Sea Recovery SRC Aqua Matic 700-1 User manual

Aqua Matic Compact 450-1800
Owner’s Manual
Manual PN B651140001 | Revision: 12-1-2017
SRC Aqua Matic 450-1 SRC Aqua Matic 900-2
SRC Aqua Matic 700-1 SRC Aqua Matic 1400-2
SRC Aqua Matic 900-1 SRC Aqua Matic 1800-2
SYSTEM MODELS
Owner’s Manual

Aqua Matic Compact
450-1800
Owner's Manual
Manual PN B651140001

Contents
Preface: About this Manual ..................................................................................vii
About Sea Recovery................................................................................................................................................vii
Purpose....................................................................................................................................................................vii
Updates....................................................................................................................................................................vii
References..............................................................................................................................................................viii
Graphics..................................................................................................................................................................viii
Notice of Liability.....................................................................................................................................................viii
Trademarks.............................................................................................................................................................viii
Terms and Conditions.............................................................................................................................................viii
Copyright.................................................................................................................................................................viii
Revision History........................................................................................................................................................ix
Chapter 1: Introduction ..........................................................................................11
Welcome..................................................................................................................................................................11
Models.....................................................................................................................................................................11
Parts Warning..........................................................................................................................................................12
Warranty and Registration.......................................................................................................................................12
Limited Warranty......................................................................................................................................................12
Cleaning...................................................................................................................................................................13
Product Changes.....................................................................................................................................................13
Obtaining Warranty Service.....................................................................................................................................13
Registration..............................................................................................................................................................13
Temperature and Pressure Effects..........................................................................................................................13
Safety.......................................................................................................................................................................14
Disposal...................................................................................................................................................................14
Compliance..............................................................................................................................................................14
Chemical Warnings..................................................................................................................................................15
Sea Recovery SRC SC Storage Chemical..............................................................................................................15
Sea Recovery SRC MCC-1 Membrane Cleaning Chemical....................................................................................15
Sea Recovery SRC MCC-2 Membrane Cleaning Chemical....................................................................................15
Sea Recovery SRC MCC-3 Membrane Cleaning Chemical....................................................................................16
Patent Information ................................................................................................................................................16
Chapter 2: System Description ............................................................................17
Pre-Installation Safety Checks .............................................................................................................................17
Storage Prior to Uncrating ....................................................................................................................................17
Chemical Precautions ...........................................................................................................................................17
System Safety Check ...........................................................................................................................................17
Installer Minimum Qualifications ...........................................................................................................................18
Warnings ..............................................................................................................................................................18
System Specifications ..........................................................................................................................................19
Installer-supplied Components .............................................................................................................................19
Water Connections ...............................................................................................................................................20
Inlet Thru Hull Fitting (with Forward-facing Scoop) ...............................................................................................20
MNPT Connections ..............................................................................................................................................20
FNPT Connections ...............................................................................................................................................20
Circuit Breaker ......................................................................................................................................................20
Properly-sized Cables ..........................................................................................................................................20
Electrical Power Source .......................................................................................................................................21
Piping and Interconnect Diagrams .......................................................................................................................21
RO Membrane Element(s) ....................................................................................................................................21

