Sealey LED112.V2 User manual

SMD LED EXTRA SLIM FLOODLIGHT WITH
WALL BRACKET
MODEL NO’S: LED112.V2, LED113.V2, LED115.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
I
MP
PO
R
RTA
TA
NT
:
PLEA
S
E READ THE
S
E IN
S
TRU
C
TI
O
N
S
C
AREFULLY. N
O
TE THE
S
AFE
O
PERATI
O
NAL RE
Q
UIREMENT
S
, WARNIN
GS
&
C
AUTI
O
N
S
. U
S
E
TH
HE
P
PR
O
ODU
C
T
CO
RRE
C
TLY AND WITH
C
ARE F
O
R THE P
U
RP
OS
E F
O
R WHI
C
H IT I
S
INTENDED. FAIL
U
RE T
O
D
O
SO
MAY
C
A
US
E DAMA
G
E AND
/O
R
PE
ER
S
SON
N
AL IN
JU
RYAND WILL INVALIDATE THE WARRANTY. KEEP THE
S
E IN
S
TR
UC
TI
O
N
S
S
AFE F
O
R F
U
T
U
RE
US
E.
1. SAFETY
1.1. ELECTRICAL
WARNING! It is the user’s responsibility to read, understand and comply with the following:
WARNING! THIS PRODUCT MUST BE INSTALLED BYA QUALIFIED ELECTRICIAN.
You must check all electrical equipment and appliances to ensure they are safe before using. You must inspect power supply leads
and all electrical connections for wear and damage.
You must ensure the risk of electric shock is minimised by the installation of appropriate safety devices.
You must also read and understand the following instructions concerning electrical safety.
Ensure the light is connected to an appropriate electrical on/offswitch.
Ensure the insulation on all cables and the product itself is safe before connecting to the mains power supply.
Ensure that cables are always protected against short circuit and overload.
Regularly inspect power supply, leads and all electrical connections for wear and damage, especially power connections, to ensure
that none are loose.
Ensure the voltage marked on the product is the same as the electrical power supply to be used.
DO NOT pull power cable once installed.
DO NOT use worn or damaged leads, or connections. Immediately replace or have repaired by a qualified Electrician.
Ensure the unit is correctly earthed and wired according to the following. (Installation should be undertaken by a qualified electrician)
a) Connect the green/yellow earth wire to the earth terminal ‘E’.
b) Connect the brown live wire to live terminal ‘L’.
c) Connect the blue neutral wire to the neutral terminal ‘N’.
After wiring, check there are no bare wires, that all wires have been correctly connected.
1.2. GENERAL SAFETY
WARNING! Turn offthe mains power supply before servicing or performing any maintenance.
Maintain the light in good condition (Repairs must only be undertaken by a qualified electrician).
Replace or repair damaged parts. Use genuine parts only, non authorised parts may be dangerous and will invalidate the warranty.
Ensure the light is installed correctly in accordance with these instructions.
Only install the light on a vertical surface.
DO NOT fix the light on any horizontal surface i.e. ceiling, or overhang.
Ideally the Installation should be away from flammable or combustible materials such as wood, cloth, paper etc.
▲DANGER! DO NOT direct the light into a persons eyes. This unit has a very intensive light output, which if incorrectly used could
cause eye damage.
DO NOT install the light where it is likely to be knocked or hit.
DO NOT install in bathrooms, shower rooms, sauna or such locations.
DO NOT install near an exhaust outlet. i.e. boiler flue, dryer outlet, etc.
DO NOT use the light without the front glass shield fitted.
2. INTRODUCTION
Mounted in die-cast powder coated aluminium extra slim housing with wall bracket. SMD LED technology allows ultra-bright illumination whilst
still keeping costs lower than traditional halogen tubes. Even spread of light across a 110° angle. Supplied with power cable at 75cm only and
suitable for outdoor mounting.
3. SPECIFICATION
Model No:.......................................... LED112.V2...........................LED113.V2............................LED115.V2
Colour Temperature:..................................6500K...................................6500K....................................6500K
Dimensions (W x D x H):........157 x 56 x 101mm................195 x 57 x 152mm.................235 x 57 x 191mm
IP Rating: .....................................................IP65......................................IP65.......................................IP65
LED Type: ................................................... SMD.....................................SMD......................................SMD
Lumen Output:..........................................1900lm................................. 5200lm ............................... 10,000lm
PIR Motion Sensor:.........................................No........................................ No.........................................No
Power:..........................................................20W......................................50W.....................................100W
Supply:........................................................230V.....................................230V......................................230V
LED112.V2, LED113.V2, LED115.V2 Issue 1 23/12/21
Original Language Version
© Jack Sealey Limited
Refer to
instructions

4. ASSEMBLY
WARNING! DO NOT connect unit to the mains power supply before installation.
4.1. INSTALLATION
4.1.1. Give careful consideration to the position of unit to ensure you obtain maximum benefit from the lighting range, and that an
appropriate electrical power source can be provided.
4.1.2. An approximate appropriate mounting height from the ground is 2.5m. See fig.1.
4.1.3. This LED floodlight develops minimal heat and is not subject to the same mounting restrictions that apply to halogen lamps that
become too hot to touch. We do however recommend that the floodlight should not be placed in cramped or restrictive positions
and should be fixed at the following minimum distances between the light and any surface/object. See fig.2.
●500mm minimum between the top of the light and any overhead surface, or objects, i.e. ceilings, overhangs.
●200mm between sides of light and wall/surfaces.
●2 metres minimum between the front of the light and any object to be illuminated.
Fix the light to a vertical surface with appropriate fixings.
Ensure the lamp is connected to the mains by a qualified electrician.
5. MAINTENANCE
5.1. Clean the casing externally (not the glass) with a moist cloth.
DO NOT use solvents or abrasives to clean the light.
5.2. Avoid touching the glass shield as handling may reduce its serviceable life and cause the glass to crack. If necessary clean the
glass shield with alcohol and a soft cloth. Undo the single screw without removing it to clean internally.
DO NOT use the light without the glass shield.
DO NOT use the light without the weather seals intact.
fig.1
fig.2
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
Original Language Version
© Jack Sealey Limited LED112.V2, LED113.V2, LED115.V2 Issue 1 23/12/21
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please email or call our
technical team on [e-mail] or 01284 757505.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 24 months from purchase date, proof of which is required for any claim.
