SCIFIT SXT7000 User manual

Users’ Operations Manual
SXT7000 & SXT7000e2
Elliptical Trainer
Before using this product, read this manual and
follow all safety rules and operating instructions.
SXT7000 SXT7000e2

SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT
This page purposely left blank

TABLE OF CONTENTS
SAFETY INFORMATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
SETUP & INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
PRODUCT OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
KEYPAD FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
BIOMECHANICAL POSITIONING . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . 8
ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
HEART RATE TRANSMITTER STRAP & CONTACT GRIPS .. . . . . . . . . . . . . . 10
PROGRAM INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11- 19
MAINTENANCE & SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 - 25
SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT
Order Online 24/7 at www.SCIFIT.com

SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT
SAFETY INFORMATION
1
Read all instructions before using your SCIFIT
exercise machine. Save these instructions for future
reference.
Close supervision is necessary when exercise machine
is being used by, or near children, or individuals with
disabilities. Keep children away from extended hand
and foot supports.
Use the exercise machine only for its intended use as
described in this manual. Do not use attachments not
recommended by the manufacturer.
Never drop or insert any object into any opening.
Do not use outdoors or in a harsh environment where
water is present (i.e. pool or spa areas).
Failure to obey a safety warning can result in injury
to yourself and others. Always follow the safety
precautions to reduce the risk of personal injury.
The purpose of safety symbols is to attract your
attention to possible dangers. The safety symbols,
and their explanations, deserve your careful attention
and understanding. The safety warnings do not, by
themselves, eliminate any danger. The instructions
or warnings they give are not substitutes for proper
accident prevention measures.
Look for these symbols to point out important safety
precautions. It means attention ! Your safety is
involved.
WARNING
Failure to obey a safety caution can result in injury
to yourself and others. Always follow the safety
precautions to reduce the risk of personal injury.
CAUTION

SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT
INTRODUCTION
2
Thank you for your purchase of the SCIFIT SXT7000
or SXT7000e2 Elliptical Rotary Walker. We have
incorporated the finest technology and ergonomic
design into this machine to assist you in achieving
your fitness goals. However, for your safety, please
adhere to the following recommendations before you
begin to exercise.
The SCIFIT SXT7000 & SXT7000e2 are designed for
Class “S” (Studio), Class “I” (Special Needs) and Class
“II a” (Medical Device Directive) applications. The
intended uses are for Cardio & Pulmonary Rehabilitation
as well as Sports Medicine, Physical Therapy, Physical
Conditioning and Strength Training. SCIFIT equipment
is suitable for placement in fitness, medical rehab,
sports performance and recreational facilities. The
SXT7000 & SXT7000e2 have 200 levels of computer
controlled resistance, which ensures that users of all
fitness levels will be able to get a challenging but not
overwhelming workout.
Consult Your Physician
Consult your physician or medical specialist before
participating in any exercise program, especially if
you are pregnant, or if you are suffering from: heart
disease, respiratory disease, diabetes, hypertension,
high blood pressure, elevated cholesterol, arthritis, or
any other diseases or physical complaints.
Adult Usage
SCIFIT equipment is designed and intended for adult
usage and children of appropriate ages while being
supervised. Young children should be kept a safe
distance away from equipment.
Cool Down
To prevent muscle injuries and soreness, you should
always cool down (at least 5 minutes) by doing a
series of stretches after each workout.
Train Intelligently
To ensure a future of good health, you should always
eat well balanced meals, drink plenty of fluid/water
during a workout, and stay fit by exercising intelligently.
Always follow training guidelines that are specific to
your own physical condition.
Stop exercising immediately if you feel nausea,
dizziness, sharp pain, or any other physical
discomfort. Failure to stop excercising can result in
injury or death to yourself.
WARNING
Always stretch after a workout session to reduce
the risk of personal injury. Failure to stretch
properly may result in injury to youerself.
CAUTION
Guidelines for Healthy Adults
The American College of Sports Medicine (ACSM) and
the American Heart Association (AHA) are continuously
updating guidelines and recommendations for physical
activity.
The current basic recommendations from ACSM and
AHA is:
Do moderately intense cardio 30 minutes a day, five
days a week.
OR
Do vigorously intense cardio 20 minutes a day, three
days a week.
AND
Do eight to ten strength-training exercises, eight to
twelve repetitions of each exercise twice a week.
Moderate-intensity physical activity means working
hard enough to raise your heart rate and break a
sweat, yet still being able to carry on a conversation.
It should be noted that to lose weight or maintain
weight loss, 60 to 90 minutes of physical activity may
be necessary. The 30 minute recommendation is
for the average healthy adult to maintain health and
reduce the risk for chronic disease.
To review the latest guidelines and recommendations,
visit the American College of Sports Medicine website:
www.acsm.org
Injuries to health may result from incorrect or
excessive training. Failure to stop excercising can
result in injury or death to yourself.
WARNING

SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT
SPECIFICATIONS
3
Weight . . . . . . . . . SXT7000 - 275 lbs. / 125 Kg. . . . . . . . . . . .SXT7000e2- 336 lbs. / 152 Kg.
Max User Weight . . 350 lbs. / 159 Kg.
Power . . . . . . . . . . Self generating w/auto recharge battery back-up.
Optional Low Voltage AC adapter available.
Resistance System . Electromagnetic Self Generating Bi-directional Resistance
Programs . . . . . . . . Manual, Fit Quik, Constant Workout, ISO-Strength, 7-Preprogrammed Hill profiles,
Heart Rate, Powr Fit Test, Heart Fit Test, Heart Fit Training,
Stress Test and Random
Accuracy Class. . . . . Class A
Warranty . . . . . . . . Within U.S. & Canada 3 years parts, 1 year labor
Outside U.S. 3 years parts, no labor
32”
813 mm
SXT7000 - 60”
1524 mm
65”
1651 mm
SXT7000e2- 73”
1854 mm

SETUP & INSTALLATION
SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT
4
Placement Of Cardiovascular Machine
Position the unit in a location that has a stable and
level sub-floor. Equipment should be positioned
in a location that is not in direct sunlight, in areas
of extreme temperature and humidity, or where
the equipment may be splashed with water or
fluids.This machine is intended for indoor use only.
Equipment should be positioned with a safety
perimeter of 40” or 1 Meter around the unit.
40” /1 Meter
Safety Space
40” / 1 Meter
Safety Space
40” / 1 Meter
Safety Space
40” / 1 Meter
Safety Space
Level Cardiovascular Machine
If the sub-floor is unlevel, the unit is equipped with
leveling end caps. The end caps are designed with
the recess of end cap off centered. This allows you
to rotate the endcap(s) to a position that will level
the equipment. After adjustment, check and make
sure end caps are fully seated against base frame
tubes.
Offset Endcap
Endcap Endcap
Proper Supervision
Close supervision is required when the exercise
machine is being used by or near individuals with
disabilities. Keep unsupervised children outside the
safety perimeter.
Cleaning
Never clean the machine with orga ,stnevloscin
alcohol or bleach based cleaners. To promote a
healthy environment, wipe any sweat off of unit with
a commercially manufactured wipe designed for the
finess industry, or a damp cloth.
Failure to place the equipment on a stable and level
sub-floor with a safety perimeter can result in injury
to yourself and others.
WARNING
Endcap Endcap

ASSEMBLY
SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT
5
Required Tools: 7/32” Allen Wrench
Position Access Step
Place Easy Access Step over the front cross tube and
telerails. Ensure access step is resting flush on floor.
Required Parts:
Item Qty. Description Part #
1 1 Left Handrail A3224
2 1 Right Handrail A3222
3 1 Easy Access Step A3223
Assembly
Some equipment shipped overseas assembly is
required (SXT7000e2 only).Follow the steps below for
assembly.
Mount Left & Right Handrails
(A) Starting on the left side, remove the two Socket
Button HD 3/8-16 x 3/4 screws from the Pivot housing.
.
(E) Repeat process for the right handrail (Item 2).
Item 3
(A) Remove
3/8-16 Screws
(B) Align the upper part of the left handrail mounting slot
with the holes of the Pivot housing, then with a 7/32”
Allen wrench loosely attach one of the 3/8-16 x 3/4
screws previously removed.
(C) Insert the bottom end of the handrail into the
recess hole of the access step.
(D) Insert the second 3/8-16 x 3/4 screw into the
Pivot housing, then tighten both screws.
(B)
(C)
(D)
Item 1

