OPERATION AND INSTALLATION
FOR SEA TEL MODEL
ST24 SATELLITE TV RECEIVE-ONLY ANTENNA
Please record your Antenna Serial Number Here;
Antenna Model: _______Serial Number: _______________

ii
Sea Tel Marine Stabilized Antenna systems are manufactured in the United
States of America.
Sea Tel is an ISO 9001:2008 registered company.
Certificate Number 13690 issued March 14, 2011.
The Coastal Series of Marine Stabilized Antenna Pedestals with Antenna Control Panel
complied with the requirements of European Norms and European Standards EN 60945
(1997) and prETS 300 339 (1998-03) on June 30, 1999. Sea Tel European Union Declaration
of Conformity for this equipment is contained in this manual.
Copyright Notice
All Rights Reserved. The information contained in this document is proprietary to Sea Tel, Inc.. This document
may not be reproduced or distributed in any form without prior consent of Sea Tel, Inc. The information in
this document is subject to change without notice. Copyright © 2010 Sea Tel, Inc is doing business as
Cobham SATCOM.
This document has been registered with the U.S. Copyright Office.
Revision History
REV ECO# Date Description By
X August 24, 2010 Preliminary Release ECM
X1 September 30, 2010 Updated text and graphics per Product Manager Feedback, added
LNB replacement Procedure, added Manual to AutoPol Conversion
Procedure
ECM
X2 November 3, 2010 Updated text and graphics to reflect current software build features.
Added Setup Wizard procedure
ECM
A December 20, 2010 Production Release ECM
B January 23, 2011 Updated text and graphics to reflect current software build features. ECM
C 8491 May 19, 2011 Updated text, graphics and drawings to reflect current production
build.
ECM

ST24 Ku-Band TVRO Table of Contents
1. Table of Contents
1. TABLE OF CONTENTS...............................................................................................................................................................................1-1
2. QUICK START ................................................................................................................................................................................................2-1
2.1. GENERAL PANEL OPERATION .......................................................................................................................................................................2-1
2.2. TARGET A SATELLITE.....................................................................................................................................................................................2-1
3. INSTALLATION.............................................................................................................................................................................................3-1
3.1. VERIFY SYSTEM COMPONENTS ...................................................................................................................................................................3-3
3.2. SITE SELECTION .............................................................................................................................................................................................3-3
3.2.1. Prepare the Antenna Radome Mounting Location ..................................................................................................3-4
3.2.2. Prepare the Antenna Control Panel mounting location........................................................................................3-5
3.3. CABLE AND EQUIPMENT INSTALLATION ................................................................................................................................................... 3-5
3.3.1. Determine your Cables...........................................................................................................................................................3-6
3.4. ADE TO BDE CABLES:..................................................................................................................................................................................3-7
3.5. BDE CABLES ...................................................................................................................................................................................................3-7
3.5.1. ST24 US/DLA/AUSSAT:............................................................................................................................................................3-7
3.5.2. ST24 DiSEqC:................................................................................................................................................................................3-7
3.5.3. ST24 Euro:......................................................................................................................................................................................3-7
3.6. ANTENNA/RADOME INSTALLATION ........................................................................................................................................................... 3-8
3.7. GRAPHIC ANTENNA CONTROL PANEL.....................................................................................................................................................3-10
4. SETUP ..................................................................................................................................................................................................................4-1
4.1. SETUP WIZARD ..............................................................................................................................................................................................4-1
5. OPERATION.....................................................................................................................................................................................................5-1
5.1. GRAPHIC ANTENNA CONTROL PANEL........................................................................................................................................................5-1
5.2. GACP HOME PAGE .......................................................................................................................................................................................5-2
5.3. SATELLITES PAGE...........................................................................................................................................................................................5-3
5.3.1. Satellite Target Page 1............................................................................................................................................................5-4
5.3.2. Satellite Target Page 2............................................................................................................................................................5-5
5.3.3. Satellite Edit Page 1..................................................................................................................................................................5-6
5.3.4. Satellite Edit Page 2..................................................................................................................................................................5-7
5.3.1. Satellite Preset Edit Page.......................................................................................................................................................5-8
5.3.2. Satellite View Page 1................................................................................................................................................................5-9
5.3.3. Satellite View Page 2.............................................................................................................................................................5-10
5.4. CURRENT SETTINGS PAGE 1......................................................................................................................................................................5-11
5.4.1. Current Settings Page 2 ......................................................................................................................................................5-12
5.5. ANTENNA PAGE............................................................................................................................................................................................5-13
5.5.1. Antenna Advanced Options Page 1...............................................................................................................................5-14
5.5.2. Antenna Advanced Options Page 2...............................................................................................................................5-15
5.6. POSITION.......................................................................................................................................................................................................5-18
5.7. SYSTEM INFORMATION PAGE....................................................................................................................................................................5-19
6. MAINTENANCE ............................................................................................................................................................................................6-1
6.1. WARRANTY INFORMATION.......................................................................................................................................................................... 6-1
6.2. WHO TO CONTACT FOR REPAIRS................................................................................................................................................................. 6-1
6.1. PREVENTIVE MAINTENANCE........................................................................................................................................................................ 6-1
6.2. TOUCH SCREEN CALIBRATION .................................................................................................................................................................... 6-2

