Schwinn S14 Folding Bicycle User manual
THIS MANUAL CONTAINS IMPORTANT SAFETY,
PERFORMANCE AND MAINTENANCE INFORMATION.
READ THE MANUAL BEFORE TAKING YOUR FIRST
RIDE ON YOUR NEW BICYCLE, AND KEEP THE
MANUAL HANDY FOR FUTURE REFERENCE.
To register your bike visit
www.schwinnbikes.com/registerbike
FOLDING
i
1 Safety ............................................4
Safety Signal Words ...............................4
User Responsibility................................4
Personal Safety...................................5
Bicycle Setup ....................................7
Riding Safety....................................11
Bicycle Safety Checklist ...........................13
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3 Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
GengStarted..................................17
Unfolding the Bicycle.............................17
AachthePedals ................................20
AachtheSeat..................................21
Folding the Bicycle ...............................22
4 Adjustments ......................................24
Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
AdjusngtheFrameLatch . . . . . . . . . . . . . . . . . . . . . . . . 25
AdjusngtheHandlebarPostLatch.................26
AdjusngtheSeatHeight . . . . . . . . . . . . . . . . . . . . . . . . . 27
BrakeAdjustment ...............................28
AdjusngtheRearDerailleur . . . . . . . . . . . . . . . . . . . . . . 32
5 Use..............................................33
HandOperatedBrakes ...........................33
GearOperaon..................................34
RearShier .....................................35
Security ........................................36
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
LubricaonSchedule .............................38
Parts Maintenance...............................39
HubBearings....................................42
InangtheTireTube . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Repairing a Flat Tire ..............................43
TroubleshoongGuide ...........................44
7 Warranty.........................................47
Purchase Record.................................48
Schwinn Folding Bicycle Manual.indb 1 7/1/14 3:58 PM
ii
for purchasing your folding bicycle. Before using your bicycle,
pleasepracceproperfoldingandunfoldingprocedures.Besure
tofollowthesequenceofstepscarefully.Properoperaonof
yourbicycleisimportantforyoursafetyandenjoyment.Witha
bitofpracce,youshouldbeabletofoldyourbicyclein15
seconds or less.
Itisimportantforyoutounderstandyournewbicycle.
Byreadingthismanualbeforeyougooutonyourrstride,you’ll
knowhowtogetbeerperformance,comfort,andenjoyment
fromyournewbicycle.Itisalsoimportantthatyourrstrideon
yournewbicycleistakeninacontrolledenvironment,awayfrom
cars, obstacles and other cyclists.
Thismanualcontainsimportantinformaonregardingsafety,
assembly,use,andmaintenanceofthebicyclebutisnot intended
tobeacompleteorcomprehensivemanualcoveringallaspects
concerningbicycleownership.Werecommendconsulnga
bicycle specialist if you have any doubts or concerns regarding
yourexperienceorabilitytoproperlyassembleandmaintain
the bicycle.
Ourcustomerservicedepartmentisdedicatedtoyour
sasfaconwithPacicCycleanditsproducts.Ifyouhave
quesonsorneedadviceregardingassembly,parts,performance,
orreturns,pleasecontacttheexpertsatPacicCycle.
1-800-626-2811.
Monday-Friday8:00amto5:00pm
CentralStandardTime(CST).
Youmayalsoreachusat:
www.pacic-cycle.com
customerservice@pacic-cycle.com
P.O.Box344
4730E.RadioTowerLane
Olney,IL62450
You will need your
modelnumberwhencallingcustomerservice.SeeSecon 7:
Purchase Recordforthelocaonofthemodelnumberon
your bicycle.
Itisatragicfactthatmostbicycleaccidentsinvolvechildren.
Asaparentorguardian,youbeartheresponsibilityfortheacv-
iesandsafetyofyourminorchild.Amongtheseresponsibilies
aretomakesurethatthebicyclewhichyourchildisridingis
properlyedtothechild;thatitisingoodrepairandsafe
operangcondion;thatyouandyourchildhavelearned,
understandandobeynotonlytheapplicablelocalmotor
vehicle,bicycle,andtraclaws,butalsothecommonsense
rules of safe and responsible bicycling. As a parent, you should
readthismanualbeforelengyourchildridethebicycle.Please
makesurethatyourchildalwayswearsanapprovedbicycle
helmetwhenriding.
