Triton TRP UL Quick guide
Unlimited Rebate Planer
with Interchangeable Sanding Drum
750W
TRP UL
tritontools.com
Operating and
Safety Instructions
Használati és
munkavédelmi útmutató
2
GB
Thank you for purchasing this Triton tool. This manual contains information necessary for safe and
effective operation of this product. This product has unique features and, even if you are familiar
with similar products, it is necessary to read this manual carefully to ensure you fully understand the
instructions. Ensure all users of the tool read and fully understand this manual.
CONTENTS
SPECIFICATION
Contents / Specification
Specification 2
Product Familiarisation 3
General Safety 4
Symbols 5
Intended Use 5
Unpacking Your Tool 5
Before Use 6
Operation 8
Maintenance 9
Warranty 9
Part no: TRPUL
Voltage: 220-240V~ 50Hz
Power: 750W
Variable Speed: 5000 – 15,500min-1
Blades: 3 reversible blades 82mm standard
Planing Width: 82mm
Depth of Cut Range: 0 – 3mm
Left or Right Chip Exit: Yes
Bevelling V Grooves: 1
Parking Stand: Automatic
Weight: 3.9kg
Noise and Vibration Information:
Sound Pressure LPA: 87.1dB(A)
Sound Power LWA: 98.1dB(A)
Uncertainty K: 3dB
Weighted Vibration ah(main handle): 9.326m/s2
Weighted Vibration ah(auxiliary handle): 7.727m/s2
Uncertainty K: 1.5m/s2
As part of our ongoing product development, specifications of Triton products may alter without notice.
The sound intensity level for the operator may exceed 85dB(A) and sound protection measures are necessary.
WARNING: Always wear ear protection where the sound level exceeds 85dB(A) and limit the time of exposure if necessary. If sound levels are uncomfortable, even
with ear protection, stop using the tool immediately and check the ear protection is correctly fitted and provides the correct level of sound attenuation for the level
of sound produced by your tool.
WARNING: User exposure to tool vibration can result in loss of sense of touch, numbness, tingling and reduced ability to grip. Long term exposure can lead to
a chronic condition. If necessary, limit the length of time exposed to vibration and use anti-vibration gloves. Do not operate the tool with hands below a normal
comfortable temperature, as vibration will have a greater effect. Use the figures provided in the specification relating to vibration to calculate the duration and
frequency of operating the tool.
Sound and vibration levels in the specification are determined according to EN60745 or similar international standards. The figures represent normal use for the
tool in normal working conditions. A poorly maintained, incorrectly assembled, or misused tool, may produce increased levels of noise and vibration. www.osha.
europa.eu provides information on sound and vibration levels in the workplace that may be useful to domestic users who use tools for long periods of time.
3
GB
Product Familiarisation
PRODUCT FAMILIARISATION
1. Depth Adjustment Dial
2. Front Handle
3. Drum Guard Release Lever
4. Power ON Indicator Neon
5. On/Off Trigger Switch
6. Lock-Off Button
7. Main Handle
8. Power Cord
9. Dust Diverter Guide Switch
10. Dust/Chip Extraction Port
11. Fixed Rear Base
12. Spanner
13. Hex Key
14. Fitted Reversible Blades (replacement blades
available separately. Part no. TRPPB)
12
13 14 15 16
17
18 19
20
21
22
23
24 25 26
1
2
3
45 6
7
8
9
10
11
15. Clamping Screws
16. Blade Drum
17. Drum Guard
18. Shavings Collection Bag
19. Rear Parking Foot
20. Spare Drive Belt (Not included)
21. Dust/Chip Adaptor Tube
22. Parallel Fence Attachment Knob
23. Parallel Fence Guide
24. Sanding Drum with Sleeve (replacement
sanding sleeves available separately: Part No. TRPSS)
25. Variable Speed Control
26. Drum Spindle Lock Button
4
GB
WARNING Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious
injury.
WARNING: This appliance is not intended for use by persons (including
children) with reduced, physical or mental capabilities or lack of experience or
knowledge unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety. Children must be
supervised to ensure that they do not play with the appliance.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded)
power tool or battery-operated (cordless) power tool.
Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
b) Do not operate power tools in explosive atmospheres, such as in
the presence of flammable liquids, gases or dust. Power tools create
sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will reduce risk of electric
shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use an extension cord
suitable for outdoor use. Use of a cord suitable for outdoor use reduces
the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a
residual current device (RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
WARNING: When used in Australia or New Zealand, it is recommended that
this tool is ALWAYS supplied via Residual Current Device (RCD) with a rated
residual current of 30mA or less.
GENERAL SAFETY
General Safety
Personal safety
a) Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired
or under the influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in serious
personal injury.
b) Use personal protective equipment. Always wear eye protection.
Protective equipment such as dust mask, non-skid safety shoes, hard hat,
or hearing protection used for appropriate conditions will reduce personal
injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position
before connecting to power source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your finger on the switch or
energising power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool
on. A wrench or a key left attached to a rotating part of the power tool
may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your
hair, clothing and gloves away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used.
Use of dust collection can reduce dust-related hazards.
Power tool use and care
a) Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the
rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off.
Any power tool that cannot be controlled with the switch is dangerous and
must be repaired.
c) Disconnect the plug from the power source and/or the battery pack
from the power tool before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to
operate the power tool. Power tools are dangerous in the hands of
untrained users.
e) Maintain power tools. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with
these instructions, taking into account the working conditions and
the work to be performed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
Service
a) Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.
5
GB
SYMBOLS
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with house-
hold waste. Please recycle where facilities exist. Check with your
local authority or retailer for recycling advice.
Wear hearing protection
Wear eye protection
Wear breathing protection
Wear head protection
Conforms to relevant legislation and safety standards.
Read instruction manual
Class II construction (double insulated for additional protection)
General Safety / Symbols / Intended Use / Unpacking Your Tool
ADDITIONAL SAFETY FOR ELECTRIC PLANERS
• Ensure all nails, screws etc are removed from the workpiece before
commencing the task. Otherwise, damage to the blade or planer could
occur, causing a safety hazard.
• Ensure all cloth, cord, rags, string and similar items are removed from the
work area to prevent entanglement in the planer mechanism
• If possible, use clamps or a vice to hold your work.
• Handle blades with caution.
• Ensure that the blade installation bolts are securely tightened before
operation.
• Before using the planer on a workpiece, switch on and allow it to run for a
while. Check for vibration or wobbling that could indicate a badly installed,
or a poorly balanced blade.
• Allow the machine to reach full speed before making contact with the
workpiece and starting cutting.
• Operate the planer only when controlled by both hands.
• Ensure the planer is at least 200mm away from your face and body.
• Always switch off and allow the cutter to stop before setting the planer
down. An exposed moving cutter may engage the surface leading to
possible loss of control and serious injury.
• Shavings may jam in the chute when cutting damp wood. Switch off and
unplug the power source and clean out the chips with a stick. WARNING:
Never put your finger into the chip chute.
• Always switch off and allow the blades to come to a complete standstill
before attempting any adjustments.
• When leaving the machine unattended, disconnect from the power source.
• When not in use, disconnect from the power source and place the front
base on a wooden block so that the blades are not in contact with
anything.
• Replace all blades at the same time, otherwise the resulting imbalance will
cause vibration and shorten the service life of planer and blades.
• Replace all blades at the same time, otherwise the resulting imbalance will
cause vibration and shorten the service life of planer and blades.
INTENDED USE
UNPACKING YOUR TOOL
Electric hand planer used for light and medium-duty planing of hard and soft
wood, with adjustable depth of cut and unlimited rebate depth.
• Carefully unpack and inspect your tool. Familiarise yourself with all its
features and functions
• Ensure that all parts of the tool are present and in good condition. If any
parts are missing or damaged, have such parts replaced before attempting
to use this tool
6
GB
Always ensure that the tool is switched off and unplugged from the power
supply before making any adjustments, and before fitting or removing the
blade or sanding drums
REPLACING BLADES
• Always completely remove the blade drum prior to installing new blades.
For your own safety, it is not recommended to remove the planer blades
while the drum is still installed in the planer.
• The planer is fitted with reversible blades. Blades can be reversed
when blunt. After both sides of the blade have been used, they must be
discarded.
