Scotsman SCCG30 User manual

Introduction:
This ice machine is the result of Scotsman’s
decades of experience as an industry leader in the
design and manufacture of both commercial and
residential ice machines.
This manual includes the information needed to
install, start up and maintain the ice machine. Note
any Caution or Warning indicators, as they provide
notice of potential hazards. Keep this manual for
future reference.
September 2009
Page 1
SCCG30 & SCCP30
Service Manual
Table of Contents
Specifications .......................................... Page 2
Cabinet Layout ......................................... Page 3
Air flow ............................................. Page 4
Water Quality .......................................... Page 5
Door Covering .......................................... Page 6
Door Panel Attachment ..................................... Page 7
Custom Panel .......................................... Page 8
Door swing change ....................................... Page 9
Installation: Water & Drain ................................... Page 10
Gravity Drain .......................................... Page 11
Electrical ............................................ Page 12
Cube Size Adjustment ..................................... Page 13
Harvest Time Adjustment .................................... Page 14
Control Settings ......................................... Page 15
Use ............................................... Page 16
How to clean the condenser and winterize. ........................... Page 17
How to remove scale from the ice making system. ....................... Page 18
System Information ....................................... Page 19
Water System .......................................... Page 20
Components .......................................... Page 21
Controller ............................................ Page 22
Performance Information .................................... Page 23
Refrigeration System ...................................... Page 24
Thermistor Values ........................................ Page 25
Service Diagnosis ........................................ Page 26
Service Diagnosis ........................................ Page 27
Removal and Repair ...................................... Page 28
Removal and Repair ...................................... Page 29
Removal and Repair - Cabinet Removal ............................ Page 30
Refrigeration Service ...................................... Page 32

Specifications
This ice machine is designed to be used indoors, in
a controlled environment. It can be used in a wide
variety of environmental conditions, but there are
limits. Use outside of the listed limitations is misuse
and will void the warranty.
Air temperature limits:
The ice machine will operate adequately within the
limits, but functions best in temperatures between
70 and 80 degrees F.
•Minimum – 50 degrees F. (10oC)
•Maximum – 100 degrees F. (38oC)
Water temperature limits:
•Minimum – 40 degrees F. (4.5oC)
•Maximum – 100 degrees F. (38oC)
Water pressure limits:
•Minimum – 20 psi (1.4 bar)
•Maximum – 80 psi (5.5 bar)
Because the ice machine is making a food product,
the water supply to the ice machine must be
potable, or fit for human consumption.
Electrical
•115 volt, 60 Hz. Plug into dedicated 15 amp
circuit.
•Power consumption: 400-180 Watts. Varies
during Freeze and Harvest cycles.
Voltage limits:
•Minimum - 104 volts
•Maximum – 126 volts
Options:
Door Panel kits:
Finished door panels are available from Scotsman
for attachment to the machine, or a custom panel
can be made.
Kit Number Panel Finish Handle Finish
KDFS Stainless Steel Stainless Steel
Drain Conversion:
A gravity drain model can be converted to a drain
pump model by installing a drain pump kit. The
drain pump kit consists of a drain pump, wiring
harness and associated tubing. The kit number is
A39462-021.
Warranty Information
Warranty information is supplied separately from
this manual. Refer to it for coverage. In general, the
warranty covers defects in materials or
workmanship and does not cover corrections of
installation errors or maintenance.
September 2009
Page 2
SCCG30 & SCCP30
Service Manual
Models: There are six models, all air cooled:
•SCCPA30M-1SU – Pump model, stainless cabinet
•SCCGA30M-1SU – Gravity drain model, stainless cabinet