Table of Contents ST24 Ku-Band TVRO
1-2
6.3. FAULT ISOLATION/TROUBLE-SHOOTING ...................................................................................................................................................6-4
6.4. REPLACING AN LNB.......................................................................................................................................................................................6-5
6.5. MANUAL POL TO AUTOPOL CONVERSION PROCEDURE..........................................................................................................................6-7
7. ST SERIES TECHNICAL SPECIFICATIONS................................................................................................................................ 7-1
7.1. INSTALLED WEIGHT.......................................................................................................................................................................................7-1
7.2. RADOME...........................................................................................................................................................................................................7-1
7.3. ANTENNA.........................................................................................................................................................................................................7-1
7.4. INTERCHANGEABLE LNB OPTIONS .............................................................................................................................................................7-1
7.4.1. US Circular LNB ..........................................................................................................................................................................7-1
7.4.2. DLA Circular LNB .......................................................................................................................................................................7-2
7.4.3. Aussat Linear LNB .....................................................................................................................................................................7-2
7.4.4. European Quad Universal Linear LNB.............................................................................................................................7-2
7.5. PEDESTAL CONTROL UNIT............................................................................................................................................................................7-2
7.6. STABILIZED PEDESTAL...................................................................................................................................................................................7-3
7.6.1. DVB Compliant Tracking Receiver....................................................................................................................................7-4
7.7. BELOW DECKS INTERFACE............................................................................................................................................................................7-4
7.8. POWER REQUIREMENTS ................................................................................................................................................................................7-5
7.9. ENVIRONMENTAL ...........................................................................................................................................................................................7-5
8. DRAWINGS......................................................................................................................................................................................................8-1

ST24 Ku-Band TVRO Quick Start
2-1
2. Quick Start
Operation of the ST24 Series antenna is accomplished via the Graphic Antenna Control Panel (GACP). Once properly
configured, the antenna will automatically search for and identify the last targeted satellite held in memory. Because of
programming requirements or changing of geographic locations, you may be required to change what satellite you wish to
track.. Read below for general panel operation instructions.
2.1. General Panel Operation
The GACP is a Panel Mount touch screen controller and navigation through its main and sub menu’s is accomplished
by pressing the desired icon itself and not the descriptive text below the icon. When applicable, the Left and Right
arrows may be used to navigate between main menu pages. The HOME icon may be pressed to return to the HOME
Page from any given menu or sub menu display. The Panel will go into a locked mode after five minutes of inactivity.
The Panel will go into Sleep mode after being in a locked mode for five minutes. NOTE: The Antenna will still be fully
functional. Press anywhere on the screen to bring the panel out of sleep mode and access the “Panel Unlock” screen.
The graphic to the right depicts the proper way to navigate through the menus by pressing
the icon itself.
The graphic to the right depicts the incorrect way to navigate through the menus by
pressing on the displayed text.
Navigational icons that are in full color are considered valid selections such as the “BACK”
arrow shown to the right.
Navigational icons that are in black and white are considered invalid selections, such as the
“BACK” arrow shown to the right.
2.2. Target a Satellite
Use the following flow chart to target a satellite.
Is desired preset
available on page? Yes
Yes
Is desired preset
available on page?
From the Home Page
No
Satellite
Preset is not
defined, refer
to “Configuring
a Preset”.
No
Press the
Satellites Icon
Press the
Target Icon
Press the
Satellite Preset
Name Icon
Press the
Right Arrow
Icon
Normal
Operation

