Seagate ST1000LX000 User manual

100716627, Rev. M
December 2016
Standard models
ST1000LM014
ST1000LX000
ST1000LX001
ST750LM000
Self-Encrypting Drive models
ST1000LM015
SED (FIPS 140-2) models
ST1000LM028
Laptop SSHD
SATA Product Manual

© 2016 Seagate Technology LLC. All rights reserved.
Publication number: 100716627, Rev. M December 2016
Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. 3D Defense System and SeaTools are
either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. The FIPS logo is a certification mark
of NIST, which does not imply product endorsement by NIST, the U.S., or Canadian governments. All other trademarks or registered trademarks are the property of their respective
owners.
No part of this publication may be reproduced in any form without written permission of Seagate Technology LLC.
Call 877-PUB-TEK1 (877-782-8351) to request permission.
When referring to drive capacity, one gigabyte, or GB, equals one billion bytes and one terabyte, or TB, equals one trillion bytes. Your computer’s operating system may use a different
standard of measurement and report a lower capacity. In addition, some of the listed capacity is used for formatting and other functions, and thus will not be available for data storage.
Actual quantities will vary based on various factors, including file size, file format, features and application software. Actual data rates may vary depending on operating environment
and other factors. The export or re-export of hardware or software containing encryption may be regulated by the U.S. Department of Commerce, Bureau of Industry and Security (for
more information, visit www.bis.doc.gov), and controlled for import and use outside of the U.S. Seagate reserves the right to change, without notice, product offerings or specifications.
Document Revision History
Revision Date Pages Affected
Rev. A 01/08/2013 Initial release
Rev. B 05/01/2013 fc, 1-2, 4-5, 11, 16 & 19-21.
Rev. C 06/05/2013 7.
Rev. D 07/08/2013 2.
Rev. E 01/16/2014 2, 5, 11 & 17-18.
Rev. F 06/24/2014 7 & 15.
Rev. G 08/27/2014 15.
Rev. H 08/05/2015 FC, BC, 5-6, 8-10 & 26-28.
Rev. J 09/30/2015 5, 9 & 15
Rev. K 05/11/2016 16: Added DC Magnetic Field Immunity Table
Rev. L 10/14/2016
17: Updated to Electromagnetic Compatibility Directive 2014/30/EU
17: Updated to Korean RRA & Added MSIP Korean text for Class B device warning
17: Updated to Australian RCM
18: Updated to China RoHS 2
Rev. M 12/07/2016 20: Removed footnote.

Seagate Laptop SSHD SATA Product Manual, Rev. M 2
Contents
Seagate® Technology Support Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.1 About the Serial ATA Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.0 Drive Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.1 Formatted Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
2.1.1 LBA mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
2.2 Physical organization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
2.3 Recording and Interface Technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
2.4 Physical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
2.5 Seek time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
2.6 Start/stop times . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
2.7 Power Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
2.7.1 Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
2.7.2 Conducted noise. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
2.7.3 Voltage tolerance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
2.7.4 Power management modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
2.8 Environmental Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
2.8.1 Shock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
2.8.2 Vibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
2.9 Acoustics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
2.9.1 Test for prominent discrete tones (PDTs). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
2.10 Electromagnetic Immunity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
2.10.1 DC Magnetic Field Immunity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
2.11 Reliability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
2.12 Agency Certification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
2.12.1 Safety certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
2.12.2 Electromagnetic Compatibility (EMC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
2.12.3 FCC verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
2.13 Environmental Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
2.13.1 European Union Restriction of Hazardous Substances (RoHS) Directive . . . . . . . . . . . . . .18
2.13.2 China Requirements — China RoHS 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
2.14 Corrosive Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
3.0 Configuring and Mounting the Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.1 Handling and Static-Discharge Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
3.2 Configuring the Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
3.2.1 Serial ATA Cables and Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
3.3 Drive Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Seagate Laptop SSHD SATA Product Manual, Rev. M 3
Contents
4.0 About FIPS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.0 About (SED) Self-Encrypting Drives. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.1 Data Encryption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
5.2 Controlled Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
5.2.1 Admin SP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
5.2.2 Locking SP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
5.2.3 Default password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
5.2.4 ATA Enhanced Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
5.3 Random Number Generator (RNG) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
5.4 Drive Locking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
5.5 Data Bands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
5.6 Cryptographic Erase. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
5.7 Authenticated Firmware Download . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
5.8 Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
5.9 Supported Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
5.10 RevertSP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
6.0 Serial ATA (SATA) Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
6.1 Hot-Plug Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
6.2 Serial ATA Device Plug Connector Pin Definitions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
6.3 Supported ATA Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
6.3.1 Identify Device command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
6.3.2 Set Features command. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
6.3.3 S.M.A.R.T. commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