Component Descriptions ......................................................................................................................................22
Pre-filtration Components .....................................................................................................................................22
Pressurization Components .................................................................................................................................24
Brine Discharge Components ...............................................................................................................................24
Product Water Components .................................................................................................................................25
Fresh Water System Components .......................................................................................................................25
Fresh Water Flush Components ...........................................................................................................................26
Electronic Components ........................................................................................................................................26
Miscellaneous Components .................................................................................................................................27
Chapter 3: Electrical Specifications.....................................................................29
Electrical Requirements and Specs ......................................................................................................................29
System Safety Check ...........................................................................................................................................29
Hazard Warning ...................................................................................................................................................29
Amperage Notes ..................................................................................................................................................29
Power Source Requirements ................................................................................................................................30
Motor Rotation ......................................................................................................................................................30
Electric Motor Specifications ................................................................................................................................30
Alternating Current Systems .................................................................................................................................30
Recommended Circuit Breaker Based on Operating Voltage ...............................................................................31
Recommended Power Wire Size to System .........................................................................................................31
Recommended Power Wire Size to Booster Pump ..............................................................................................31
Recommended Power Wire Size to High Pressure Pump ....................................................................................31
Chapter 4: Installation............................................................................................33
System Frame ......................................................................................................................................................33
Component Mounting ...........................................................................................................................................33
Tube-Fitting Assembly ..........................................................................................................................................33
Interconnecting Components with Supplied Hose ................................................................................................34
Remote Touch Screen ..........................................................................................................................................35
Water Tank and Optional Components ................................................................................................................35
UV Sterilizer .........................................................................................................................................................36
Install Fittings .......................................................................................................................................................36
Install Quartz Sleeve ............................................................................................................................................37
Connect Plumbing ................................................................................................................................................38
Install Ultraviolet Lamp .........................................................................................................................................39
Mounting the Unit .................................................................................................................................................39
Chapter 5: Commissioning.....................................................................................41
Check the Installation ...........................................................................................................................................41
Check RO Membrane(s) .......................................................................................................................................41
System Valve Positions ........................................................................................................................................42
Controller Setup ...................................................................................................................................................42
System Main Controller Update As Of 10/30/2017 ...............................................................................................47
System Commissioning ........................................................................................................................................48
Display Setting .....................................................................................................................................................52
Setting System Clock ...........................................................................................................................................54
Setting System Run Timers ..................................................................................................................................55
Setting System Salinity .........................................................................................................................................59
Setting Fresh Water Flush ....................................................................................................................................60
Manual System Check ..........................................................................................................................................63
Multi Media Filter Backwash and Rinse ................................................................................................................64
Chapter 6: General Operation ..............................................................................67
Important Notes ....................................................................................................................................................67
New Systems .......................................................................................................................................................67
Freezing Temperature Warning ............................................................................................................................67
RO Membrane Element Warning .........................................................................................................................67
Fresh Water Flush Warning ..................................................................................................................................68

System Storage ....................................................................................................................................................68
Powering the System ON .....................................................................................................................................68
Automatic Mode ...................................................................................................................................................69
Manual Mode ........................................................................................................................................................69
Startup Sequence .................................................................................................................................................70
Powering the System OFF ...................................................................................................................................71
Automatic Mode ...................................................................................................................................................71
Manual Mode ........................................................................................................................................................71
System Short- and Long-Term Storage ................................................................................................................72
Once-through Configuration .................................................................................................................................72
Closed-loop Configuration ....................................................................................................................................72
System Main Controller Update As Of 10/30/2017 ...............................................................................................73
Manual Operation .................................................................................................................................................74
Automatic Operation .............................................................................................................................................80
Accessing Your Various Display Screens .............................................................................................................83
Accessing System Fault & Warning Log ...............................................................................................................86
Accessing High Pressure Pump Hour Meter ........................................................................................................87
Short-term Shutdown Procedure ..........................................................................................................................89
Long-term Shutdown Procedure ...........................................................................................................................90
Draining Component Water (for Winterizing) ........................................................................................................91
Cleaning the RO Membrane .................................................................................................................................91
About New Systems .............................................................................................................................................92
Reverse Osmosis Water and Cleaning Requirements .........................................................................................92
Cleaning Procedure ..............................................................................................................................................92
Chapter 7: Maintenance and Repair ....................................................................95
Prerequisites ........................................................................................................................................................95
System Updates ...................................................................................................................................................95
Installer Minimum Qualifications ...........................................................................................................................95
System Safety Check ...........................................................................................................................................96
Chemical Precautions ...........................................................................................................................................96
Note on Component Cleaning ..............................................................................................................................96
Warnings ..............................................................................................................................................................96
Weekly Quick Check ............................................................................................................................................97
Operator Maintenance Intervals ...........................................................................................................................97
Third-Party Parts Warning ....................................................................................................................................97
Component Maintenance and Repair ...................................................................................................................98
Inlet Thru Hull Fitting ............................................................................................................................................98
Sea Cock Valve ....................................................................................................................................................98
Inlet Connection ...................................................................................................................................................98
Sea Strainer .........................................................................................................................................................98
Electric Motor and Booster Pump Assembly ........................................................................................................98
T-Connector Pressure Pick-Up ...........................................................................................................................100
Pressure Transducers ........................................................................................................................................100
Plankton Filter Element (Cleaning)........................................................................................................................100
Multi Media Filter Backwash ...............................................................................................................................100
Commercial or Dual Pre-filter Element Replacement .........................................................................................101
Oil/Water Separator Filter Element Replacement ...............................................................................................101
Transducer Manifold ...........................................................................................................................................102
Electric Motor and High Pressure Pump .............................................................................................................102
High Pressure Hose ...........................................................................................................................................103
Reverse Osmosis Membrane and Pressure Vessel Assembly ...........................................................................103
High Pressure Manifold ......................................................................................................................................105
High Pressure Transducer ..................................................................................................................................105
Automatic Motor Actuated Back Pressure Regulator .........................................................................................105
Brine Discharge and Product Water Flow Meters ...............................................................................................106
Brine Discharge T-Connector .............................................................................................................................106
Brine Discharge Connector ................................................................................................................................106
Multi Media Filter Waste and Brine Discharge Tee ............................................................................................106
Thru-Hull Discharge Fitting .................................................................................................................................106
Product Water T-Collector ..................................................................................................................................106

