Screen Innovations Jopplin User manual

Jopplin Kits - Installation Instructions
For use with Janus
Parts in the Box
90º Power
Connectors
Shovels
Power Supply
Upper
Stack Mount
screws
Power
supply &
shovel screws
Universal
Enclosure
screws
Power Supply Lower
for 375
for 275
Janus Stack
Mount
www.screeninnovations.com • [phone] • 9715 B Burnet Road, Suite 400 Austin, TX 78758
Bracket only kit:
(2) 90ºPower Connectors, (1)
Janus Stack Mount, (1) Power
Supply Upper, (1) Power Supply
Lower, (2) Janus stack shovels,
Mounting screws
20” enclosure kit:
(2) 90º Power Connectors, (1)
Janus Stack Mount, (1) Power
Supply Upper, (1) Power Supply
Lower, (2) Janus stack shovels,
Mounting screws, (1) 20” metal
enclosure, (1) 20” premium
door
40” enclosure kit:
(4) 90ºPower Connectors, (2)
Janus Stack Mount, (2) Power
Supply Upper, (2) Power
Supply Lower, (4) Janus stack
shovels, Mounting screws, (1)
40” metal enclosure, (1) 40”
premium door
Pg 1 of 2
Version 1.2 March 2021

Jopplin Kits - Installation Instructions
1. Connect your Janus unit(s) into the Stack mount bracket(s) with the stack mount screws.
2. Attach the 2 shovels using the power supply and shovel screws, as shown below.
3. Now attach the stacked Janus assembly to the enclosure.
4. Assemble top and bottom Power Supply Bracket(s) and insert Janus Power Supply(ies), as shown on 1st page, there
are holes for both 275 and 375.(Only 2 of those holes can be used depending on what power supply you use.
Note: If you have both a 275 and a 375, you must use the 375 holes.
5. You can now attach the power supply upper and lower brackets and power supply(ies) to the enclosure.
6. Route Power Supply cable(s) from Power Supply(ies) up to the Janus unit(s) installed into the Stack Mount(s). You may
need to use the 90º power connectors and the power cable extensions that come with the power supply(ies) depending
on which face you are connecting the power to on Janus.
Note: To mount the IP gateway like SI.FI in the enclosure as shown below, use the included din rail.
7. Optionally, if your kit includes an enclosure, scan the QR code below to access the installation and cut out drawings.
Note: Use the included 90ºPower Connectors if your Stack
Mount is all the way to one of the sides of the enclosure.
Please scan the QR code or use the link to download
the enclosure and door installation instructions and
the cutout drawings.
For further details about Janus please see visit the
Janus page by scanning this QR code.
www.screeninnovations.com • [phone] • 9715 B Burnet Road, Suite 400 Austin, TX 78758 Version 1.2 March 2021
20” Enclosure
without door for reference only
Installation Instructions
Pg 2 of 2
SI.FI
