Page 1 Original Language Version VS8196 Issue: 1 - 01/07/10
INSTRUCTIONS FOR:
VIDEO BORE SCOPE
MODEL No. VS8196
Table of Contents
1. Safety Instructions...............................................................................2
1.1 Work Area Safety......................................................................2
1.2 Electrical Safety.........................................................................2
1.3 Personal Safety...........................................................................3
2. Description, Specications ...............................................................4
2.1 Description...................................................................................4
2.2 Specications...............................................................................4
2.3 Accessories Included ................................................................5
2.4 Buttons and Controls...............................................................6
3. Installation........................................................................................................ 7
3.1 Battery Removal and Installation ......................................7
3.2 The Imager Head and Cable Installation........................8
3.3 Accessories Installation...........................................................8
3.4 Video-Out Cable Connection ...............................................9
4. Operation Instructions...............................................................................9
4.1 Basic Operation .........................................................................9
4.2 Operation Precautions ..........................................................10
4.3 Battery Precautions................................................................ 11
4.4 Maintenance Instructions.................................................... 11
5. Troubleshooting............................................................................................12
6. Warranty Information .....................................................................12
6.1 Service Procedures..................................................................12
7. Environmental protection............................................................ 13
8. Declaration of Conformity .......................................................... 14
Thank you for purchasing a Sealey Heater. Manufactured to a high standard this product will, if used according to these
instructions and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL
REQUIREMENTS, WARNINGS AND CAUTIONS. USE THIS PRODUCT CORRECTLY AND WITH CARE FOR THE
PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL
INJURY AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.

Page 2 Original Language Version VS8196 Issue: 1 - 01/07/10
1. Safety Instructions
IMPORTANT: Failure to understand and follow the instructions listed
below may result in electric shock, re and/or serious personal injury.
1.1 Work Area Safety
Always perform automotive testing in a safe environment.•
Keep your work area clean and well lit. Cluttered benches and dark areas•
may cause accidents.
Keep clothing, hair, hands, tools, test equipment, etc. away from all•
moving or hot engine parts.
Operate the tool in a well-ventilated work area.•
DO NOT• operate the tool in explosive atmospheres, such as in the
presenceofammableliquids,gases,orheavydust.
Keepareextinguishersuitableforgasoline/chemical/electricalres•
nearby.
DO NOT• use the tool around corrosive chemicals which can damage the
tool.
DO NOT• abuse the cable. Never use the cable to carry the tool.
Keep bystanders, children and visitors away while operating the tool.•
Keep the tool dry, clean, free from oil, water and grease. Use a mild•
detergent on a clean cloth to clean the outside of the tool when necessary.
1.2 Electrical Safety
Avoid body contact with earthed or grounded surfaces such as pipes,•
radiators, ranges and refrigerators.
DO NOT• expose the tool to rain or wet conditions. Water entering the
tool will increase the risk of electric shock.
DO NOT• abuse the cable. Never use the cable for carrying, pulling,
or unplugging the tool. Keep cable away from heat, oil, sharp edges or
moving parts.
1. Safety Instructions

Page 3 Original Language Version VS8196 Issue: 1 - 01/07/10
1.3 Personal Safety
DO NOT• usethetoolwhiletiredorundertheinuenceofdrugs,
alcohol, or medications. A moment of interruption can result in serious
personal injury.
DO NOT• over-reach. Keep proper footing and balance at all times.
Proper footing and balance enables better control of the tool in
unexpected situations.
Always wear safety eye protection that meets ANSI standards.•
DO NOT• place the tool on any unstable surface. The tool may fall
causing serious injury to a person or serious damage to the tool itself.
Never spill liquid on the display units. Liquid increases the risk of•
electric shock and damage to the tool.
DO NOT• use the tool for personal or medical use in any way.
The product is not shock-resistant. Do not use it as a hammer or drop it.•

Page 4 Original Language Version VS8196 Issue: 1 - 01/07/10
2. Description, Specications and Tool
2.1 Description
Versatile video bore scope with Ø8.5mm x 1000mm semi-rigid probe. Image
displayed on a crystal clear, 60mm high resolution LCD display with on-screen
horizontal/verticalipfeaturesforusewithside-viewmirrors.CMOScamera
withadjustableLEDfornecontroloflightoutputandclearpictures.Suitablefor
internalinspectionofcylinderheadboresandvehiclecompartments/components.
Quickest and most cost effective solution, ideal for the inspection of engines,
machinery, buildings and infrastructure. Supplied with AV cable for external
viewing of image. Uses 4 x AA batteries.
2.2 Specications
Recommended
use Indoor
Minimum
viewing distance 25mm (1”)
Image controls Low light vision
Lighting 1 fully adjustable LED
Screen type
display 2.4” TFT LCD
Display
resolution 234 x 480
Power supply 4 alkaline AA, 1.5 Volt batteries
Cable reach 1m (3’) -- expandable to 5m (16’)
Imager head
diameter 8.5mm (0.22”)
Operating temp. Mainunit:32°Fto113°F(0°Cto45°C);
Cable:14°Fto176°F(-10°Cto80°C)
Storage temp. -4°Fto158°F(-20°Cto70°C)
Operating
humidity 5% to 95% non-condensing (display unit)
2. Description / Specication

