Scott Living 1064TW-18-219 Quickspecs

Questions, problems, missing parts?
Before returning to your retailer,
call our customer service department at
1-855-571-1044
8 a.m. - 8 p.m., EST, Monday - Friday.
www.greentouchchinaltd.com
Français p. 11
Español p. 21
Date Purchased _______________________
Dual Zone Wine
Cooler Cabinet
MODEL # 1064TW-18-219
ASSEMBLY, CARE & USE INSTRUCTIONS
ITEM # 0723990
TM
This unit doesn't
include adjusting
levelers

2
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
AWine Cooler Cabinet
(Fully Assembled) 1
A
HARDWARE CONTENTS
AA
PART DESCRIPTION QUANTITY
AA 1
Touch-up Pen

3
INSTALLING (SETTING UP) YOUR WINE COOLER
Unpacking the Wine Cooler Cabinet
• Remove all packing material from the outside and inside of the wine cooler.
• Keep the box and packing materials until you have confirmed all parts are included and the unit
is working properly.
• The product is designed for indoor home use only. It should not be located next to a source of
high heat or in direct sunlight. Do not install your wine cooler cabinet in any location not properly
insulated or climate controlled. e.g. garage, etc.
• Use two or more people to move the unit into place. Failure to do so may result in back injury or
other injury.
• Make sure to place your wine cooler on a floor that is strong enough to support it when fully
loaded.
• Check the power cord for any damage that may have occurred during shipping. If any damage
is detected make sure the unit is unplugged and contact customer service.
• Simply plug the unit into a suitable properlygrounded power outlet (115V ~60H 15A).
Then gently push the cabinet back towards the wall. Make sure to allow approx 10 cm / 4 in
between the cabinet and the wall for proper ventilation of the wine cooler appliance. Wooden
spacer blocks have been designed into the cabinet body to keep the cabinet away from wall at
the proper distance.
• The wine cooler appliance is designed and rated to be built in a cabinet, however proper
ventilation must still be maintained in order to insure the proper function and longevity of the
product.
• The wood cabinet has been designed with strategic opening and vents to allow proper air
ventilation.
• To insure proper air circulation do not overfill the wine cooler appliance.
IMPORTANT: It may take 24 hours for the wine cooler internal temperature to properly adjust.
Please make sure to have 3 to 6 bottles in the unit during this time.
Installation Guidelines
Venting

4
SAFETY INFORMATION
Follow these precautions to reduce the risk of fire, electrical shock or injury when using this appliance.
• Fully read all the instructions before operating this appliance.
• Do not use this appliance for any use other than that which is outlined in this instruction manual.
For indoor household use only. Any other usage may void the warranty.
• Make sure to place the unit on a solid level surface.
• Do not lift or pull the appliance by the plug. Also do not remove the plug from the outlet by pulling on
the cord. Always grasp the plug body when unplugging the unit.
• Do not use a power cord that shows any damage such as cracking, pinching or abrasion or if the plug
is damaged. If the power cord is damaged repair or replace it immediately.
• Before cleaning or repairing your wine cooler make sure it is unplugged or that the power is
disconnected. We strongly suggest you use a qualified servic e technician if service is required.
• Do not clean the appliance with any flammable fluids or products.
• Do not use or store flammable liquids or items that may cause flammable vapors near this appliance
as it could cause a fire or explosion.
• This appliance is designed to store wine bottles. Do not attempt to store perishable foods as the
temperature may not be cool enough to prevent them from spoiling.
• Do not overfill the wine cooler to insure proper air circulation.
• Connect power to a suitable power outlet (115V ~60H 15A) with proper polarization and grounding.
Do not use a three plug adapter or alter the plug in any way. Do not use an outlet that can be turned
off by a switch.
• Use of extension cords is strongly discouraged. It can be hazardous under certain circumstances.
If it is necessary to use an extension cord, use only a 3 wire grounded UL listed type extension cord.
The electrical rating of the cord must be equal to or greater than the electrical rating of the appliance.
ELECTRICAL CONNECTIONS
• A 15-Amp, 115-volt, 60 Hz circuit with a properly grounded outlet is required. Always plug wine cooler
directly into wall outlet/ receptacle. Never use a relocatable tap (outlet/power strip).
• This appliance is for use on 115 volts. The cord has a three prong plug as shown below.
Do not attempt to alter or modify the plug in any way.
Rated Voltage 115V
Rated Frequency 60Hz
Input Power 130W
Upper Zone Temperature 7°C ~ 12°C / 45°F~ 54°F
Lower Zone Temperature 12°C ~ 18°C / 54°F ~ 64°F
Note
The actual cabinet temperature in a thermoelectric unit is dependent upon the ambient room
temperature. The above listed temperatures are approximate and based on an average room
temperature of 25°C or 77°F .
IMPORTANT INSTRUCTIONS
SAVE THESE INSTRUCTIONS
•

5
WINE COOLER CABINET DIAGRAM
DOUBLE INSULATED
CONTROL PANEL
GLASS DOOR
UPPER COOLING
ZONE APPROX
6 BOTTLES
LOWER
COOLING ZONE
APPROX 12 BOTTLES
SAFETY INFORMATION (CONT’D)
!!WARNING DANGER!!
Risk of child entrapment and suffocation. Before you throw away this or any appliance:
A. Remove the doors so children may not become trapped.
B. Leave the shelves in place so that children may not easily climb inside.