• Replacement planer blades are available
from your Triton retailer (Part no. TRPPB)
REMOVING THE BLADE DRUM
1. Place the planer on its side so that the motor
is facing down
2. Press the Drum Guard Release Lever (3) to
raise the Drum Guard (17) for access to the
Blade Drum (16)
3. Insert the short end of the supplied Hex Key (13) into the screw head in the
centre of the blade drum
4. Press the Drum Spindle Lock Button (26), and rotate the drum until it is
locked. Note: The blade drum has two lock out positions
5. Keep the spindle locked whilst you loosen and remove the hex head screw,
and then the two flat washers
6. Carefully remove the drum from the spindle
WARNING: The blades are very sharp. Take care when handling the drum
REMOVING PLANER BLADES
1. Secure the blade drum in a vice with one Blade (14) facing up so that it is
accessible
2. Protect the drum with a cloth or similar padding when putting it in the vice
3. Using the Spanner (12), loosen the three screws on the blade clamp just
sufficiently to remove the clamp from the drum
4. Carefully remove the blade from the blade clamp slot
BEFORE USE
12
3
Before Use
INSTALLING PLANER BLADES
• The blades have a cutting edge on both
sides so are reversible. If a blade is worn or
damaged on one side, you can re-install it
the other way round to use the other cutting
edge
• IMPORTANT: A single blade may be re-
placed only if it is damaged. If the blade is
worn, you must replace all three blades in
the drum to prevent unbalanced operation,
which can cause dangerous vibration and
damage to the tool
• If replacing blades, use blades of the same
dimensions and weight, or the drum will
oscillate and vibrate causing poor planing
action and possibly breakdown
• The quality of finish relies on correct
installation of the blades. Clean away any
woodchips or other foreign matter adhering
to the blade drum or clamps
1. Slide the blade into the slot in the blade clamp so that:
• The new cutting edge is face up
• The raised back of the blade is positioned on the opposite side to the
clamping screws, and the flat face of the blade is pointing towards the
clamping screws
2. Check that the blade is centred in the slot and is fully inserted. This is es-
sential in order to enable correct rebating and to prevent the blade coming
into contact with the drum guard – this may break the guard and cause an
injury
3. Now re-fit the blade clamp. Ensure that it is facing the correct way and
that it sits square in the drum
4. Tighten the Clamping Screws (15) evenly as follows:
a. Tighten the two outside clamping screws snug tight, then the middle
screw
b. Working in the same order, fully tighten all three screws
5. Loosen the vice and rotate the drum to repeat the above procedure to fit the
other two blades
REFITTING THE BLADE DRUM
1. Place the planer on its side
2. Raise the Drum Guard (17)
3. Slide the Blade Drum (16) onto the spindle and into the housing
4. Press in the Drum Spindle Lock Button (26) and rotate the Drum (16)
until it is locked in place. Continue to hold the lock button until you have
secured the drum in position
Note: the blade drum has two lock out positions
5. Re-insert the large washer, adjusting its
position so that it engages onto the end of
the spindle
6. Insert the smaller washer followed by the
hex head screw
WARNING: If the larger washer is not
correctly orientated the drum cannot be
firmly secured.
7. Use the Hex Key (13) to fully tighten the
hex head screw to secure the drum in position
8. Release the spindle lock and close the drum guard
7
GB
CORRECT SETTING OF BLADES
It is essential that the blades are set correctly or the workpiece will end up
rough and uneven. For a clean, smooth cut, the blades must be mounted so
that the cutting edge is absolutely level. i.e. parallel to the surface of the rear
base (b)
Nicks in surface
The cutting edge of one or all blades is not parallel to the rear base
Gouging at start
One or all blades are not protruding enough in relation to the rear base
Gouging at end
One or all blades protrude too far in relation to the rear base
FITTING THE SANDING DRUM
• A Triton Sanding Drum (24) and sanding
sleeve are supplied for use with this tool.