Cabinet Layout
September 2009
Page 3
SCCG30 & SCCP30
Service Manual
14 7/8"
AIR IN
AIR OUT
.75 SHEET METAL DOOR FRONT
.63 MIN. CABINET DOOR
29 1/4"
1" LEG ADJUSTMENT
(4) PLACES
33 3/8" MIN.
34 3/8" MAX.
22"
2 3/4"
4"
3 3/4"
1 1/2"
2 1/2" 3 1/4"
7 3/8"
115 V
POWER CORD
DRAIN
FLEXIBLE TUBING
3/8 I.D.PUMP MODEL (INCLUDED)
5/8 I.D.GRAVITY MODEL (NOT INCLUDED)
POTABLE WATER INLET
1/4" COMPRESSION FITTING
3 7/8"
20 3/8"
FLOOR DRAIN
ACCESS HOLE

Air flow
The machine takes in room temperature air at the
lower right front and forces warm air out the lower
left front. Restricting the airflow will adversely affect
the ability of the ice machine to make ice.
Scotsman Ice Systems are designed and
manufactured with the highest regard for safety
and performance. They meet or exceed the
standards of agencies like U.L.
Scotsman assumes no liability or responsibility of
any kind for products manufactured by Scotsman
that have been altered in any way, including the
use of any parts and/or other components not
specifically approved by Scotsman.
Scotsman reserves the right to make design
changes and/or improvements at any time.
Specifications and designs are subject to change
without notice.
September 2009
Page 4
SCCG30 & SCCP30
Service Manual
Air Intake
Warm Air Out
On/Off Switch
Ice Making
Area

Water Quality
All water, including potable water supplied by
municipalities, contains some impurities or
minerals. Water absorbs impurities from the air as
rain and/or as it flows through the ground. Some of
the impurities are solid particles, these are known
as suspended solids, and a fine particle filter will
remove them. Other impurities are chemically
bonded to the water molecules, and cannot be
filtered out, these are called dissolved solids.
Ice made by this machine will have a lower mineral
content than the water it was made from. This is
due to the method of making ice. Purer water will
freeze first in the ice making molds. The reason for
this is that anything dissolved in water lowers the
water’s freezing temperature. This concentrates
most of the impurities in the ice machine water
reservoir where they may form hard deposits
known as scale. The machine dilutes the
concentration of minerals by over-filling the
reservoir during the harvest cycle (with the excess
water flowing down the drain). s. Between 2 and 4
pints of water flow into the unit each cycle.
Between 1 and 3.5 pints of that rinses the reservoir
and goes down the drain.
Some impurities will inevitably remain, and will stick
to the parts in the machine, and will cause
malformed ice cubes. Eventually, built up mineral
scale can shorten machine life.
To keep the machine operating properly, these
impurities or minerals will have to be regularly
dissolved by an acid cleaning, using Scotsman Ice
Machine Scale Remover. Directions for this may be
found in the section under cleaning.
Filters and Treatment
In general, it is always a good idea to filter the
water. A water filter, if it is of the proper type, can
remove taste and odors as well as particles. Some
methods of water treatment for dissolved solids
include reverse osmosis, and polyphosphate
feeders.
RO Water
This machine can be supplied with Reverse
Osmosis water. A reverse osmosis system should
include post treatment to satisfy the R.O. water’s
potential aggressiveness. Deionized water is not
recommended.
Because water softeners exchange one mineral for
another, softened water may not improve water
conditions when used with ice machines. Where
water is very hard, softened water could result in
white, mushy cubes that stick together.
If in doubt about the water, contact a local point of
use water specialist for recommendations on water
treatment.
Installation Overview
The ice machine must:
•be connected to cold, potable water
•be connected to a drain
•be connected to the proper power supply
•be able circulate air through the vents at the
front.
Note: Do not build in so that the door is recessed.
September 2009
Page 5
SCCG30 & SCCP30
Service Manual

