OWNER’S
MANUAL
Schwinn® SC5/SC7
Core Health & Fitness

Page 2
INTRODUCTION ............................................................................................................................................. 3
PRODUCT SPOTLIGHT ............................................................................................................................................. 4
Features .......................................................................................... 6
SAFETY INSTRUCTIONS ............................................................................................................................................. 7
Important Label Locations .......................................................................................... 8
OPERATIONS ............................................................................................................................................. 9
Locking Pop Pins / Seatpost & Handlebar Adjustment....................................................... 9
Emergency Stop ........................................................................................10
Slider Tension Knob ........................................................................................11
SUPPORT AND SERVICE RESOURCES ...........................................................................................................................................12
PREVENTATIVE MAINTENANCE ...........................................................................................................................................13
WARRANTY ...........................................................................................................................................15
TABLE OF CONTENTS

Page 3
Congratulations on the purchase of a Schwinn S.C.™ bike! This manual will acquaint you with the
operation, safety, and maintenance of your Schwinn® group cycling bike, and covers the following
units:
• 9-7400 - S.C.™ 7
• 9-7410 - S.C.™ 5
Refer to the Assembly Instructions in the box for your specic model for proper assembly of your
bike.
INTRODUCTION

Page 4
Page 5
9-7400 S.C.™ 7
Overall Weight Width Length Height User Weight
120 lbs (54 kg) 21” (53 cm) 55” (140 cm) 46” (117 cm) 0-350 lbs (0-159 kgs)
Product Conformity
• EN957-1 (S,H)
• EN957-10 (S,H)
• ASTM F1250-13
• ASTM F2276-10
All products may be covered by US and Foreign Patents and Patents Pending.
PRODUCT SPOTLIGHT

Page 4
Page 5
9-7410 S.C.™ 5
Overall Weight Width Length Height User Weight
134 lbs (61 kg) 21” (53 cm) 55” (140 cm) 47” (119 cm) 0-350 lbs (0-159 kgs)
Product Conformity
• EN957-1 (S,H)
• EN957-10 (S,H)
• ASTM F1250-13
• ASTM F2276-10
All products may be covered by US and Foreign Patents and Patents Pending.

Page 6
Features
A
C
B
L
D
E
H
I
F
G
J
K
A
C
B
L
D
E
H
I
F
G
J
K
ALocking Pop Pin BSeat Post CSeat Slider
DSeat EBrake Adjustment Knob and
Emergency Brake FHandlebar Slider
GHandlebar HFlywheel IStabilizer
JLeveling Foot KTransport Wheels LPedal with Morse Taper

Page 7
SAFETY INSTRUCTIONS
This symbol indicates a potentially hazardous situation, which, if not avoided, could result in
death or serious injury.
Before using this equipment, obey the following warnings:
• This machine is not intended to be used by children.
• It is not intended to be used by persons with reduced physical, sensory, or mental
capabilities or lack of experience and knowledge, unless given instruction and under the
personal supervision concerning use of the machine by a person responsible for their
safety. Do not leave children unsupervised around the machine
• Consult a physician before you start an exercise program. Stop exercising if you feel pain
or tightness in your chest, become short of breath, or feel faint. Contact your doctor before
you use the machine again. Use the value calculated or measured by the console for
reference purposes only.
• If you have a pacemaker or other implanted electronic device, consult your physician be-
fore using a wireless chest strap or other telemetric heart rate monitor.
• Do not use or put the device into service until it has been fully assembled and inspected
for correct performance in accordance with the Owner’s Manual and Installation Guide.
Caution: Read and understand the complete Owner’s Manual supplied with the device before
using the device. Keep the Owner’s Manual for future reference.
Danger: Pedals that have not been tested and qualied by Schwinn should never be used on
Schwinn bikes. Unqualied pedals can lead to pedal failure and serious injury to the rider.

Page 8
Important Label Locations
Serial Label
Warning Label
Serial Label
Warning Label

Page 9
To operate the features shown, see the directions below.
For bike t and coaching resources, refer to https://www.corehandf.com/schwinn-resources/
For Schwinn Group Cycle Education and Certication, refer to https://corehandf.com/certication
Locking Pop Pins
Emergency Stop
Handlebar
Seatpost
Slider Tension Knob
Locking Pop Pins
Emergency Stop
Handlebar
Seatpost
Slider Tension Knob
Locking Pop Pins / Seatpost & Handlebar Adjustment
1. Turn pin counterclockwise and pull to loosen.
OPERATIONS

Page 10
Page 11
2. Adjust tube.
Caution: Do not lift the Seatpost or Handlebar posts above
the MAX mark on the tube.
3. Release pin and turn clockwise to lock. Tighten knob until snug
and post is secure without wobble.
Emergency Stop
1. Push down on red knob to stop ywheel.
