Scion XB Back Up Camera 2015 Configuration guide

xB 2015
xB
BACK UP
CAMERA
OWNER’S
MANUAL
SUPPLEMENT
GET INFORMED.
ROLL.

To see the camera's image of the
view behind the vehicle on the
monitor screen, the vehicle ignition
switch must be in the ON position
and the gear selector must be in the
REVERSE position. For the system
to function properly the back door of
the vehicle must be completely
closed
The rear view monitor system assists
the driver by displaying an image of the
camera’s view behind the vehicle
when
in reverse.
2015xBRearViewMonitorSystem 1

Theareadetected bythecamera is
limited. The camera does not detect
objects which are close to either corner
of the bumper or under the bumper.
The area displayed on the screen may
vary according to vehicle orientation or
road conditions.
The camera uses a special lens. The
distance of the image that appearson
the screen differs from the actual
distance.
Whenthecamera isusedunderfluores-
cent lights, sodium lights or mercury
lights etc., the lights and the illuminated
areasmayappeartoflicker.
In the following cases, it may become
difficult to see the images on the screen,
evenwhenthe systemis functioning:
• Inthe dark (for example, at night)
• When the temperature near thelens is
high or low
• When water droplets are adhering to
the camera, or when humidity is high
(forexample,whenit rains)
• When foreign matter (for example,
snow or mud) is adhering to the
camera
• Whenthecamerahasscratchesordirt
on it
• When the sun or the beam of head-
lights is shining directly into the
camera lens
INFORMATION
22015xBRearViewMonitorSystem 2015xBRearViewMonitorSystem 3

• If a bright light (for example, sunlight
reflected off the vehicle body) is picked
up by the camera, a smear effect*
may occur.
*Smear effect
A phenomenon that occurs when a
bright light (for example, sunlight
reflectedoff the vehiclebody) ispicked
up by the camera; when transmitted by
thecamera,thelightsourceappearsto
haveaverticalstreakabove andbelowit.
INFORMATION
42015xBRearViewMonitorSystem
