INSTRUCTIONS FOR
TORQUE ADAPTOR DIGITAL 1/2”SQ. DRIVE
40-200NM (29.5-147.5LB.FT)
MODEL NO: STW290.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! DO NOT use the digital torque adaptor if damaged or thought to be faulty.
9Ensure all workshop safety rules, regulations and conditions are complied with when using this digital torque adaptor.
9 Maintaincorrectbalanceandfooting.Ensuretheoorisnotslipperyandwearnon-slipshoes.
9Keep children and unauthorised persons away from the working area.
9After use clean with a soft dry cloth and store in a safe, dry, childproof location.
9Keep the digital torque adaptor away from magnets.
8DO NOT subject the digital torque adaptor to excessive force or shocks.
8DO NOT drop or throw the digital torque adaptor.
8DO NOTusedigitaltorqueadaptorunlessyouhavebeeninstructedinitsusebyaqualiedperson.
8DO NOT leave the digital torque adaptor in any place exposed to excessive heat, humidity or direct sunlight.
8DO NOT use organic solvents such as alcohol or thinners to clean the digital torque adaptor.
8DO NOT submerge the digital torque adapter in water or any other liquid.
8DO NOT disassemble the digital torque adaptor.
8DO NOT exceed the permitted torque value for the digital torque adaptor.
9 Toensureaccuratemeasurementperiodicre-calibrationisnecessary.
2. INTRODUCTION
Designedforusewitharatchetorbreakerbar.Idealforworkaroundtheenginebayandthetighteningofwheelnutstofactoryspecications.
LargeLCDdisplaywithselectablereadingsinNm,lb.ft,lb.in,kg-cmorkg-mandaccurateto±2%ofstatedcapacity.Memorystoresupto 
50readingsandfeaturesautoshuto󰀨after70seconds.Suppliedwithcerticateandstoragecase.
3. SPECIFICATION
Model no: ................................................................. STW290
Drive type:.................................................................. 1/2”Sq.
Length:......................................................................... 75mm
Range: ........................................ 40-200Nm(29.5-147.5lb.ft)
Battery: ....................................................... 2xAAAsupplied
4. OPERATION
WARNING! DO NOTpressMemandOn/o󰀨button
together as this will enter the unit into Calibration Mode.
4.1. POWER ON (g.1).
4.1.1. Attach the adaptor to a ratchet or breaker bar.
4.1.2. After2secondstheLCDpanelwillshow0.0.
4.1.3. Tighten the nut or bolt.
4.1.4. The LCD displays the torque value measured.
 Note:Ifnotusedfor70secondstheDigitalTorqueAdaptorwill
 automaticallyshuto󰀨.
4.2. HOW TO SELECT UNIT(g.1).
Press Mem and Peak / Trace button together and release to
 selectdi󰀨erenttorqueunits.
Note: When you change units the target setting will also be
changed to the new units value.
This Digital Torque Adaptor contains 5 unit selections.
 (kg-cm,kg-m,in-lb,ft-lb,N-m).
4.3. HOW TO SELECT TARGET TORQUE VALUE (g.1).
4.3.1. Increase(+):Pressandholdthe(+)buttontoincreasethe
current target value.
STW290.V2|Issue:131/01/18
Original Language Version
© Jack Sealey Limited
Refer to
instruction
manual
Wear eye
protection
Fig.1

4.3.2. Decrease(-):Pressandholdthe(-)buttontolowerthecurrenttargetvalue.
4.3.3. The target will show for 10 seconds.
4.3.4. After 10 seconds the LCD will display 0.0.
 Note:Whenthedigitaltorqueadaptorgetto20unitsbeforethetarget,theredLEDwillashandanintermittentbuzzerwillsound,
warning that the target value is close.
 WhenthetargetvalueisattainedtheredLEDwillbeilluminatedandthebuzzerwillsoundcontinuously. 
4.4. HOW TO SET PEAK OR TRACE (g.1).
4.4.1. Peak:PressandreleasePeak/Trace-buttonwhenthedigitaltorqueadaptorison.TheLCDpanelshowsPtoP.
4.4.1.1. TheLCDpanelshows0.0after2seconds.
4.4.2. Trace:PressandreleasePeak/Trace-buttonwhenthedigitaltorqueadaptorison.
4.4.3. The LCD panel shows trACE.
4.4.4. TheLCDpanelshows0.0after2seconds.
4.5. TURN OFF (g.1).
4.5.1. Iftheadaptorisnotusedfor70seconds,itwillautomaticallyshutdown.
4.5.2. Tomanuallyturno󰀨thedigitaltorqueadaptorpressandreleasetheOn/O󰀨button.
4.6. MEMORY(g.1).
4.6.1. To display the stored readings. Turn on the digital torque adaptor.
4.6.2. Press and release the Mem button.
4.6.3. ThedisplayshowsthememorynumberisP01andthentheTorqueValue.
4.6.4. Pressandreleasethe“M”button,again.
4.6.5. ThedisplayshowsthememorynumberisP02andthentheTorqueValue.
Note: This Digital Torque Adaptor stores the last 50 torque value readings, P01 is the latest reading, P50 is the oldest.
5. MAINTENANCE
5.1. BATTERY REPLACEMENT(g.2)
5.1.1. Remove the two screws from the battery cover.
5.1.2. Lifto󰀨thebatterycover.
5.1.3. Remove the battery from the holder.
5.1.4. Install new batteries observing correct polarity.
5.1.5. Retthebatterycoverandthescrews.
Note: When the battery is low the will light.
Remove the battery if the torque adaptor is to be stored for a long time.
Battery life is dependant on battery quality and the amount of torque adaptor is used
 (typicallifeisupto55hours).
5.2. CALIBRATION
5.2.1. Periodic calibration is required for this product contact your Sealey stockist for details.
© Jack Sealey Limited
Fig.2
Original Language Version
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersanddisposeoftheproductandfluids
according to local regulations.
BATTERY REMOVAL SEE SECTION 5.1
UndertheWasteBatteriesandAccumulatorsRegulations2009,JackSealeyLtdarerequiredtoinformpotentialpurchasersofproducts
containingbatteries(asdefinedwithintheseregulations),thattheyareregisteredwithValpak’sregisteredcompliancescheme.Jack
SealeyLtd’sBatteriesProducerRegistrationNumber(BPRN)isBPRN00705.
STW290.V2|Issue:131/01/18
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE).Whentheproductisnolongerrequired,itmustbedisposedofinanenvironmentallyprotectiveway.Contactyourlocalsolid
waste authority for recycling information.
