GENERAL INFORMATION
SCMshallnotberesponsiblefordamageensuingfrommachineusedifferenttothatdescribedinthismanualor
incorrectmaintenance.
For any requirements or advice on how to use the machine, contact your local dealer:
WithregardtoECcertification,themachineisinconformitywith
councildirective89/392EEC,subsequentlyintegratedby91/368
EEC, 93/44 EEC and 93/68 EEC
Pagine totali compresa copertina e retro N° 147
Data
01/09/95 LIBRETTO USO E MANUTENZIONE
SUPERSET 23/ 23E /23PLUS
UNIFICATO
N° Bolla B9373
Modifica N° Bolla
Firma
S.I.T. /R.L./13/05/05 N° 0000502421A Data

GENERAL INFORMATION
1.2 SUPERSET 23/23E/PLUS ad-gb1.pm5
GENERAL INFORMATION..........................................................................SECTION 1
1-1 SENDING OF CORRESPONDENCE ............................................................................................. 1.4
1-2 SERVICING RECOMMENDATIONS............................................................................................ 1.4
1-3 MACHINE IDENTIFICATION ....................................................................................................... 1.5
1-4 CEXPECTED CONDITIONS OF USE AND CONTRAINDICATIONS ..................................... 1.5
1-5 MACHINE USE WITH REFERENCE TO THE OPERATOR....................................................... 1.6
1-6 SAFETY HINTS............................................................................................................................... 1.7
1-7 TECHNICAL FEATURES ............................................................................................................... 1.9
1-8 NOISE LEVELS ............................................................................................................................. 1.17
1-9 OVERALL DIMENSIONS ............................................................................................................ 1.18
1-10 WORK POSITIONS AND AREAS................................................................................................ 1.18
INSTALLATION ..............................................................................................SECTION 2
2-1 MACHINE UNLOADING ............................................................................................................... 2.2
2-2 POSITIONING ................................................................................................................................. 2.2
2-3 LEVELLING. ................................................................................................................................... 2.2
2-4 POWER CONNECTIONS AND EARTHING ................................................................................ 2.4
2-5 DUST EXTRACTION SYSTEM CONNECTION.......................................................................... 2.6
2-6 PNEUMATIC CONNECTIONS ...................................................................................................... 2.8
2-7 SAFETY DEVICES FITTED......................................................................................................... 2.10
USE - SETTINGS .............................................................................................SECTION 3
3-1 CONTROL PANEL. ..................................................................................................................... 3.2
3-2 PNEUMATIC CONTROL PANEL .............................................................................................. 3.7
3-3 CONTROL 10 PLUS MICROPROCESSOR CONTROL
(SUPERSET 23E) ......................................................................................................................... 3.8
3-4 STARTING THE MACHINE IN AUTOMATIC CYCLE .......................................................... 3.9
3-5 MACHINE STOP ......................................................................................................................... 3.9
3-6 EMERGENCY STOP ................................................................................................................... 3.9
3-7 SELF-BRAKING MOTOR ......................................................................................................... 3.10
3-8 MODE SELECTOR SWITCH OPERATION ............................................................................ 3.10
HEADS ............................................................................................................SECTION 4
4-1 TOOL ADJUSTMENT AND SPINDLE CLAMPING ................................................................ 4.2
4-2 HEADS.......................................................................................................................................... 4.8
4-3 FEMED ASSEMBLY ................................................................................................................. 4.20
4-4 INFEED TABLE AND FENCE.................................................................................................. 4.24
4-5 FENCES ...................................................................................................................................... 4.24
4-6 PRESSERS.................................................................................................................................. 4.32