Schwinn Folding Bicycle Manual.indb 2 7/1/14 3:58 PM
iii
CorrectFing
Makesureyourhelmetcoversyourforehead
IncorrectFing
Forehead is exposed and vulnerable to serious injury
Helmets
Schwinn Folding Bicycle Manual.indb 3 7/1/14 3:58 PM
4
1 Safety
❶Safety
SAFETY SIGNAL WORDS
The following safety signal words indicate a safety message.
The symbol alerts you to potenal hazards. Failure to follow the
warning may result in damage to property, injury, or death.
This manual contains many Warnings and Cauons concerning
the consequences of failure to follow safety warnings. Because
any fall can result in serious injury or even death, we do not
repeat the warning of possible injury or death whenever the risk
of falling is menoned.
Indicates a hazard or unsafe pracce that will result in severe
injury or death. Failure to read, understand and follow the safety
informaon in this manual may result in serious injury or death.
Indicates a hazard or unsafe pracce that could result in
minor injury.
NOTICE
Indicates a hazard unrelated to personal injury, such as
property damage.
USER RESPONSIBILITY
All persons assembling, using, and maintaining the bicycle must
read and understand the safety warnings and operang
instrucons in this manual before using the bicycle.
It is the responsibility of the user, or in the case of a child rider,
an adult, to ensure the bicycle is properly maintained and in
proper operang condion. Doing so will reduce the risk of
injury. Always conduct regular maintenance and inspecon of
your bicycle. Complete the Safety Checklist at the end of this
secon before each use.
A responsible adult must always supervise the use of the bicycle
by a child. You must ensure:
• The child is wearing the proper protecve are and approved
bicycle helmet.
• The child is seated securely and the bicycle is properly ed
to the child.
• The child understands applicable laws and common sense
rules of safe responsible bicycling.
WARNING!
CAUTION!
Schwinn Folding Bicycle Manual.indb 4 7/1/14 3:58 PM
Safety 1
5
Protecve Gear and Clothing
Always wear: Figure 1.1
• Colors that are easily seen and, if possible, reecve clothing.
• Clothing appropriate for the weather condions.
• Use of protecve gear such as pads for the knees and elbows
is highly recommended for children.
• A properly ed, ASTM or SNELL approved, bicycle helmet
shall be worn at all mes by riders of the bicycle. For
informaon regarding how to properly t a helmet visit:
hp://www.nhtsa.gov/people/injury/pedbimot/bike/
easystepsweb
Do not wear:
• Loose clothing parts, strings, jewelry that may become
entangled with moving parts on the bicycle or interfere with
handling of the bicycle.
PERSONAL SAFETY
• Pants with loose pant legs. If necessary, always tuck pant legs
into a sock or use a leg band to avoid the clothing becoming
caught in the drive chain.
• Shoes with uned shoe laces.
Riding a bicycle without protecve gear, clothing, or a helmet
may result in serious injury or death. Always wear protecve
gear, clothing, and helmet when riding the bicycle. Ensure
protecve gear does not interfere with steering, braking, and
pedaling.
WARNING!
Properly ed helmet
Elbow pads
Knee pads
Leg band
Laces ed
Easily seen or
reecve clothing
Figure 1.1
Schwinn Folding Bicycle Manual.indb 5 7/1/14 3:58 PM
6
1 Safety
Helmet Use
Important! Many states have passed helmet laws regarding
children. Make sure you know your states helmet laws. It is your
job to enforce these rules with your children. Even if your state
does not have a children’s helmet law, it is recommended that
everyone wear a helmet when cycling. When riding with a child
carrier seat or trailer, children must wear a helmet.
It is strongly advised that a properly ng, ASTM or SNELL
approved, bicycle safety helmet be worn at all mes when riding
your bicycle. In addion, if you are carrying a passenger in a
child safety seat, they must also be wearing a helmet.