You can convert the Triton Unlimited Rebate
Planer into a sander by fitting the sanding
drum in place of the blade drum
• Replacement sanding sleeves are available
from your Triton retailer (Part no. TRPSS)
(a) (b)
Before Use
• Using the sanding drum and sleeve, this
tool is ideal for quickly removing a large
amount of material
• Do not use this sander for sanding steel or
magnesium
Fitting a sanding sleeve
The sanding drum is supplied in two sections.
Separate the two sections in order to fit or
remove a sanding sleeve
1. Ensure all the rubber ‘O’ rings are in place
2. Slide the sanding sleeve fully onto the
larger section of the sanding drum (Note: it
will only fit on one way)
3. Insert the smaller section of the sanding
drum into the sanding sleeve and align
so that the groove in the inner ring of the
smaller drum section fits over the nib on
the spigot of the larger section
Fitting the sanding drum in the tool
• Always ensure that the tool is switched
off and unplugged from the power supply
beforeinstalling or removing a drum
• To fit or remove the sanding drum, use
the same method as set out above for
‘Removing the Blade Drum’ and ‘Refitting
the Blade Drum’
PARALLEL FENCE GUIDE
1. Fit the Parallel Fence Guide (23) using the
fixing angle and the Parallel Fence Attach-
ment Knob (22)
2. When set at right angles to the planer base,
the fence provides a guide to help control
the planing action
8
GB
OPERATION
SWITCHING ON AND OFF
WARNING: Before plugging the machine into
the power socket always check that the On/
Off Trigger Switch (5) and Lock-Off Button (6)
work properly
1. Plug in the machine and grip the tool with
your index finger on the on/off trigger
switch and thumb on the lock-off button
2. Depress the lock-off button with your
thumb and squeeze the on/off trigger
switch with the rest of your hand gripping
the tool. You can release the lock-off
button once the planer has started
3. To stop the tool, release the thumb hold on
the on/off trigger switch
4. In order to restart the machine, it is
necessary to operate both the lock-off
button and the on/off switch
WARNING: Please note that the planer blades
continue to turn for some time after switching off the planer. Wait until the
motor has completely stopped before setting down the tool to prevent damage
to the planer blades or the surface
If you wish to rest the planer on its side, do not rest it on the side with the
vents to prevent dust or chips from getting into the motor
5. When the planer is not to be used for a short period, set the depth control
knob to the ‘P’ position and rest the front of the planer on a block of wood
to keep the base clear of the surface. Ensure that the rear parking foot is
down to protect blades
ADJUSTING THE SPEED
The speed of the drum can be adjusted to suit the
material being planed or sanded.
Use the Variable Speed Control (25) to adjust the
speed for the job in hand.
Note: For planing it is recommended to have
the planer running at full speed to obtain
the cleanest possible result. When sanding,
the speed should be set from 1-6; on ‘MAX’
(maximum speed), the unit will vibrate and be
hard to hold.
ADJUSTING THE DEPTH OF CUT
1. Rotate the Depth Adjustment Dial (1) clock-
wise for a deeper cut and anticlockwise for
a shallower cut
2. The calibrations on the ring under the Depth
Adjustment Dial indicate the depth of cut.
For example, when “1” is next to the pointer
on the front of the planer, the depth of cut is
approximately 1mm
3. If depth of cut is critical, plane a scrap
piece of wood, measure the difference in
thickness and adjust the setting as needed
PLANING
1. Rest the front of the planer on the work-
piece, ensuring the blades are not in contact
with the workpiece
2. Switch on the tool and wait for the blades to
reach full speed
3. Move the planer gently forward, applying pressure on the front of the tool
at the start of planing, and pressure at the rear of the tool towards the end
of the planing stroke
Note: As a feature this planer has been fitted with a larger front handle than
traditional electric planers. The front handle provides for good ergonomics
when planing, allows the operator to balance and control the unit with ease
and is particularly useful when vertical planing
4. Push the planer beyond the edge of the workpiece without tilting it
downwards
1 2
Operation
Note: Planing is easier if you incline the
workpiece slightly away from you so that you
plane 'downhill'
5. The rate of planing and the depth of cut
determine the quality of the finish. For
rough cutting, you can increase the depth
of cut, however to achieve a good finish
you will need to reduce the depth of cut
and advance the tool more slowly
WARNING: Moving the machine too fast may
cause a poor quality of cut and can damage
the blades or the motor.Moving the machine
too slowly may burn or mar the cut. The proper
feed rate will depend on the type of material
being cut and the depth of the cut. Practice
first on a scrap piece of material to gauge the
correct motion
WARNING: Always use two hands to hold the
planer
WARNING: Where possible, clamp the workpiece to a workbench
6. In between operations, you can rest the planer on a flat surface with the
Rear Parking Foot (19) hinged down to support the planer so that the
blades are kept clear of the surface. Ensure the rear parking foot has
been moved across from the locked position (for transit) to the automatic
position
CHAMFERING
1. To make a chamfered cut as shown in fig.1, First align the 'V' groove
(fig.2) in the front base of the planer with the corner edge of the work-
piece.