SUPERSET 23/23E/PLUS 1.3
GENERAL INFORMATION
ADJUSTMENTS AND USE OF HORIZONTAL UNITS ..........................SECTION 10
10-1 SUPPLEMENTARY FEED ASSEMBLIES .............................................................................. 10.2
10-2 OPTIONALS ON INFEED TABLE AND FENCE.................................................................... 10.6
10-3 PRESSERS.................................................................................................................................. 10.8
10-4 LEFT VERTICAL UNIT AUTOMATIC POSITIONING DEVICE....................................... 10.14
10-5 UNIVERSAL SPINDLE........................................................................................................... 10.18
10-6 PRESET .................................................................................................................................... 10.30
SELF-BRAKING MOTOR ...........................................................................SECTION 19
MAINTENANCE ...........................................................................................SECTION 20
20-1 CLEANING THE MACHINE .................................................................................................... 20.2
20-2 PERIODICAL LUBRICATION ................................................................................................. 20.2
20-3 PNEUMATIC SYSTEM............................................................................................................. 20.6
20-4 HEAD BELTS............................................................................................................................. 20.8
20-5 REPLACING THE SPEED CHANGE UNIT BELT. .............................................................. 20.12
20-6 BELTS BETWEEN SPEED CHANGE UNIT AND GEAR BOXES ..................................... 20.14
20-7 UNIVERSAL UNIT BELTS. ................................................................................................... 20.16
20-8 ADDA ELECTRO MOTORS................................................................................................... 20.16
20-9 SAFETY DEVICE INSPECTION............................................................................................ 20.18
20-10 REMOVAL-STORAGE-DISMANTLING .............................................................................. 20.19
20-11 EMERGENCY SITUATIONS ................................................................................................. 20.19
20-12 TROUBLESHOOTING ............................................................................................................ 20.20
APPENDIX ...................................................................................................... SECTION A
SUPERSET 23 LAYOUT 1 ....................................................................................................................... A2
SUPERSET 23 LAYOUT 2 ....................................................................................................................... A3
SUPERSET 23 LAYOUT 5 ....................................................................................................................... A4
SUPERSET 23 LAYOUT 6 ....................................................................................................................... A5
SUPERSET 23 LAYOUT 13 ..................................................................................................................... A6
SUPERSET 23 LAYOUT 14 ..................................................................................................................... A7
SUPERSET 23 LAYOUT 15 ..................................................................................................................... A8
SUPERSET 23 LAYOUT 16 ..................................................................................................................... A9
SUPERSET 23 LAYOUT 17 ................................................................................................................... A10
SUPERSET 23 LAYOUT 18 ................................................................................................................... A11

GENERAL INFORMATION
1.4 SUPERSET 23/23E/PLUS ad-gb1.pm5
1.1
FORNIT. Companywhichfittedtheelectricalsystem
DATA Constructiondateofpowerbox
CODICEDISTINTA Listnumberofelectricalcomponents
N. Wiringdiagramnumber
VOLT RETE Mainspowervoltage tomachine (V)
VOLTAUX Auxiliarycircuitpowervoltage(V)
VOLTFRENO Motorbrakepowervoltage (V)
Hz PowerfrequencyinHz
kW Machinepowerabsorption
MACCH. Machinetype
1-1 SENDING OF CORRESPONDENCE
Whenwriting orphoning thedealeror SCMfor any reasonwhatsoever relatingtothe machine,always provide
thefollowinginformation:
1) machinemodel
2) serialnumber
3) voltage and frequency
4) date of purchase
5) name of dealer from whom the machine was purchased
6) details of any problems found
7) details of the type of work to be carried out
8) period of use - number of hours operation
SCM
ViaEmilia, 71
47900 - RIMINI - ITALY
Tel. [phone] - Fax. [phone]
1-2 SERVICING RECOMMENDATIONS
Incompilingthisbookletwehavetakenintoconsiderationalloperationswhichfallintotheroutinemaintenance
bracket.
Never perform repairs or maintenance work not indicated in this manual.
All operations requiring dismantling of parts should be done by authorized engineers. In the event of machine
partshavingto bereplaced, onlyever useSCM originalspares, havingidentical featurestothosewhichhaveto
be replaced.
Informationconcerningexclusivelythosemachinesinconformitywithdirective89/392/EECareindicatedbythe
symbol while information concerning non-EEC machines is indicated by the symbol .
To correctly use the machine, carefully follow the instructions in this manual.
Only trained and authorized personnel, who have read this manual, should use the machine and perform
maintenanceoperations.
Observe all accident prevention regulations, general safety regulations and work medicine regulations.
Note for servicing:
- Only ever use original SCM spares. The manufacturer declines all responsibility for the use of non-
originalspares.
- For specific information on the wiring system, supply details indicated on the plate (fig. 1.1) situated
inside the access door of the electrical compartment.
This manual must be kept for future reference.

