Sealey HT08R User manual

RECHARGEABLE HEAD TORCH WITH AUTO-
SENSOR, 8W COB LED, 500LM
MODEL NO: HT08R
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGEAND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL
9Ensure the lamp is fully charged before initial use.
8DO NOT turn the lamp on when it is being charged.
8DO NOT shine directly into your, another person’s or an animal’s eyes.
8DO NOT allow children to use the lamp.
8DO NOT handle or move the lamp whilst it is being charged.
8DO NOT use the lamp if you suspect that the battery or the lamp casing is damaged.
8DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery, subsequently
recharge the battery at least once every six months of non-use.
WARNING! To reduce the risk of burns or re:
8DO NOT attempt to open, disassemble, modify or service the battery pack.
8DO NOT crush, puncture, short external contacts or dispose of in re or water.
8DO NOT expose to temperatures above 60°C (140°F).
9Replace only with the battery pack designated for this product.
9Recycle or dispose of used battery as stipulated by local regulation.
9If the electrolyte in the cells gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with cool
water and seek immediate medical attention.
WARNING: The warnings, cautions and instructions discussed in this instruction manual cannot cover all possible conditions and
situations that may occur. It must be understood that common sense and caution are factors which must be applied by the operator.
2. INTRODUCTION
Powered by 3.7V lithium rechargeable battery. Auto-sensor means once active, you can simply move your hand alongside the
head torch to turn it on and off. IP65 Water resistant. The four modes include: full, 30%, red and ashing red. Inclination can be
adjusted to better direct the light. 1200mAh battery with level indicator while charging.
3. SPECIFICATION
Model No:...................................................................HT08R
Battery: ................................3.7V 1200mAh Lithium-Polymer
Charging Time:..................................................................3hr
LED Type: ................................................................8W COB
Lumen Output: .............................................................500lm
Operating Time: ....................................(High/Low): 2.5hr/4hr
Original Language Version
© Jack Sealey Limited
Refer to
Instructions
HT08R Issue 1 03/05/23
g.1

4. OPERATION
4.1. Remove USB cover to reveal USB charging point, where the provided USB charging cable can be inserted g.1.
4.2. Plug in the cable to an appropriate power source. Charging will take approximately 3hr.
4.3. There are four lights which illuminate when charging. These indicate the amount of charge in the battery. 1 = low charge and 4 =
fully charged.
4.4. When charged remove USB cable and replace the USB cover.
4.5. To switch on press on/mode change/off button full power white light, press again to change mode reduced power white light, press
again for a constant red light a forth time for a ashing red light once more to turn off.
4.6. To activate by hand movement, there is a second switch hold down (approx 3 sec.) on/mode change/off button until button turns full
power light on. It can now be operated by passing hand in front of sensor. Press button again to switch off.
4.7. The head torch can be tilted forward up to 53° from vertical in four stages. This is achieved by a cog system moulded to the rear of
the unit.
5. MAINTENANCE
5.1. Keep the torch clean by wiping with a damp cloth.
5.2. Store torch in a dry childproof area.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 [e-mail] www.sealey.co.uk
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste.All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
HT08R Issue 1 03/05/23
Original Language Version
© Jack Sealey Limited
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
