Seagate ST310014ACE - U Series X 10 GB Hard Drive User manual

... ... ... ... .. ... ... ... ... ... .. ... ... ... ... ..
ST310014ACE
... ... ... ... .. ... ... ... ... ... .. ... ... ... ... ..
Ultra ATA Interface Drive
... ... ... ... .. ... ... ... ... ... .. ... ... ... ... ..
Product Manual
... ... ... ... .. ... ... ... ... ... .. ... ... ... ... ..

... .. ... ... ... ... ... .. ... ... ... ... ... .. ... ...
ST310014ACE
... .. ... ... ... ... ... .. ... ... ... ... ... .. ... ...
Ultra ATA Interface Drive
...... ........ ........ ........ ........ .......
Product Manual
...... ........ ........ ........ ........ .......

 2002 Seagate Technology LLC All rights reserved
Publication Number: 100216026, Rev B, July, 2002
Seagate, Seagate Technology and the Seagate logo are registered
trademarks of Seagate Technology LLC. SeaShield, SeaShell and C
Family are either registered trademarks or trademarks of Seagate Tech-
nology LLC. Other product names are registered trademarks or trade-
marks of their owners.
Seagate reserves the right to change, without notice, product offerings
or specifications. No part of this publication may be reproduced in any
form without written permission from Seagate Technology LLC.

ST310014ACE Product Manual, Rev. B v
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Specification summary table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.0 Drive specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1 Formatted capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1.1 Default logical geometry . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Physical organization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.3 Recording and interface technology . . . . . . . . . . . . . . . . . . . . 4
1.4 Physical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.5 Start/stop times . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.6 Seek times . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.7 Power specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.7.1 Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.7.2 Conducted noise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.7.3 Voltage tolerance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.7.4 Power-management modes . . . . . . . . . . . . . . . . . . . . . . 8
1.8 Environmental tolerances . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.8.1 Ambient temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.8.2 Temperature gradient . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.8.3 Humidity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.8.4 Altitude . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.8.5 Shock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.8.6 Vibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.9 Drive acoustics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.10 Electromagnetic immunity . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.11 Reliability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.12 Agency certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.12.1 Safety certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.12.2 Electromagnetic compatibility . . . . . . . . . . . . . . . . . . . 13

vi ST310014ACE Product Manual, Rev. B
1.12.3 FCC verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.0 Configuring and mounting the drive . . . . . . . . . . . . . . . . . . . 15
2.1 Handling and static-discharge precautions . . . . . . . . . . . . . . 15
2.2 Jumper settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.2.1 Master/slave configuration . . . . . . . . . . . . . . . . . . . . . . 16
2.2.2 Cable-select option . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.2.3 Ultra ATA/100 cable . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.1 Drive mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.0 ATA interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.1 ATA interface signals and connector pins . . . . . . . . . . . . . . 19
3.1.1 Supported ATA commands . . . . . . . . . . . . . . . . . . . . . . 21
3.1.2 Identify Drive command . . . . . . . . . . . . . . . . . . . . . . . . 22
3.1.3 Set Features command . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.1.4 S.M.A.R.T. commands . . . . . . . . . . . . . . . . . . . . . . . . . 29

ST310014ACE Product Manual, Rev. B vii
Figures
Figure 1. Typical startup and operation current profile . . . . . . . . . . . . 7
Figure 2. Master/slave jumper settings . . . . . . . . . . . . . . . . . . . . . . . 16
Figure 3. Mounting dimensions—top, side and end view . . . . . . . . . 18
Figure 4. I/O pins and supported ATA signals. . . . . . . . . . . . . . . . . . 20

viii ST310014ACE Product Manual, Rev. B

ST310014ACE Product Manual, Rev. B 1
Introduction
This manual describes the functional, mechanical and interface specifi-
cations for the ST310014ACE. This drive provides the following key
features:
•Low power consumption
•High instantaneous (burst) data-transfer rates (up to 100 Mbytes per
second) using Ultra DMA mode 5
•Giant magnetoresistive (GMR) recording heads and GPRML technol-
ogy, which provide the drives with increased areal density
•State-of-the-art cache and on-the-fly error-correction algorithms
•Full-track multiple-sector transfer capability without local processor
intervention
•Quiet operation
•350 Gs nonoperating shock
•SeaToolsdiagnostic softwareperformsadrive self-test thateliminates
unnecessary drive returns.
•Support for S.M.A.R.T. drive monitoring and reporting
•Support for drive self-test (DST) with S.M.A.R.T. Execute Off-line
Immediate
•Support for Read Multiple and Write Multiple commands
•Support for autodetection of master/slave drives that use cable select
(CSEL)

