Sealey DCDST User manual

1. SAFETY
9 Onlyuseonrm,level,unobstructedsurfaceswhicharecapableofsupportingthestandanddrill.
9 Ensurestandisxedtosurfacecapableofsupportingstand,drillandworkpiece.
9 Replaceorrepairdamagedparts.Useonlyrecommendedparts.Unauthorisedpartsmaybedangerousandwillinvalidatethe 
 warranty.
WARNING!Failuretocomplywiththeseinstructionsmayresultindamagetothestandorotherpropertyand/orpersonalinjury.
WARNING!Thewarnings,cautionsandinstructionsdiscussedinthisinstructionmanualcannotcoverallpossibleconditionsand
 situationsthatmayoccur.Itmustbeunderstoodthatcommonsenseandcautionarefactorswhichcannotbebuiltintothisproduct,
 butmustbeappliedbytheoperator
2. INTRODUCTION
Lightweightaluminiumdiamondcoredrillstandfeaturestiltingmechanismandbaseplatewithanchortting.Handleandwheelsforeaseof
transport.IdealforusewithModelNo’sDCD110VandDCD230VDiamondCoreDrills.
3. SPECIFICATION
MaximumDrillBitDiameter:.................................... Ø200mm
TravelLength:............................................................ 600mm
4. OPERATION
4.1. ATTACHING DRILL TO STAND REF. FIG 1
4.1.1. Thedrillisattachedtothestandusingthedrillclamp(g.1)
4.1.2. Removeonehalfofthedrillclampbymeansofthescrews,slotthedrillintoplaceandreplacetheclamp.
4.1.3. Securetheclampbyusingthetwolockinghandles.
4.2. SECURING STAND TO THE GROUND
4.2.1. Toboltthestandtotheground,drillaholeforasecuringboltasuitabledistanceawayfromyourintendeddrillingarea.
Note: Youdohavesomeadjustmentonthedrillbasebutplanbeforeyoudrill.
4.2.2. Thebasecanbelevelledusingthe4levellingbolts.Adjustthesebeforesecuringtheanchorbolt.
4.3. SETTING THE ANGLE
4.3.1. Loosentheangleadjustmentboltandthebracelockinghandle,slideupordownuntilyougetthedesiredangle.
g.1
DIAMOND CORE DRILLS STAND
MODELNO:DCDST
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Original Language Version
©JackSealeyLimited
Referto
instructions
Weareye
protection
Wearprotective
gloves
Wearear
protection
Wearsafety
footwear
Wearprotective
clothing
Wearamask
DCDSTIssue3(2)26/08/2020

5. MAINTENANCE
5.1.  Keepclean,removethespatterfromthecradleguidechannels.
6. TROUBLESHOOTING
Symptoms Problem Solution
Material/DrillVibration,ResultinginUneven
DrillHoles
Checkfordrillrun-out. Makesurethemachineismountedintherig
correctly.
Cleanthemachinethoroughlyand
reassemblethedrillandcheckforrun-out
again.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycleunwantedmaterialsinsteadofdisposingofthemaswaste.Alltools,accessoriesandpackagingshouldbesorted,takento
arecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.Whentheproductbecomescompletely
unserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersanddisposeoftheproductandfluids
accordingtolocalregulations.
Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specificationsandcomponentpartswithoutprior
notice.
Important:NoLiabilityisacceptedforincorrectuseofthisproduct.
Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.