SUPERSET 23/23E/PLUS 1.5
GENERAL INFORMATION
1.2
Ref.
Mod. Machinemodel
Matr. Serialnumber
Ref. Internalreference
Comp. Machinelayoutnumber
N GrossweightexpressedinNewton
kg Massexpressedinkilograms
Volt Powervoltage
~ F Phasenumber
Hz PowerfrequencyinHz
Amp. PowerabsorptioninAmpere
1-4 EXPECTED CONDITIONS OF USE AND CONTRAINDICATIONS
This machine must be used only for the cutting of wood and similar materials. By “similar materials” is meant
materialswithsimilartechnologicalandphysicalfeaturestothoseofwoodandtothemechanismofworkingand
removalofshavings.
Materials different from those mentioned above, not being similar to wood, must necessarily be excluded. The
user alone shall be responsible for any damage to the machine produced by machining such materials.
DIMENSIONS OF THE PIECES TO BE MACHINED
The maximum dimensions of the machined pieces are:................................. height 120 mm x width 230 mm
considering that maximum removal size is 10 mm, the maximum dimensions of the pieces to be worked are:
height 140 mm x width 250 mm.
Given the possibility of removals from 10 mm to 0.1 mm, minimum dimensions can be achieved of: machined
piece height 6 mm (10 mm with electronic control positioning) x width 25 mm
withsupplementary equipmentfor narrowpieces,dimensions are:height 6 mm(10 mmwithelectronic control
positioning) x width 15 mm
The minimum length of the piece with single feed is: ......................................................................... 600 mm
with relative optional equipment:....................................................................................................... 435 mm.
TOOLS TO BE USED
The machine has been designed to use exclusively tools in conformity with prEN847-1 standards, suitable for
the type of material to be machined.
The relationship between tool diameter and tool height, given equal rotation speed, is indicated on the table at
chapter 4-1
ENVIRONMENT
The machine can operate in the following environmental conditions:
Humidity: 90 % max.
Temperature: +1°C min. +40°C max.
Altitude: 1000 m a.s.l. max. (above this altitude, consult the manufacturer)
The machine can only operate in closed environments.
This machine cannot work in explosive environments.
1-3 MACHINE IDENTIFICATION
The machine can be identified from the indications provided on the metal plate on the side of the bed.

GENERAL INFORMATION
1.6 SUPERSET 23/23E/PLUS ad-gb1.pm5
PROHIBITED USES
It is forbidden
- To use the machine in a different way to that described above
- To use the machine without the envisaged protections for each operation, or to remove any of these
protections
- To use materials of type and dimensions different from those indicated above.
- TousetoolsnotincludedinprEN847-1standardorhavingdimensionswhicharenotcompatible(seetable
at chapter 4-1)
The user shall be the only person responsible for damage resulting from improper machine use.
OTHER RISKS
Despitehavingobservedallsafetyregulations,andpropermachineuseasdescribedinthismanual,other
risks still remain:
- Contact with tools
- Contact with the rotating spindle
- Contact with the rotating elements (belts, pulleys, rollers)
- Danger from inhaling of dust in the event of machining without dust extraction system
1-5 MACHINE USE WITH REFERENCE TO THE OPERATOR
The control panel features one or more key selector switches.
These switches enable machine use according to precise safe work setting and logics.
These switches must only be used by qualified and expressly authorized personnel. Improper use can cause
precarious machine operating conditions and hazardous situations.
Onceallsettingsandadjustmentshavebeenmadebymeansofthekeyselectorswitches,theexpertoperatormust
remove the keys from the control panel and authorize the production operator to use the machine.
It is also most important to obtain two padlocks to lock the main power switch and the main pneumatic system
valve.
The qualified and authorized operator is responsible for these padlocks and should keep the keys.