The correct helmet should: Figure 1.2
• Be comfortable
• Have good venlaon
• Fit correctly
• Cover forehead
Incorrect helmet posion: Figure 1.3
• Helmet does not cover the forehead
Figure 1.3
Figure 1.2
Schwinn Folding Bicycle Manual.indb 6 7/1/14 3:58 PM
Safety 1
7
Figure 1.4
BICYCLE SETUP
Correct Bicycle Size
Riding a bicycle that is not correctly sized to the rider may result
in the rider’s feet not being able to touch the ground and
balance the bicycle, properly reach the handlebar for steering or
braking, and loss of control when pedalling.
Use the wheel size in the following table as a guide to match the
rider and bicycle. For example, bicycles with a wheel size of 12
inches t a rider that is 28 to 38 inches tall. Note: Some bicycles
such as folding bicycles may have smaller wheels but sll t
adults.
If the bicycle has a top tube on the frame, check that there is
one to three inches of clearance between the rider and the top
tube. Figure 1.4
Inability to safely reach the handlebars and dismount the
bicycle may result in loss of control of the bicycle. If the
bicycle has a top tube on the frame, ensure there is one to
three inches of clearance between the rider and the top tube.
Improper setup or maintenance of the bicycle may result in
an unexpected movement, loss of control, and serious injury
or death.
WARNING! Wheel Size Riders Approximate Height
12 inch 28 - 38 inches tall
16 inch 38 - 48 inches tall
18 inch 42 - 52 inches tall
20 inch 48 - 60 inches tall
24 inch 56 - 66 inches tall
26 inch, 27.5 inch,
29 inch, 700c 64 - 74 inches tall
Top tube
1 to 3 inch
clearance
Schwinn Folding Bicycle Manual.indb 7 7/1/14 3:58 PM
8
1 Safety
Quick-release Levers
Frame
❶ The frame must be securely locked. Ensure the frame
latch is properly seated and the quick-release lever locked
in place. Figure 1.5
Handlebar
❷ The handlebar must be securely locked. Ensure the
handlebar post latch is properly seated and the quick-
release lever locked in place.
Seat
❸ Ensure the seat post’s minimum inseron marks are not
visible above the quick-release seat clamp and the clamp is
locked in place.
Note: See Secon 4: Adjusng the Seat Height if
adjustments are needed.
Improper setup or maintenance of the quick-release levers may
result in an unexpected movement, loss of control, and serious
injury or death.
WARNING!
Figure 1.5
2
1
3
Handlebar
Seat post
Frame
Schwinn Folding Bicycle Manual.indb 8 7/1/14 3:58 PM
Safety 1
9
Seat Height and Handlebar Reach
❶Your legs should be almost completely straight when the
pedal is in the down most posion, just a slight bend in
the knee. Figure 1.6
Note: The rider’s feet may not touch the ground easily. If
this is the case the rider can simply move forward o the
seat to mount and dismount the bicycle or the seat can be
adjusted lower if the rider is uncomfortable with the height,
but note that riding is more dicult with the seat too low,
as the legs are in an unnatural posion.
Do not raise the seat so much the knees lock straight when
pedaling or you have to move forward o the seat to pedal.
This is unsafe and the bicycle cannot be controlled in this
condion.
❷You should be able to safely reach the handlebar with
your arms bent slightly (approximately 10 degrees) at
the elbow.
Adjust the seat
height
Improperly adjusted seat height could aect the rider’s ability
to reach the handlebar and pedals may result in an unexpected
movement, loss of control, and serious injury or death. Follow
these guidelines when adjusng the seat height. Always
ensure the seat post minimum inseron marks are below the
seat clamp and cannot be seen. Ensure the seat clamp is
locked and the seat cannot move.
WARNING!
Figure 1.6
1
2
Schwinn Folding Bicycle Manual.indb 9 7/1/14 3:58 PM
10
1 Safety
Front wheel (white)
Reectors
Important! Federal regulaons require every bicycle over 16
inches to be equipped with front, rear, wheel, and pedal
reectors. Many states require specic safety devices. It is your
responsibility to familiarize yourself with the laws of the state
where you ride and to comply with all applicable laws, including
properly equipping yourself and your bike as the law requires.