PRODUCT OVERVIEW
SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT
6
Leveling Base
Endcaps
Water Bottle
Holder
Molded Assist Step
(SXT7000e2Only)
Ergonomically Positioned Handrails
(SXT7000e2Only)
BioFlex™ Articulating
Footbed Pivots
Heart Rate
Contact Grips
LCD Display
Control Console

KEYPAD FUNCTIONS
SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT
7
-
QUICK START -This key provides a one-touch
PAUSE/CLEAR - The [Pause/Clear]
key will pause the workout. Pressing
[Pause/Clear] a second time when in
the pause mode will stop the workout
and return to the main screen.
To restart in the paused mode press
the[Quick Start] key.
ENTER -
Work Level Status LCD Screen -
The Work Level Status L C D Screen gives
a progressive real-time indication of the
current work level of any and all programs
Select Workout or Insert Fitkey
Copyright c 1998-2010. SCFIT Systems, Inc.
Manual Hills Random Heart Rate Iso-Strength More
Press to start or choose a program
Profile Selection Area -
Allows the user option to
choose from 12 different
workout profiles
The Enter Key is pressed to
enter selected values for the
workout parameters.
“Quick Start” into the Manual mode, or after logging
into a program.The Quick Start key will activate the
selected program.
Up Arow and Down Arrow - These keys
increase or decrease values of the workout
parameters.

BIOMECHANICAL POSITIONING
SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT
Body Positioning
Comfort is a key issue to obtain the most beneficial exercise. The feet should be centered above the pivot points
of the footbed. This will reduce foot stress, ankle strain and promote better circulation.
SCIFIT’s patented Bio-Flex is designed to accommodate the user’s natural gait and allow the user to target
specific muscle groups. For example, keeping your heels down longer throughout the stride pattern encourages
greater muscle recruitment of the glutes and hamstrings. The Bio-Flex footbed also recruits the stabilizing
muscles in the legs and torso. Use extreme caution when attempting to use the SCIFIT Elliptical without holding
onto either the moving or stationary handles.
SCIFIT SXT7000 and SXT7000e2Ellipticals can be used in forward and reverse. To change directions, bring the
movement to a slow stop and begin the opposite movement. Changing direction of movement during exercise
recruits the largest group of muscles and helps bring balance to the muscle groups. Consult your fitness or
medical professional for specific targeting of muscle groups or for the rehabilitation of specific conditions.
An upright body posture will result in a broader muscle recruitment and greater torso rotation.
Hand Position
Placing the hands on the upper most part of the handle grip provides greater upper body arm movement
and torso rotation, while placing the hands on the lower part of the handle grip will minimize arm movement
and torso rotation.
Always follow medical professionals guidelines to
reduce the risk of personal injury. Failure to follow
their directions may result in injury to yourself.
CAUTION
Important Note: When using this product for medical
or rehabilitation purpose, the program selection and
work load should be set by the attending therapist or
medical professional based on the specific needs of
the user.
8
Place hand high
for greater upper
body movement Place hand low
for minimal upper
body movement

ACCESSORIES
SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT
9
12V Power Pack (Dom. #P1562, Int’l #P3733)
To provide continuous power to the display when
equipment is not in operation, plug in the 12V power
pack into the jack located on the lower front of the
machine.
RH Handlebar
LH Handlebar
Step-up
Platform
Add-on Handlebar Kit For SXT7000 (#A3453)
An add-on easy access handlebar kit is also available
for the SXT7000 models
(handlebars standard on SXT7000e versions)
for easier mounting and dismounting of the machine.
Order Online 24/7 at www.SCIFIT.com