Salinity Probe .....................................................................................................................................................106
3-way Product Water Diversion Solenoid Valve .................................................................................................107
Charcoal Filter ....................................................................................................................................................108
pH Neutralizing Filter ..........................................................................................................................................108
Ultraviolet Sterilizer ............................................................................................................................................109
Fresh Water Flush Carbon Filter Element ..........................................................................................................109
UV Sterilizer Maintenance ..................................................................................................................................110
Exterior Surfaces ................................................................................................................................................111
Quartz Sleeve .....................................................................................................................................................111
Checking for Leaks .............................................................................................................................................111
Repairing Leaks .................................................................................................................................................112
Measuring Performance .....................................................................................................................................112
Verifying Lamp Operation ...................................................................................................................................112
Obtaining Water Samples ...................................................................................................................................112
Chapter 8: Troubleshooting ...............................................................................113
Alarm and Error Screens ....................................................................................................................................113
Thru-Hull Inlet Fitting ..........................................................................................................................................114
Sea Cock Valve ..................................................................................................................................................114
Inlet Connection .................................................................................................................................................114
Inlet Vacuum/Pressure Gauges ..........................................................................................................................115
Sea Strainer .......................................................................................................................................................115
Booster Pump .....................................................................................................................................................115
T-Connector Pressure Pickup ............................................................................................................................116
Pressure Transducers ........................................................................................................................................116
Plankton Filter ....................................................................................................................................................116
Multi Media Filter ................................................................................................................................................116
Dual Pre-Filter ....................................................................................................................................................117
Commercial Pre-Filter .........................................................................................................................................117
Oil and Water Separator .....................................................................................................................................117
Std HP Pump Assembly .....................................................................................................................................117
HP Pump Assembly ............................................................................................................................................119
RO Membrane and Assembly ............................................................................................................................119
Automated Motor-Actuated Back Pressure Regulator ........................................................................................121
Brine Discharge Flow Meter ...............................................................................................................................121
Salinity Probe .....................................................................................................................................................122
System Main Controller Update As Of 10/30/2017 .............................................................................................123
System Fault Error Messages ............................................................................................................................124
System Warning Messages ................................................................................................................................129
Chapter 9: Glossary.............................................................................................133
Terms .................................................................................................................................................................133
Chapter 10: Appendix ........................................................................................135
ABS Certificate of Design Assessment ...............................................................................................................136
ABS Certificate of Manufacturing Assessment ...................................................................................................137
Declaration of Conformity ...................................................................................................................................139
Management System Certificate..........................................................................................................................140
Single-Phase Electrical Motor Wiring .................................................................................................................141
Three-Phase Electrical Motor Wiring ..................................................................................................................142
Three Phase Transformer Wiring .......................................................................................................................143
New System Initial Readings Form ....................................................................................................................144
Daily System Readings ......................................................................................................................................145
Chapter 11: Exploded Parts Views ...................................................................147
Pre-Installation Matrix Drawing ...........................................................................................................................148
Chapter 12: Electrical Diagrams (Foldouts) ......................................................211