Bicycles under 16 inches are considered “sidewalk bicycles”, and
may not be ed with reectors. These bicycles should not be
ridden on streets, at night or unaended by an adult.
Check and conrm the front and rear reectors are in the
correct posion: Figure 1.7
• Front Reector: Should aim forward (when viewed from
above) and be mounted so it is within 5 degrees of vercal.
• Rear Reector: Should aim straight back (when viewed from
above) and be mounted so it is within 5 degrees of vercal.
Missing, damaged, or dirty reectors will aect the ability of
others to see and recognize you as a moving bicyclist increasing
the risk of being hit, serious injury or death. Always check the
reectors are in place and make sure they are clean, straight,
unbroken and securely mounted before riding the bicycle.
WARNING!
Rear wheel (white)
Figure 1.7
Pedal (orange)
Front (white)
Pedal (orange)
Rear (red)
Schwinn Folding Bicycle Manual.indb 10 7/1/14 3:58 PM
Safety 1
11
Riding the bicycle in unsafe condions (ie: at night), in an unsafe
manner, or disregarding trac laws may result in an unexpected
movement, loss of control, and serious injury or death.
WARNING!
General Safety
• Familiarize yourself with all the bicycle’s features before
riding. Pracce gear shis, braking, and the use of toe clips
and straps, if installed.
• Always ride defensively in a predictable, straight line. Never
ride against trac.
• Expect the unexpected (e.g. opening car doors or cars backing
out of concealed driveways).
• Take extra care at intersecons and when preparing to pass
other vehicles.
• Maintain a comfortable stopping distance from all other
riders, vehicles and objects. Safe braking distances and forces
are subject to the prevailing weather condions. Do not lock
up the brakes. When braking, always apply the rear brake
rst, then the front. The front brake is more powerful and if it
is not correctly applied, you may lose control and fall.
• Always use the correct hand signals to indicate turning
or stopping.
• Obey the trac laws (e.g. stopping at a red light or stop sign,
giving way to pedestrians).
• Wear proper riding are, reecve if possible, and avoid
open toe shoes.
• Do not use items that may restrict your hearing and vision.
• Do not carry packages or passengers that will interfere with
your visibility or control of the bicycle.
Road Condions
• Be aware of road condions. Concentrate on the path ahead.
Avoid pot holes, gravel, wet road markings, oil, curbs, speed
bumps, drain grates and other obstacles.
• Cross train tracks at a 90 degree angle or walk your
bicycle across.
Wet Weather
• When riding in wet weather always wear reecve clothing
and use safety lights to enhance visibility.
• Exercise extreme cauon when riding in wet condions.
• Ride at a slower speed. Turn corners gradually and avoid
sudden braking.
• Brake earlier, it will take a longer distance to stop.
• Pot holes and slippery surfaces such as line markings and train
tracks all become more hazardous when wet.
RIDING SAFETY
Schwinn Folding Bicycle Manual.indb 11 7/1/14 3:58 PM
12
1 Safety
Night Riding
• Important! Riding a bicycle at night is not recommended.
Check your local laws regarding night riding.
• Ensure bicycle is equipped with a full set of correctly
posioned and clean reectors.
• Use a white light on the front and a red light on the rear.
Use lights with ashing capability for enhanced visibility.
• If using baery powered lights, make sure baeries are
well charged.
• Wear reecve and light colored clothing. Wear reecve
clothing and use safety lights for increased visibility.
• Ride at night only if necessary. Slow down and use familiar
roads with street lighng.
Hill Technique
• Gear down before a climb and connue gearing down as
required to maintain pedaling speed.
• If you reach the lowest gear and are struggling, stand up on
your pedals. You will then obtain more power from each
pedal revoluon.
• On the descent, use the high gears to avoid rapid pedaling.
• Do not exceed a comfortable speed; maintain control and
take addional care.
• Braking will require addional distance. Iniate braking slowly
and earlier than usual.