SUPERSET 23/23E/PLUS 1.7
GENERAL INFORMATION
1-6 SAFETY HINTS
Carefully read all the instructions in this booklet before starting the machine.
This machine has been built to provide maximum safety combined with maximum performance.
Themanufacturerdeclinesanyresponsibilityforanychangesmadetothemachinebytheuser,andforanydamage
which could result.
Safetyisultimatelyinyourhands.Theuseofanymachinetoolinvolvescertainrisks.Alwaysbearthisinmind.
PROCEDURES FOR SAFE OPERATION
GENERAL INFORMATION
1- Only persons who have been correctly instructed should use the machine. Instructions should include
information concerning the dangers associated with machine use and the..precautions which have to be
taken.
2- The operator must be trained and instructed on the correct use of guards and safetydevices. He should also
be taught to perform periodical inspections of these guards and safety devices.
3- For safe operation, the area around the machine must be free at all times.
The floor must be level, well maintained and free from all materials like shavings, etc.,
4- There must be sufficient general and localized lighting in the place of work.
5- Semi-finished and finished products must be near the operator’s normal work position.
6- Experience teaches that you often carry or wear objects which can cause accidents:
remove rings, watches, or bracelets; fasten sleeves well around wrists, remove ties which could become
trapped,fastenhairbackwithsuitableaccessories(caps,rubberbands).Apersonalprotectivegarmentmust
be worn. This includes:
- suitable footwear, in accordance with accident-prevention regulations in all countries of the world;
- ear protection, to lower risks of deafness;
- breathing protection, to reduce risks of inhaling harmful dust;
- gloves when handling tools, (tools must be handled using a tool support whenever possible)
- glasses or protective screens to protect the eyes.
7- The operator must never leave the machine unattended during operation;
8- All machine faults, including those to guards or tools, must be reported as soon asthese are discovered and
the necessary remedial measures must be taken.
9- Proceduresmustbefollowedforsafecleaning,maintenance,regularremovalofshavingsanddusttoprevent
firerisks.

GENERAL INFORMATION
1.8 SUPERSET 23/23E/PLUS ad-gb1.pm5
MACHINE SAFETY
10- Take every care before starting machine operation
11- Themachinemustneverbeusedunlesstheguardsandothersafetydevicesareinposition,ingoodcondition
andproperlymaintained.
12- Before starting the machine, make sure there are no foreign parts on the worktable.
13- Never work pieces which are too small or too big for the machine.
14- Before fitting blades, planes or cutters in their housings or shafts, make sure all fittingsurfaces are clean,
smooth and perfectly flat.
15- The piece must be suitably supported, if necessary using additional supports, eg. for long........... pieces.
16- The ejection and removal of scraps can be a problem. Scraps must be deviated from thecuttingareaintoa
suitablecontainerwhichmust be periodically emptied.
17- No attempt must be made to remove scraps or other parts of pieces from the work area while the machine
isrunning.
TOOLS
18- Only prEN847-1 approved tools must be used
19- The instructions of the manufacturer or SCM concerning use, settings and repair of toolsmustbecarefully
followed.
20- The speed limit indicated on the tool must be observed.
21- Make sure the blades, the planes and the cutters are perfectly balanced, sharp and accurately keyed and
fastened.
22- Never use bent blades, planes or cutters.
MAINTENANCE SAFETY
23- Ifthemachineisstoppedformakingadjustmentsortoremoveanypart,zero-setthemainswitch,signalthe
factwithanoticeandpadlockthemainswitch.Ifthemachineisfittedwithpneumaticsystem,closethemain
air stopcock, signal the fact with a notice and padlock the stopcock.
24- Completely stop the machine before proceeding to clean and before removing any guards for servicing.

SUPERSET 23/23E/PLUS 1.9
GENERAL INFORMATION
1-7 TECHNICAL FEATURES SUPERSET 23 SUPERSET 23E SUPERSET 23 PLUS
Minimumwork height(finishedsection) 6 mm 10 mm 6 mm
Maximumwork width(finished section) 230 mm 230 mm
Minimumwork width(finishedsection) 23/15*mm 23/15*mm
Max. work height (finished section) 120 mm 120 mm
Feed speed 4“24m/min 5“35m/min
Spindle rotation speed 6000 RPM 6000 RPM
Spindlediameter 40 mm 40 mm
Verticalspindlelength 150 mm 150 mm
Verticalspindle workinglength 130 mm 130 mm
Horizontalspindle workinglength 250 mm 250 mm
Universalspindleworkinglength 240 mm 240 mm
Axialsettingofvertical spindles with
respect to worktable 45 mm 45 mm
Axial setting of horizontal spindles with
respect to right fence 50 mm 50 mm
Spindlecylinderdiameter 120 mm 120 mm
Minimumandmaximumprofiling
tool diameter 100-200 mm 100-200 mm
Minimumand maximumtooldiameter
on 1st lower horizontal spindle 120-140 mm 120-140 mm
Minimumandmaximumdiameteron
2nd lower horizontal spindle 100-200 mm 100-200 mm
Profiling capacity on 2nd lower horizontal
spindle with 200 mm dia. tool 15 mm 15 mm
Plane spindle motor power rating
(1st lower horizontal) 5,5 HP (4 kW) 5,5 HP (4 kW)
Vertical spindle motor power rating 10 HP (7,5 kW) 11 HP (8 kW)
Upper horizontal spindle motor power rating 7,5 HP (5,5 kW) 7,5 HP (5,5 kW)
Lower horizontal spindle motor power rating 5,5 HP (4 kW) 5,5 HP (4 kW)
2nd upper horizontal spindle motor power rating 5,5 HP (4 kW)
Feed motor power rating 4 HP (3 kW) 5,5 HP (4 kW)
Universal spindle motor power rating 5,5 HP (4 kW) 5,5 HP (4 kW)
Feed roller diameter 140mm 140mm
Infeedtable length 2000mm 2000mm
Infeed table and fence quick setting 10mm 10mm
Suction inlet diameter 130mm 130mm
Upper horizontal spindle suction
inletdiameter 150 mm 150 mm
Singlepieceminimumlength 600 mm 600 mm
Singlepieceminimumlengthwith
relativeoptional 435 mm 435 mm
Net weight 2300 kg ( layout 1) 3550 kg ( layout 13)
2450 kg ( layout 5) 3550 kg ( layout 15)
4800 kg ( layout 17)
Universal unit net weight 700 kg 700 kg
* with relative optional