Quick Start ST24 Ku-Band TVRO
2-2
THIS PAGE INTENIONALLY LEFT BLANK

ST24 Ku-Band TVRO Installation
3-1
3. Installation
Installation of the ST24 Antenna system will be presented into two major sections, the Above Decks Equipment (ADE) and the
Below Decks Equipment (BDE). This installation must be performed by or under the direct supervision of an authorized Sea Tel
Dealer for the limited warranty policy to be valid and enforced. A proper Site Survey MUST be performed prior to the actual
antenna installation to help ensure the best possible operation of the system. Proper planning is the key to a good installation,
please read this entire chapter thoroughly before beginning the actual installation and measure it against your site survey and
make adjust any details that you may have been overlooked.
The three following Simplified Block Diagrams (figures 1-3) are for visual reference only. Always refer to the System Block
Diagram, located in the drawings section of this manual for Coax and Wire interconnections and/or troubleshooting purposes.
Figure 1 ST24 DiSEqC Simplified Block Diagram

Installation ST24 Ku-Band TVRO
3-2
Figure 2 ST24 US/DLA/AUSSAT Simplified Block Diagram

ST24 Ku-Band TVRO Installation
3-3
Figure 3 ST24 Euro Simplified Block Diagram
3.1. Verify System Components
Before beginning it is critical that you inventory all system components. Refer to the appropriate packing list for your
Model antenna. Any discrepancies should be immediately reported to the Sea Tel service department so that a Service
Call may be filed and the required parts be shipped out.
3.2. Site Selection
Determine the optimum mounting location for the antenna radome assembly. Choosing the best mounting location
on vessels where there are few choice locations to choose from, is frequently a compromise. Below are some
considerations that should be taken as part of the Site Survey process.
•Above Decks
1. Blockage: The antenna should be mounted where the antenna has a clear line-of-sight view to as much of
the sky as is practical. Choosing a location where masts or other structures do not block the satellite signal
from the dish as the boat turns will directly affect the antenna’s ability to locate and track the desired
satellite.
2. The antenna is at least 5 feet away from other transmitting antennas (HF, VHF and radar) that may generate
signals that may interfere with the Coastal Series antenna. The further away the Coastal antenna is from
these other antennas, the less impact their operation will have on it as will our antenna have less of an impact
on them.
3. The antenna radome assembly should be rigidly mounted to the boat. If necessary, reinforce the mounting
area to assure that it does not flex due to the boat motion or vibration.
4. Bow or the Stern? Due to the violent G-forces exerted onto an antenna while the vessel’s BOW heaves versus
the relatively “cushioned” G-forces exerted onto an antenna at the stern of the vessel choosing the Stern
would be the ‘best’ option with all other factors being equal.

