PDM170F, 210F, 240F, 260F Issue: 4 - 03/10/17

Original Language Version

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE THE PRODUCT

CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL

INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions

and maintained properly, give you years of trouble free performance.

Refer to instruction

manual

Wear eye

protection

Wear ear

protection

Wear a maskWear protective

gloves

1. SAFETY

INSTRUCTIONS FOR:

FLOOR MOUNTED PILLAR DRILLS

MODEL NO’S: PDM170F, PDM210F, PDM240F,

PDM260F

1.2. GENERAL SAFETY

pWARNING! Disconnect drill from mains power before changing accessories, servicing or performing any maintenance.

pWARNING! Keep all guards and holding screws in place, tight and in good working order. Check regularly for damaged parts.

A guard or any other part that is damaged should be replaced, before the tool is used, to ensure that it will operate properly and

perform its intended function. The safety guard is a mandatory fitting where drill is used in premises covered by the Health &

Safety at Work Act.

3Check alignment of moving parts and check for possible broken parts.

3Replace or repair damaged parts. Use recommended parts only. Unauthorised parts may be dangerous and will invalidate the warranty.

3Ensure the set screws of the head frame are screwed tight before using the drill.

3Secure the drill to the floor.

3Drill is designed for use with drill bits only.

3Ensure the chuck is securely fastened to the spindle.

3Remove adjusting keys, chuck key and wrenches from the machine and working area before switching on.

3Use clamps or a vice (not included; available from your Sealey stockist) to secure the workpiece. DO NOT attempt to hold the

workpiece by hand.

3Refer to speed chart for recommended drilling speeds.

pWARNING! Always wear approved eye or face protection when operating this drill. Use a face or dust mask if dust is generated.

3Keep drill bits clean and sharp for best and safest performance. Follow the instructions for lubrication and changing accessories.

3Remove ill fitting clothing. Remove ties, watches, rings and other loose jewellery and contain long hair.

3Locate the drill in a suitable work area, keep area clean and tidy and free from unrelated materials. Ensure there is adequate lighting.

3Exclude children and non-essential persons from the work area.

3Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip shoes.

3Secure unstable work with a clamp, vice or other adequate holding device.

3 Avoid unintentional starting.

7DO NOT use the drill for a task it is not designed to perform.

7DO NOT allow untrained persons to operate the drill.

7DO NOT get the drill wet or use in damp or wet locations or areas where there is condensation.

7DO NOT operate the drill if damaged or parts are missing.

1.1. Electrical Safety

 WARNING! It is the user’s responsibility to check the following:

Check all electrical equipment and appliances to ensure that they are safe before using. Inspect power supply leads, plugs and all

electrical connections for wear and damage. Sealey recommend that an RCD (Residual Current Device) is used with all electrical

products. You may obtain an RCD by contacting your local Sealey dealer.

if the product is used in the course of business duties, it must be maintained in a safe condition and routinely PAT (Portable Appliance

Test) tested.

Electrical safety information: it is important that the following information is read and understood.

1.2. Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.

1.3. Regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure that they are secure.

1.4. Important: Ensure that the voltage rating on the appliance suits the power supply to be used and that the plug is fitted with the correct

fuse - see fuse rating in these instructions.

7DO NOT pull or carry the appliance by the power cable.

7DO NOT pull the plug from the socket by the cable.

7DO NOT use worn or damaged cables, plugs or connectors. Ensure that any faulty item is repaired or

replaced immediately by a qualified electrician.

1.5. This product is fitted with a BS1363/A 13 Amp 3 pin plug.

If the cable or plug is damaged during use, switch the electricity supply and remove from use.

Ensure that repairs are carried out by a qualified electrician.

Replace a damaged plug with a BS1363/A 13 Amp 3 pin plug. If in doubt contact a qualified electrician.

A) Connect the GREEN/YELLOW earth wire to the earth terminal ‘E’.

B) Connect the BROWN live wire to the live terminal ‘L’.

C) Connect the BLUE neutral wire to the neutral terminal ‘N’.

Ensure that the cable outer sheath extends inside the cable restraint and that the restraint is tight.

Sealey recommend that repairs are carried out by a qualified electrician. Recommended fuse

rating: 13A

.7DO NOT use drill in an area where paint fumes, solvents or flammable liquids pose a potential hazard. Keep flammable material away

from the drill when operating. Flammable waste, such as wiping or cleaning rags, must be placed in a closed metal container and

disposed of correctly.

7DO NOT exceed the rated capacity of the drill.

7DO NOT leave the drill operating unattended.

7DO NOT operate the drill when you are tired, under the influence of alcohol, drugs or intoxicating medication.

3When not in use switch off the drill, remove plug from the power supply and do not leave until the drill has come to a complete stop.

2. INTRODUCTION

A comprehensive range of floor pillar drills for the professional workshop. Models feature heavy-duty aluminium-bodied motors for long and reliable

performance. No-volt release switch to prevent inadvertent start up and pulley cover protected by microswitch to prevent drill operating when cover

is open. Selected models are fitted with an integral work light which illuminates the drilling table giving operator a clear view of the drilling process.