Door Covering
Door Panel
The ice machine is supplied without a conventional
door covering so it can be decorated to the user’s
preference. Scotsman offers several coverings
including white, black and stainless steel. In
addition, a custom built panel can be placed onto
the door.
Door Panel Attachment
To attach a Scotsman supplied panel:
Note: If door swing is to be changed, it must be
done before panel is attached.
The panel will be held on by 6 sheet metal screws
and 2 machine screws.
1. Remove the gasket and retain for later use.
2. If the door panel is stainless steel, remove any
plastic covering the stainless steel panel.
3. Place the panel onto the outside of the door,
and secure it to the door using two machine
screws, located at the left center and right
center.
4. Fasten the panel to the door using the 6 sheet
metal screws. In the hinge area, use the
outermost screw holes.
5. Place the covers over the hinge areas, and
secure each cover to the door using a sheet
metal screw.
6. Insert hole plug over screw installed in step 5.
7. Return the gasket to its original position.
Custom Panel
A custom panel of wood or other material not
exceeding 15 lb can be attached to the door.
Attachment is from the ice side of the door. Holes
are provided in the door for this purpose.
See instructions in information packet to create and
attach a custom panel:
September 2009
Page 6
SCCG30 & SCCP30
Service Manual

Door Panel Attachment
September 2009
Page 7
SCCG30 & SCCP30
Service Manual
Gasket
Scotsman
Door Panel
Cover
Machine
Screw
Use Upper
Hole at the
Top
Use Lower
Hole at the
Bottom
Hole Plug

Custom Panel
A custom panel of wood or other material not
exceeding 15 lb can be attached to the door.
Attachment is from the ice side of the door. Holes
are provided in the door for this purpose.
To create and attach a custom panel:
•Panel width: 14 7/8”
•Panel height: Between 29 3/8” and 30 3/8”.
•Panel thickness: 5/8” to ¾”
1. Measure overall height of cabinet
opening where ice machine will be
(floor to bottom of countertop edge).
2. Determine desired kickplate
space (from bottom of door to floor).
This could be equal to the adjacent
cabinet’s kickplate space or another
space the user wants.
3. Subtract kickplate space from
cabinet opening.
4. Subtract 1/8 or more for clearance
space between top of door and
bottom of countertop edge from
cabinet opening. This is the
maximum door length.
5. Cut panel to width.
6. Cut panel to length (cabinet space
- kickplate space - top clearance =
length).
7. Determine top of panel.
8. Mark hole locations using drawing
on the back of these instructions.
Drawing assumes top of panel will
be flush with top of door. Measure
hole locations from the top of the
panel.
9. Drill pilot holes for wood screws.
Use drill stop to prevent drilling
through the panel.
10. Mount panel to door using wood screws or
supplied panel mounting screws.
Note: When installed Ice machine must be adjusted
for height to position top of door to desired
clearance.
September 2009
Page 8
SCCG30 & SCCP30
Service Manual
Ø 1/8"
TYP. (10)
13/16"
13/32"
4 1/8"
6 25/32"
14 11/16"
13 31/64"
13/32"
8 1/4"
13 9/16"
14 7/8"
30 3/8"
29 3/8"
{Centerline}

