MX-M Microplate Mixer
User Manual
Please read the User Manual and the related Video of this
instrument on our website carefully before use, and follow
all operating and safety instructions!
The website www.scilogex.com
MX-M Microplate Mixer
Cat No.12300138

Contents
Contents Inside front cover
Preface 1
Service 1
Warranty 1
1 Safety Instructions 2
2 Proper use 3
3 Inspection 3
3.1 Receiving Inspection 3
3.2 Listing of Items 3
4 Trial run 3
5 Control 4
6 Maintenance and Cleaning 4
7 Associated Standards and Regulations 4
8 Technical Data Inside back
9 Products and Accessories Inside back

1
MX-M Microplate Mixer
Preface
Welcome to the “MX-M Microplate Mixer User Manual”.
Users should read this Manual carefully, follow the
instructions and procedures, and beware of all the cautions
when using this instrument.
Service
When help needed, you can always contact manufacturer for
technical support in the following ways:
SCILOGEX, LLC
500 Four Rod Road
Suite 122
Berlin, CT 06037
USA
Tel：1- [phone]
Fax：1- [phone]
E-mail: [email protected]
Website：Http://www.scilogex.com
Please provide the customer care representative with the
following information:
•Serial Number（on the rear panel）
•Description of problem (i.e., hardware or software)
•Methods and procedures adopted to resolve the problems
•Your contact information
Warranty
You have purchased a Scilogex instrument. This instrument
is warranted to be free from defects in materials and
workmanship under normal use and service, for a period
of 24 months from the date of invoice. The warranty is
extended only to the original purchaser. It shall not apply to
any product or parts which have been damaged on account
of improper installation, improper connections, misuse,
accident or abnormal conditions of operation.
For claims under the warranty please contact your local
dealer. You may also send the instrument direct to our works,
enclosing the invoice copy and by giving reasons for the
claim. You would be solely liable for freight costs.

2
MX-M Microplate Mixer
1 Safety Instructions
Warning!
•Read the operating instructions in
full before use and follow the safety
instructions
•Ensure that only trained staff work with
the appliance.
Protective ground contact！
•Make sure that socket is earthed
(protective ground contact) before use.
•When work ，wear the personal guard to avoid the risk
from:
- Splashing of liquids.
- Release of toxic or combustible gases.
•Set up the instrument in a spacious area on an even,
stable,clean, non-slip, dry and fireproof surface, do not
operate the instrument in explosive atmospheres, with
hazardous substances or under water.
•Gradually increase the speed, reduce the speed if :
- The medium splashes out of the vessel because of too
high speed.
- The instrument is not running smoothly.
•Beware of hazards due to:
- Overfilling of media
- Unsafe container
•Process pathogenic materials only in closed vessels.
•Always disconnect the plug before fitting accessories.Do
not use damaged components.
•The operating voltage required on the type plate and
voltage supply network must match.
•Ensure that the mains power supply cable does not touch
the hotplate. Do not cover the instrument.
•The instrument may only be opened by experts .
•Observe the minimum distances between the devices,
between the instrument and the wall and above the assembly
(min. 100 mm).
>100mm
>100mm
Figure 1

3
MX-M Microplate Mixer
2 Proper use
The instrument is designed for schools, laboratories or
factories. This device is not suitable for use in residential
areas or other areas that may cause danger to the user or
instrument as mentioned in Chapter 1.
3 Inspection
3.1 Receiving Inspection
Unpack the equipment carefully and check for any damages
which may have arisen during transport. If it happens, please
contact manufacturer for technical support.
Note:
If there is any apparent damage to the system,
please do not plug it into the power line.
3.2 Listing of Items
The packing includes the following items:
Items Qty
Main unit 1
Power adaptor 1
User manual 1
Table 1
4 Trial run
•Make sure the required operating voltage and power
supply voltage match.
•Ensure the power be off and the speed control knob at the
lowest position. Plug in the power adapter.
•Place a microtiter or other vessel in holder.
•Power ON the device and the Power LED is lit.
•Set the rated speed regulation and the device begins to
work.
•Set the rated speed regulation to ‘0’and the device stop
to work.
•Power OFF the device.
If these operations above are normal, the device is ready
to operate. If these operations are not normal, the device
may be damaged during transportation, please contact
manufacturer for technical support.

4
MX-M Microplate Mixer
5 Control
Power
LED
Adapter
Speed control Knod
Figure 3
6 Maintenance and cleaning
Proper maintenance can keep instruments working in a
good state and lengthen its lifetime. Be careful not spray the
cleanser into the instrument when cleaning.
Unplug the power line when cleaning.Only use cleanser that
we advised as below:
Dyes isopropyl alcohol
Construction
materials Water containing tenside / isopropyl alcohol
Cosmetics Water containing tenside / isopropyl alcohol
Foodstuffs Water containing tenside
Fuels Water containing tenside
•Before using other method for cleaning or decontamination,
the user must ascertain with the manufacturer that this method
does not harm or destroy the instrument.
•Wear the proper protective gloves during cleaning of the
instrument.
•Forbid to place the instrument in the cleanser to clean
•The instrument must be cleaned and put it into the initial
packaging carton before sending to service for repair,
avoiding the contamination of hazardous.
•Switch off the device and put it in the dry, clean, stable
place at room temperature in long-term disuse.
7 Associated standards and regulations
Construction in accordance with the following safety standards:
EN 61010-1
Construction in accordance with the following EMC
standards:
EN 61326-1
Associated EU guidelines:
EMC-guidelines: 89/336/EWG
Machine guidelines: 73/023/EWG

MX-M Microplate Mixer
8 Technical data
Items Parameters
Voltage [VAC] 100~240
Frequency [Hz] 50/60
Power [W] 20
Shaking movement Orbital
Orbital diameter [mm] 4.5
Max. shaking weight (with
attachments) [kg] 0.5
Motor type External rotor brushless motor
Motor rating input [W] 18
Motor rating output [W] 10
Permissible ON time [%] 100
Speed range [rpm] 0-1500
Speed display Scale
Microplate working Yes
Microplate amount 1
Dimensions (mm) 260×150×80
Weight [kg] 3
Permitted ambient
temperature[°C] 5－40
Permitted relative humidity 80%
Protection class acc. to DIN
60529 IP21
Table 2
9 Products and Accessories
Cat.No. Description
822000019999
MX-M Microplate Mixer，with
MicroPlate Attachment, Cn plug,
110v/220v/50Hz/60Hz
822000029999
MX-M Microplate Mixer，with
MicroPlate Attachment, Euro plug,
110v/220v/50Hz/60Hz
822000039999
MX-M Microplate Mixer，with
MicroPlate Attachment, UK plug,
110v/220v/50Hz/60Hz
822000049999
MX-M Microplate Mixer，with
MicroPlate Attachment, USA plug,
110v/220v/50Hz/60Hz
Accessories
18900042 ps1.2 Adapter used for
Microplate, continuous operation mode
Table 3
Other accessories of this instrument will be on the market ,serial
number and pattern number and accessories names on the
type plate must be supplied when ordering other accessories.