About this Manual
About Sea Recovery
Since 1981, Sea Recovery Corporation has produced water desalination systems, used in various applications,
for customers around the world.Currently, Sea Recovery Corporation stands apart as a leader in advanced water
desalination systems for leisure marine applications.
Sea Recovery  USA
Parker Water Purification
2630 E. El Presidio Street
Carson, CA 90810
Purpose
This manual is intended for Sea Recovery’s system technicians, technical support and training personnel.It contains
technical information and instructions for the installation, operation, maintenance and troubleshooting of the .Sea
Recovery’s RO desalination systems are designed and engineered to function as complete, working units and are
subject to cascading failure if installation, operation and maintenance instructions are not followed correctly.Thus,
the intent of this manual is to familiarize you, or other installer(s) and/or operator(s) with each system component.
With a core understanding of the function, importance and normal operation of each subsystem component, you
will be equipped to diagnose minor problems, which, if detected early on, are typically correctable. Note that if a
minor component problem is left uncorrected, it can affect the rest of the system and lead to more extensive issues
and/or damage.
Important: Sea Recovery encourages you to read the manual thoroughly before attempting installation or
operation, as well as to keep the manual for future reference.By gaining a better understanding of your
system, you will be equipped with the knowledge to achieve optimum performance and a longer service life.
Updates
From time to time, Sea Recovery Corporation may make programming changes to the control logic.Other physical
production changes may also be made, and are tracked by Sea Recovery Corporation through the System's serial
number.
Remember:Troubleshooting and repair method results can vary depending on the information that is
displayed on the SYSTEM INFORMATION screen.
•SERIAL NUMBER: Helps Sea Recovery Corporation to determine the latest physical version and configuration
of your System, ensuring that you are provided with correct part information.
•TYPE: Tells Sea Recovery Corporation the production capacity of your System, which provides a bench mark in
diagnosing product water flow and pressure concerns.
•VERSION: Allows Sea Recovery Corporation to determine the specific sequential operation of the System based
on the programming control logic version.
vii

Depending on the issue, Sea Recovery Corporation may also request the System's operating Voltage, cycles and
phase.
References
All references in this manual refer to sections within this manual, unless otherwise specified.
Graphics
Graphics used in this manual are for reference and illustration purposes only, and may not represent the actual
part or arrangement of parts in a customized system.
Notice of Liability
The information contained in the manual is distributed on an “as is”basis, without warranty.While every effort has
been taken in the preparation of this manual, Sea Recovery Corporation shall not be held liable with respect to
any liability, loss or damage caused by the instructions contained in this manual.The information contained in this
manual is subject to change without notice.
Trademarks
The Sea Recovery®logo mark is a U.S.Registered Trademark and belongs to Sea Recovery Corporation with all
rights reserved.Sea Recovery®is a U.S. Registered trademark of Sea Recovery Corporation. Aqua Matic™is a
trademark of Sea Recovery Corporation.
Terms and Conditions
The use of this manual acknowledges acceptance of the terms and conditions provided herewith and the agreement
to comply with all applicable laws and regulations pertaining to the use of this manual. In addition, the use of this
manual forms an agreement that Sea Recovery’s trademarked name or Sea Recovery’s trademarked logo mark
are not to be used in any form or manner except with Sea Recovery Corporation’s written permission.Sea Recovery
Corporation holds all rights to its copyrights and trademarks, and to the material contained in this manual.Any use
of such requires the written permission from Sea Recovery Corporation.
Copyright
All content included within this manual, including text, graphics, logos and images, is the property of Sea Recovery
Corporation and protected by U.S.and international copyright laws.The compilation (i.e., the preparation, collection,
arrangement and assembly) of all content within this manual is the exclusive property of Sea Recovery Corporation
and protected by U.S. and international copyright laws. All software used in the design and manufacture of the is
the property of and protected by U.S.and international copyright laws. All computer and logic programming used
Aqua Matic Compact 450-1800viii

in the design and manufacture of the is the property of Sea Recovery Corporation and protected by U.S. and
international copyright laws.The content of this manual and the software, programming, and graphics used in the
design and manufacture of the is for the purpose of operation, maintaining and repair of the . Any other use,
including the reproduction, modification, distribution, transmission, republication, display or performance, of the
content within this manual is strictly prohibited. ©Copyright Sea Recovery Corporation 2008 - 2012.
Revision History
About this Manual
Description8Affected PagesDateRev #
Added HP75 & SoftStartParts ViewMay 20137
Full revision of manual layout and contentAll2011 August 316
Updated drawings for exploded parts view10-1 through 10-47March 30 20105
Multi media filter installation revision5-223 November 20094
General layout and typesetting changes-22 September 20093
Replaced wiring diagrams4-11 through 4-15, and fold-outs4 September 20092
Additional installation option diagrams3-6 through 3-103 August 20091
Initial release of 2008 models-1 December 20080
ix

