Sealey CP20VDDX User manual

BRUSHLESS HAMMER DRILL/DRIVER
20V 13MM - BODY ONLY
MODEL NO: CP20VDDX
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL SAFETY
9Disconnect the drill from the battery unit before changing accessories, servicing or performing any maintenance.
9Maintain the drill and battery in good condition. Check moving parts alignment on a regular basis.
9Replace or repair damaged parts. Use an authorised service agent and recommended parts only. Unauthorised parts may be
dangerous and will invalidate the warranty.
9Ensure the drill is switched off before installing the battery pack.
9Keep the drill and charger clean for best and safest performance.
9 Removeillttingclothing.Removeties,watches,ringsandotherloosejewelleryandcontainlonghair.
9 Evaluateyourworkingareabeforeusingthedrille.g.ceilings,oorsandenclosuresmaycontainelectricalitemsorwaterpiping.
9Ensure battery pack is correctly inserted into the drill handle and latched in place before attempting to switch on drill.
9Secure loose work pieces with a clamp, vice or other adequate holding device.
9Avoid unintentional starting.
9Wear approved safety eye protection (standard spectacles are not adequate).
9 Maintaincorrectbalanceandfooting.Ensuretheoorisnotslipperyandwearnon-skidshoes.
9Keep chuck direction switch in the locked position until the drill is required for use.
9Keep children and unauthorised persons away from the working area.
9Keep drill and charger in the case and store in a safe, dry, childproof area where the temperature will not exceed 104°F (40°C).
8DO NOTusethedrillwherethereareammableliquids,solidsorgases,suchaspaintsolvents,etc.
8DO NOT allow children to operate the drill.
8DO NOToperatethedrillifanypartsaremissingasthismaycausefailureand/orpersonalinjury.
8DO NOT hold unsecured work piece in your hand.
8DO NOT leave the drill operating unattended.
8DO NOTcarrythedrillwithyourngeronthepowerswitch.Keepchuckdirectionswitchinthelockedposition.
8DO NOT use the drill for a task it is not designed to perform.
8DO NOToperatethedrillwhenyouaretiredorundertheinuenceofalcohol,drugsorintoxicatingmedication.
8DO NOT get the drill or battery charger wet or use in damp or wet locations.
2. INTRODUCTION
The20VSerieshasbeendesignedtosuitusersfromtheDIYenthusiasttotheprofessional.Thesebodyonlytoolsofferaonebatterytsall
solution with a choice of 20V lithium batteries ranging from 2Ah to 4Ah, meaning costs can be kept down whilst quality remains high. Quality,
stylish, lightweight tools with durable composite housing and a soft grip making them comfortable and easy to use.
3. SPECIFICATION
Model No......................................................................CP20VDDX
Battery: ....................................(notincluded)20V2Ah-4AhLi-ion
Chuck Size:.........................................................................Ø13mm
Impact rate:................................................................. 0-30000bpm
No load Speed: ................................................................. 2000rpm
Maximum Torque: ..................................................................65Nm
Noise power:...................................................................... 87dB(A)
Noise pressure:.................................................................. 76dB(A)
Vibration:......................................................................... 3.051m/s²
Uncertainty:......................................................................... 1.5m/s²
Battery Model No’s
2Ah ........................................................(not included) CP20VBP2
3Ah .........................................................(not included) CP20VBP3
4Ah .........................................................(not included) CP20VBP4
Mains Charger Model No ..................... (not included) CP20VMC
CP20VDDX | Issue 1 12/06/2019
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Wear eye
protection
Wear protective
gloves
Wear ear
protection
Wear a mask

