled or objects have fallen into the device,
the device has been exposed to rain or moisture, does not operate normally, or has been dropped.
SAFETY
IN THE BOX
(1) Modi
(1) 5V USB
Wall-Wart
(1) USB A-C
Cable
(And maybe some stickers,
and the appreciation of
the production, QC, and
engineering staff at Schiit in
Texas and California.)
This product is in compliance with standards
and regulations of the European Community.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
