Scion-Tech SC05.8070U User manual

Scion Tech SC05.8070U User Manual
Tel: [phone] www.scion-tech.co.uk [email protected]
HDMI HDBaseT Extender, 70m
with USB
SC05.8070U
Scion Tech Ltd
Unit 10
Thatcham Business Village
Colthrop Lane
Thatcham
Berkshire. RG19 4LW
United Kingdom

Scion Tech SC05.8070U User Manual
Tel: [phone] www.scion-tech.co.uk [email protected]
Thank you for purchasing this product
For optimum performance and safety, please read these instructions carefully before connecting,
operating or adjusting this product. Please keep this manual for future reference.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged by electrical spikes,
surges, electric shock, lighting strikes, etc. Use of surge protection systems is highly recommended in
order to protect and extend the life of your equipment.
Table of Contents
1. Introduction............................................................................................................ 1
2. Features ................................................................................................................ 1
3. Package Contents ................................................................................................. 1
4. Specications ........................................................................................................ 2
5. Operation, Control and Functions ......................................................................... 3
5.1 Transmitter Panel ............................................................................................ 3
5.2 Receiver Panel ................................................................................................ 4
5.3 IR Pin Connections.......................................................................................... 5
6. Application Drawing............................................................................................... 6
7. Servicing, Warranty and Maintenance................................................................... 7
7.1 Servicing.......................................................................................................... 7
7.2 Warranty .......................................................................................................... 7
7.3 Returning a product......................................................................................... 7
7.4 Limited Warranty and Exclusions .................................................................... 8

Scion Tech SC05.8070U User Manual
Tel: [phone] www.scion-tech.co.uk [email protected]
• HDMI 2.0b, HDCP 2.2 Compliant
• Up to 4K/60Hz with 24bit RGB/YCBR 4:4:4
• 18Gbps Zero Latency (Uncompressed)
• HDR, HDR10, HDR10+ and Dolby Vision pass
through
• LPCM 7.1CH, Dolby True HD and DTS-HD
Master Audio
• Up to 70m using CAT6/6a cable
• Supports USB 2.0 for KVM
• Two way IR and Full Duplex RS232
• Receiver Supports Audio Extraction
• Power over Cable (PoC)
Main Features
Package Contents
1 x Transmitter
1 x Receiver
1 x IR Blaster Cable (1.5m)
1 x IR Receiver Cable (1.5m)
1 x 24V / 1A Power Supply
2 x 3-Pin Phoenix Terminal
4 x Mounting Ears
1 x User Manual
Page 1
Description
This 18Gbps Extender extends high denition video, audio, bi-directional IR, RS-232 and USB 2.0 for
KVM. The supported transmission distance is up to 40 meters for 4K2K@60Hz 4:4:4 resolution and
70 meters for 1080P60Hz resolution between transmitter and receiver over a single CAT 5e/6 cable.
The transmitter supports local audio extraction, bi-directional IR pass-through for controlling both
source and display devices. It also supports PoC (power over cable).
The extender includes two units, transmitter and receiver. The transmitter captures the incoming
signals and transmits them over one cost effective Cat5e/6 cable. The receiver unit receives the
signals and presents them as outputs for connecting to your devices.
This extender offers the most convenient solution for HDMI extension via a single Cat5e/6 with long
distance capability, and is the perfect solution for any application.