GENERAL INFORMATION
1.10 SUPERSET 23/23E/PLUS ad-gb1.pm5
SUPERSET 23/23E OPTIONALS
LAYOUT 1-2 LAYOUT 5-6
INCREASED POWER FOR:
Right/leftvertical 15 HP 15 HP
Upper horizontal 10 HP 10 HP
INCREASED POWER FOR:
1st lower horizontal (planer) 7,5 HP 7,5 HP
Right/leftvertical 15 HP 15 HP
Upper horizontal 10 HP 10 HP
2nd lower horizontal / 7,5 HP
INCREASED POWER FOR:
1st lower horizontal (planer) 7,5 HP 7,5 HP
Right/leftvertical 15 HP 15 HP
Upper horizontal 15 HP 15 HP
2nd lower horizontal / 10HP
INCREASED POWER FOR:
1st lower horizontal (planer) 10 HP 10 HP
Right/leftvertical 10 HP 10 HP
Upper horizontal 15 HP 15 HP
2nd lower horizontal / 10HP
INCREASED POWER FOR:
1st lower horizontal (planer) 10 HP 10 HP
Right/leftvertical 20 HP 20 HP
Upper horizontal 15 HP 15 HP
2nd lower horizontal / 10 HP
INCREASED POWER FOR
UNIVERSAL UNIT 7,5 - 10 - 15 HP
– 220 V model
– Automatic delta-star start for 5.5 HP motors
– Feed assembly before surfacer with pneumatic pressure
– Second feed assembly after universal with pneumatic pressure
– Feed assembly for 435 mm pieces with pneumatic pressure and mechanical cutout system
– Tandem feed assembly at infeed before surfacer with pneumatic pressure and quick cutout.
– Tandem feed assembly before right vertical with pneumatic pressure and quick cutout.
– Tandem feed assembly before universal with pneumatic pressure and quick cutout (with universal)
– Feed speed 5-35 m/min
– Mechanical and power setting for subsequent fitting of universal spindle unit (layout 1 and 5)
–Automatic brake for 5.5 to 10 HP motors for quick tool stop (for all motors)
–Automatic brake for 15 to 20 HP motors for quick tool stop (for all motors)
– Supplementary steel feed roller - 140 x 20 mm
– Supplementary steel feed roller - 140 x 50 mm
– Supplementary steel flanged feed roller - 140 x 20 mm
– Supplementary rubber feed roller - 140 x 20 mm
– Supplementary rubber feed roller - 140 x 50 mm

