Sealey CP108VMGBO User manual

10.8V CORDLESS MULTIPURPOSE MINI
GRINDER & 50PC ACCESSORY KIT - BODY
ONLY
MODEL NO: CP108VMGBO
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Remove the battery pack from the cordless multipurpose mini grinder before changing accessories, servicing or
performing any maintenance.
9Maintain the cordless multipurpose mini grinder in good condition. Check moving parts alignment on a regular basis.
9Replace or repair damaged parts. Use an authorised service agent and recommended parts only. Unauthorised parts may be
dangerous and will invalidate the warranty.
9 Ensurethecordlessmultipurposeminigrinderisswitchedo󰀨beforeinstallingthebatterypack.
9Keep the cordless multipurpose mini grinder clean for best and safest performance.
9 Removeillttingclothing.Removeties,watches,ringsandotherloosejewelleryandcontainlonghair.
9 Evaluateyourworkingareabeforeusingthecordlessmultipurposeminigrindere.g.ceilings,oorsandenclosuresmaycontain 
electrical items or water piping.
9Ensure battery pack (sold separately) is correctly inserted into the cordless multipurpose mini grinder and latched in place before
attempting to switch on.
9Secure loose work pieces with a clamp, vice or other adequate holding device (not supplied).
9Avoid unintentional starting.
9Wear approved safety eye protection (standard spectacles are not adequate).
9 Maintaincorrectbalanceandfooting.Ensuretheoorisnotslipperyandwearnon-skidshoes.
9Keep children and unauthorised persons away from the working area.
9Store the cordless multipurpose mini grinder and accessories in the original box, in a safe, dry, childproof area where the
temperature will not exceed 104°F (40°C).
8DO NOTusethecordlessmultipurposeminigrinderwherethereareammableliquids,solidsorgases,suchaspaintsolvents,etc.
8DO NOT allow children to operate the cordless multipurpose mini grinder.
8DO NOToperatethecordlessmultipurposeminigrinderifanypartsaremissingasthismaycausefailureand/orpersonalinjury.
8DO NOT hold unsecured work piece in your hand.
8DO NOT leave the cordless multipurpose mini grinder operating unattended.
8DO NOTcarrythecordlessmultipurposeminigrinderwithyourngeronthepowerswitch.
8DO NOT use the cordless multipurpose mini grinder for a task it is not designed to perform.
8DO NOToperatethecordlessmultipurposeminigrinderwhenyouaretiredorundertheinuenceofalcohol,drugsorintoxicating
medication.
8DO NOT get the cordless multipurpose mini grinder or battery wet or use in damp or wet locations.
8DO NOTforcethecordlessmultipurposeminigrinder.Usethecorrecttoolforthejobitwasdesignedfor.
8DO NOT use any accessories other than those supplied with the cordless multipurpose mini grinder.
8DO NOT use any accessory tools which require any liquid coolant.
2. INTRODUCTION
Compact,lightweightcordlessmultipurposeminigrinderand50-pieceaccessorykit-bodyonly.Comfortablecompositehousingwithsoftgrip
toreducevibration.7-Speedsettingsprovidethecontrolrequiredtocompletevarioustasks.Quickreleasecolletandspindlelockforfasttool
changes.Suppliedwitha50-piecerangeoftips,wheels,discs,dressingstonesandachuckspanner.IntegralLEDworkinglightandLED
battery level indicator. Requires compatible 10.8V 2Ah or 4Ah battery and mains charger, sold separately.
3. SPECIFICATION
Model no: ....................................................... CP108VMGBO
Battery: ......................................................10.8V 2aH or 4Ah
Consumable parts (battery)....................................................
2Ah ...................................................................... CP108VBP
4Ah .................................................................... CP108VBP4
Collets:.........1.0 (x1), 1.7 (x1), 2.0 (x1), 2.4 (x1), 3.2 (x1)mm
Free speed:.................................................5000-25000rpm
CP108VMGBOIssue107/04/21
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Wear eye
protection
Wear protective
gloves
Wear a mask