Installation ST24 Ku-Band TVRO
3-4
5. Mounting Height: The pedestal mounting height specification is not intended to be an absolute restriction on
pedestal placement. It is generically referred to in the section of the manual which describes the vessel
motions for which the stabilization accuracy is guaranteed. An exact mounting height limit is difficult to
quantify since all vessels respond differently to various wave patterns and no two sea-states produce the
same pattern of waves. We can, however, state a range of practical conditions and show the expected
pedestal response and limits for those conditions. Figure 2-2 shows the expected antenna performance in
relationship to vessel motion.
Figure 3-2 Antenna Mounting Height vs. Antenna Performance
6. Below Decks Equipment. Knowing where the BDE will be installed is useful so that you can determine the
shortest and most convenient cable path from the antenna to below decks.
•Below Decks
The Graphic Antenna Control Panel should be mounted in a convenient location for the operation of the
antenna system. It should be near one of the satellite receiver/television locations so that the receivers’ TV
screen can be viewed while the antenna is being operated. The supplied antenna control cable is routed from
the radome to the control panel, so routing path and cable length are important considerations both in
choosing the location of the control panel and to determine what type of RF cable should be used. The
technical specifications section of this manual provides the Sea Tel recommended cable type(s) as defined by
the overall cable run (from radome to the furthest receiver on the network).
Satellite receiver(s) and television set(s) - Satellite receiver(s) and television set(s) should be mounted near
each other in convenient viewing locations. If enclosed in a cabinet or panel, assure that there is adequate
airflow to prevent the receiver(s) and active matrix switch from over-heating and provide forced airflow if
needed. At each receiver location, leave a sufficient length of cable (service loop) to remove the receiver in
order to access its rear panel without pulling connections off of the rear panel.
3.2.1.
1. Lay the Installation Template (drawing 132903) on the mounting surface location that you have
chosen to mount the radome on.
Prepare the Antenna Radome Mounting Location
2. Align the radome “bow” mark on the template to be parallel to the bow of the boat. By default the
orientation of the “Sea Tel” logo is oriented towards BOW. You may as you see fit, adjust the
position of the “Bow” marker on template to orient the LOGO where you want it. When you are
satisfied with the position, tape the template in place.
Pedestal Mounting Height vs Roll Period
@ 25 degrees of Roll amplitude
0
50
100
150
200
250
6 7 8 9 10 11 12 13 14 15
Roll Period in Seconds
Mounting Height in Feet
2.0G
1.0G
0.5G
Full System Performance
Reduced Stabilization Accuracy
Full System Performance
Full Stabilization Accuracy
Reduced System
Performance
Not
Recomended
Possible
Mechanical
Failure

ST24 Ku-Band TVRO Installation
3-5
3. Using the center punch and hammer, mark the locations of the four radome mounting holes and the
cable passage. Remove the template drawing.
The 29” radome assembly provides the means to install the antenna to its
mounting surface on either a 9” D.B.C (factory default) or 12” D.B.C. You are only
required to use one of these hole patterns, not both.
4. Drill the four radome mounting holes using the 7/16” drill bit and the cable passage hole using a 4.5”
hole saw.
3.2.2.
1. Lay the Installation Template (drawing 132230) on the mounting surface location that you have
chosen to mount the Graphic Antenna Control Panel in.
Prepare the Antenna Control Panel mounting location
2. Adjust the position of the template to center the Antenna Control Panel cutout portion of the
drawing where you want it. When you are satisfied with the position tape the template in place.
3. Using the center punch and hammer, mark the locations of the four mounting holes and the four
corners of the cutout area. Remove the template drawing.
4. Mark the perimeter of the cutout area. Drill a hole inside the perimeter of the cutout area to enable
you to cut the area out with the saw (the 1” hole saw might be used for this).
5. Cut the area out.
6. Drill out the four GACP mounting holes.
3.3. Cable and Equipment Installation
Using the Matrix list below, determine the System Block Diagram (SBD) document number for your model antenna
system. This SBD will be utilized for component interconnection information.
System Model System Block Diagram Document #
ST24, Euro, AutoPol 132766-1
ST24 US, AutoPol 132766-2
ST24 DLA, AutoPol 132766-3
ST24 DiSEqC, AutoPol 132766-4
ST24 Aussat, AutoPol 132766-5
ST24, Euro, Manual Pol 132766-6
ST24 US, Manual Pol 132766-7
ST24 DLA, Manual Pol 132766-8
ST24 DiSEqC, Manual Pol 132766-9
ST24 Aussat, AutoPol 132766-10