Door swing change
The door can be attached to open with hinges on
the left or right using new brackets shipped loose in
the ice bin. Retain all screws for re-use.
To change:
1. Remove innermost
screw holding each
hinge to cabinet, loosen
the other.
2. Slide hinges to the side
and remove door from
cabinet. Remove
screws loosened in step
1 from both hinge brackets.
3. Remove two screws securing top panel to
back, pull top panel back and remove from
cabinet.
4. Remove two screws at
the top and lift the door
hinge bracket out of the
cabinet. Replace with the
one supplied loose with
the machine. Fasten it to
the cabinet using the
original screws.
5. Return the top panel to the cabinet and fasten
it with the original screws.
6. Remove kickplate and front service panel.
7. Remove two front screws and two bottom
screws holding the bottom cross brace to the
cabinet. Replace the brace with the one
supplied loose with the machine. Secure it
using the original screws.
Note: If door panel is installed it must be removed
to access hinge screws and to reverse handle
position.
8. Remove the upper hinge and move it to the
door's opposite side, bottom location. Secure
using the original screws.
9. Remove the original lower hinge and move it to
the door's opposite side, upper location.
Secure using the original screws.
10. Install a screw removed in step 2 in outermost
hole of upper and lower cross braces.
11. Attach the door to the cabinet using the original
screws.
12. Return kickplate and front service panel to their
original positions and attach to the cabinet
using the original screws.
Installation Notes
Built In Situations: If a finished floor is to be
installed in the area after the ice machine has been
built in, shims the expected thickness of the floor
should be installed under the unit to keep the
machine level with the planned floor level.
Installations on a slab: Use a pump model and
pump the water to the point of drainage. Pump
models will pump 1 story (10 feet) high.
Installations over a crawl space or basement:
Either gravity drain or pump model units may be
used, if there is not enough room behind the
machine for a drain/waste receptacle, the drain will
have to be below the floor.
Note: When installed in a corner, the door swing
may be limited due to handle contact with the wall
or cabinet face.
September 2011
Page 9
SCCG30 & SCCP30
Service Manual
Screw Below
Door Hinge
Bracket

Installation: Water & Drain
Water Supply, all models: The recommended water
supply tubing is ¼ inch OD copper. Stainless steel
flex or reinforced PVC tube may also be used.
Install an easily accessible shut-off valve between
the supply and the unit. This shut-off valve should
not be installed behind the unit.
Note: Do not use self-piercing type valves.
1. Remove the front service panel.
2. Route the tubing
through the right
hole in the back to
the inlet water
solenoid valve inlet
at the front.
3. Install a
compression fitting
on the tubing and
connect to the inlet
of the solenoid.
Note: Do NOT connect water to tubing at the back,
the water inlet connection is at the front.
Drains
There are two types of ice machine models, one
that drains by gravity and one that has an internal
drain pump.
Drain Pump Model drain installation
1. Locate the coil of 3/8” ID plastic drain tubing
secured to the back of the unit.
2. Route the plastic drain tube from the back of the
unit to the drain connection point.
IMPORTANT NOTE: Often an air gap is required by
local codes between the ice maker drain tube and
the drain receptacle.
September 2011
Page 10
SCCG30 & SCCP30
Service Manual
Back View, Drain Pump Model
Water Inlet
Tube (field
supplied)
Drain Tube,
Route to
building drain
Screw Securing Front
Service Panel
Connect Water Here

Gravity Drain
Caution: Restrictions in the drain system to the
machine will cause water to back up into the ice
storage bin and melt the ice. Gravity drain tubing
must be vented, have no kinks and slope to the
building drain. Air gaps are typically required by
local code.
1. Place the ice machine in front of the installation
opening. Adjust leveling legs to the approximate
height.
2. Remove the front service access panel and the
upper back panel.
Note: If you are connecting a gravity drain model
and the drain opening has been located in the floor
under the base pan according to the pre install
specifications, follow steps 3 through 5 to drain the
unit through the base. If not, proceed to step 6b.
3. Remove the clamp and barbed elbow and take
off the plastic cover in the base pan below the drain
hose.
4. Connect a straight 5/8” barbed connector to the
drain hose, securing with the clamp removed in
step 4.
5. Cut an 8” piece of 5/8” ID X 7/8” OD tygon (clear
plastic) tubing. Slide one end of the tube onto the
outlet of the barbed connector and secure with a
clamp. Leave the other end of the tube lying on the
floor of the base pan until the unit is positioned
over the floor drain.
6. Route the drain tube. Either a) Insert the drain
tube through the base pan into the floor drain or b)
Route the drain tube through the left hole in the
lower back panel and connect to barbed elbow and
secure with a clamp.
7. Reinstall the upper back panel.
8. Reinstall the service access panel. Level the
unit.
September 2009
Page 11
SCCG30 & SCCP30
Service Manual
Back View, Gravity Drain Model
Water Inlet
Tube (field
supplied)
Drain Hose Barbed Elbow
Drain Hose,
Route to
building drain