4. OPERATION
WARNING:Removebatterybeforettingtoolormaintenanceis
carried out.
4.1. To remove the battery from the equipment, depress the spring
loaded button on the battery pack. Remove the battery pack by
sliding out. DO NOT touch the metal battery terminals.
4.2.  USINGTHEDRILL(g.1)
Ensure that you have read, understood and comply with all the
safety instructions in Section 1.
4.2.1. Ensure the direction switch is in the mid (lock) position. Open the
chuck and insert the required drill or screwdriver bit.
4.2.2. Select high or low speed by using the selector on top of the
casing (high speed for drilling, low for hammer or screwdriving).
4.2.3. Select the direction of rotation by means of the forward/reverse
selector.
4.2.4. Select hammer, screw or drill by turning the selector ring.
4.2.5. If driving screws, set the required torque by means of the torque
selector ring. Setting value1 is the lowest torque setting.
4.2.6. The LED worklight is lit whenever the trigger is depressed.
4.2.8. When finished, remove the bit, clean the drill and bit and replace the drill in its case.
4.2.9. Store in a cool, dry place out of the reach of children.
5. MAINTENANCE
WARNING: Always disconnect the battery before carrying out any inspection, maintenance or cleaning.
5.1. GENERAL INSPECTION
5.1.1. Regularlycheckthatallthexingscrewsaretight.Repairsshouldbecarriedoutbyanauthorisedservicecentre. 
5.2. CLEANING
WARNING: Always wear protective equipment including eye protection and gloves when cleaning this tool.
5.2.1. Keep your tool clean at all times. Dirt and dust will cause internal parts to wear quickly, and shorten the device’s service life.
5.2.2. Clean the body of your machine with a soft brush, or dry cloth.
5.2.3. Neverusecausticagentstocleanplasticparts.Ifdrycleaningisnotsufcient,amilddetergentonadampclothisrecommended.
5.2.4. Water must never come into contact with the tool. Ensure the tool is thoroughly dry before using it.
5.2.5. If available, use clean, dry, compressed air to blow through the ventilation holes (where applicable).
5.3. LUBRICATION
5.3.1. Slightly lubricate all moving parts at regular intervals with a suitable spray lubricant.
5.4. STORAGE
5.4.1. Store this tool carefully in a secure, dry place out of the reach of children.
CP20VDDX | Issue 1 12/06/2019
Original Language Version
© Jack Sealey Limited
g.1

CP20VDDX | Issue 1 12/06/2019
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 36 months labour and two years parts warranty from purchase date, proof of which is required for any claim.
WARNING! – Risk of Hand Arm Vibration Injury.
This tool may cause Hand Arm Vibration Syndrome if its use is not managed adequately.
ThistoolissubjecttothevibrationtestingsectionoftheMachineryDirective2006/42/EC.
This tool is to be operated in accordance with these instructions.
Measured vibration emission value (a): .........3.051 m/s²
Uncertainty value (k):...........................1.5 m/s²
Please note that the application of the tool to a sole specialist task may produce a different average vibration emission. We recommend that
a specific evaluation of the vibration emission is conducted prior to commencing with a specialist task.
A health and safety assessment by the user (or employer) will need to be carried out to determine the suitable duration of use for each tool.
NB: StatedVibrationEmissionvaluesaretype-testvaluesandareintendedtobetypical.
Whilst in use, the actual value will vary considerably from and depend on many factors.
Such factors include; the operator, the task and the inserted tool or consumable.
NB: ensure that the length of leader hoses is sufficient to allow unrestricted use, as this also helps to reduce vibration.
The state of maintenance of the tool itself is also an important factor, a poorly maintained tool will also increase the risk of Hand Arm Vibration
Syndrome.
Health surveillance.
Werecommendaprogrammeofhealthsurveillancetodetectearlysymptomsofvibrationinjurysothatmanagementprocedures
can be modified accordingly.
Personal protective equipment.
Wearenotawareofanypersonalprotectiveequipment(PPE)thatprovidesprotectionagainstvibrationinjurythatmayresultfromthe
uncontrolled use of this tool. We recommend a sufficient supply of clothing (including gloves) to enable the operator to remain warm and dry
and maintain good blood circulation in fingers etc. Please note that the most effective protection is prevention, please refer to the Correct Use
and Maintenance section in these instructions. Guidance relating to the management of hand arm vibration can be found on the HSE website
www.hse.gov.uk-Hand-ArmVibrationatWork.