Chapter 1
Introduction
Welcome
Congratulationson yourpurchase ofa newSea Recovery Aqua MaticCompact Reverse Osmosis (RO) Desalination
System! The Aqua Matic RO Desalination System is engineered to be easier to use and more reliable than
conventional water-makers. Featuring the latest technology, the System is able to regulate and monitor functions
without the need of an operator.
Inside this manual, you will find detailed technical information and instructions for the installation, operation,
maintenance and troubleshooting of your Aqua Matic RO Desalination System.
Note: The term "System" refers to the Aqua Matic RO Desalination System and will be used throughout this
manual.
Models
The Aqua Matic Compact series is available in the following six models: 450-1, 700-1, 900-1, 900-2, 1400-2 and
1800-2. Please note that your System also includes a system tag that lists the product name, model number and
serial number.
11

Parts Warning
The major documented cause of failures and problems are from the use of third-party, non-Sea Recovery parts;
improper installation; and improper operation. Do not use parts, components from any source other than Sea
Recovery! The use of third-party, non-Sea Recovery parts is strongly discouraged and will result in the following
consequences:
•The use of third-party, non-Sea Recovery components, spares and assemblies will damage the Sea Recovery
System and/or specific components within the System.
•The use of third-party, non-Sea Recovery components, spares and assemblies will void any and all warranty of
the System and/or void the affected component within the System.
Important: Sea Recovery Corporation maintains inventory for immediate shipment and our Service Dealers
throughout the world maintain stock of Sea Recovery parts.Always insist on Sea Recovery supplied parts
in order to avoid failures, eliminate problems, and maintain your warranty.
Warranty and Registration
Sea Recovery Corporation guarantees its product, components and replacement parts, and strongly advises that
customers use only Sea Recovery parts.The majority of problems derive from premature failure of unauthorized
third party replacement parts.
Attention: Using unauthorized parts will void the Sea Recovery Corporation warranty! Use of non Sea
Recovery Corporation supplied parts and accessories, including but not limited to, maintenance parts, pre-filter
elements, cleaning and storage chemical, spare parts, replacement parts, system components, installation
components and/or system accessories, shall void all warranty expressed or implied.
Limited Warranty
Sea Recovery warrants that the performs according to specifications for a period of 12 months from the date of
shipment. Sea Recovery’s liability under this warranty is limited to repair or replacement of the at Sea Recovery
Corporation’s discretion. Under no circumstances is Sea Recovery Corporation liable for consequential damages
arising out of or in any way connected with the failure of the system to perform as set forth herein.This limited
warranty is in lieu of all other expressed or implied warranties, including those of merchantability and fitness for a
particular purpose.The warranty period starts from the date of original shipment by Sea Recovery Corporation, or
with proof of purchase from the date of sale to the original retail purchaser.The following warranty periods apply:
Aqua Matic Compact 450-180012

•System and accessories: One (1) year
•Repairs made by Sea Recovery Corporation after the original warranty period has expired:Three (3) months
•Normal, reoccurring user maintenance on the following is not covered by this or any Sea Recovery Corporation
limited warranty:Sea Strainer Element, fuses, instrument calibration, cartridge filter elements and/or the centrifugal
pump seal assemblies
The implied warranties, which the law imposes on the sale of this product, are expressly LIMITED in duration to
the time period above. Sea Recovery Corporation shall not be liable for damages, consequential or otherwise,
resulting from the installation, use, and/or operation of this product or from the breach of this LIMITEDWARRANTY.
Attention: The Sea Recovery Corporation limited warranty does not cover third-party installation components.
Improper installation resulting in System or component failure/performance decline is not covered by this or
any Sea Recovery Corporation limited warranty.The limited warranty does not extend to any system or
system component which has been subjected to alteration, misuse, neglect, accident, improper installation,
inadequate or improper repair or maintenance or subject to use in violation of instructions furnished by Sea
Recovery Corporation, nor does the warranty extend to components on which the serial number has been
removed, defaced, or changed.
Cleaning
The is guaranteed to be cleanable for a minimum of one (1) year from date of shipment, providing cleaning periods
are adhered to, and fouling is acid soluble metal hydroxides and calcium carbonates or alkaline soluble organic,
inorganic substances and microbiological slimes.The Sea Recovery RO Membrane Element is not guaranteed
against iron fouling (rust), chemical or petroleum products attack, extreme temperatures [over 120°F (49°C) under
32° F (0° C)], drying out, or extreme pressures [over 1000 psig (69 bar)].In the event of a defect, a malfunction,
or failure specifically covered by this warranty and during the warranty period, Sea Recovery Corporation will repair
or replace, at its option, the product or component therein which upon examination by Sea Recovery Corporation
appears to be defective.
Product Changes
Sea Recovery Corporation reserves the right to make changes or improvements in its product, during subsequent
production,without incurring the obligationto incorporate suchchanges or improvements onpreviously manufactured
equipment.
Obtaining Warranty Service
To obtain warranty service, the defective product or part must be returned to an authorized Sea Recovery Corporation
Service Center or direct to Sea Recovery Corporation.An updated listing of Sea Recovery Corporation Factory
Service Centers can be found on the Sea Recovery Corporation web site at http://www.searecovery.com.The
purchaser must pay any transportation or labor expenses incurred in removing and returning the product to the
service center or to Sea Recovery Corporation.
Registration
Sea Recovery Corporation recommends that all customers register their System immediately after delivery to
ensure and guarantee product technical support and warranty.
Temperature and Pressure Effects
Note: Do not use this chart for brackish water systems and applications
As the sea water temperature gets higher, the pressure must be adjusted so that the System does not exceed
100% of its rated product water flow. Product water flow that is greater than 100% of rated capacity causes
premature fouling of the RO Membrane Element, which voids the RO Membrane Element warranty.The System
will also require more frequent cleaning. Please refer to the chart below for pressure adjustments.
13
Introduction