Seagate Laptop SSHD SATA Product Manual, Rev. M 4
Figures
Figure 1 Typical 5V Startup and Operation Current Profile. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Figure 2 Attaching SATA Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Figure 3 Mounting Dimensions (for standard models) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Figure 4 Example of FIPS tamper evidence labels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Seagate Laptop SSHD SATA Product Manual, Rev. M 5
For information regarding online support and services, visit: http://www.seagate.com/contacts/
For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/
For information regarding data recovery services, visit: http://www.seagate.com/services-software/data-recovery-services/
For Seagate OEM, Distribution partner and reseller portals, visit: http://www.seagate.com/partners/
Seagate® Technology Support Services

Seagate Laptop SSHD SATA Product Manual, Rev. M 6
Introduction
1.0 Introduction
This manual describes the functional, mechanical and interface specifications for the following Seagate®Laptop SSHD model drives:
For more information on SED drives see About (SED) Self-Encrypting Drives on page 22.
For more information on FIPS 140-2 Level 2 certification About FIPS on page 21.
These drives provide the following key features:
n8GB NAND flash on models ST1000LM014, ST1000LM015, ST1000LM028 & ST750LM0000
n16GB NAND flash on model ST1000LX000
n32GB NAND flash on model ST1000LX001
n1000 Gs nonoperating shock and 350 Gs of operating shock.
n5400-RPM spindle speed.
n64MB buffer.
nFull-track multiple-sector transfer capability without local processor intervention.
nHigh instantaneous (burst) data-transfer rates (up to 6Gb/s).
nNative Command Queuing (NCQ) with command ordering.
noffers the industry’s most comprehensive protection for disk drives.
nPerpendicular recording technology.
nQuiet operation. Fluid Dynamic Bearing (FDB) motor.
nSeaToolsTM diagnostic software performs a drive self-test that eliminates unnecessary drive returns.
nState-of-the-art cache and on-the-fly error-correction algorithms.
nSupport for Read Multiple and Write Multiple commands.
nSupport for S.M.A.R.T. drive monitoring and reporting.
nThe 3D Defense System™, which includes Drive Defense, Data Defense and Diagnostic Defense,
nWorldwide Name (WWN) capability uniquely identifies the drive.
Standard models Standard SED models SED (FIPS 140-2) models
ST1000LX000 ST1000LM014 ST1000LM015 ST1000LM028
ST1000LX001 ST750LM000
Note
Previous generations of Seagate Self-Encrypting Drive models were called
Full Disk Encryption (FDE) models before a differentiation between drive-
based encryption and other forms of encryption was necessary.
Note
For improved reliability, Seagate SSHDs incorporate a technique referred
to as 'Combo Mode', utilizing proprietary controls to reduce the number
of bits stored to a portion of the NAND Flash.

Seagate Laptop SSHD SATA Product Manual, Rev. M 7
Introduction
Seagate Laptop SSHD Self-Encrypting Drive models have the following additional features
n16 independent data bands
nAuthenticated firmware download.
nAutomatic data encryption/decryption
nControlled access
nCryptographic erase of user data for a drive that will be repurposed or scrapped
nDrive locking
nRandom number generator
There is no significant performance difference between Self-Encrypting Drive and standard (non-Self-Encrypting Drive) models.
1.1 About the Serial ATA Interface
The Serial ATA interface provides several advantages over the traditional (parallel) ATA interface. The primary advantages include:
nEasy installation and configuration with true plug-and-play connectivity. It is not necessary to set any jumpers or other configuration options.
nThinner and more flexible cabling for improved enclosure airflow and ease of installation.
nScalability to higher performance levels.
In addition, Serial ATA makes the transition from parallel ATA easy by providing legacy software support. Serial ATA was designed to allow users to
install a Serial ATA host adapter and Serial ATA disk drive in the current system and expect all of the existing applications to work as normal.
The Serial ATA interface connects each disk drive in a point-to-point configuration with the Serial ATA host adapter. There is no master/slave
relationship with Serial ATA devices like there is with parallel ATA. If two drives are attached on one Serial ATA host adapter, the host operating
system views the two devices as if they were both “masters” on two separate ports. This essentially means both drives behave as if they are Device 0
(master) devices.
The Serial ATA host adapter and drive share the function of emulating parallel ATA device behavior to provide backward compatibility with existing
host systems and software. The Command and Control Block registers, PIO and DMA data transfers, resets, and interrupts are all emulated.
The Serial ATA host adapter contains a set of registers that shadow the contents of the traditional device registers, referred to as the Shadow
Register Block. All Serial ATA devices behave like Device 0 devices. For additional information about how Serial ATA emulates parallel ATA, refer to
the Serial ATA International Organization: Serial ATA (Revision 3.0). The specification can be downloaded from www.serialata.org.
Note
The host adapter may, optionally, emulate a master/slave environment to host software where two devices on
separate Serial ATA ports are represented to host software as a Device 0 (master) and Device 1 (slave) accessed
at the same set of host bus addresses. A host adapter that emulates a master/slave environment manages two
sets of shadow registers. This is not a typical Serial ATA environment.