6
OPERATING INSTRUCTIONS
F
F
88
F
F
88
F
F
INTERIOR LIGHTS
Press to power the interior lights on or off
UPPER ZONE TEMPERATURE CONTROLS
Use up and down arrows to set the temperature by 1°C or 1°F.
The unit temperature range is from 7°C - 12°C / 45°F - 54 °F.
LOWER ZONE TEMPERATURE CONTROLS
Use up and down arrows to set the temperature by 1°C or 1°F.
The unit temperature range is from 12°C - 18°C / 54°F - 64°F.
CELSIUS OR FAHRENHEIT BUTTON
Press button to toggle between Celsius or Fahrenheit
DETAIL OF CONTROL PANEL
LOWER ZONE
TEMPERATURE
SETTING
UPPER ZONE
TEMPERATURE
SETTING
Wine Storage
This cooler is designed to hold 18 wine bottles. As bottle dimensions can differ in dimensions and size,
the actual number of bottles you are actually able to store may vary.
UPPER ZONE LOWER ZONE
88
F
F
88
88
F
88
F
F
88
88
F
F
88
88
F
F
88
E9
OPERATING INSTRUCTIONS
INTERIOR LIGHTS
Press to power the interior lights on or off
UPPER ZONE TEMPERATURE CONTROLS
Use up and down arrows to set the temperature by 1°C or 1°F.
The unit temperature range is from 7°C - 12°C / 45°F - 54°F.
LOWER ZONE TEMPERATURE CONTROLS
Use up and down arrows to set the temperature by 1°C or 1°F.
The unit temperature range is from 12°C - 18°C / 54°F - 64°F.
CELSIUS OR FAHRENHEIT BUTTON
Press button to toggle between Celsius or Fahrenheit
DETAIL OF CONTROL PANEL
LOWER ZONE
TEMPERATURE
SETTING
UPPER ZONE
TEMPERATURE
SETTING
Wine Storage
This cooler is designed to hold 18 wine bottles. As bottle dimensions can differ in dimensions
and size, the actual number of bottles you are actually able to store may vary.
UPPER ZONE LOWER ZONE
88
F
F
88
88
F
88
F
F
88
88
F
F
88
88
F
F
88
E9
OPERATING INSTRUCTIONS
INTERIOR LIGHTS
Press to power the interior lights on or off
UPPER ZONE TEMPERATURE CONTROLS
Use up and down arrows to set the temperature by 1°C or 1°F.
The unit temperature range is from 7°C - 12°C / 45°F - 54°F.
LOWER ZONE TEMPERATURE CONTROLS
Use up and down arrows to set the temperature by 1°C or 1°F.
The unit temperature range is from 12°C - 18°C / 54°F - 64°F.
CELSIUS OR FAHRENHEIT BUTTON
Press button to toggle between Celsius or Fahrenheit
DETAIL OF CONTROL PANEL
LOWER ZONE
TEMPERATURE
SETTING
UPPER ZONE
TEMPERATURE
SETTING
Wine Storage
This cooler is designed to hold 18 wine bottles. As bottle dimensions can differ in dimensions
and size, the actual number of bottles you are actually able to store may vary.
UPPER ZONE LOWER ZONE

7
CARE AND MAINTENANCE
To Clean the Wine Cooler
Make sure to unplug the wine cooler before performing any cleaning or maintenance.
To Clean and Care For the Wood Cabinet
To Clean and Care For the Stone Top
Power Interruptions or Power Failure
• Turn off the power, unplug the unit and empty all items from the shelves.
• The wire shelves can be washed with a mild detergent.
• The interior of the cooler can be wiped down with a mixture of baking soda and warm water.
The mixing ratio should be approximately one quart of water to two tablespoons of baking soda.
• When wiping down the control panel use only a dampened cloth. If it is too wet the water can
damage the electronic components.
• Never use abrasive or harsh cleaners or scrubbing pads as these can damage the surface and
finishes.
• Do not use flammable liquids to clean the wine cooler as the fumes can cause a fire hazard or
explosion.
• Do not plug or unplug the appliance if you have wet hands.
• Do not allow cleaning solutions to come in contact with the wooden parts of the cabinet.
• Dust the wood cabinet regularly with soft, non-lint producing cloth or household dusting product.
• You will usually want to avoid cleaning wood with water. However, sticky spots may need to be
treated with soap and water. Here’s how: dip the cloth in mild soap or detergent dissolved in
water, wring the cloth nearly dry, and wipe the area. Rinse and immediately dry with a clean, soft
cloth.
• Tips for using included touch up pen: For scratches, stroke in the direction of the scratch. For
worn areas, stroke in the direction of the wood grain. Rub the excess colorant promptly with a
soft clean cloth.
• Most power failures are corrected within a short time such as a few hours and should not affect
the wine coolers temperature as long as you minimize the number of times the door is opened
during the period. If the power outage is expected to last longer it is best to remove the plug from
the outlet and take the necessary actions to protect the contents of the cooler during this time.
Once power is restored you can plug the unit back into the outlet.
• Shade variations and patterns are an inherent characteristic of Stone (e.g. Granite, Marble,
Engineered Stone). Stone Tops will vary from product to product.
• Use caution when placing items on the stone surface such as fragranced soap or alcohol.
• Use a coaster or similar item to protect the surface if placing any alcohol or fragranced products
on the stone.
• If a fragranced or alcohol liquid comes in contact with the Stone Top, rinse the surface with water
and dry using a soft non-abrasive cloth.
• There are Stone Care products available at your local home center store which should be used
periodically to clean and protect the Stone Top. Follow the manufacturers directions on how to
use. Do not use products to clean the Stone Top that contain acetone, lemon, vinegar or other
acids as these may cause damage to the stone surface.
• Periodically reseal the stone top using an appropriate stone sealer available from your local
home store. Follow the manufacturers directions on how to apply.