Installation ST24 Ku-Band TVRO
3-6
3.3.1.
In addition to the required Coaxial cable that will interconnect the above decks equipment with the below decks
equipment, you will need to determine what cables are going to be used to interconnect satellite receivers to the
televisions and if installed the surround sound system. The below guide may be used to help determine which cable
type is best suited for your installation. You should refer to the manual of the CFE equipment for additional guidance.
Determine your Cables
Video Connection Reference Audio Connection Reference:
OK: Composite Video (Non-HD Video Only)
Typically an RCA Jack, this type
of connection combines and
transmits chrominance and
luminance information on a
single cable.
OK: Stereo RCA (2 channel Analog)
These RCA Jack connections are a means of
passing analog line-level audio signals (split
into left and right channels) from the
satellite receiver to your television or audio
amplifier.
Good: S-Video (Non HD Video Only)
S-video connections transmit
the chrominance (color) and
luminance (brightness) portions
of a video signal along different
paths, allowing them to be
processed separately.
Good: RCA (Multi-Channel Analog)
These preamp-level analog inputs
features jacks for up to 8 channels:
left front, right front, center channel,
left surround, right surround, and
subwoofer. Because the subwoofer
channel carries a limited range of frequencies, it's the
".1" in 5.1. A 6.1 input features the same jacks as a 5.1
input, but adds a back surround jack. A 7.1 input adds
two back surround jacks.
Better: Component (HD Video Only )
This 3-cable connection allows the
chrominance (color) and luminance
(brightness) portions of a video
signal to be processed separately
.S-Video works similarly, but
component video improves color
accuracy further by splitting the chrominance
signal into two portions.
Better: XLR (Hi Resolution Analog)
XLR audio
connections are
used primarily
with high-
performance audio gear. This 3 pin connector
dedicates one of these pins for ground which helps
reduce electronic noise throughout the cable. A clasp
built into the round XLR plug locks it tightly into the
socket, ensuring a secure connection even during full
ships motion.
Best: HDMI (Both HD Video and Digital Audio)
HDMI is a multi-pin connection used for passing standard- and high-definition
digital video signals, as well as up to 8 discrete digital audio channels, through a
single cable.

ST24 Ku-Band TVRO Installation
3-7
3.4. ADE to BDE Cables:
3.4.1.
Route and label an Antenna M&C Coax from the radome mounting location through the vessel and down to
the GACP mounting location.
Antenna M&C Coax
Adjust the cable routing so that about 12 inches (30.5cm) of cable extends beyond the radome mounting
surface and about 4 inches (10cm) of cable extending out of the antenna control panel mounting surface.
3.4.2.
If required, route and the IF Coax(es) from the radome mounting location through the vessel and down to
the active multi-switch mounting location.
Satellite IF Coaxes
Adjust the cable routing so that about 12 inches (30.5cm) of cable extends beyond the radome mounting
surface and about 6 inches (10cm) of cable extending out of the antenna control panel mounting surface.
ST24 Euro Systems require 4 ADE to BDE Coax cables in addition to the Antenna M&C Coax. (Horizontal
High Band IF is stacked onto the Antenna M&C Coax)
ST24 US/DLA Systems require 2 ADE to BDE Coax Cables in addition to the Antenna M&C Coax.
ST24 DiSEqC System require 1 ADE to BDE Coax Cable in addition to the Antenna M&C Coax.
3.5. BDE Cables
3.5.1.
3.5.1.1. Multiswitch to Receiver(s)
ST24 US/DLA/AUSSAT:
Route the receiver IF coaxes from the Multiswitch mounting location to each of the receivers on the
network. Leave about 4 inches (10cm) of coax extending out each mounting location.
3.5.1.2. Receiver(s) to Television(s)
Route the appropriate Audio/Visual cables from each Television mounting location to each of the
receivers mounting locations.
3.5.2.
3.5.2.1. Multiswitch to DiSEqC Switch(es)
ST24 DiSEqC:
Route the receiver IF coaxes from the Multiswitch mounting location to each of the DiSEqC switch
mounting locations of the network. Leave about 4 inches (10cm) of coax extending out each
mounting location.
3.5.2.2. DiSEqC Switch(es) to Receiver(s)
Route the receiver IF coaxes from DiSEqC switch mounting locations to each of the Receiver
mounting locations on the network. Leave about 4 inches (10cm) of coax extending out each
mounting location.
3.5.2.3. Master DiSEqC Switch to GACP
Route the RS-232 Serial Cable from Master DiSEqC switch mounting locations to the GACP
mounting location. Leave about 4 inches (10cm) of coax extending out each mounting location.
3.5.2.4. Receiver(s) to Television(s)
Route the appropriate Audio/Visual cables from each Television mounting location to each of the
receivers mounting locations.
3.5.3.
3.5.3.1. Multiswitch to Receiver(s)
ST24 Euro:
Route the receiver IF coaxes from the Multiswitch mounting location to each of the receivers on the
network. Leave about 4 inches (10cm) of coax extending out each mounting location.