All models supplied with flip-up chuck guard. Large sized square tables fitted with precision rack and pinion height adjustment.

3. SPECIFICATION

Model No: ........................PDM170F ............PDM210F .............. PDM240F ...............PDM260F

Drilling Capacity (Chuck Size):.........16mm................16mm ................. 20mm .....................20mm

Spindle Nose Taper: .................MT2 .................MT2 .................. MT3 .......................MT4

Swing: ...........................413mm...............460mm ................ 512mm ...................612mm

Spindle Centre to Column: ............170mm...............190mm ................ 216mm ...................260mm

Spindle Travel: .....................80mm................80mm ................. 80mm ....................120mm

Number of Speeds: .................16...................16 .................... 16 ...........................12

Speed Range: .....................190-3000rpm ..........190-3000rpm ........... 160-3000rpm .........120-3480mm

Maximum Distance Spindle to Table: ....770mm...............725mm ................ 720mm ...................680mm

Maximum Distance Spindle to Base: ....1255mm..............1225mm ............... 1230mm .................1160mm

Working Table Surface Size: ..........254 x 254mm..........290 x 290mm ........... 356 x 356mm .........425 x 475mm

Working Base Surface Size: ..........205 x 200mm..........205 x 200mm ........... 205 x 200mm .........410 x 330mm

Overall Base Size: ..................450 x 270mm..........495 x 290mm ........... 495 x 290mm .........575 x 455mm

Column Diameter: ..................73mm................80mm ................. 80mm .....................92mm

Collar Diameter: ....................55mm................60mm ................. 75mm .....................85mm

Overall Height: .....................1610mm..............1610mm ............... 1635mm .................1710mm

Motor Power (Start):.................370W (550W) .........370W (550W)........... 750W (925W) .........750W (925W)

Supply: ...........................230V ................230V.................. 230V .......................230V

Weight: ...........................52kg.................63kg .................. 73kg ......................131kg

Noise Pressure: ....................76.9dB ...............76.9dB ................ 76.9dB ...................76.9dB

Noise Power: ......................89.1dB ...............89.1dB ................ 89.1dB ...................89.1dB

Duty Cycle: ........................S2 ..................S2.................... S2 ...........................S2

Optional Keyless Chuck 16mm: ........PDM/KC..............PDM/KC ............... PDM/KC .................PDM/KC

Integral Work Light (Bulb not included):..No ..................Ye s ................... Yes .........................Yes

4. CONTENTS

4.1. Package contents Unpack the parts listed below and check to ensure they are in good condition. Any queries must be reported to

your stockist immediately.

3Head Assembly 3Base 3Chuck and Key

3Column with Flange 3Feed Handle 3Table Arm, Bracket & Worm (PDM260F - no arm)

3Adjusting Handle with Set Screw (table) 3Table 3Rack and Rack Ring

3Pivoted Clamp Bolts (2, except PDM260F-1) 3Bolts and Washers (4) 3Screw (upper pulley cover)

3Safety Guard 3Arbor 3Set Screws (2)

3Wedge 3Hex. Keys (2)

5. ASSEMBLY

Note: Figures are illustrative and may differ in detail from your drill.

5.1. Assembly

5.1.1. Place the column assembly on the base, align holes and secure with the bolts and washers provided.

5.1.2. Install table bracket onto column together with rack (fig.1), engaging gear in bracket with rack.

5.1.3. Install the rack collar and tighten firmly (fig.2).

5.1.4. Install the table adjusting handle (fig.2.A) and pivoted clamp bolt (the longer of the two - fig.2.B).

5.1.5. Tighten the handle set screw (with the hex. key provided) and the bracket clamp bolt.

5.1.6. Install the table and table clamp bolt (fig.3).

5.1.7. Carefully place the head assembly over the column and slide it into position. Align head with base.

5.1.8. Fit the two set screws in the side of the head and tighten with hex. key (fig.4) to lock head in position.

5.1.9. Fit the feed handle to the hub of the pinion shaft (align pin with slot) and retain with central screw.

5.1.10. To install chuck: open the chuck jaws completely by turning the chuck key anticlockwise. Place a piece of wood on the drill table

(to prevent the chuck from getting damaged).

5.1.11. Insert arbor (fig.5.B) into drill spindle (reduced diameter end first), fit chuck to protruding end of arbor and hold in place.

5.1.12. Turn feed handle to bring nose of chuck down onto wood (fig.5). Firmly pull on feed handle to seat arbor tapers in spindle and chuck.

fig. 1

PDM170F, 210F, 240F, 260F Issue: 4 - 03/10/17

Original Language Version

5.1.13. Loosen clamp screw on safety guard mounting collar, pass guard up over chuck and fit collar round flange of quill shaft. Ensure guard

pivot is central and tighten clamp screw.

5.2. Drill mounting

5.2.1. For stability and safety it is important that the drill base is securely bolted to the floor.

5.2.2. Ensure that the floor is capable of supporting the drill together with the weight of the heaviest likely workpiece.

fig. 4

6. OPERATION

pWARNING! Ensure the drill is unplugged from the mains power supply before commencing.