HEART RATE TRANSMITTER STRAP & CONTACT GRIPS
SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT
10
Uses of the Heart Rate Transmitter Strap
The optional wireless heart rate transmitter accessory
is a useful device if you desire continuous feedback on
your current heart rate during a workout. In addition,
the SXT7000 & SXT7000e2include a Heart Rate
Control program which requires use of the strap.
The Heart Rate Control program enables the user to set-
up a target heart rate. Through real-time monitoring
of the user’s heart rate, the computer maintains the
user’s heart rate at or below this established target
rate by decreasing the workload if the user’s heart rate
exceeds the target.
Activating & Deactivating Transmitter
Heart Rate Transmitter Straps come in a variety of styles
and manufacturers. To properly activate, secure strap
to the chest and to deactivate follow the instructions
that come with the Transmitter Strap.
Calculating Target Heart Rate Zone
Your approximate Maximum Heart Rate (MHR) is
equal to 220 minus your age. The upper limit of your
target zone is equal to 0.85 times your MHR. The lower
limit of your target zone is equal to 0.60 times your
MHR.
For Example:
Your age is 40:
220 - 40 = 180
180 x .85 = 153 (max MHR)
180 x .65 = 108 (min MHR)
These values are based upon averages, always consult
your physician to establish the proper Heart Rate Zone
for your individual health condition.
Heart Rate monitoring systems may be inaccurate.
If you feel faint, stop exercising immediately. Over
exercising may result in serious injury or death.
WARNING
Always follow manufacturers instructions for proper
care and use. Failure to follow manufacturers
instructions may result in injury to yourself.
CAUTION
Heart Rate
Contact Grips
Use of the Heart Rate Contact Grips
For those models with contact heart rate grips, simply
grip the contact pads lightly. After a short delay the
pulse reading will appear on the display. If a heart rate
transmitter strap is worn, it will override the contact
pickup.
The contact grips are not designed for use with SCIFIT’s
Heart Rate Control program. This program requires a
steady, continuous telemetry signal which can not be
provided using contract heart rate grips.
While the contact grips provide a good barometer
for monitoring the users heart rate, they are not
recommended for medical where accuracy of
monitoring is vital.

PROGRAM INSTRUCTIONS
SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT
11
Programs
SCIFIT products have 200 levels of computer controlled
resistance, which ensures that users of all fitness levels
will be able to get a challenging but not overwhelming
workout. Because the resistance is adjustable in .1
increments, it is easy for the user to track progress.
SCIFIT products feature one of the highest resistance
capabilities available on any cardio equipment.
SCIFIT products are self generated and have an
extremely low starting resistance. One pedal movement
or crank revolution activates the console and the
screen will remain lit at the most minimal levels of
movement.
SCIFIT products have a battery back up which will
keep the screen lit for a short period after exercise or
if the user stops. This varies between 0 seconds and
5 minutes and can change with the amount of use each
product gets.
If you prefer the console to remain lit before and
after use, an optional wall pack can be plugged in to
accomplish this. This is common in medical settings
and with Fit-Key Programs.
MANUAL
Manual Workout
Press Then
Level 1.0
Weight 150
Time 15:00
Time 15:00
Weight 150
Level 1.0
Adjust workout time with the keys,
then press
Allows the user to set the intensity at any level. This
level will not change unless the user manually increases
or decreases the intensity using the [UP] or [DOWN]
arrow keys.
Adjust level intensity with the
keys, then press
Time 15:00
Level 1.0
Weight 150
Enter user weight with the keys,
then press and begin exercise.
Fit-Quik
Press Then
Fit Quik
Allows the user to select a two stage program of
cardiovascular work with ISO-strength (Isokinetic)
work loads and duration determined within the
factory set up.

PROGRAM INSTRUCTIONS
SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT
12
Constant Work
Pedal resistance is automatically adjusted to
compensate for any change in pedal speed (RPM),
thus workload (Watts) will remain constant at any
given setting.
Watts 20
Weight 150
Time 15:00
Adjust workout time with the
keys, then press
Watts 20
Enter the user weight with the
keys, then press and begin exercise
Weight 150
Time 15:00
Adjust target watts with the
keys, then press
Watts 20
Weight 150
Time 15:00
CONSTANT WORK
Press Then
Fit-Quik Cont’d
The categories displayed will depend on the
workout that is selected in the factory setting. The
following will be seen for the workout choosen.
Manual or Hills
Weight 150
Level 1
Adjust the Level and Weight with the
keys, then press
Constant Workout
Weight 150
Adjust the Weight with the
keys, then press