8
CARE AND MAINTENANCE
• If the appliance will not be used for prolonged periods of time such as several months. Unplug
the unit and empty the contents, clean the wipe dry the interior walls, wire racks and the door
gasket. Leave the door propped slightly open to allow air to circulate inside.
• Make sure to remove all contents from the wine cooler and wood cabinet before attempting to
move it. Make sure the unit stays in an upright position at all times.
Vacations and Moving Care
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
Motor operate for long
periods or cycles
Appliance is too warm
Wait 12 hours for the
appliance to completely cool
down.
Often occurs when large
Normal when appliance is first
plugged in.
amounts of wine are placed in
the appliance.
This is normal.
Door is left open. Door is not self -closing, Always
make sure that the door is
closed after openin g.
Check to see if a bottle is holding
door open.
Hot weather or frequent door
openings.
This is normal.
Temperature control set at the
coldest setting.
See section on Operating
Instructions.
Appliance is too close to the
wall.
See the Installation Guidelines
section for the correct
clearances.
Appliance has odor Interior needs to be cleaned. See Care and Maintenance
section.
Moisture collects inside (in humid
weather, air carries moisture
ture into the appliance when
the door is opened)
Too frequent or too long door
openings.
Check door gas ket for proper
seal.
Wine bottles touching the back
wall.
Reposition bottles.
Appliance is too cold Temperature control is set too
cold.
See section on Operating
Instructions.
The room temperature where
the appliance is located is too
cold.
For proper operation the room
temperature should be equal or
greater than the set temperature
of the appliance.

9
ONE-YEAR LIMITED WARRANTY
This wine cooler & cabinet is warranted by the manufacturer to be free of material and manufacturing
defects for the time period of one year from the purchase date. This is subject to the following
limitations and conditions.
This appliance must be installed and operated in accordance with the installation instructions and the
operating instructions that were provided with the product. Unauthorized repairs or alterations,
accidents, willful abuse and misuse of the product will nullify this warranty.
This warranty is non-transferable and is offered to the original owner in so long as the product was
purchased from a licensed and authorized supplier and reseller of the product.
The warranty is limited to the repair or replacement of part(s) that have been determined to be
defective in material or workmanship. This is provided that the part(s) have been subjected to
“normal” conditions of use once the defect is agreed upon through the manufacturer’s inspection
process.
Any costs or related expenses that have arisen from the transportation, construction, labor or
otherwise of same that have arisen from repairs, replacement, defective part(s), or otherwise the
same, is not covered by this warranty, nor shall the manufacturer assume the same.
The manufacturer may , at its discretion, fully discharge all obligations with respect to this warranty by
refunding the wholesale price of defective part(s).
The owner/ user assumes all other risks, if any, including the risk of any direct, indirect or
consequential loss or damage arising out of use, or inability to use the product, except as provided
by law.
All other warranties-expressed or implied-with respect to the product, it’s components and
accessories, or any obligations/ liabilities on the part of the manufacturer are hereby expressly
excluded.
The manufacturer neither assumes, nor authorizes any third party to assume on its behalf, any other
liabilities with respect to the sale of the product.
The warranties as outlined within this document do not apply to non-accessories used in conjunction
with the installation of this product.
This warranty gives you specific legal rights, and you may also have other rights which vary from
state to state.
This warranty is void if:
1. The wine cooler is subjected to prolonged periods of dampness or condensation.
2. Any unauthorized alterations, willful abuse, accident, or misuse of the product.
3. You do not have the original receipt.
4. The wine cooler is used outdoors or in commercial applications.

For replacement parts, call our customer service department at 1-855-571-1044, 8 a.m. - 8 p.m., EST,
Monday - Friday.
REPLACEMENT PARTS
AA BB CC
10
PART DESCRIPTION PART #
BB Hinge (with screws)
CC Door Pull (with screws) PH-1064TW-18-002
PH-1064TW-18-001
AA Touch-up Pen 1064TW-18-219-001
Shelves have
made corrosion
prevention