SUPERSET 23/23E/PLUS 1.11
GENERAL INFORMATION
– Supplementary rubber feed roller - 140 x 20 mm
– Working length 240 mm
– Kit for minimum 15 mm working length with 120 mm minimum tool diameter
– 150 mm maximum work height with vertical spindles L=180 mm (with grooved worktable, the maximum
working height is 127 mm)
– Spindle diameter 1" 13/16
– High-precision50 mm dia. spindle
– Rotation speed 8300 RPM (only for high-precision spindles or horizontal spindles)
– Leftverticalspindleautomaticsettingdevice(TTL)forquicksequencemachiningofpiecesofdifferentwidth
– Micrometric horizontal and vertical setting of work height and width (for SUPERSET 23)
– Micrometric vertical setting of work height ( for SUPERSET 23)
– Infeed table 2500 mm
– Supplementarytablewithrexiloninsert
– 2nd lower horizontal unit for max. 200 mm blades
– Cutter with profile above 15 mm depth
– Chrome-plating for grooved table (layouts 5 and 6)
– Grooved table for layouts 5 and 6 complete with sector cutters:
– on left vertical max. dia. tool movable under the table...................................................145 mm
– on right vertical max. depth profilable under the table.......................................................6 mm
– maximumworkheight......................................................................................................97 mm
– tablelubricationpump
– Chrome-plated wearproof work table
– Chrome-plated wearproof infeed table
– Infeedfence with bearings
– Front pneumatic presser on upper horizontal hood
– Slidingblock verticalpresser
– Horizontal presser before surfacer with control panel pneumatic cutout
– Supplementaryvertical roller presser
– Front and rear pressure pads on the hood of the universal spindle
– Static inverter on universal spindle (rotation speed varies continually from 1000 to 6000 rpm, power rating
2-7.5 HP)
– Universal spindle hood setup for recovery of glazing bead on left side
– Glazing bead separation kit on right side
– Supplementary dust extraction hood for max. 250 mm blades on universal spindle
– Kit for cutting right bead on upper horizontal spindle
– 3 mm thick supplementary fence (layouts 1 and 5)
– Setup for multi-blade cutting with second lower horizontal:
– maximum height of piece ..................................................................................................50 mm
– minimum heightof piece ...................................................................................................15mm
– maximum diameter of blade ............................................................................................200 mm
– minimum width of piece ....................................................................................................10mm
– 5 dividing blades, thickness 2.5 mm for 2.2 mm thick blades
– Safety device featuring piece non-return arms at machine infeed
– 25 HP motor on second lower horizontal for blade cutting
– Operation hour counter
– Counter meters with zero-setting
– Manual action pump for table lubrication
– Automatic action pump for table lubrication
– Blade gauge for planer heads with diameter 120/160 mm
– Digital detector for vertical setting with planer unit decimal indicator
– Wiring system preset for use of automatic loaders

GENERAL INFORMATION
1.12 SUPERSET 23/23E/PLUS ad-gb1.pm5
– PRESET mod. 25 for measuring tool diameter
– reading is through tool contact on electronic digital indicator;
– centesimalprecision;
– maximummeasurablediameter ............................................................................... 250 mm.
– Shaver on first spindle dia. 165 mm
– Supplementary shaver dia. 150 mm
– Supplementary shaver dia. 165 mm
– 2 blade heads dia. 140x240x40 mm in light alloy for horizontal spindles (8500 RPM)
– 2 blade heads dia. 140x235x40 mm in light alloy and interchangeable reversible blades with centrifugal
chucking for horizontal spindles max. 6000 RPM
– 2 blade heads dia, 140x130x40 mm in light alloy for vertical spindles max. 8500 RPM
– 2 blade heads dia. 140x125x40 mm in light alloy and interchangeable reversible blades with centrifugal
chucking for vertical spindles max. 6000 RPM
– 2 blade heads dia. 140x250x40 mm in light alloy for horizontal spindles (for maximum working width 240
mm) (8500 RPM)
SUPERSET 23 PLUS OPTIONALS
INCREASED POWER FOR:
– 1st lower horizontal (planer) .............................................................................................. 7,5 - 10 - 15 HP
– right/leftvertical................................................................................................................. 7,5 - 10 - 15 HP
– 2nd lower horizontal .......................................................................................................... 7,5 - 10 - 15 HP
– 2nd upper horizontal .......................................................................................................... 7,5 - 10 - 15 HP
INCREASED POWER FOR:
1st upper horizontal spindle ............................................................................................................10 - 15 HP
INCREASED POWER FOR:
piecefeed ....................................................................................................................................... 7,5 HP
– 220 Volt model
– Automatic star-delta start for motors with 5.5 HP rating
– Feed assembly before surfacer with pneumatic pressure
– Second feed assembly after universal with pneumatic pressure
– Feed assembly after upper horizontal complete with tandem feed assembly after second right vertical with
quick cutout for drive centre distance of 435 mm with pneumatic pressure and mechanical cutout system
(layout 13-14)
– Feed assembly after 2nd upper horizontal for drive centre distance of 435 mm with pneumatic pressure and
mechanical cutout system (layout 15 and 16)
– Feedassembly after 2nd upper horizontal complete with tandem feed assembly beforethe upper horizontal
unit with quick cutout for drive centre distance of 435 mm with pneumatic pressure and mechanical cutout
system (layout 17 and 18)
– Tandem feed assembly in infeed before the surfacer with pneumatic pressure and quick cutout
– Tandemfeedassemblybeforerightverticalunitwithpneumaticpressureandquickcutout(layout15and16)
– Tandemfeedassemblybeforerightverticalunitwithpneumaticpressureandquickcutout(layout13-14-17-
18)
– Tandemfeedassemblybetweenthetwohorizontal/upperspindleswithpneumaticpressureandquickcutout
(layout 15-16-17-18)
– Tandem feed assembly before universal with pneumatic pressure and quick cutout.
– 2 motorized lower drive rollers on worktable (layout 13-15)