Seagate Laptop SSHD SATA Product Manual, Rev. M 8
Drive Specifications
2.0 Drive Specifications
Unless otherwise noted, all specifications are measured under ambient conditions, at 25°C, and nominal power. For convenience, the phrases the
drive and this drive are used throughout this manual to indicate the following drive models:
The specification summaries listed in the following tables are for quick reference. For details on specification measurement or definition, refer to the
appropriate section of this manual.
Table 1 Drive Specifications Summary
Drive Specification ST1000LX000 ST1000LX001
ST1000LM014,
ST1000LM015
ST1000LM028
ST750LM000
Formatted capacity (1) 1TB 750 GB
Guaranteed sectors 1,953,525,168 1,465,149,168
Heads 4
Disks 2
Bytes per sector 512 (logical) / 4096 (physical)
NAND flash
Commercial Multilevel Cell (cMLC) 16GB 32GB 8GB
Recording density 1894 Kb/in
Track density 375 Ktracks/in avg
Areal density 705 Gb/in2 avg
Spindle speed 5400 RPM
Sustained data transfer rate OD 100 MB/s max
I/O data-transfer rate 600 MB/s max
ATA data-transfer modes supported
PIO modes 0–4
Multiword DMA modes 0–2
Ultra DMA modes 0–6
Cache buffer 64MB
Height 9.5 +/- 0.2 mm (0.374 +/-.008 in)
Width 69.85 +/- 0.25 mm (2.750 +/- 0.010 in)
Length 100.35 +0.20 / -0.25 mm (3.951 +0.008 / -0.010 in)
Weight (typical) 115 g (0.254 lb)
Average latency 5.6 ms
Startup current (typical) 5V (peak) 1.0 A
Voltage tolerance (including noise) 5V ± 5%
Operating temperature 0° to 60°C
Nonoperating temperature
(Ambient) –40° to 70°C
Temperature gradient (max) 20°C per hour max (operating)
35°C per hour max (nonoperating)
Relative humidity 5% to 95% (operating)
5% to 95% (nonoperating)

Seagate Laptop SSHD SATA Product Manual, Rev. M 9
Drive Specifications
Relative humidity gradient 30% per hour max
Wet bulb temperature (max) 37.7°C max (operating)
40.0°C max (nonoperating)
Altitude, operating –304.8 m to 3048 m (–1000 ft to 10,000+ ft)
Altitude, nonoperating
(below mean sea level, max) –304.8 m to 12,192 m (–1000 ft to 40,000+ ft)
Operational Shock 350 Gs at 2 ms max
Non-Operational Shock 1000 Gs at 1 ms max
Vibration, operating 5–200 Hz: 2.0 Gs
201–500 Hz: 1.0 Gs
Vibration, nonoperating 5–500 Hz: 5.0 Gs
Nonrecoverable read errors 1 per 1015 bits read
Annualized Failure Rate (AFR) 1%
Rated workload
Average annualized workload rating: <55 TB/year.
The AFR specification for the product assumes the I/O workload does not exceed the aver-
age annualized workload rate limit of 55 TB/year. Workloads exceeding the annualized rate
may degrade the product AFR and impact reliability as experienced by the particular
application. The average annualized workload rate limit is in units of TB per calendar year.
Warranty
To determine the warranty for a specific drive, use a web browser to access the following
web page: http://www.seagate.com/support/warranty-and-replacements/
From this page, click on the “Is my Drive under Warranty” link. Users will be asked to pro-
vide the drive serial number, model number (or part number) and country of purchase.
The system will display the warranty information for the drive.
Load-unload cycles 600,000 at 25°C, 50% rel. humidity
Supports Hotplug operation per the
Serial ATA Revision 3.2 specification Yes
1. One GB equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting.
Table 1 Drive Specifications Summary (continued)
Drive Specification ST1000LX000 ST1000LX001
ST1000LM014,
ST1000LM015
ST1000LM028
ST750LM000