Safety
Parties responsible for the installation, operation, and maintenance of the must read this manual thoroughly and
comply with the instructions and safety requirements at all times.
Disposal
If System disposal is necessary, you must comply with all federal and state environmental regulations.
Compliance
•Sea Recovery’s Reverse Osmosis Desalination Systems areType Accepted by the American Bureau of Shipping,
ABS.
•Sea Recovery’s Reverse Osmosis Desalination Systems comply with FCC § 15.105
•Sea Recovery’s Reverse Osmosis Desalination Systems have been independently tested and determined to be
in compliance with European CE (Conformité Européne).
Please refer to the Appendix for copies of compliance certificates.
Aqua Matic Compact 450-180014

ChemicalWarnings
Sea Recovery SRC SC Storage Chemical
WARNING! CONTAINS SODIUM METABISULFITE. HARMFUL IF SWALLOWED, AVOID BREATHING DUST &
FUMES.CAUSES IRRITATION TO EYES & MUCOUS MEMBRANES.DO NOT TAKE INTERNALLY. KEEP
AWAY FROM FOOD.
FIRST AID: IF SWALLOWED, CALL A PHYSICIAN, GIVE TAP WATER & INDUCE VOMITING. IN CASE OF
CONTACT IMMEDIATELY FLUSH EYES WITH WATER FOR 15 MINUTES & GET IMMEDIATE MEDICAL
ATTENTION.THOROUGHLY WASH AFFECTED SKIN AFTER HANDLING PRODUCT.
MEDICAL PERSONNEL FAMILIAR WITH Sea Recovery “SRC SC”, SYSTEM & MEMBRANE STORAGE
CHEMICAL, ARE AVAILABLE 24 HOURS A DAY, 7 DAYS AWEEK, U.S.A.TOLL FREE MEDICAL EMERGENCY
NUMBER: 1-800-228-5635.
FOR INDUSTRIAL USE ONLY.
Use with adequate ventilation.Prevent breathing dust and prevent contact with eyes.Thoroughly wash contacted
parts after handling. Do not allow powder to become wetted with small amounts of water. Adding small amounts
of water to power may liberate irritating sulfur dioxide gas. Add powder to above specified amount of water only.
Do not mix with other chemicals or cleaners.If spilled, sweep up as much as possible then flush with water to
drain.
KEEP OUT OF REACH OF CHILDREN
NET CONTENTS 1.5 POUNDS (.68 Kg)
Sea Recovery SRC MCC-1 Membrane Cleaning Chemical
WARNING: CONTAINS SODIUM METASILICATE. HARMFUL IF SWALLOWED. MAY CAUSE BURNS. AVOID
CONTACT WITH EYES. AVOID PROLONGED CONTACT WITH SKIN. DO NOT TAKE INTERNALLY. KEEP
AWAY FROM FOOD.
FIRST AID: IF SWALLOWED, CALL A PHYSICIAN, DO NOT INDUCE VOMITING, GIVE ONE GLASS OFTAP
WATER OR MILK. IN CASE OF CONTACT IMMEDIATELY FLUSH EYES WITH WATER FOR 15 MINUTES &
GETIMMEDIATE MEDICALATTENTION.THOROUGHLYWASHAFFECTED SKIN AFTERHANDLINGPRODUCT.
CONTACT A PHYSICIAN IF IRRITATION PERSISTS.
MEDICAL PERSONNEL FAMILIAR WITH Sea Recovery “SRC MCC1”, R.O. MEMBRANE ELEMENT ALKALINE
DETERGENT CLEANING CHEMICAL, ARE AVAILABLE 24 HOURS A DAY, 7 DAYS A WEEK, U.S.A.TOLL
FREE MEDICAL EMERGENCY NUMBER: 1-800-228-5635.
FOR INDUSTRIAL USE ONLY.
Use with adequate ventilation.Prevent breathing dust & prevent contact with eyes.Thoroughly wash contacted
parts after handling. Do not allow powder to become wetted with small amounts of water. Add powder to above
specified amount of water only. Do not mix with other chemicals or cleaners. If spilled, sweep up as much as
possible then flush with water to drain.
KEEP OUT OF REACH OF CHILDREN
NET CONTENTS 1.5 POUNDS (.68 Kg)
Sea Recovery SRC MCC-2 Membrane Cleaning Chemical
DANGER:CONTAINS SULFAMIC ACID.CAUSESBURNS,EYE& SKIN IRRITATION.HARMFUL IF SWALLOWED.
AVOID BREATHING DUST. DO NOT TAKE INTERNALLY. KEEP AWAY FROM FOOD.
FIRST AID: IF SWALLOWED, CALL A PHYSICIAN, DO NOT INDUCE VOMITING, GIVE ONE GLASS OFTAP
WATER OR MILK. IN CASE OF CONTACT IMMEDIATELY FLUSH EYES WITH WATER FOR 15 MINUTES &
GETIMMEDIATE MEDICALATTENTION.THOROUGHLYWASHAFFECTED SKIN AFTERHANDLINGPRODUCT.
CONTACT A PHYSICIAN IF IRRITATION PERSISTS.
15
Introduction