SUPERSET 23/23E/PLUS 1.13
GENERAL INFORMATION
– 3 motorized lower drive rollers on worktable (layout 14-16)
– 4 motorized lower drive rollers positioned on worktable (layout 18)
– Mechanically and electrically preset for subsequent fitting of universal spindle unit (layout 13-15-17)
–Automatic brake for 5.5 to 10 Hp motors for quick tool stop
–Automatic brake for 15 to 25 HP motors for quick tool stop
– Supplementary steel feed roller - 140x20 mm
– Supplementary steel feed roller - 140x50 mm
– Supplementary flanged steel feed roller - 140x20 mm
– Supplementary rubber feed roller 140x20 mm
– Supplementary rubber feed roller 140x50 mm
– Supplementary rubber flanged feed roller 140x20 mm
– 15 mm minimum working width kit with minimum tool diameter 120 mm (with grooved worktable having
20mm minimumwidth)
– Working width 240 mm
– Spindle diameter 1" 13/16
– High-precisionspindle dia. 50 mm
– Rotation speed 8300 RPM (for high-precision spindles only)
– Maximum working height 150 mm with vertical spindles L = 180 mm (with grooved worktable maximum
working height is 127 mm)
– Automatic left vertical spindle setting device with maximum tool diameter 180 mm
– Maximum working width 220 mm with plane diameter 100 mm
– Horizontal micrometric setting of work width
– Infeed table 2500 mm
– Supplementarytable with rexilon inserts
– 2nd lower horizontal unit for max. 200 mm blades
– Cutter with profile above 15 mm depth
– Chrome-plating for grooved table (layouts 13-14-15-16)
– Grooved table for layouts 13-14-15-16 complete with sector cutters:
– on left vertical max. dia. tool movable
under the table ..............................................................................145 mm (vertical movement)
– on right vertical max. depth profilable under the table ......................................................6 mm
– maximum workheight.....................................................................................................97 mm
– tablelubricationpump
– Grooved worktable for layouts 17 and 18 complete with sector cutters:
– on left vertical max. dia. tool movable
under the table ............................................................................. 145 mm (vertical movement)
– on right vertical max. depth profilable under the table ..................................................... 6 mm
– maximum workheight.................................................................................................... 97 mm
– tablelubricationpump
– Chrome-plated wearproof work table (layouts 13-14-15-16)
– Grooved worktable
– Chrome-plating for grooved table (layout 17-18)
– Chrome-plated wearproof infeed table
– Chrome-plated wearproof worktable (layout 17 and 18)
– Infeedfence with bearings
– Front pneumatic presser on upper horizontal hood
– Vertical pressure pads
– Horizontal presser before surfacer with control panel pneumatic cutout
– Supplementaryvertical roller presser
– Front and rear pressure pads on the hood of the universal spindle
– Universal spindle hood setup for recovery of glazing bead on left side
– Static inverter on universal spindle (rotation speed varies continually from 1000 to 6000 rpm, power rating
2-7.5 HP) (layout 14-16-18)
– Glazing bead separation kit on right side