Cornering Technique
• Brake slightly before cornering and prepare to lean your body
into the corner.
• Maintain the inside pedal at the 12 o’clock posion and
slightly point the inside knee in the direcon you are turning.
• Keep the other leg straight, do not pedal through fast or ght
corners.
• Decrease your riding speed, avoid sudden braking and
sharp turns.
Safe Riding Rules for Children
• Many states require that children wear a helmet while cycling.
Always wear a properly ed helmet.
• Do not play in driveways or the road.
• Do not ride on busy streets.
• Do not ride at night.
• Obey all the trac laws, especially stop signs and red lights.
• Be aware of other road vehicles behind and nearby.
• Before entering a street: Stop, look le, right, and le again
for trac. If there’s no trac, proceed into the roadway.
• If riding downhill, be extra careful. Slow down using the
brakes and maintain control of the steering.
• Never take your hands o the handlebars, or your feet o the
pedals when riding downhill.
Schwinn Folding Bicycle Manual.indb 12 7/1/14 3:58 PM
Safety 1
13
BEFORE YOU RIDE SAFETY CHECKLIST
Before every ride, it is important to carry out the following
safety checks. Do not ride a bicycle that is not in proper
working condion!
Accessories
□The reectors are properly placed and not obscured.
□ All other ngs on the bike are properly and securely
fastened, and funconing.
□ The rider is wearing a properly ed helmet (protecve gear
if necessary) and that clothing and loose items are properly
constrained.
Bearings
□ All bearings are lubricated, run freely and display no excess
movement, grinding or raling.
Brakes
□ The front and rear brakes work properly.
□ The brake shoe pads are not overly worn and are correctly
posioned in relaon to the rims.
□The brake control cables are lubricated, correctly adjusted
and display no obvious wear.
□ The brake control levers are lubricated and ghtly secured
to the handlebar.
Chains
□The chains are oiled, clean and run smoothly.
Cranks and Pedals
□ The pedals are securely ghtened to the crank arms.
□ The crank arms are secured to the axle and are not bent.
Frame and Fork
□The frame and fork are not bent or broken.
□ The quick-release clamps are locked in place.
Steering
□The handlebar and post are correctly adjusted and
ghtened, and allow proper steering.
□ The handlebars are set correctly in relaon to the forks and
the direcon of travel.
□ The handlebar binder bolt is ghtened.
Wheels and Tires
□ The rims do not have dirt or grease on them.
□ The wheels are properly aached to the bicycle and axle.
□ The res are properly inated within the recommended
pressures displayed on the res sidewall.
□ The res have the proper amount of tread, no bulges or
excessive wear.
Schwinn Folding Bicycle Manual.indb 13 7/1/14 3:58 PM
14
Folding Bicycle
❷Parts Idencaon
Part name Torque (in. lb.)
1Handlebar grip -
2Rear brake lever 55 - 70
3Front brake lever 55 - 70
4Brake control cables -
5Handle post -
6Handle post latch -
7Front reector -
8Front brake cable pinch bolt 50 - 70
9Brake pads 50 - 60
10 Pivot bolt 17 - 20
11 Head tube -
12 Tire valve -
13 Front wheel axle 180-240
14 Front wheel reector -
15 Tire -
16 Spoke -
17 Wheel rim -
18 Front fender -
Part name Torque (in. lb.)
19 Front fork -
20 Frame latch -
21 Crank arm 390
22 Pedal 300 - 360
23 Seat tube -
24 Seat clamp with quick-release lever -
25 Seat post -
26 Seat -
26a Seat post aaching hardware 130 -170
27 Rear brake cable pinch bolt 50 - 70
28 Rear brake pad -
29 Brake pad adjustment screw 50 - 60
30 Spring tension adjusng screw -
31 Rear reector -
32 Rear wheel reector -
33 Derailleur -
Get to know the parts of your bicycle. This will help with assembly, maintenance, and troubleshoong. Models vary in color and style.