Scion Tech SC05.8070U User Manual
Tel: [phone] www.scion-tech.co.uk [email protected]
4. Specications
Page 2
Connections
Transmitter
Input:
1 x HDMI Type A (19-Pin Female)
1 x IR IN (3.5mm Jack Socket)
1 x Service (Mini-USB)
1 x USB (USB-B, 4-Pin Female)
Output:
1 x HDBaseT (RJ45 Data Socket)
1 x IR Out (3.5mm Jack Socket)
1 x L/R Stereo Audio (3.5mm Jack Socket)
1 x SPDIF (Optical)
1 x RS232 (Phoenix Terminal)
Receiver
Input:
HDBaseT (RJ45 Data Socket)
1 x IR IN (3.5mm Jack Socket)
1 x Service (Mini-USB)
Output:
1 x HDMI Type A (19-Pin Female)
1 x RS232 (Phoenix Terminal)
1 x IR Out (3.5mm Jack Socket)
2 x USB (USB-A, 4-Pin Female)
Technical
HDMI and HDCP Compliance HDMI 2.0b, HDCP 2.2 / HDCP 1x and DVI 1.0
HDMI in/out Video Resolutions
4K2K 50/60Hz 4:4:4
4K2K 50/60Hz 4:2:0
4K2K 30Hz 4:4:4
1080p, 1080i, 720p, 480p, 480i
All PC resolutions including 1920 x 1200
Colour Space RGB, YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0
Colour Depth 8-bit, 10-bit, 12-bit, [1080p, 4K/30Hz, 4K/60Hz (YCbCr 4:2:0) 8-bit
[4K/60Hz (YCbCr 4:4:4)]
HDMI Audio Formats
PCM 2.0 / 5.1 / 7.1CH, Dolby Digital/Plus/EX, Dolby True HD,
DTS, DTS-EX, DTS-96/24, DTS High Res, DTS HD Master Audio,
DSD
HDR Formats HDR10, HDR10+, HLG
USB USB 2.0, Transmission Rate up to 480mb/s
L/R Audio Formats LPCM 2.0CH
Power
Power Supply Input: 100~240V 50/60Hz
Output: DC 24V / 1A
Power Consumption 13W (max)
Operating Temperature Operating Temp. 0℃~ 40℃, Storage Temp. -20℃~ 60℃
Relative Humidity 20~90% RH (non-condensing)
Mechanical
Housing Metal Enclosure, Colour Black
Dimensions TX & RX = (W) 165 x (D) 88 x (H) 20mm
Weight TX = 170g and RX = 165g

Scion Tech SC05.8070U User Manual
Tel: [phone] www.scion-tech.co.uk [email protected]
5. Operation Controls and Functions
5.1 Transmitter Panel
Number Name Description / Function
1 Power LED The LED will illuminate RED when powered ON
2 USB Host USB Type B port. Connection for PC.
3 Service Port Used only for rmware updates
4 Power
DC 24V /1A Power Input.
Note: The products support PoC and therefore only one end (either the
transmitter or receiver) requires power.
5 HDBaseT Out
RJ45 Data output for connecting directly to the receiver.
Note: This product does not support routers, switches or other network devices
and should be connected end to end only.
6 Connection LED
Illuminates: Good connection between transmitter & receiver
Flashes: Poor connection between transmitter & receiver
Dark: No connection between the transmitter & receiver
7 Signal LED
Illuminates: HDMI signal with HDCP
Flash: HDMI signal without HDCP
Dark: No HDMI Signal
8 HDMI In Connect HDMI source
9 IR In IR input for receiver IR signals from a remote control
10 IR Out IR output for controlling source device.
11 L/R Out Stereo analogue audio output
12 SPDIF Out SPDIF digital audio output
13 RS232 Full Duplex RS232 data between transmitter & receiver
Page 3

Scion Tech SC05.8070U User Manual
Tel: [phone] www.scion-tech.co.uk [email protected]
5.2 Receiver Panel
Page 4
Number Name Description / Function
1 Power LED The LED will illuminate RED when powered ON
2 USB 2.0 Two USB 2.0 ports for devices (keyboard & mouse) etc.
3 Service Port Used only for rmware updates
4 Power
DC 24V /1A Power Input.
Note: The products support PoC and therefore only one end (either the
transmitter or receiver) requires power.
5 HDBaseT In
RJ45 Data output for connecting directly to the transmitter.
Note: This product does not support routers, switches or other network devices
and should be connected end to end only.
6 Connection LED
Illuminates: Good connection between transmitter & receiver
Flashes: Poor connection between transmitter & receiver
Dark: No connection between the transmitter & receiver
7 Signal LED
Illuminates: HDMI signal with HDCP
Flash: HDMI signal without HDCP
Dark: No HDMI Signal
8 HDMI Out Connect HDMI display
9 IR In IR input for receiver IR signals from a remote control
10 IR Out IR output for controlling source device.
11 RS232 Full Duplex RS232 data between transmitter & receiver