2 ST310014ACE Product Manual, Rev. B
Specification summary table
The specifications listed in this table are for quick reference. For details
on specification measurement or definition, see the appropriate section
of this manual.
Drive Specification ST310014ACE
Formatted Gbytes (×106bytes) 10.0
Guaranteed sectors 20,005,650
Bytes per sector 512
Default sectors per track 63
Default read/write heads 16
Default cylinders 16,383
Physical read/write heads 1
Discs 1
Recording density BPI (bits/inch max) 376,200
Track density TPI (tracks/inch) 58,000
Areal density (Mbits/inch2 max) 21,800
Spindle speed (RPM) 5,400
Internal data-transfer rate (Mbits/sec
max) 366
I/O data-transfer rate
(Mbytes/sec max) 100
ATA data-transfer modes supported PIO modes 0–4
Multiword DMA modes 0–2
Ultra DMA modes 0–5
Cache buffer (Mbytes) 2
Height (mm max) 19.99
Width (mm max) 101.9
Length (mm max) 147.0
Weight (typical) 455 grams (1.0 lb)
Average seek time (msec typical) 12.7
Track-to-track seek time (msec typical) 1.2 (read) 2.0 (write)
Read/write seek time (msec typical) 18.0 (read) 24.9 (write)
Full-stroke seek time (msec typical) 36.8 (read); 42.0(write)
Power-on to ready (sec max) 7 sec

ST310014ACE Product Manual, Rev. B 3
Standby to ready (sec typical) 6.5 sec
Spindown (sec typical) 10 sec
Startup current (typical) 0.9 amps (5V), 1.9 amps (12V)
Seek power (typical) 6.0 watts
Read/Write power (typical) 5.5 watts
Idle mode power (typical) 4.5 watts
Standby mode power (typical) 1.2 watts
Sleep mode (typical) 1.0 watts
Voltage tolerance (including noise) 5V ±5%, 12V ±10%
Ambient temperature 0° to 60°C (op.), –40° to 70°C (nonop.)
Temperature gradient
(°C per hour max) 20°C
Relative humidity (op. and nonop.) 5% to 90% (op.)
5% to 95% (nonop.)
Relative humidity gradient 30% per hour max
Wet bulb temperature (°C max) 29.4 (op.), 40.0 (nonop.)
Altitude, operating –60.96 m to 3,048 m (–200 ft to 10,000+ ft)
Altitude, nonoperating
(meters relative to mean sea level) –121.92 m to 12,192 m (–400 ft to 40,000+ ft)
Shock, operating (Gs max at 2 msec) 63 Gs
Shock, nonoperating
(Gs max at 1 and 2 msec) 350 Gs
Vibration, operating 0.5 Gs (0 to peak, 22–350 Hz)
Vibration, nonoperating 5 Gs (0 to peak, 22–350 Hz)
Drive acoustics
Sound power in bels Idle: 2.6 (typical), 2.8 (max) Seek: 2.7 (typical), 2.9 (max)
Nonrecoverable read errors 1 per 1013 bits read
Mean time between failures
(power-on hours) 600,000
Contact start-stop cycles
(25°C, 40% relative humidity) 50,000
SeaShield No
Drive Specification ST310014ACE