Electrical & Start Up
The ice machine is supplied with a power cord. Do
not remove the grounding pin from the cord’s plug.
Do not use extension cords. Follow all codes.
Connect the machine to its own 115 volt, 15 amp
circuit.
1. If the electrical outlet for the ice maker is
behind the unit, plug in the unit.
2. Position the unit in the installation opening.
3. Turn on the water supply. Make sure that the
ice maker is plugged in and the power is on.
4. Slide unit into installation opening, paying
careful attention to water supply and drain
connections. Do not kink!
5. Pour a couple of quarts of water into the ice
storage bin; on drain pump equipped machines
the drain pump should start and water should
pump out. Check for leaks.
6. Replace the service access panel.
7. Level the unit as needed.
Installation check list:
1. Has the unit been connected to the proper
water supply?
2. Has the water supply be checked for leaks?
3. Has the unit been connected to a drain?
4. Has the drain been tested for flow and leaks?
5. Has the unit been connected to the proper
electrical supply?
6. Has the unit been leveled?
7. Have all packing materials been removed from
the machine?
8.Has the door covering been installed?
Initial Start Up
1. Turn on the water supply.
2. Switch on the electrical power.
3. Move the On/Off switch to the ON position.
4. The compressor will start and water will begin
to flow into the unit. When the reservoir is full,
water will start to drain from the machine. After
a few minutes the water pump and fan motor
will begin to operate and the first ice making
cycle will have begun.
No adjustments are needed.
After about a half hour, ice will fall into the ice
storage bin. The machine makes 12 cubes per
batch. It is normal for the first batches of ice to
melt, that continues until the bin has cooled. It will
take 16 to 24 hours of continuous run time to fill the
ice bin. When the bin is full of ice, the ice machine
will shut off. It will automatically restart when the
ice level falls, either from use or normal meltage.
September 2009
Page 12
SCCG30 & SCCP30
Service Manual

Cube Size Adjustment
The size of the ice cubes is determined by how
long the ice machine is in the freezing cycle. That
is controlled by the cube size thermostat.
The cube size thermostat's sensing portion is
attached to the suction tube, near the outlet of the
evaporator. As the machine makes ice, the
temperature of the suction tubing falls. When it
reaches a preset point, the thermostat's contacts
close and connect power to the electronic timer.
The electronic timer finishes the freeze cycle.
Adjustment
There is only one proper ice cube size, see the
diagram to the right. If the cubes are not the correct
size, adjust the cube size thermostat.
Rotate the cube size thermostat's adjustment
screw clockwise to increase the size of the cube.
Rotate the cube size thermostat's adjustment
screw counter clockwise to make the ice cube size
smaller.
September 2009
Page 13
SCCG30 & SCCP30
Service Manual
Too Small, Adjust Cycle Longer
Side Views of Cubes
Just Right
Too Large, Adjust Cycle Shorter

Harvest Time Adjustment
The harvest time can be adjusted so that all the ice
is released during the harvest period, with a few
seconds extra for a safety margin. The adjustment
range is between 2 to 5 minutes.
There is an adjustment screw on the surface of the
electronic timer. Rotate the screw CCW to reduce
harvest time, and CW to increase it. It should be
set to match the machine's performance. If the
machine takes 2 and a half minutes to release the
ice, the harvest time should be set to about 3
minutes.
September 2009
Page 14
SCCG30 & SCCP30
Service Manual