PROGRAM INSTRUCTIONS
SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT
13
ISO-Strength Program
ISO-Strength is a isokenitic program, meaning that
the unit will resist your movements in order to force
you to stay at a set speed. This type of strength
workout will not cause excessive soreness because
it is accommodating. The computer will adjust
resistance to keep the user at the target RPM speed.
ISO-STRENGTH
Press Then
Weight 150
Time 15:00
Adjust workout time with the
keys, then press
RPM 35
Weight 150
Time 15:00
Adjust target RPM with the keys,
then press
RPM 35
Weight 150
Time 15:00
Enter user weight with the keys,
then press and begin exercise
RPM 35
HILLS
Press Then
Hills Program
Allows the user to select from seven different Hill
profiles at various pre-programmed intensities.
The following profiles are available:
Hill Course, Sprints, Twin Peaks, Peak,
Progressive, Multi-Peaks and Ramp.
Time 15:00
Level 1.0
Select 1 of 7 profiles with the
keys, then press
Prole Course

PROGRAM INSTRUCTIONS
SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT
14
MORE
Pressing this key will enter the user into the 2nd
of three workout program selection screens. This
screen will show an additional five more
pre-programmed workout profiles.
MORE
Press
A new screen will appear with additional programs:
Heart Rate, Stess Test, Random, Power Fit and
Heart Fit.
Level 1.0
Adjust workout time with the
keys, then press
Time 15:00
Level 1.0
Adjust level intensity with the
keys, then press
Time 15:00
Weight 150
Time 15:00
Enter user weight with the keys,
then press and begin exercise
Level 1.0
Hills Cont’d
Heart Rate Program
The Heart Rate Transmitter Strap is required for this
program. Refer to page 10 for a complete
instruction on using the strap and to understand
how to calculate your Target Heart Rate.
•Put on Heart Rate Transmitter Strap
Heart Rate 120
Weight Rate 150
Time 15:00
Adjust the workout time with the
keys, then press
HEART RATE
Press Then
Prole Course
Prole Course

PROGRAM INSTRUCTIONS
SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT
15
Weight 150
Time 15:00
Adjust the target Heart Rate with the
keys, then press
Heart Rate 120
Weight 150
Time 15:00
Enter the user weight with the
keys, then press and begin exercise
Heart Rate 120
Heart rate Cont’d
Stress Test
A designed step test to be used as training
program or use with other diagnostic devices
(if appropriate). The user sets a target wattage
with timed intervals and preset wattage
increments.
Increment 5
Interval 5:00
First Target 50
Select target wattage with the
keys, then press
Select wattage increments after each interval with
the keys, then press
Increment 5
Interval 5:00
First Target 50
Enter user weight with the
keys, then press and begin exercise
Increment 5
Weight 150
Interval 5:00
Select the length of each interval with the
keys, then press
Increment 5
First Target 50
Interval 5:00

PROGRAM INSTRUCTIONS
SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT
16
RANDOM
Press Then
Random Program
The Intelli-Fit console will randomly display
different workout profiles each with its own level of
difficulty. The operator only has to choose the type
of the profile, then select the time length of the
workout and the level difficulty.
Note: The highest column of the profile represents
the workout level you selected. Columns below it
are percentages of the level selected.
Time 15:00
Level 1.0
Select a random profiles with the
keys, then press
Prole Random
Level 1.0
Adjust workout time with the
keys, then press
Time 15:00
Level 1.0
Adjust level intensity with the
keys, then press
Time 15:00
Weight 150
Time 15:00
Enter user weight with the keys,
then press and begin exercise
Level 1.0
Prole Random
Prole Random

PROGRAM INSTRUCTIONS
SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT
17
Test Training More
Power Fit
Power Fit Programs
This key displays two options “Test” and “Training”.
These programs are power and strength indicators
for the user.
Power Fit
Press and the screen will display
a choice of “Test” or “Training” as shown below.
Test
This program is based on a pre-programmed
wourkout designed to evaluate your
“Power Drop %”, which gives a fitness indication
of power and strength using wattage as the main
measurement.
Press Then
and begin exercise
TEST
Press Then
Level Beginner
Weight 150
Program 1
Select 1 of 3 programs with the
keys, then press
Training
Specifically designed preset wattage training
programs based off user Power Fit test evaluation.
Three programs and four levels
(Beginner, Intermediate, Advanced and
Sport Performance) are available.
TRAINING
Weight 150
Level Beginner
Weight 150
Program 1
Select 1 of 4 levels with the keys,
then press
Level Beginner
Program 1
Enter user weight with the keys,
then press and begin exercise