Seagate Laptop SSHD SATA Product Manual, Rev. M 10
Drive Specifications
2.1 Formatted Capacity
2.1.1 LBA mode
When addressing these drives in LBA mode, all blocks (sectors) are consecutively numbered from 0 to n–1, where n is the number of guaranteed
sectors as defined above.
Refer to Configuring and Mounting the Drive on page 19 (words 60-61 and 100-103) for additional information about 48-bit addressing support
of drives with capacities over 137 GB.
2.2 Physical organization
2.3 Recording and Interface Technology
2.4 Physical Characteristics
Model Formatted Capacity(1)
1. One GB equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment
and formatting.
Guaranteed Sectors Bytes per Sector
ST1000LX000, ST1000LX001,
ST1000LM014, ST1000LM015
and ST1000LM028
1000 GB 1,953,525,168 512 (logical) /
4096 (physical)
ST750LM000 750 GB 1,465,149,168
Drive model Read/write heads Number of discs
ST1000LX000, ST1000LX001,
ST1000LM014, ST1000LM015
and ST1000LM028 4 2
ST750LM000
Interface Serial ATA (SATA)
Recording method Perpendicular
Recording density 1894 Kb/in
Track density 375 ktracks/in avg
Areal density 705 Gb/in2 avg
Spindle speed 5400 RPM +/- 0.2%
Sustained data transfer rate 100 MB/s max
I/O data-transfer rate 600 MB/s max
All models
Height 9.5 +/- 0.2 mm (0.374 +/-.008 in)
Width 69.85 +/- 0.25 mm (2.750 +/- 0.010 in)
Length 100.35 +0.20 / -0.25 mm (3.951 +0.008 / -0.010 in)
Typical weight 115 g (0.254 lb)
Cache buffer 64MB (65,536 KB)

Seagate Laptop SSHD SATA Product Manual, Rev. M 11
Drive Specifications
2.5 Seek time
Seek measurements are taken with nominal power at 25°C ambient temperature. All times are measured using drive diagnostics. The specifications
in the table below are defined as follows:
nTrack-to-track seek time is an average of all possible single-track seeks in both directions.
nAverage seek time is a true statistical random average of at least 5000 measurements of seeks between random tracks, less overhead.
2.6 Start/stop times
2.7 Power Specifications
The drive receives DC power (+5V) through a native SATA power connector (refer to Figure 2).
2.7.1 Power consumption
Power requirements for the drives are listed in the table in Table 4. Typical power measurements are based on an average of drives tested, under
nominal conditions, at 25°C ambient temperature. These power measurements are done with Interface Power Management modes like HIPM
and DIPM enabled.
nSpinup power
Spinup power is measured from the time of power-on to the time that the drive spindle reaches operating speed.
nSeek mode
During seek mode, the read/write actuator arm moves toward a specific position on the disk surface and does not execute a read or write
operation. Servo electronics are active. Seek mode power is measured based on three random seek operations every 100 ms. This mode is not
typical.
nRead/write power and current
Read/write power is measured with the heads on track, based on three 63 sector read or write operations every 100 ms.
nIdle mode power
Idle mode power is measured with the drive up to speed, with servo electronics active and with the heads in a random track location.
nStandby mode
During standby mode, the drive accepts commands, but the drive is not spinning, and the servo and read/write electronics are in power-down
mode.
Table 2 Typical seek times
Typical seek times (ms) Read
Track-to-track 2.0
Average 12.0
Average latency 5.6
Note
These drives are designed to consistently meet the seek times represented in this manual. Physical seeks, regardless
of mode (such as track-to-track and average), are expected to meet the noted values. However, due to the manner in
which these drives are formatted, benchmark tests that include command overhead or measure logical seeks may
produce results that vary from these specifications.
Table 3 Start/stop times
Typical seek times (ms) Typical Max @ 25°C
Power-on to ready (sec) <1.0 <1.0
Standby to ready (sec) <1.0 <1.0

Seagate Laptop SSHD SATA Product Manual, Rev. M 12
Drive Specifications
2.7.1.1 Typical current profiles
The typical 5V startup and operation current profile is shown in Figure 1.
Figure 1 Typical 5V Startup and Operation Current Profile
Table 4 DC Power Requirements
Power Dissipation +5V input average (25° C)
Spinup (max) 1.50A
Seek average 2.7W
Write average 3.7W
Read average 3.1W
Idle, performance (1) 2.2W
Idle, active 1.1W
Idle, low power mode 0.9W
Standby(2) 0.53W
Sleep 0.53W
1. During periods of drive idle, some offline activity may occur according to the S.M.A.R.T.
specification, which may increase acoustic and power to operational levels.
2. Standby power is measured at steady state (after 200ms from transition)