4 ST310014ACE Product Manual, Rev. B
1.0 Drive specifications
Unless otherwise noted, all specifications are measured under ambient
conditions, at 25°C, and nominal power. For convenience, the phrases
the drive and this drive are used throughout this manual to indicate the
ST310014ACE.
1.1 Formatted capacity
1.1.1 Default logical geometry
LBA Mode
When addressing drive in LBA mode, all blocks (sectors) are consecu-
tively numbered from 0 to
n–1, where n is the number of guaranteed
sectors as defined above
.
1.2 Physical organization
1.3 Recording and interface technology
Drive Model Formatted Gbytes Guaranteed
sectors Bytes per sector
ST310014ACE 10.0 20,005,650 512
CHS Mode Cylinders Read/Write
heads Sectorsper track
ST310014ACE 16,383 16 63
Drive Model Read/Write heads (GMR) Number of discs
ST310014ACE 1 1
Interface ATA
Recording method 96/102 GPRML
Recording density BPI (bits/inch) 376,200
Track density TPI (tracks/inch) 58,000
Areal density (Mbits/inch2max) 21,800
Spindle speed (RPM) (±0.2%) 5,400
Internal data-transfer rate
(Mbits/sec max) 366

ST310014ACE Product Manual, Rev. B 5
1.4 Physical characteristics
1.5 Start/stop times
1.6 Seek times
Seek measurements are taken with nominal power at 25°C ambient
temperature. All times are measured using drive diagnostics. Seek time
specifications are defined as follows:
•Track-to-track seek time is an average of all possible single-track
seeks in both directions.
•Averageseektimeisatruestatisticalrandomaverageofatleast5,000
measurements of seeks between random tracks, less overhead.
•Full-stroke seek time is one-half the time needed to seek from the first
data cylinder to the maximum data cylinder and back to the first data
cylinder. The full-stroke typical value is determined by averaging 100
full-stroke seeks in both directions.
I/O data-transfer rate
(Mbytes/sec max) 16.6 (PIO mode 4) 100 (Ultra DMA mode 5)
Interleave 1:1
Cache buffer (Mbytes) 2
Drive Specification ST310014ACE
Maximum height mm (inches) 19.99 (0.787)
Maximum width mm (inches) 101.9 (4.01)
Maximum length mm (inches) 147.0 (5.78)
Typical weight grams (pounds) 455 (1.0)
Power-on to Ready (sec) 6.5 (typical)
Standby to Ready (sec) 6.5 (typical)
Ready to spindle stop (sec) 10 (typical)
Average seek time (msec typical) 12.7
Track-to-track seek time (msec typical) 1.2 (read) 2.0 (write)
Read/write seek time (msec typical) 18.0 (read) 24.9 (write)
Full-stroke seek time (msec typical) 36.8 (read); 42.0(write)
Power-on to ready (sec max) 7 sec

6 ST310014ACE Product Manual, Rev. B
Note. These drives are designed to meet the seek times represented
in this manual consistently. Physical seeks, regardless of mode
(such as track-to-track and average), are expected to meet or
exceed the noted values. However, due to the manner in which
these drives are formatted, benchmark tests that include com-
mand overhead or measure logical seeks may produce results
that vary from these specifications.
1.7 Power specifications
The drive receives DC power (+5V or +12V) through a four-pin standard
drive power connector.
1.7.1 Power consumption
Power requirements for the drives are listed in the table on page 9.
Typical power measurements are based on an average of drives tested,
under nominal conditions, using 5.0V input voltage at 25°C ambient
temperature.
•Spinup power
Spinup power is measured from the time of power-on to the time that
the drive spindle reaches operating speed.
•Seek Mode
The read/write actuator arm moves in a random seek mode, with 80%
of the time spent seeking randomly among all the logical blocks, and
20%ofthetimeidle.Thecurrentismeasuredovera10-secondperiod.
No data is read or written during this test.
•Read/Write power and current
Read/write power is measured with the heads on track, based on a
16-sector write followed by a 32-msec delay, then a 16-sector read
followed by a 32-msec delay.
•Operating power and current
The read/write actuator arm moves in a random read/write mode, with
80% of the time spent seeking, reading, and writing randomly among
allthelogicalblocks,and20%ofthetimeidle.The currentismeasured
over a 10-second period.
•Idle mode power
Idle mode power is measured with the drive up to speed, with servo
electronics active and with the heads in a random track location.
•Standby mode
During Standby mode, the drive accepts commands, but the drive is