2. Run the planer along the corner edge.
Fig. 1. Chamfered edge.
Fig. 2. Aligning the 'V' groove
FULL/UNLIMITED REBATING
The planer has an unlimited rebating capa-
bility. When operating the planer to achieve a
full rebate, adhere to all instructions below:
1. Using the thumb on the hand gripping
the Front Handle (2), push the Drum
Guard Release lever (3) down to raise
the Drum Guard (17) to expose the Blade
Drum (16). This enables full unlimited
rebating
2. Run the planer along the workpiece
3. Once you have finished planing the section take the pressure off the
Drum Guard Release Lever (3) and check the drum guard fully covers the
blade drum
WARNING: Do not raise the drum guard if you are not performing a full/
unlimited rebate application
WARNING: If the drum guard does not close completely, stop using the tool
immediately and have the unit serviced by a qualified service agent. If you use
the product with a defective blade drum guard the manufacturer will not be
held liable for any damage or personal injury caused.
Note: Do not apply too much force on the lever, excess pressure may cause
blade guard to break.
9
GB
Operation / Maintenance / Guarantee
GUARANTEE
To register your guarantee visit our web site at
www.tritontools.com* and enter your details.
Your details will be included on our mailing list (unless indicated otherwise) for
information on future releases. Details provided will not be made available to any
third party.
PURCHASE RECORD
Date of Purchase:
Model: TRPUL
Serial Number:_________________________ (located on motor housing)
Retain your receipt as proof of purchase
Triton Precision Power Tools guarantees to the purchaser of this
product that if any part proves to be defective due to faulty materials
or workmanship within 12 MONTHS from the date of original
purchase, Triton will repair, or at its discretion replace, the faulty part
free of charge.
This guarantee does not apply to commercial use nor does it extend
to normal wear and tear or damage as a result of accident, abuse
or misuse.
* Register online within 30 days of purchase.
Terms & conditions apply.
This does not affect your statutory rights
SANDING
To use this tool as a sander, fit the sanding
drum and sleeve designed for this tool. See
‘Fitting the Sanding Drum’
Replacement sanding sleeves are available
from your Triton retailer (Part no. TRPSS)
• Wear safety goggles, a dust mask and
earmuffs
4. Check that the sanding drum and
sanding sleeve are in good condition and fixed securely
5. IMPORTANT: Set the planing Depth Adjustment Dial (1) to the ‘O’ height
setting
6. Use the Variable Speed Control (25) to set an appropriate speed 1 - 6. Do
not use the MAX setting as this will cause the sander to vibrate
7. Depress the Lock-Off Button (6) and squeeze the On/Off Trigger Switch
(5). Allow the motor to reach the set speed before bringing the sander into
contact with the workpiece
8. Sand with the grain, in parallel overlapping strokes.
9. Adjust the variable speed dial as required
10. To remove paint or smooth very rough wood, sand across the grain at 45º
in two directions, and then finish the parallel with the grain
11. Lift the sander off the workpiece before switching it off
• Remember to keep your hands away from the moving sanding drum, as it
will continue to move for a short time after the machine is switched off
Note: After sanding with a drum sander, use of an orbital sander is recom-
mended to achieve a smoother finished surface
DUST/SHAVINGS EXTRACTION
1. Connect the Dust/Chip Adaptor Tube (21) to the Dust/Chip Extraction Port
(10)
2. The adaptor tube can be installed to allow shavings to flow either to the
left or to the right of the workpiece
3. Use the Dust Diverter Guide Switch (9) to
select the Dust/Chip Extraction Port (10).