Seagate Laptop SSHD SATA Product Manual, Rev. M 13
Drive Specifications
2.7.2 Conducted noise
Input noise ripple is measured at the host system power supply across an equivalent 15-ohm resistive load on the +5 volt line.
nUsing 5-volt power, the drive is expected to operate with a maximum of 100 mV peak-to-peak square-wave injected noise at up to 10 MHz.
2.7.3 Voltage tolerance
Voltage tolerance (including noise):
n+5V ± 5%
2.7.4 Power management modes
The drive provides programmable power management to provide greater energy efficiency. In most systems, power management is controlled
through the system setup program. The drive features the following power-management modes:
nActive mode
The drive is in active mode during the read/write and seek operations.
nIdle mode
The buffer remains enabled, and the drive accepts all commands and returns to active mode any time disk access is necessary.
nStandby mode
The drive enters standby mode when the host sends a standby Immediate command. If the host has set the standby timer, the drive can also
enter standby mode automatically after the drive has been inactive for a specifiable length of time. The standby timer delay is established using
a standby or idle command. In standby mode, the drive buffer is enabled, the heads are parked and the spindle is at rest. The drive accepts all
commands and returns to active mode any time disk access is necessary.
nSleep mode
The drive enters sleep mode after receiving a sleep command from the host. In sleep mode, the drive buffer is disabled, the heads are parked and
the spindle is at rest. The drive leaves sleep mode after it receives a hard reset or soft reset from the host. After receiving a reset, the drive exits
sleep mode and enters standby mode with all current translation parameters intact.
nIdle and standby timers
Each time the drive performs an active function (read, write or seek), the standby timer is reinitialized and begins counting down from its
specified delay times to zero. If the standby timer reaches zero before any drive activity is required, the drive makes a transition to standby mode.
In both Idle and standby mode, the drive accepts all commands and returns to active mode when disk access is necessary.
Note Equivalent resistance is calculated by dividing the nominal voltage by the typical RMS read/write current.
Power modes Heads Spindle Buffer
Active (operating) Tracking Rotating Full power
Idle, performance Tracking Rotating Self refresh—low power
Idle, active Floating Rotating Self refresh—low power
Idle, low power Parked Rotating Self refresh—low power
Standby Parked Stopped Self refresh—low power
Sleep Parked Stopped Self refresh—low power

Seagate Laptop SSHD SATA Product Manual, Rev. M 14
Drive Specifications
2.8 Environmental Specifications
This section provides the temperature, humidity, shock, and vibration specifications for Seagate Laptop SSHD drives. Ambient temperature is
defined as the temperature of the environment immediately surrounding the drive. Above 1000 feet (305 meters), the maximum temperature is
derated linearly by 1°C every 1000 feet.
2.8.1 Shock
All shock specifications assume that the drive is mounted securely with the input shock applied at the drive mounting screws. Shock may be
applied in the X, Y, or Z axis.
2.8.1.1 Operating shock
These drives comply with the performance levels specified in this document when subjected to a maximum operating shock of 350 Gs based on
half-sine shock pulses of 2ms. Shocks should not be repeated more than one time per axis
2.8.1.2 Nonoperating shock
The nonoperating shock level that the drive can experience without incurring physical damage or degradation in performance when subsequently
put into operation is 800 Gs based on a nonrepetitive half-sine shock pulse of 2 ms duration.
The nonoperating shock level that the drive can experience without incurring physical damage or degradation in performance when subsequently
put into operation is 1000 Gs based on a nonrepetitive half-sine shock pulse of 1 ms duration.
Table 5: Environmental specifications
Parameters Operating Non-Operating
Ambient temperature 0° to 60°C (32° to 140°F) -40° to 70°C (-40° to 158°F)
Temperature gradient 20°C per hour (68°F per hour) max,
without condensation
35°C per hour (95°F per hour) max,
without condensation
Humidity 5% to 95% non-condensing
(30% per hour)
5% to 95% non-condensing
(30% per hour)
Wet bulb 37.7°C (99.8°F) max 40°C (104°F) max
Altitude -304.8m to 3048m
(-1000ft to 10,000ft)
-304.8m to 12,192m
(-1000ft to 40,000ft)
Note
The recommended storage period:
•1 year under controlled conditions of 34°C 90%RH or less
•90 days in uncontrolled storage conditions