MEDICAL PERSONNEL FAMILIAR WITH Sea Recovery “SRC MCC2”, R.O. MEMBRANE ELEMENT ACID
CLEANING CHEMICAL, ARE AVAILABLE 24 HOURS A DAY, 7 DAYS A WEEK, U.S.A.TOLL FREE MEDICAL
EMERGENCY NUMBER: 1-800-228-5635.
FOR INDUSTRIAL USE ONLY.
DO NOT MIX WITH CHLORINATED SOLUTIONS OR COMPOUNDS.Use with adequate ventilation.Prevent
breathing dust & prevent contact with eyes.Thoroughly wash contacted parts after handling. Do not allow powder
to become wetted with small amounts of water. Add powder to above specified amount of water only. Do not mix
with other chemicals or cleaners.If spilled, sweep up as much as possible then flush with water to drain.
KEEP OUT OF REACH OF CHILDREN
NET CONTENTS 1.5 POUNDS (.68 Kg)
Sea Recovery SRC MCC-3 Membrane Cleaning Chemical
WARNING: CONTAINS SODIUM METABISULFITE. HARMFUL IF SWALLOWED. AVOID BREATHING DUST
AND FUMES.CAUSES IRRITATION TO EYES AND MUCOUS MEMBRANES.DO NOT TAKE INTERNALLY.
KEEP AWAY FROM FOOD.
FIRST AID: IF SWALLOWED, CALL A PHYSICIAN, GIVE TAP WATER AND INDUCE VOMITING. IN CASE OF
CONTACT IMMEDIATELY FLUSH EYES WITH WATER FOR 15 MINUTES & GET IMMEDIATE MEDICAL
ATTENTION.THOROUGHLY WASH AFFECTED SKIN AFTER HANDLING PRODUCT.CONTACT A PHYSICIAN
IF IRRITATION PERSISTS.
MEDICAL PERSONNEL FAMILIAR WITH Sea Recovery “SRC MCC3”, R.O. MEMBRANE ELEMENT RUST
REMOVER CLEANING CHEMICAL, ARE AVAILABLE 24 HOURS A DAY, 7 DAYS A WEEK, U.S.A.TOLL FREE
MEDICAL EMERGENCY NUMBER: 1-800-228-5635.
FOR INDUSTRIAL USE ONLY.
Use with adequate ventilation.Prevent breathing dust & prevent contact with eyes.Thoroughly wash contacted
parts after handling. Do not allow powder to become wetted with small amounts of water. Adding small amounts
of water to powder may liberate irritating sulfur dioxide gas. Add powder to above specified amount of water only.
Do not mix with other chemicals or cleaners.If spilled, sweep up as much as possible then flush with water to
drain.
KEEP OUT OF REACH OF CHILDREN
NET CONTENTS 1.5 POUNDS (.68 Kg)
Patent Information
Certain aspects of the are protected by U.S.and International Patent Laws.
Aqua Matic Compact 450-180016