Use
No special instructions are needed for use. Just
take as much ice as you need, the machine will
replace it. A scoop is provided, and it can be stored
in the machine using the loop of tubing on the right
side as a holder.
The machine can be shut off anytime by moving
the On/Off switch to OFF.. The machine will shut
off immediately.
What shouldn’t be done?
Never keep anything in the ice storage bin that is
not ice. Objects like wine or beer bottles are not
only unsanitary, but the labels can slip off and plug
up the drain.
Never allow the machine to operate without regular
cleaning. The machine will last longer if it is kept
clean. Regular cleaning should happen at least
once per year, and preferably twice. Some water
conditions will dictate even more frequent cleaning
of the ice making section, and some carpets or
pets will dictate more frequent cleaning of the
condenser.
Noise:
The ice machine is designed for quiet operation,
but will make some noise during the ice making
cycle. During a freezing cycle, it is normal to hear
the fan moving air and the water pump circulating
water. Ice hitting the bin or ice in the bin can be
heard during harvest.
If ice making noise is objectionable, an appliance
grade timer can be added to the power supply. Set
the timer to turn the machine off at the time(s) of
day when the noise is most objectionable.
Maintenance
There are 5 things to keep clean:
1. The outside cabinet & door.
2. The ice storage bin.
3. The condenser.
4. The ice making system.
5. The ice scoop.
How to clean the cabinet.
Wipe off any spills on the surface of the door and
handle as they occur. If anything spilled on the
door or gasket dries onto the surface, wash with
soap and warm water to remove.
How to clean the ice storage bin.
The ice storage bin should be sanitized
occasionally. It is usually convenient to sanitize the
bin after the ice making system has been cleaned,
and the storage bin is empty.
A sanitizing solution can be made of 1 ounce of
household bleach and two gallons of hot (95oF. –
115oF.) water. Use a clean cloth and wipe the
interior of the ice storage bin with the sanitizing
solution, pour some of the solution down the drain.
Allow to air dry.
September 2009
Page 15
SCCG30 & SCCP30
Service Manual
Normal cubes are tapered cylinders. If the cubes
are ragged and mis-shaped, mineral scale must be
removed from the ice making system

How to clean the condenser and winterize.
Condenser cleaning
The condenser is like the radiator on a car, it has
fins and tubes that can become clogged with dirt
and lint. To clean:
1. Remove the kickplate and front service panel.
2. Locate the condenser surface.
3. Vacuum the surface, removing all dust and lint.
Caution: Do not dent the fins.
4. Return the kickplate and front service panel to
their original positions. Fasten them to the cabinet
using the original screws.
Winterizing
1. Clean the ice making system.
2. Open the door and push and release the On/Off
switch to turn the machine off.
3. Turn off the water supply.
4. Drain the water reservoir by removing the rubber
cap under the reservoir - it's near the back wall of
the ice storage bin.
5. Disconnect the incoming water line at the inlet
water valve.
6. Open the door, push and release the on/off
switch to turn the machine on.
7. Blow air through the inlet water valve; a tire
pump could do the job.
8. Drain pump models should have about 1/2
gallon of RV antifreeze (propylene glycol) poured
into the ice storage bin drain.
Note: Automotive antifreeze must NOT be used.
9. Switch off and unplug the machine.
September 2009
Page 16
SCCG30 & SCCP30
Service Manual
Rubber Cap

How to remove scale from the ice making system.
1. Scoop out all of the ice, either discard it or save
it in an ice chest or cooler.
2. Switch the machine Off.
3. Pour 8 ounces of Scotsman Ice
Machine Scale Remover
(available from a local Scotsman
Distributor or Dealer) into the ice
machine reservoir.
4. Switch the machine On.
5. Operate the machine for about
2 hours.
6. Pour a gallon of hot (95oF. –
115oF.) water into the bin to melt
ice formed during the cleaning
process and to flush out the drain.
7. Clean the bin liner of mineral
scale by mixing some ice machine
scale remover and hot water, and
using that solution to scrub the
scale off of the liner.
8. Rinse the liner with hot water.
9. Sanitize the bin interior.
10. Replace the ice removed in step 1.
The ice scoop should be washed regularly, wash it
just like any other food container.
September 2009
Page 17
SCCG30 & SCCP30
Service Manual
Pour Scale
Remover Here