Seagate Laptop SSHD SATA Product Manual, Rev. M 15
Drive Specifications
2.8.2 Vibration
All vibration specifications assume that the drive is mounted securely with the input vibration applied at the drive mounting screws. Vibration may
be applied in the X, Y, or Z axis.
2.8.2.1 Operating vibration
The maximum vibration levels that the drive may experience while meeting the performance standards specified in this document are specified
below.
2.8.2.2 Nonoperating vibration
The maximum nonoperating vibration levels that the drive may experience without incurring physical damage or degradation in performance
when subsequently put into operation are specified below.
2.9 Acoustics
Drive emission of sound is measured consistent with the ECMA-74 and its referenced standards. Testing is conducted at room temperature
(approximately 25°C). Emission levels are reported as the total A-weighted sound power levers for steady state, idle, and active seeks modes of
operation.
2.9.1 Test for prominent discrete tones (PDTs)
Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute
threshold of hearing. Seagate uses the lower limit for the threshold curve* to discern tone audibility and to compensate for the inaudible
components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards.
*Defined as the median curve given by ISO 389-7 (Tf curve) minus 10dB at all frequencies.
5–200 Hz 2.0 Gs (0 to peak). Max displacement may apply below 10 Hz.
201–500 Hz 1.0 Gs (0 to peak).
5–500 Hz 5.0 Gs (0 to peak). Max displacement may apply below 22 Hz.
Table 6 Drive A-weighted Sound Power Levels (SWL, BA)
Idle(1)
1. During periods of drive idle, some offline activity may occur according to the S.M.A.R.T.
specification, which may increase acoustic and power to operational levels.
Performance Seek
2.2 bels (typ)
2.4 bels (max)
2.4 bels (typ)
2.6 bels (max)

Seagate Laptop SSHD SATA Product Manual, Rev. M 16
Drive Specifications
2.10 Electromagnetic Immunity
When properly installed in a representative host system, the drive operates without errors or degradation in performance when subjected to the
radio frequency (RF) environment as defined in Table 7.
2.10.1 DC Magnetic Field Immunity
2.11 Reliability
Table 7 Radio Frequency Environments
Test Description Performance
Level Reference Standard
Electrostatic discharge Contact, HCP, VCP: ± 4 kV; Air: ± 8 kV B EN 61000-4-2: 95
Radiated RF immunity 80 to 1,000 MHz, 3 V/m, 80% AM with 1 kHz sine
900 MHz, 3 V/m, 50% pulse modulation @ 200 Hz AEN 61000-4-3: 96 ENV 50204: 95
Electrical fast transient ± 1 kV on AC mains,
± 0.5 kV on external I/O B EN 61000-4-4: 95
Surge immunity ± 1 kV differential,
± 2 kV common, AC mains B EN 61000-4-5: 95
Conducted RF immunity 150 kHz to 80 MHz,
3 Vrms, 80% AM with 1 kHz sine A EN 61000-4-6: 97
Power Frequency H-field immunity 1 A/m, 50Hz/60Hz, 3 axes A EN 61000-4-8: 97
Voltage dips, interrupts
30% Reduction for 25 cycles
>95% Reduction for 250 cycles
>95%, 0.5 cycles
C
C
B
EN 61000-4-11: 94
Table 8: DC Magnetic Field Immunity
Test Product Spec (Standalone)
DC Magnetic Field Immunity 1, 2, 3 400 Gauss, RMS
1Field in Gauss at the drive envelope. Testing per procedures 20800109-349 and 20800109-350.
2Passing Field in Gauss at the drive envelope. In practice, testing is conducted using a fixed distance from the bottom of the
magnet to the top of the drive. Calibration of the field vs. distance is done with a Hall probe with no magnetic materials present.
3Testing to be done with magnet .375” dia. x 0.100” Ni-plated NdFeB; B,~11.5 kG, magnetized along its length; the magnet is
oriented with the length perpendicular to the drive cover/PCBA. Drive to be properly secured during test.
Nonrecoverable read errors 1 per 1015 bits read, max
Annualized Failure Rate (AFR) 1%
Load/Unload (U/UL)
25°C, 50% relative humidity 600,000 software-controlled power on/off cycles
20,000 hard power on/off cycles
Rated workload
Average annualized workload rating: <55 TB/year.
The AFR specification for the product assumes the I/O workload does not exceed the average
annualized workload rate limit of 55 TB/year. Workloads exceeding the annualized rate may
degrade the product AFR and impact reliability as experienced by the particular application. The
average annualized workload rate limit is in units of TB per calendar year.
Warranty
To determine the warranty for a specific drive, use a web browser to access the following web
page: http://www.seagate.com/support/warranty-and-replacements/
From this page, click on the “Is my Drive under Warranty” link. Users will be asked to provide the
drive serial number, model number (or part number) and country of purchase. The system will
display the warranty information for the drive.