ST310014ACE Product Manual, Rev. B 7
not spinning, and the servo and read/write electronics are in power-
down mode.
Typical current profile
Figure 1. Typical startup and operation current profile
Power Mode Typical Watts Typical Amps Means
5V 12V
Spinup — 0.90 1.90
Seek (Random,
no read/write) 6.0 0.672 0.220
Operating (read/write) 5.5 0.572 0.220
Idle 4.5 0.468 0.180
Standby 1.2 0.192 0.020
Sleep 1.0 0.157 0.018
2.0
1.0
123456
-1.0
0.0
Current (amps)
Time (seconds)

8 ST310014ACE Product Manual, Rev. B
1.7.2 Conducted noise
Input noise ripple is measured at the host system power supply across
an equivalent 80-ohm resistive load on the +12 volt line or an equivalent
15-ohm resistive load on the +5 volt line.
•Using 12-volt power, the drive is expected to operate with a maximum
of 120 mV peak-to-peak square-wave injected noise at up to 10 MHz.
•Using 5-volt power, the drive is expected to operate with a maximum
of 100 mV peak-to-peak square-wave injected noise at up to 10 MHz.
Note. Equivalent resistance is calculated by dividing the nominal volt-
age by the typical RMS read/write current.
1.7.3 Voltage tolerance
Voltage tolerance (including noise): 5V ± 5% and 12V ± 10%
1.7.4 Power-management modes
The drive provides programmable power management to provide great-
er energy efficiency. In most systems, you can control power manage-
mentthroughthesystemsetupprogram.Thedrivefeaturesthefollowing
power-management modes:
•Active mode
The drive is in Active mode during the read/write and seek operations.
•Idle mode
The buffer remains enabled, and the drive accepts all commands and
returns to Active mode any time disc access is necessary.
•Standby mode
The drive enters Standby mode when the host sends a Standby
Immediate command. If the host has set the standby timer, the drive
can also enter Standby mode automatically after the drive has been
inactive for a specifiable length of time. The standby timer delay is
Power Modes Heads Spindle Buffer
Active Tracking Rotating Enabled
Idle Tracking Rotating Enabled
Standby Parked Stopped Enabled
Sleep Parked Stopped Disabled

ST310014ACE Product Manual, Rev. B 9
established using a Standby or Idle command. In Standby mode, the
drive buffer is enabled, the heads are parked and the spindle is at rest.
The drive accepts all commands and returns to Active mode any time
disc access is necessary.
•Sleep mode
The drive enters Sleep mode after receiving a Sleep command from
the host. In Sleep mode, the drive buffer is disabled, the heads are
parked and the spindle is at rest. The drive leaves Sleep mode after
it receives a Hard Reset or Soft Reset from the host. After receiving a
reset, the drive exits Sleep mode and enters Standby mode with all
current translation parameters intact.
•Idle and Standby timers
Each time the drive performs an Active function (read, write or seek),
the standby timer is reinitialized and begins counting down from its
specified delay times to zero. If the standby timer reaches zero before
any drive activity is required, the drive makes a transition to Standby
mode. In both Idle and Standby mode, the drive accepts all commands
and returns to Active mode when disc access is necessary.
1.8 Environmental tolerances
1.8.1 Ambient temperature
Ambient temperature is defined as the temperature of the environment
immediatelysurroundingthedrive.Actualdrivecasetemperatureshould
not exceed 65°C (149°F) within the operating ambient conditions. Rec-
ommended measurement locations are shown in Figure 3 on page 18.
Above 1,000 feet (305 meters), the maximum temperature is derated
linearly to 112°F (44°C) at 10,000 feet (3,048 meters).
1.8.2 Temperature gradient
Operating 0° to 60°C (32° to 131°F)
Nonoperating –40° to 70°C (–40° to 158°F)
Operating/Nonoperating 20°C per hour (36°F per hour) max,
without condensation