Installation ST24 Ku-Band TVRO
3-8
3.5.3.2. DC Power Cable (All Models)
3.5.3.2.1.
Route the DC Power cable assembly from the Vessel Power Source to the GACP mounting
location.
Supply to GACP
3.5.3.2.2.
Perform the following step only if installing the optional power switch.
Supply to Optional Power Switch
Route the DC Power cable assembly from the Vessel Power Source to the Optional Power
Switch mounting location.
Continue routing the remaining wires from the Optional Power Switch mounting location
to the GACP mounting location.
3.6. Antenna/Radome Installation
Connect and secure the Antenna M&C Coax to the
M&C connector (Black Heat Shrink) at the base of
the radome.
Referring to the System Block Diagram for color
code callouts, connect and secure the IF Coaxes
from below decks to the connector bracket at the
base of the radome.
Apply Loctite™ thread locker to the four M8
Mounting Studs. Using the provided L-Key, install
and secure the studs onto the deck mounting
adapters located at the base of the radome.
Carefully place radome onto mounting location, be
careful not to pinch coaxes in between radome
and mounting surface.

ST24 Ku-Band TVRO Installation
3-9
From below the mounting surface, apply Loctite
thread locker to the four M8 mounting studs.
Install the fender washers and the M8 nut and
Torque to 15 N-m.
NOTE: Graphic to the right is shown with the radome
mounting pad (normally installed flush with mounting
adapter) removed for clarity.
Using a 3mm Allen Wrench, remove the hardware
that secures radome top to radome base.
Use caution as to not lose the mounting inserts.
Locate and disengage the Elevation Stowage lock.
Refer to the Maintenance section of this manual
for complete procedures to stow and un-stow your
antenna.

Installation ST24 Ku-Band TVRO
3-10
Locate and disengage the Azimuth Stowage lock.
Refer to the Maintenance section of this manual
for complete procedures to stow and un-stow your
antenna.
Perform range of motion check on antenna.
Verify free range in Azimuth, Elevation and Polarization drive.
3.7. Graphic Antenna Control Panel
Label, Connect, and Secure the Antenna M&C
Coax (from Above Decks) to the RF In port of
the GACP.
Connect and secure the DC Power Cable
Assembly or the optional DC Power Switch
Cable Assembly onto the “BATT” connector of
the GACP.
Carefully remove GACP front lid to provide access to the four mounting holes.
Use caution as to not damage or pull out the “COM 0” interface harness that interconnects the display
module PCB to the controller PCB.

ST24 Ku-Band TVRO Installation
3-11
Carefully install the GACP into the mounting
location while placing the excess cables into
the void of the mounting location and secure
using 4 self tapping screws.
Reinstall the GACP front lid to the enclosure.

Installation ST24 Ku-Band TVRO
3-12
THIS PAGE INTENIONALLY LEFT BLANK

ST24 Ku-Band TVRO Setup
4-1
4. Setup
As a part of initial commissioning of the ST24 you will be required to configure and optimize the system to the clients specific
needs. An easy to use Setup Wizard will aid in this configuration process. Use the below procedures and flowcharts as a guide
to accomplish these tasks.
4.1. Setup Wizard
When the system is turned on for the first time, the user will be prompted to configure the ST24 Antenna System for
operation via an easy 6 step setup wizard. Otherwise, this setup wizard is accessible on page two of the Antenna’s
Advanced Options menu.
1. When prompted press the right arrow to begin the setup Wizard.
2. If desired, press in the middle of the screen to calibrate the touch screen panel. Press the right arrow to skip
this step.
3. Select the receive polarization type of the satellite(s) you intend to track and press the right arrow to accept
and continue.

Setup ST24 Ku-Band TVRO
4-2
4. Select the Antenna’s Polarization type, choose Auto if your feed assembly is fitted with a drive motor
otherwise choose Manual.
5. Select the satellite switching mode. Choose "Active" to enable DiSEqC based satellite switching or choose
Inactive for manual satellite switching mode. NOTE: DiSEqC switches and compatible EchoStar based
receivers are required in order to run in Active mode.