Seagate Laptop SSHD SATA Product Manual, Rev. M 17
Drive Specifications
2.12 Agency Certification
2.12.1 Safety certification
These products are certified to meet the requirements of UL60950-1, CSA60950-1 and EN60950 and so marked as to the certify agency.
2.12.2 Electromagnetic Compatibility (EMC)
Hard drives that display the CE mark comply with the European Union (EU) requirements specified in the Electromagnetic Compatibility Directive
2014/30/EU. Testing is performed to the levels specified by the product standards for Information Technology Equipment (ITE). Emission levels are
defined by EN 55022, Class B and the immunity levels are defined by EN 55024.
Drives are tested in representative end-user systems. Although CE-marked Seagate drives comply with the directives when used in the test systems,
we cannot guarantee that all systems will comply with the directives. The drive is designed for operation inside a properly designed enclosure, with
properly shielded I/O cable (if necessary) and terminators on all unused I/O ports. Computer manufacturers and system integrators should confirm
EMC compliance and provide CE marking for their products.
Korean RRA
If these drives have the Korean Communications Commission (KCC) logo, they comply with paragraph 1 of Article 11 of the Electromagnetic
Compatibility control Regulation and meet the Electromagnetic Compatibility (EMC) Framework requirements of the Radio Research Agency (RRA)
Communications Commission, Republic of Korea.
These drives have been tested and comply with the Electromagnetic Interference/Electromagnetic Susceptibility (EMI/EMS) for Class B products.
Drives are tested in a representative, end-user system by a Korean-recognized lab.
Australian RCM
If these models have the RCM marking, they comply with the Australia/New Zealand Standard AS/NZS CISPR22: 2009, and meet the
Electromagnetic Compatibility (EMC) Framework requirements of the Australian Communication and Media Authority (ACMA).
2.12.3 FCC verification
These drives are intended to be contained solely within a personal computer or similar enclosure (not attached as an external device). As such, each
drive is considered to be a subassembly even when it is individually marketed to the customer. As a subassembly, no Federal Communications
Commission verification or certification of the device is required.
Seagate has tested this device in enclosures as described above to ensure that the total assembly (enclosure, disk drive, motherboard, power
supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules. Operation with noncertified
assemblies is likely to result in interference to radio and television reception.
Radio and television interference. This equipment generates and uses radio frequency energy and if not installed and used in strict accordance
with the manufacturer’s instructions, may cause interference to radio and television reception.
This equipment is designed to provide reasonable protection against such interference in a residential installation. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause interference to radio or television, which can be determined
by turning the equipment on and off, users are encouraged to try one or more of the following corrective measures:
nReorient the receiving antenna.
nMove the device to one side or the other of the radio or TV.
nMove the device farther away from the radio or TV.
nPlug the computer into a different outlet so that the receiver and computer are on different branch outlets.
If necessary, users should consult the dealer or an experienced radio/television technician for additional suggestions. Users may find helpful the
following booklet prepared by the Federal Communications Commission: How to Identify and Resolve Radio-Television Interference Problems. This
booklet is available from the Superintendent of Documents, U.S. Government Printing Office, Washington, DC 20402. Refer to publication number
004-000-00345-4.
ࣗطیࡈ࢕߇ΰח
% 
ɼࢽࡈ؏ܞݦ࢕ࢢ
ࢇЕɼࢽࡈ%  ࢷ࢕ળࢶଢԻ۰࣯Ի
ɼࢽ߾۰یࡈଜЕʨࡶּࢶࡳԻଜֲ ֻҘ
ࠇ߾۰یࡈଟܹ࢑ݡТЬ