System Information
Overall:
•Refrigerant: 8 oz R-134a
•Compressor: Hermetic, 700 BTUH
•Condenser: Forced draft
•Fan blade: 3 blade, 6 inch
•Evaporator: Inverted, 12 cube cells. copper,
continuous serpentine
•Metering device: Cap tube
•Defrost method: Hot gas bypass with water
assist
•Spray method: 6 water jets
•Water charge: 30 ounces
•Water valve: 115 volt solenoid, .19 GPM
•Water fill time: Varies with harvest time
•Spray pump: Pedestal type.
•Drain pump: Magnetic drive, controlled by
pressure switch
•Purge method: Overflow standpipe
•Control method: Electronic timer with electro
mechanical cube size thermostat
•Cycle control: Reverse acting thermostat
•Cube size adjustment: Thermostat cut in
change
•Harvest cycle adjustment: Harvest timer
change, range between 2 and 5 minutes.
•Bin control: Thermostat. Opens on
temperature fall, Cut Out: 35 degrees F. Cut
In 45 degrees F. Range is adjustable.
Electrical Components:
•Compressor
•Fan motor
•Spray pump motor
•Drain pump motor
•Drain pump switch
•Inlet water solenoid valve
•Freeze & harvest timer
•Cube size thermostat
•Hot gas valve
•Bin thermostat
Electrical Sequence:
The machine uses a temperature initiated, timed
cycle to make ice.
A closed bin thermostat connects power to the
compressor and electronic timer. The timer NO
contacts close, connecting power to the water and
hot gas solenoids.
The compressor starts, the inlet water solenoid
valve opens and fills the reservoir. The harvest
timer starts. At the end of the pre-set harvest time,
the timer will open the NO contacts, stopping the
inlet water valve and hot gas valve. At the same
time, it closes the NC contacts, powering the fan
and pump motors. This is the beginning of the
freeze cycle.
The freeze cycle continues until the cube size
contacts close, this starts a freeze timer. No other
changes occur until the freeze timer expires, when
the NC contacts open and the NO contact close,
starting the harvest cycle.
The harvest cycle is time controlled. At the end of
the harvest cycle the unit returns to a freeze cycle.
Bin control.
The machine's on and off modes are regulated by a
bin thermostat. The cap tube for the bin thermostat
is in the tube that holds the scoop. The machine
will only begin ice making when the thermostat's
contacts close. The machine will stop ice making
whenever the bin thermostat contacts open.
September 2009
Page 18
SCCG30 & SCCP30
Service Manual

Water System
The water system consists of a water pump, inlet
water solenoid valve, reservoir with overflow
standpipe and spray platform.
Harvest cycle: The inlet water solenoid valve is
open during the harvest cycle. Water flows through
it to the top of the machine and onto the evaporator
platen. The water flows across the platen, warming
it up to assist in releasing the ice. Water drains
from the platen through drain holes at the platen
corners. That water, now chilled by contact with the
evaporator platen, drains into the reservoir. When
the reservoir is full, excess water drains out the
standpipe. When harvest is complete, the inlet
water solenoid closes and water stops flowing into
the machine.
Freeze cycle: The water pump takes water from
the reservoir and forces it through the 6 spray jets,
causing the water to contact the inverted cups of
the evaporator. Unfrozen water falls back into the
reservoir. As ice forms in the cups, the water level
in the reservoir fails. This continues until the
harvest cycle starts.
September 2009
Page 19
SCCG30 & SCCP30
Service Manual
Freeze Cycle Water Schematic
Harvest Cycle Water Schematic
Pump
Inlet Water Solenoid Valve
Standpipe
Evaporator
Reservoir
Drain

Model and Serial Plate Location
Components
September 2009
Page 20
SCCG30 & SCCP30
Service Manual
Condenser and Bin ThermostatInlet Water Solenoid Valve
Model and
Serial Tag
Location
Bin Thermostat Bracket and Scoop
Evaporator Platen Evaporator & Top of Unit