Scion Tech SC05.8070U User Manual
Tel: [phone] www.scion-tech.co.uk [email protected]
5.3 IR Pin Connections
IR receiver and blaster pin connections.
Note: When the angle between the IR receiver and the remote control is ± 45 °, the transmission
distance is 0-5 meters; when the angle between the IR receiver and the remote control is ± 90 °, the
transmission distance is 0-8 meters. the angle between the IR receiver and the remote
Page 5

Scion Tech SC05.8070U User Manual
Tel: [phone] www.scion-tech.co.uk [email protected]
6. Application Drawing
Page 6

Scion Tech SC05.8070U User Manual
Tel: [phone] www.scion-tech.co.uk [email protected]
7. Maintenance, Service & Warranty
Clean this unit with a soft, dry cloth. Never use alcohol, pint thinner of benzene to clean these devices.
7.1 Servicing
Damage requiring service: This product should be serviced by a qualied service engineer if:
● The DC power cord or AC adaptor has been damaged.
● Objects or liquids have entered the housings.
● The product has been exposed to rain.
● The product has stopped working or shows signs of signicant change in operating performance or
function. ● The unit has been dropped or severely damaged externally.
Servicing personnel: Do not attempt to service the product beyond that described in these instructions.
Refer all other servicing to authorised serving personnel.
Replacement parts: When parts need replacing ensure the service engineer uses parts specied by
the manufacture or parts that have the same characteristics as the original parts. Unauthorised
substitutes may result in re, electric shock or other hazards.
Safety check: After a repair or service, ask the engineer to perform safety checks to conrm the
product is in proper working condition.
7.2 Warranty
If your product does not work properly because of a defect in materials or workmanship, our Company
(referred to as "the warrantor" ) will , for the length of the period indicated as below, (Parts and labour
2 years) which starts with the date of original purchase ("Limited Warranty period"), at its option either
(a) repair your product with new or refurbished parts, or (b) replace it with a new of a refurbished
product. The decision to repair or replace will be made by the warrantor.
During the "Labour" Limited Warranty period there will be no charge for labour. During the "Parts"
warranty period, there will be no charge for parts. You must mail-in your product during the warranty
period. This Limited Warranty is extended only to the original purchaser and only covers product
purchased as new. A purchase receipt or other proof of original purchase date is required for Limited
Warranty service.
7.3 Returning a Product
When shipping the unit carefully pack and send it prepaid, adequately insured and preferably in the
original carton. Include a letter detailing the complaint and provide a day time phone number and/or
email address where you can be reached.
Page 7

Scion Tech SC05.8070U User Manual
Tel: [phone] www.scion-tech.co.uk [email protected]
7.4 Limited warranty limits and exclusions
This Limited Warranty ONLY COVERS failures due to defects in materials or workmanship, and
DOES NOT COVER normal wear and tear or cosmetic damage. The Limited Warranty ALSO
DOES NOT COVER damages which occurred in shipment, or failures which are caused by
products not supplied by warrantor, or failures which result from accidents, misuse, abuse, neglect,
mishandling, misapplication, alteration, faulty installation, set-up adjustments, maladjustment of
consumer controls, improper maintenance, power line surge, lightning damage, modication, or
service by anyone other than a Factory Service centre or other authorised service engineer, or
damage that is attributable to acts of God.
THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER "LIMITED WARRANTY
COVERAGE".THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY
BREACH OF THIS WARRANTY. (As examples, this excludes damages for lost time, cost of having
someone remove or re-install an installed unit if applicable, travel to and from the service, loss of or
damage to media or images, data or other recorded content. The items listed are not exclusive, but
are for illustration only).
PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY, ARE YOUR
RESPONSIBILITY. This returns policy does not affect your legal rights. Details of your legal rights
are available from Trading Standards or Citizens Advice Consumer Service.
Scion Tech Ltd
Unit 10
Thatcham Business Village
Colthrop Lane
Thatcham
Berkshire. RG19 4LW
United Kingdom
Page 8