Seagate Laptop SSHD SATA Product Manual, Rev. M 18
Drive Specifications
2.13 Environmental Protection
Seagate designs its products to meet environmental protection requirements worldwide, including regulations restricting certain chemical
substances.
2.13.1 European Union Restriction of Hazardous Substances (RoHS) Directive
The European Union Restriction of Hazardous Substances (RoHS) Directive, restricts the presence of chemical substances, including Lead, Cadmium,
Mercury, Hexavalent Chromium, PBB and PBDE, in electronic products, effective July 2006. This drive is manufactured with components and
materials that comply with the RoHS Directive.
2.13.2 China Requirements — China RoHS 2
China RoHS 2 refers to the Ministry of Industry and Information Technology Order No. 32, effective July 1, 2016, titled Management
Methods for the Restriction of the Use of Hazardous Substances in Electrical and Electronic Products. To comply with China RoHS 2,
we determined this product's Environmental Protection Use Period (EPUP) to be 20 years in accordance with the Marking for the
Restricted Use of Hazardous Substances in Electronic and Electrical Products, SJT 11364-2014.
中国电器电子产品有害物质限制使用管理办法
(Management Methods for the Restriction of the Use of Hazardous Substances in Electrical and Electronic
Products _ China RoHS)
产品中有害物质的名称及含量
(Name and Content of the Hazardous Substances in Product)
2.14 Corrosive Environment
Seagate electronic drive components pass accelerated corrosion testing equivalent to 10 years exposure to light industrial environments
containing sulfurous gases, chlorine and nitric oxide, classes G and H per ASTM B845. However, this accelerated testing cannot duplicate every
potential application environment.
Users should use caution exposing any electronic components to uncontrolled chemical pollutants and corrosive chemicals as electronic drive
component reliability can be affected by the installation environment. The silver, copper, nickel and gold films used in Seagate products are
especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. In addition, electronic
components should never be exposed to condensing water on the surface of the printed circuit board assembly (PCBA) or exposed to an ambient
relative humidity greater than 95%. Materials used in cabinet fabrication, such as vulcanized rubber, that can outgas corrosive compounds should
be minimized or eliminated. The useful life of any electronic equipment may be extended by replacing materials near circuitry with sulfide-free
alternatives.
Table 9 Hazardous Substances
部件名称
Part Name
有害物质
Hazardous Substances
铅
Lead
(Pb)
汞
Mercury
(Hg)
镉
Cadmium
(Cd)
六价铬
Hexavalent
Chromium
(CF (VI))
多溴联苯
Polybrominated
biphenyls (PBB)
多溴二苯醚
Polybrominated
diphenyl ethers
(PBDE)
印刷电路板组装
PCBA XOOOOO
机壳
Chassis XOOOOO
本表格依据 SJ/T 11364 的规定编制。
This table is prepared in accordance with the provisions of SJ/T 11364-2014
O：表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572 规定的限量要求以下。
O: Indicates that the hazardous substance contained in all of the homogeneous materials for this part is below the limit requirement of
GB/T26572.
X：表示该有害物质至少在该部件的某一均质材料中的含量超出 GB/T 26572 规定的限量要求。
X: Indicates that the hazardous substance contained in at least one of the homogeneous materials used for this part is above the limit
requirement of GB/T26572.
20

Seagate Laptop SSHD SATA Product Manual, Rev. M 19
Configuring and Mounting
3.0 Configuring and Mounting the Drive
This section contains the specifications and instructions for configuring and mounting the drive.
3.1 Handling and Static-Discharge Precautions
After unpacking, and before installation, the drive may be exposed to potential handling and electrostatic discharge (ESD) hazards. Observe the
following standard handling and static-discharge precautions.
3.2 Configuring the Drive
Each drive on the Serial ATA interface connects in a point-to-point configuration with the Serial ATA host adapter. There is no master/slave
relationship because each drive is considered a master in a point-to-point relationships. If two drives are attached on one Serial ATA host adapter,
the host operating system views the two devices as if they were both “masters” on two separate ports. Both drives behave as if they are Device 0
(master) devices.
3.2.1 Serial ATA Cables and Connectors
The Serial ATA interface cable consists of four conductors in two differential pairs, plus three ground connections. The cable size may be 30 to 26
AWG with a maximum length of one meter (39.37 in). Refer to Table 10 for connector pin definitions. Either end of the SATA signal cable can be
attached to the drive or host.
For direct backplane connection, the drive connectors are inserted directly into the host receptacle. The drive and the host receptacle incorporate
features that enable the direct connection to be hot pluggable and blind mateable. For installations which require cables, users can connect the
drive as shown in Figure 2.
Figure 2 Attaching SATA Cabling
Each cable is keyed to ensure correct orientation. Seagate Laptop SSHD SATA drives support latching SATA connectors.
3.3 Drive Mounting
Users can mount the drive in any orientation using four screws in the side-mounting holes or four screws in the bottom-mounting holes. Refer to
Figure 3 for drive mounting dimensions. Follow these important mounting precautions when mounting the drive:
nAllow a minimum clearance of 0.030 in (0.76 mm) around the entire perimeter of the drive for cooling.
nUse only M3 x 0.5 mounting screws.
nDo not overtighten the mounting screws. Maximum torque: 4.0 in-lb (0.4519 N-m).
nFour (4) threads (0.080 in, 2.032 mm) minimum screw engagement recommended.
CAUTION
• Keep the drive in the electrostatic discharge (ESD) bag until users are ready for installation to
limit the drive’s exposure to ESD.
• Before handling the drive, put on a grounded wrist strap, or ground oneself frequently by
touching the metal chassis of a computer that is plugged into a grounded outlet. Wear a
grounded wrist strap throughout the entire installation procedure.
• Handle the drive by its edges or frame only.
• The drive is extremely fragile—handle it with care. Do not press down on the drive top cover.
• Always rest the drive on a padded, antistatic surface until users mount it in the computer.
• Do not touch the connector pins or the printed circuit board.
• Do not remove the factory-installed labels from the drive or cover them with additional
labels. Removal voids the warranty. Some factory-installed labels contain information
needed to service the drive. Other labels are used to seal out dirt and contamination.
Power cable
Signal cable
Signal connector
Power connector
