FLIPS PLUS PHOTOCELLS (23102205)
TX - TRANSMITTER PHOTOCELL INSTALLATION
- Place the TX photocell by the use of the appropriate fixing screws according to the nature of the surface
- Insert the cables in the housing and make the connections as indicated on the next page according to the type
of application required (12V or 24V~ or 24V ; synchronized or not synchronized)
- Arrange the cables so that the excess is removed
- Fix the TX photocell
- Seal the sheath and any holes that may convey foreign bodies inside the plastic case
RX - RECEIVER PHOTOCELL INSTALLATION
- Place the RX photocell on the opposite surface and align it with the TX photocell
- Insert the cables in the appropriate housing and make the connections as indicated on the next page according
to the type of application required (12V or 24V~ or 24V ; synchronized or not synchronized)
- Arrange the cables so that the excess is removed
- Fix the RX photocell in front position and perfectly aligned on the same axis and at the same height as the
associated TX photocell. Adjust the alignment of the circuit if necessary (see next page)
- Seal the sheath and any holes that may convey foreign bodies inside the plastic case
Once the installation for both the TX and the RX photocell is complete, power the photocells (12V or 24V ~
or 24V ) and check their alignment: if the connection, positioning and alignment of the photocells is correct,
the red LED on the RX photocell will be on
IMPORTANT NOTE - FOR THE «SYNCHRONIZED PHOTOCELLS» FUNCTION, THE POWER SUPPLY MUST NECESSARILY
BE 12V/24V~ (AC)
CHECKING
Interrupt the infrared ray several times with a black card (or something opaque to the infrared) checking:
- the response (exchange) of the relay
- that the red LED on the RX photocell turns off every time the beam is interrupted
LED OPERATION
RED LED ON: device ALIGNED
RED LED OFF: device NOT ALIGNED
1 RX receiver photocell
1 TX transmitter photocell
1 KIT for fixing
1 Instruction
OPTIONAL ACCESSORIES:
Aluminum cover (23101195)
to replace the nylon cover
CARTON INVENTORY
12/24V /V~
15 meters
Modulated infrared
880 nm
1000 Hz 24V - 1A Max
From 5% to 90% - non condensing
129 x 48 x 42 mm
- 20° C + 70° C
IP 55
TX: 30 mA RX: 30 mA
- 15° C + 60° C
Absorption
Operating
temperature
Relay contact rating
Humidity
Dimensions
Storage temperature
Protection degree
Range
Signal
Wavelength
Modulation frequency
Power supply
TECHNICAL DATA
**
THE RANGE OF THE DEVICE CAN BE REDUCED BY UP TO 70% IN
CASE OF BAD WEATHER CONDITIONS (FOG, RAIN, ETC.)
**
The FLIPS PLUS are photocells made of nylon with glass fiber, equipped with an EMI
screen that ensures operation even in the presence of electromagnetic disturbances.
They can also be synchronized if powered in 24Vac; they are equipped with a relay
output with 1A contact capacity and can be adjusted by ± 90° along the horizontal axis
and by ± 5° along the vertical axis, to allow easy installation. The FLIPS PLUS have
been designed for installations where it is necessary to apply two superimposed
photocells, without colliding each other; to obtain this result, it is sufficient to power the
photocells in 24V~ and cross the power supplies: if the TX and RX of the first photocell
are powered with a black cable on 0V~ and with a red cable on 24V~, then the TX and
RX of the second photocell must have the red cable on 0V~ and the black cable on 24V~