10 ST310014ACE Product Manual, Rev. B
1.8.3 Humidity
1.8.3.1 Relative Humidity
1.8.3.2 Wet bulb temperature
1.8.4 Altitude
1.8.5 Shock
All shock specifications assume that the drive is mounted securely with
the input shock applied at the drive mounting screws. Shock may be
applied in the X, Y or Z axis.
1.8.5.1 Operating shock
These drives comply with the performance levels specified in this docu-
ment when subjected to a maximum operating shock of 63 Gs (based
on half-sine shock pulses of 2 msec). Shocks should not be repeated
more than two times per second.
1.8.5.2 Nonoperating shock
The nonoperating shock level that the drive can experience without
incurring physical damage or degradation in performance when subse-
quently put into operation is 350 Gs (based on nonrepetitive half-sine
shock pulses of 1 and 2 msec duration).
1.8.6 Vibration
All vibration specifications assume that the drive is mounted securely
with the input vibration applied at the drive mounting screws. Vibration
may be applied in the X, Y or Z axis.
Operating 5% to 90% noncondensing (30% per hour max)
Nonoperating 5% to 95% noncondensing (30% per hour max)
Operating 29.4°C (84°F) max
Nonoperating 40.0°C (104°F) max
Operating –60.96 m to 3,048 m (–200 ft to 10,000+ ft)
Nonoperating –121.92 m to 12,192 m (–400 ft to 40,000+ ft)

ST310014ACE Product Manual, Rev. B 11
1.8.6.1 Operating vibration
The following table lists the maximum vibration levels that the drive may expe-
rience whilemeeting the performance standards specified in this document.
1.8.6.2 Nonoperating vibration
The following table lists the maximum nonoperating vibration that the
drive may experience without incurring physical damage or degradation
in performance when subsequently put into operation.
1.9 Drive acoustics
Drive acoustics are measured as overall A-weighted acoustic sound
power levels(nopuretones).Allmeasurementsaregenerallyconsistent
with ISO document 7779. Sound power measurements were taken
under essentially free-field conditions over a reflecting plane. For all
tests, the drive was oriented with the cover facing upward.
Note. For seek mode tests, the drive was placed in seek mode only.
The number of seeks per second is defined by the following
equation:
(Number of seeks per second = 0.4 / (average latency + average access time)
5–21 Hz 0.02-inch displacement (peak to peak)
22–350 Hz 0.5 Gs acceleration (zero to peak)
351–500 Hz 0.25 Gs acceleration (zero to peak)
5–21 Hz 0.2-inch displacement (peak to peak)
22–350 Hz 5.0 Gs acceleration (zero to peak)
351–500 Hz 1.0 Gs acceleration (zero to peak)
ST310014ACE
Acoustic mode Idle Seek
Sound power (bels) 2.6 (typ)
2.8 (max) 2.7 (typ) 2.9 (max)

12 ST310014ACE Product Manual, Rev. B
1.10 Electromagnetic immunity
When properly installed in a representative host system, the drive
operates without errors or degradation in performance when subjected
to the radio frequency (RF) environments defined in the following table:
1.11 Reliability
1.12 Agency certification
1.12.1 Safety certification
The drives are recognized in accordance with UL 1950 and CSA C22.2
(950)andmeetallapplicablesectionsofIEC950andEN60950astested
by TUV North America.
Test Description Performance
Level Reference Standard
Electrostatic
discharge Contact,HCP,VCP:±4kV;Air:
± 8 kV B EN 61000-4-2: 95
Radiated RF
immunity 80 to 1,000 MHz, 3 V/m, 80% AM with 1 kHz sine
900 MHz, 3 V/m, 50% pulse
modulation @ 200 Hz
A EN 61000-4-3: 96
ENV 50204: 95
Electricalfast
transient ± 1 kV on AC mains, ± 0.5 kV
on external I/O B EN 61000-4-4: 95
Surge
immunity ± 1 kV differential, ± 2 kV com-
mon, AC mains B EN 61000-4-5: 95
Conducted
RF
immunity
150 kHz to 80 MHz, 3 Vrms,
80% AM with 1 kHz sine A EN 61000-4-6: 97
Voltage dips,
interrupts 0% open, 5 seconds 0% short, 5 seconds
40%, 0.10 seconds
70%, 0.01 seconds
C
C
C
B
EN 61000-4-11: 94
Nonrecoverable read errors 1 per 1013 bits read, max
Mean time between failures 600,000power-onhours(nominalpower,
25°C ambient temperature)
Contact start-stop cycles 50,000 cycles
(atnominalvoltageandtemperature,with
60 cycles per hour and a 50% duty cycle)
Preventive maintenance None required