Chapter 2
System Description
Pre-Installation Safety Checks
Ensure that you—as the Installer, Operator or both—read and understand the prerequisites, warnings and important
notes within this topic.
Storage Prior to Uncrating
You must adhere to the following crate markings:
•DO NOT store in direct sunlight
•DO NOT store above 120ºF (50ºC)
•DO NOT allow the System to freeze (do not store below 32ºF (0ºC))
•DO NOT store longer than four (4) months without flushing with storage chemical
•Store only on base with ARROWS UP
•Keep the RO Membrane Element wet at all times
Chemical Precautions
Danger: The RO Membrane Element is susceptible to chemical attack.Take extreme caution in handling
and storing! Do not expose your Aqua Matic RO Desalination System to feed water containing chemicals not
approved in writing by Sea Recovery Corporation.
Do not connect a water line to your Aqua Matic RO Desalination System that may contain any of the following
chemicals:
•Hydrogen peroxide chloramines-T
•Chlorine dioxide chlorine
•Bromine phenolic disinfectants
•Chloramines N-chlorioisocyanurates
•Hypochlorite iodine
•Bromide petroleum products
Important: The use of non-authorized and/or the misuse of authorized chemicals will void your Sea Recovery
Corporation warranty! For example, DO NOT connect the Aqua Matic RO Desalination System's inlet to your
ship’s potable water system if it contains chlorinated or brominated water.These chemicals destroy the
copolymer components and the oxidants will damage the RO Membrane Element. In this situation, you can
use the optional Sea Recovery FreshWater Flush Accessory to remove the chlorine and bromine from
your ship's potable water system before connecting theAqua Matic RO Desalination System.
System Safety Check
Danger: Do not perform installation, maintenance or troubleshooting procedures until you have verified the
following conditions:
17

•The System's Feed Water Sea Cock Valve is closed.
•The System's main electrical disconnect switch is OFF, LOCKED and TAGGED.
Installer Minimum Qualifications
The System's Installer must have technical expertise in the following areas:
•Electrical, Electronic, Electric Motors and Circuits
•Electromechanical and Mechanical Systems
•Hydraulic and Liquid Pressure and Flow Systems
•Piping and Plumbing Systems
•Water Suction and Pressure Lines
•Thru-Hull Fitting below and above water level
Do not attempt maintenance and repair if you are not proficient in the aforementioned fields of expertise.
Warnings
Danger: ELECTRICAL SHOCK HAZARD The Aqua Matic RO Desalination System installation procedures
expose the installer to high voltage and potential electrical hazards.Technicians should only attempt installation
if (1) they are qualified electricians and (2) surrounding conditions are safe.
Caution: Do not attempt Installation, commissioning, troubleshooting, or repair of the unless you are proficient
in the fields/functions listed within the section Installer Minimum Qualifications on page 18.
Caution: The RO Membrane Element is stored in sodium bisulfite.Avoid skin and eye contact with this
packaging solution.If skin contact occurs, rinse skin thoroughly with water. If eye contact occurs, flush eyes
repeatedly with water and notify a physician immediately.
Caution: Never mount the liquid holding component above any electrical or electronic device. Extensive
damage to the electronic device will result if liquid enters device during maintenance and/or component
failure.
Important: Do not over-tighten PVC fittings.If threaded pipe fittings leak after installation, remove the fitting,
clean the mating threads, apply three (3) to four (4) wraps of Teflon tape to the male threads, apply liquid
Teflon pipe sealer sparingly, and thread the parts back together. PVC fittings should be hand tightened,
without the use of a wrench.
Important: The Sea CockValve, Inline Pressure Gauge, Sea Strainer, Rinse Clean Inlet Valve, and Booster
Pump should be installed below water level.This will aid the Booster Pump in priming.
Important: Always allow hoses and tubes to enter and exit straight from the connection for a minimum of 1
in. prior to a bend. If stress is placed on the fitting due to a tight bend, the fitting will leak and may break.
Important: All connection lines should be as short and straight as possible using minimum fittings. Ensure
that they are not “kinked”.
Important: Ensure that the power source is sufficiently sized to provide the correct voltage and cycles during
System start up and operation.
Remember: Install the system and its supporting components in an accessible manner.
Aqua Matic Compact 450-180018