6.1. Install drill bit

6.1.1. Insert drill bit into chuck jaws to 1" (25mm) deep (avoid inserting small bits too far) and centre bit in chuck before tightening.

6.2. Adjusting the table

6.2.1. To adjust table up or down, loosen the clamp bolt (fig.2.B) then turn the bracket handle (fig.2.A).

6.2.2. To adjust table tilt, loosen the work table bolt (fig.2.C), remove locking pin (below bolt) and adjust to the desired angle using the

angle scale, then retighten. When returning table to horizontal replace locking pin.

6.2.3. To turn the table around the column, loosen the rack collar slightly, then loosen the clamp bolt (fig.2.B).

Turn the table to the desired position then secure the bolt and the rack collar.

6.3. Adjusting the speed

6.3.1. Open the pulley case and loosen the belt tension lock screws (fig.6.A) - one either side of head.

6.3.2. Choose the speed for drilling operation (see drill speed chart - Section 7) and move the belts to the

correct position for that speed, as shown on the chart inside the pulley cover.

6.4. Belt tension

6.4.1. With the belt tension lock screws (fig.6.A) loose and using hand pressure on the adjusting handle

(fig.5.C), set tension so that belt give is no more than 1/2" (13mm). Tighten lock screws.

6.5. Positioning the workpiece

6.5.1. Use a piece of wood to rest the workpiece on. The drill bit may break through the workpiece and damage the table otherwise.

The wood should rest on the table so that one end of it is against the left side of the column, to prevent it spinning when the drill

bit breaks through the workpiece.

6.5.2. For small workpieces that cannot be clamped to the table, use a drill vice (not included). Vice must be clamped or bolted to table.

6.6. Setting the drill depth

6.6.1. Use the scale on the side of the drill head near the drill handle.

6.6.2. Loosen locking screw (fig.5.D) and set the scale to the depth desired. Tighten locking screw.

6.6.3. When ready to drill, simply pull the feed handle. The drill will stop at the set depth.

6.7. Illumination (not PDM170F)

6.7.1. The workpiece illumination is controlled by the rocker switch located immediately above the main power switch on the front of the

head.

fig. 6

7. DRILL SPEEDS

Drill Speed (rpm)

Drill Dia. (mm) Steel Cast Iron Iron Alum. & Copper

3 1820 2580 2580 2580

4 1350 1820 1820 2580

5 1290 1350 1350 2580

6 970 1290 1290 2580

7 830 970 970 2580

8 830 970 970 2580

9 500 970 830 1820

10 500 830 830 1820

11 500 830 830 1820

12 420 830 500 1820

13 420 500 500 1350

14 420 500 500 1350

16 320 500 500 1290

18 320 420 420 1290

20 280 320 320 970

22 210 320 280 970

25 120 280 210 830

8. MAINTENANCE

pWARNING! Disconnect drill from mains power before changing accessories, servicing or performing any maintenance.

8.1. Clean the tool after each use. A coat of maintenance spray applied to the table and column will help to keep the surfaces clean.

8.2. Blow out any dust that may have accumulated in the motor.

8.3. Periodically lubricate the table elevation rack/gear/worm mechanism and the spindle sleeve exterior.

8.4. Belt changing Please note that an instructional video for this product is available to view on our YouTube channel.

8.4.1. Isolate the drill from the power supply.

8.4.2. Remove the belt tension as in section 6.4.

8.4.3. Remove the belt(s) and replace with another of the same specification.

8.4.4. Re-tension the belts as in section 6.4.

8.4.5. Close and secure the pulley case.

PDM170F, 210F, 240F, 260F Issue: 4 - 03/10/17

Original Language Version

fig. 2 fig. 3

fig. 4

fig. 5

9. TROUBLESHOOTING

PROBLEM POSSIBLE CAUSE SOLUTION

Excessive noise 1. Incorrect belt tension 1. Adjust tension

2. Spindle is dry 2. Disassemble spindle/quill and lubricate

3. Pulley is loose 3. Tighten pulley

4. Bearing damaged 4. Replace the bearing

Excessive drill wobble 1. Chuck is loose 1. Tighten the chuck by pressing it against the table (see 5.1.12.)

2. Bearing or spindle shaft is worn 2. Replace worn part

3. Chuck is worn 3. Replace the chuck

Drill binds in the 1. Feed pressure is wrong 1. Apply less pressure

workpiece 2. Belt is loose 2. Adjust tension

3. Drill bit is loose 3. Tighten the chuck jaws with the key

4. Speed is too fast 4. Change the speed

Drill burns or smokes 1. Speed is too fast 1. Change the speed

2. Chips are not discharging 2. Clean the drill bit

3. Drill bit is dull 3. Use a new bit

4. Lubrication needed 4. Lubricate while drilling

5. Feed pressure is wrong 5. Apply less pressure

Table is difficult to raise 1. Lubrication is needed 1. Lubricate with light oil

2. Rack is bent 2. Straighten the rack

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk

Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior

notice.

Important: No Liability is accepted for incorrect use of this product.