GENERAL INFORMATION
1.14 SUPERSET 23/23E/PLUS ad-gb1.pm5
– Kit for cutting right glazing bead on upper horizontal spindle (layout 13-15-17)
– Setup for multi-blade cutting with second lower horizontal:
– maximumheight ofpiece.................................................................................................50 mm
– minimumheightofpiece .................................................................................................15 mm
– maximumdiameterofblade ..........................................................................................200 mm
– minimumwidthof piece ..................................................................................................10 mm
– 5 dividing blades, thickness 2.5 mm for 2.2 mm thick blades
– Safety device featuring piece non-return arms at machine infeed
– 25 HP motor on second lower horizontal for blade cutting
– Supplementary dust extraction hood for max. 250 mm blades on universal spindle
– Operation hour counter
– Manual action pump for table lubrication
– Counter meters with zero-setting
– Automatic action pump for table lubrication
– Blade gauge for planer heads with diameter 120/160 mm
– Digital detector for vertical setting with planer unit decimal indicator
– Wiring system preset for use of automatic loaders
– PRESET mod. 25 for measuring tool diameter
– reading is through tool contact on electronic digital indicator;
– centesimalprecision
– maximummeasurablediameter .....................................................................................250 mm.
– Shaver on first spindle dia. 165 mm
– Supplementary shaver dia. 150 mm
– Supplementary shaver dia. 165 mm
– 2 blade heads dia. 140x240x40 mm in light alloy for horizontal spindles (8500 RPM)
– 2 blade heads dia. 140x235x40 mm in light alloy and interchangeable reversible blades with centrifugal
chucking for horizontal spindles max. 6000 RPM
– 2 blade heads dia. 140x130x40 mm in light alloy for vertical spindles max. 8500 RPM
– 2 blade heads dia. 140x125x40 mm in light alloy and interchangeable reversible blades with centrifugal
chucking for vertical spindles max. 6000 RPM
– 2bladeheadsdia.140x250x40mminlightalloyforhorizontalspindles(formaximumworkingwidthof240
mm) (8500 RPM)

SUPERSET 23/23E/PLUS 1.15
GENERAL INFORMATION
LAYOUTS
Legend:
Lower horizontal unit Upper horizontal unit
Presetting of supplementary lower horizontal unit
Rightvertical unit Left vertical unit
Universalunit
SUPERSET 23/23E LAYOUTS
LAYOUT 1
LAYOUT 2
LAYOUT 5

GENERAL INFORMATION
1.16 SUPERSET 23/23E/PLUS ad-gb1.pm5
LAYOUT 6
SUPERSET 23 PLUS LAYOUTS
LAYOUT 13
LAYOUT 14
LAYOUT 15
LAYOUT 16
LAYOUT 17
LAYOUT 18

SUPERSET 23/23E/PLUS 1.17
GENERAL INFORMATION
1-8 NOISE LEVELS
Planer moulder type: Superset 23/23S
In accordance with test report: CSR no. 93115
Operatingconditions:Planing
Reference standards: ISO/DIS 7960 Attached document H
Empty without
dust extraction In operation
Monitored
soundlevel
dB W (A) [mW (A)]
Level of sound
pressure at
operator infeed
dB (A) [dB max]
Level of sound
pressure at
operator outfeed
dB (A)[dB max]
94.5 [2.8] 103.6 [22.9]
78.5 90.0 [98.2]
74.0 81.5 [87.0]
Constant K=2
The above values refer to a “free field” in accordance with test
procedures indicated in reference standards.
IMPORTANT
The figures shown are emission levels and do not necessarily represent definite operating levels.
While a relation exists between emission levels and exposure levels, this cannot be reliably used to determine
whether further precautions are required or not. The factors affecting real worker exposure levels include
durationofexposure,environmentcharacteristics,otheremissionsources,eg.thenumberofmachinesandother
adjacent operations.
Approved exposure levels can vary from country to country.
This information will in any event enable the machine user to better assess dangers and risks.
Some factors which reduce exposure to noise are
- correct choice of tools
- correct speed selection
- tooland machine maintenance
- use of noise protection devices supplied with machine
- correct use of hearing protectors

GENERAL INFORMATION
1.18 SUPERSET 23/23E/PLUS ad-gb1.pm5
1.3
1.4
125.006 Ec.0
125.004 Ec.0
1-9 OVERALL DIMENSIONS (FIG. 1.3)
3500 mm (layouts 1-2-5-6 SUPERSET 23/23E)
4600 mm (layouts 13-14-15-16 SUPERSET 23 PLUS)
5200 mm (layouts 17-18 SUPERSET 23 PLUS)
1.10. WORK POSITIONS AND AREAS (FIG. 1.4)
Legend:
A- Control position.
B- Manual loading or other machine link area.
C- Operator unit control and adjustment area.
D- Universal unit control and adjustment area.
E- Manual unloading or other machine link area.
Distance X must be equal to maximum length of machined piece + 500 mm.
F- Perimeter area.
*