Swing the lever across to close the port
you do not want to use
4. A workshop dust extraction system or
a household vacuum cleaner can be
connected to the adaptor tube for the
efficient removal of dust and shavings,
permitting a safer and cleaner working
environment
MAINTENANCE
WARNING: Always ensure that the tool is switched off and the plug
is removed from the power point before making any adjustments or
maintenance procedures.
GENERAL INSPECTION
• Regularly check that all the fixing screws are tight. They may vibrate loose
over time
• Inspect the supply cord of the tool, prior to each use, for damage or wear.
Repairs should be carried out by an authorised Triton service centre. This
advice also applies to extension cords used with this tool
DRIVE BELT REPLACEMENT
It is suggested that you wear leather gloves to change the belt in case you
make contact with the blades
1. To replace the drive belt first take out the five crosshead screws that
secure the drive belt cover on the left-hand side of the planer as viewed
from the rear
2. Remove the damaged belt and use a soft brush to clean the pulleys and
the surrounding area
Note: Wear eye protection when cleaning out the pulley area.
3. With the four continuous ‘V’ profiles on the inside, place the new belt over
the bottom pulley
Half fit the other end of the belt on the top pulley then roll the belt in place
whilst turning the pulley
4. Check that the belt runs evenly by manually turning the belt
5. Replace the cover and the five fixing screws
6. Connect the tool to the power supply and run the planer for a minute or
two to make sure that the motor and belt are operating correctly
CLEANING
WARNING: ALWAYS wear protective equipment including eye protection and
gloves when cleaning this tool.
• Keep your tool clean at all times. Dirt and dust will cause internal parts to
wear quickly, and shorten the device’s service life
• Clean the body of your machine with a soft brush, or dry cloth
• Never use caustic agents to clean plastic parts. If dry cleaning is not
sufficient, a mild detergent on a damp cloth is recommended
• Water must never come into contact with the tool
• Ensure the tool is thoroughly dry before using it
• If available, use clean, dry, compressed air to blow through the ventilation
holes (where applicable)
LUBRICATION
• Lubricate all moving parts with a suitable lubricant spray, at regular
intervals
STORAGE
• Store this tool carefully in a secure, dry place out of the reach of children
DISPOSAL
Always adhere to national regulations when disposing of power tools that are
no longer functional and are not viable for repair.
• Do not dispose of power tools, or other waste electrical and electronic
equipment (WEEE), with household waste
• Contact your local waste disposal authority for information on the correct
way to dispose of power tools
RU
10
10
11
11
13
13
13
13
16
17
TRPUL
1
PA:
:
h2
h
2
2
RU
11
ь
!
12
RU
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
13
RU
•
•
!
14
RU
.
(a) (b)
12
3
15
RU
16
RU
1.
1.
2.
3.
1 2
•
17
RU
•
•
•
•
•
•
•
18
UA
18
19
19
21
21
21
21
23
25
25
TRPUL
5,000 – 15,500min-1
1
2
2
2
19
UA
Other manuals for TRP UL
3
Table of contents
Languages:
Other Triton Planer manuals
Triton
Triton TRP UL Quick guide
Triton
Triton TCMPL Assembly instructions
Triton
Triton TR208537 Assembly instructions
Triton
Triton TSPL 152 Assembly instructions
Triton
Triton TPL180B Assembly instructions
Triton
Triton TCMPL Quick guide
Triton
Triton TPL180 Quick guide
Triton
Triton TPT 125 Quick guide
Triton
Triton TRP UL Quick guide
Triton
Triton TPT 125 User manual
Triton
Triton TRP UL Quick guide
Triton
Triton TMNPL Assembly instructions
Triton
Triton TCMPL Quick guide
Triton
Triton TPL180 Quick guide
Triton
Triton TCMPL Assembly instructions
Triton
Triton TPL180 Assembly instructions
Triton
Triton TR210143 Quick guide
Triton
Triton TPL180 Assembly instructions
Triton
Triton TPT 125 Quick guide
Triton
Triton EPA 001 Quick guide