4. CONTENTS
ACCESSORIES
HSS drill bits: .......................................................................6
Mandrels as tool holders:..................................................... 2
Polishing discs: ....................................................................3
Grinding discs: .....................................................................4
Metal brush: .........................................................................1
Cutting discs: ..................................................................... 16
Collet chucks: ...................................................................... 5
Synthetic brushes: ...............................................................2
Milling bits ............................................................................3
Engraving bits: .....................................................................2
Grinding bits:........................................................................ 5
Combination spanner:.......................................................... 1
5. OPERATION
Unpack the product and check contents. Should there be any damaged or missing parts contact your supplier immediately.
 Beforeuse,ensurethatyouhavereadandunderstoodsection1SafetyInstructions.
5.1. SWITCHING ON AND OFF
Also refer to sections 7 and 8.
5.1.1. Insertthebattery.
5.1.2. ToturnthecordlessmultipurposeminigrinderOnsettheOn/O󰀨switch(g1-1)to“I”.
5.1.3. ToturnthecordlessmultipurposeminigrinderO󰀨settheOn/O󰀨switch(g1-1)to“O”.
5.2. SETTING THE SPEED RANGE
5.2.1. Setthespeedcontroldial(g1-5)toapositionbetween“1”and“MAX”.
5.3. CHECKING THE BATTERY CHARGE LEVEL
5.3.1. Insertthebattery.
5.3.2. SettheOn/O󰀨switch(g1-1)tothe“I”position.
5.3.3. TheremainingchargewillbeshownonthebatterychargelevelLED(g1-2)asfollows:
Red/Orange/Green = maximum charge
Red/Orange = medium charge
  Red=lowcharge-re-chargethebattery
5.4. CHANGING THE COLLET CHUCK
5.4.1. Ensure the cordlessmultipurposeminigrinderisswitchedo󰀨andthebatteryremoved.
5.4.2. Pressthespindlelockbutton(g1-4)andholditdown.
5.4.3. Keepingpressureonthespindlelockbutton(g1-4)turnthecolletnut(g1-3)untilthespindlelockclicksintoplace.
5.4.4. Undothecolletnut(g1-3)fromthethreadedoutputshaftusingthecombinationspannerandremove.
5.4.5. Selecttheappropriatecolletchuck(g1-6)andinsertcentrallyintotheopeninginthethreadedoutputshaft.
5.4.6. Replacethecolletnut(g1-3)andscrewngertightonly.Releasethespindlelockbutton(g1-4).
5.5. INSERTING THE ACCESSORY TOOL
5.5.1. Repeat sections 5.4.1 to 5.4.3.
5.5.2. Selectthetoolrequiredandinsertthetoolshaftcentrallyintotheappropriatecolletchuck(g1-6).
5.5.3. Fullytightenthecolletnut(g1-3)usingthecombinationspanner.Releasethespindlelockbutton(g1-4).
NOTE: Use the screwdriver end of the combination spanner to undo and tighten the screw on the mandrels.
5.6. OPERATING THE CORDLESS MULTIPURPOSE MINI GRINDER
5.6.1. Select the speed required. See section 5.2
5.6.2. Selectcolletchuckandthetoolingaccessoryrequired.Seesections5.4and5.5.Re-insertthebatterypack.
5.6.3. Holdthecordlessmultipurposeminigrinderrmlybytheinsulatedgrippingsurfacesandturnthecordlessmultipurposemini 
grinder ON. See section 5.1.
8DO NOT switch the cordless multipurpose mini grinder ON if the accessory tool is in contact with the workpiece. Allow the cordless
multipurpose mini grinder to reach the required speed before applying it to the workpiece.
8DO NOT press the spindle lock button when the cordless multipurpose mini grinder is running.
WARNING!Ensurethatthecolletnut(fig1-3)isfullytightened,andthatthetoolingspindleisexactlymatchedtothe  
corresponding collet chuck. Accessory tools which do not fit precisely with the collet chuck, or become loose, will rotate unevenly,
  vibrate,or“fly”offviolentlywhichcanleadtoalossofcontrolandtheriskofpersonalinjury.
WARNING! The brush accessory tool can loose wire bristles during normal operation. DO NOT apply excessive pressure to the wire
brush as the discarded wire bristles can easily penetrate light clothing and/or skin.
g.1
CP108VMGBOIssue107/04/21
Original Language Version
© Jack Sealey Limited

CP108VMGBOIssue107/04/21
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specificationsandcomponentpartswithoutprior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
6. MAINTENANCE
6.1. Use a clean cloth to remove dirt, dust, oil, grease etc.
8DO NOT use solvents to clean the cordless multipurpose mini grinder.
7. ROTATIONAL SPEED SELECTION
8. ACCESSORY TOOL SELECTION
SUGGESTED TOOL SELECTION
FUNCTION ACCESSORY USE
Drilling HSS drills Wood working
Milling Milling bit Recesses-Hollows-Grooves-Slits
Engraving Engraving bits Labelling-Handicrafts
Rust removal Metal brush Rust removal
Polishing Polishing discs Plastics-Preciousmetals
Cleaning Synthetic brushes Cleaning hard to access areas
Grinding Grindingdiscs-Grindingbits Stone-Wood-Ceramics-Alloysteel
Cutting Cutting discs Metal-Plastic-Wood
SUGGESTED SUITABLE SPEEDS
Speed control dial number Material
1-3 Plastics
4-5 Stone-Ceramics
5Softwood-Metal
6 Hardwood
Max Steel