Schwinn Folding Bicycle Manual.indb 14 7/1/14 3:58 PM
15
2
1
3
15
19
26
31
24
22
21
23
17
20
26
32
16
18
6
25
12
13
21
33
4
5
10
9
8
7
11
14
26a
29
28 27
30
Parts Idencaon 2
Schwinn Folding Bicycle Manual.indb 15 7/1/14 3:58 PM
3 Assembly
16
❸Assembly
Your new bicycle was assembled and tuned in the factory and
then parally disassembled for shipping. You may have
purchased the bicycle already fully assembled and ready to ride
or in the shipping carton in the parally disassembled form. The
following instrucons will enable you to prepare your bicycle for
years of enjoyable cycling.
For more details on inspecon, lubricaon, maintenance and
adjustment of any area please refer to the relevant secons in
this manual. If you have quesons about your ability to properly
assemble this unit, please consult a qualied specialist before
riding.
WARNING!
• Improper assembly of this product may result in serious
injury or death. Always follow the instrucons in this
manual and check crical components (eg.: wheels, seat,
pedals, brakes, derailleurs, res) before each use.
• We recommend that you consult a bicycle specialist if you
have doubts or concerns as to your experience or ability to
properly assembly, repair, or maintain your bicycle. If your
bicycle was obtained assembled, we recommend that you
read these instrucons and perform checks specied in
this manual before riding.
If you need replacement parts or have quesons pertaining to
the assembly of your bicycle, call the service line direct at:
1-800-626-2811. Monday - Friday 8:00 am to 5:00 pm Central
Standard Time (CST).
TOOLS REQUIRED
• Adjustable wrench or a 15 mm open end wrench
Schwinn Folding Bicycle Manual.indb 16 7/1/14 3:58 PM
Assembly 3
17
17
GETTING STARTED
❶ Open the carton from the top and remove the bicycle.
Figure 3.1
❷ Remove the straps and protecve wrapping from the bicycle.
❸ Inspect the bicycle and all accessories and parts for possible
shortages. It is recommended that the threads and all moving
parts in the parts package be lubricated prior to installaon.
Important! Do not discard packing materials unl assembly
is complete to ensure that no required parts are
accidentally discarded.
Note: We recommend using a lithium based grease on the
parts before assembly.
UNFOLDING THE BICYCLE
❶ Begin by standing on the chain side of the bicycle. The chain
and crank will be in front of you. Figure 3.2
❷ Open the front and rear halves of the frame apart and the
halves come together.
Figure 3.2
Figure 3.1
Pedals
Folded
bicycle
Carry case
2
Schwinn Folding Bicycle Manual.indb 17 7/1/14 3:59 PM
3 Assembly
18
Lock the Frame Latch
❶ Push on quick-release
lever and move the
locking pin up. Figure 3.3
❷ Move the two frame
halves together. Release
pressure on the quick-
release lever. Check that
the locking pin is fully
engaged.
❸ Move the lever into the
slot on the frame.
❹ Move the quick-release
lever into the locked
posion. The bicycle
should arrive with the
quick-release lever
properly adjusted but if it
is not see Secon 4:
Adjusng the Frame
Latch.
Important! It should require
some pressure to engage the
lock and your hand should
have indent marks from the
lever. Adjust the quick-release
lever unl it is rmly engaged. Figure 3.3
2
1
4
3
Locking pin
Quick-release lever
Schwinn Folding Bicycle Manual.indb 18 7/1/14 3:59 PM
Assembly 3
19
19
Lock the Handlebar
Post Latch
❶ Move the quick-release
lever as shown. The
locking pin should be
completely retracted.
Figure 3.4
❷ Move the handlebar post
onto the post latch.
❸ Move the lever up into the
slot on the base of the
handlebar post.
❹ Move the quick-release
lever into the locked
posion. The bicycle
should arrive with the
quick-release lever
properly adjusted but if
it is not see Secon 4:
Adjusng the Handle
Post Latch.
Important! It should require
some pressure to engage the
lock and your hand should
have indent marks from the
lever. Adjust the quick-release
lever unl it is rmly engaged.
34
Figure 3.4
2
1
Locking pin
Schwinn Folding Bicycle Manual.indb 19 7/1/14 3:59 PM
Table of contents
