Fabtech FTS24129 User manual

INSTALLATION INSTRUCTIONS
2007-18 JEEP WRANGLER
1.75-5” CHROMOLY FRONT TRACK BAR
FT24129i
FTS24129 1.75-5” CHROMOLY FRONT TRACK BAR
1 FT50483BK CHROMOLY FRONT TRACK BAR
1 FT50504 HARDWARE SUBASSEMBLY
FT50504 HARDWARE SUBASSEMBLY
1 FTS98003 3/4” ROD END
2 FT95066 MISALIGNMENT
1 75160003252 JAM NUT 3/4-16 RH
1 FTLOCK THREAD LOCKING COMPOUND
1 FTAS12 STICKER FT BLUE 10X4
1 FTAS16 DRIVER WARNING DECAL
1 FTREGCARD REGISTRATION CARD
1 FT24129I INSTRUCTIONS

READ THIS BEFORE YOU BEGIN INSTALLATION -
Check all parts to the parts list above before beginning installation.
Read all instructions thoroughly from start to finish before beginning the installation. If these instructions are not properly
followed severe frame, driveline and / or suspension damage may occur.
Check your local city and state laws prior to the installation of this system for legality. Do not install if not legal in your area.
Prior to the installation of this suspension system perform a front end alignment and record. Do not install this system if the
vehicle alignment is not within factory specifications. Check for frame and suspension damage prior to installation.
The installation of this suspension system should be performed by two professional mechanics.
This suspension must be installed with Fabtech shock absorbers.
Use the provided thread locking compound on all hardware.
WARNING- Installation of this system will alter the center of gravity of the vehicle and may increase roll over as compared to
stock.
Vehicles that receive oversized tires should check ball joints, uniballs, tie rods ends, pitman arm and idler arm every
2500-5000 miles for wear and replace as needed.
Verify differential fluid is at manufactures recommended level prior to kit installation. Installation of the kit will reposition the
differential and the fill plug hole may be in a different position. (For example, if the manufacture recommends 3 quarts of
fluid, make sure the diff has 3 quarts of fluid). Check your specific manual for correct amount of fluid.
- PRE-INSTALLATION NOTES -
Required Tools (Not Included)
Basic Hand Tools
Floor Jack
Jack Stands
Assorted Metric and S.A.E sockets, and Allen wrenches
Torque Wrench
- TOOL LIST -
NOTE: REFER TO OPTIONAL KIT BOX INSTRUCTIONS PRIOR TO
INSTALLATION.

- INSTRUCTIONS -
1. Disconnect the negative terminal on the battery. Jack up
the front end of the truck and support the frame rails with
jack stands. NEVER WORK UNDER AN UNSUPPORTED
VEHICLE!
2. Remove the factory hardware that connects the track bar
to the frame and axle. Discard the factory track bar and
save hardware.
3. Install the 3/4” jam nut onto the rod end until its stops.
Then, install the rod end into the new Fabtech track bar.
NOTE: When the rod end is adjusted all the way in
equals stock length. This is a good starting point when
installing. Adjustments may be required depending on
the amount of lift you have or if using in conjunction
with a track bar bracket.
4. Install the new track bar using the supplied misalignments
and factory hardware. The rod end side should be installed
to the axle. Also, the bend needs to installed away from
the axle. Leave loose. SEE FIGURES
1-2
FIGURE 1 - STEP 4
5. Once the vehicle is on the ground proceed with tightening
the hardware. Torque to 180 ft-lbs.
6. Check front end alignment and set to factory
specications. Readjust headlights.
7. Install Driver Warning Decal. Complete product
registration card and mail to Fabtech in order to receive
future safety and technical bulletins on this suspension.
Vehicles that will receive oversized tires should check ball
joints, uniballs and all steering components every
2500-5000 miles for wear and replace as required.
RE-TORQUE ALL NUTS, BOLTS AND LUGS
AFTER 50 MILES AND PERIODICALLY
THEREAFTER.
FIGURE 2 - STEP 4
FT50483BK