Page 5 Original Language Version VS8196 Issue: 1 - 01/07/10
2.3 Accessories Included
1) User’sManual
2) Imager head and cable
3) Magnet,hookandmirror
4) Video-out cable
5) 4xAA batteries
6) Protective case
Note: Because of continuing improvements, actual product may differ
slightly from picture.
Fig. 1
1) Handheld Display Unit – Ergonomic tool with comfortable pistol grip
design.
2) Imager Head and Cable – Connects to the tool while in use to view
images and videos.
3) Cable Connector – Connects the handheld display unit to the imager
head and cable.
4) Power Indicator Light – Illuminates once the tool is turned on.
5) Video-Out Port–ToconnecttoaTV/monitor.
6) Battery Compartment Cap – Remove to install or remove batteries.

Page 6 Original Language Version VS8196 Issue: 1 - 01/07/10
Fig. 2
7) Accessory Magnet – Picks up metal objects such as dropped rings or
 screwsontheoor.
8) Accessory Hook – Unclogs obstacles and picks up wires in the pipes or
 connedareas.
9) Accessory Mirror – Helps users look around corners and see inside
unreachable areas.
2.4 Buttons and Controls
Fig. 3
A.LCD Screen – Backlit, 234 x 480 resolution.
B. Power Button–Turnsthetoolon/off.
C.Reverse Button - Controls the direction of the real-time image.
D.DOWN Arrow LED Lighting Adjusting Button – Adjusts dim LED
lighting.
E.UP Arrow LED Lighting Adjusting Button – Adjusts bright LED lighting.

Page 7 Original Language Version VS8196 Issue: 1 - 01/07/10
3. Installation
3.1 Battery Removal and Installation
NOTE: If the power indicator light is blinking continuously, this reminds
you to replace batteries in time as instructed.
Fig. 4
1) Turn the handheld display unit upside down to expose the battery
compartment cap. (Fig.4)
2) Slide the catch in and remove the battery compartment cap.
Fig. 5
Pull out the battery holder and remove batteries. (Fig.5)
To install new batteries, insert four (4) new AA batteries into the slots
in the battery holder.
4) Battery orientation is indicated in the battery holder.
5) Replace the battery holder and compartment cap.
3. Installation

Page 8 Original Language Version VS8196 Issue: 1 - 01/07/10
3.2 The Imager Head and Cable Installation
To use the tool, the imager head and cable must be connected to the
handheld display unit. To connect the cable to the handheld display unit,
make sure the key and slot (Fig.6) are properly aligned. Once they are
 aligned,nger-tightentheknurledknobtoholdtheconnectionrmlyin
place.
Fig. 6
3.3 Accessories Installation
The three accessories include magnet, hook and mirror (Fig.2). All are
attached to the imager head in the same manner. Hold the imager head as
shown in Fig.7,sliptheendoftheaccessoryovertheatsoftheimager
 headandthenrotatetheaccessory90°toxasshowninFig.8.
Fig.7/8

Page 9 Original Language Version VS8196 Issue: 1 - 01/07/10
3.4 Video-Out Cable Connection
Insert the supplied video-out cable into the video-out port of the tool, and
the other end of the cable into the video-in port of a TV, the LCD screen will
output a high quality real-time image.
4. Operation Instructions
4.1 Basic Operation
CAUTION: Keep the cable away from heat, oil, sharp edges or moving parts.
Replace damaged cables immediately.
1) To turn on, hold the handheld display unit with LCD screen facing
you.
2) Press Power button to turn on the screen. The power indicator light will
illuminate green. The real-time image will appear on the display LCD
screen.
3) Press LED Light Adjusting buttons to adjust LED light intensity as
needed. Press DOWN arrow button to dim LED, press UP arrow button to
brighten LED.
4) Press Reverse button to control the direction of the real-time image. The
real-time image will do a horizontal reverse or vertical reverse. (Fig.9)
Fig. 9
.
4. Operation Instructions

Page 10 Original Language Version VS8196 Issue: 1 - 01/07/10
4.2 Operation Precautions
CAUTION: Do not insert the tool into anything or anywhere that may contain a
live electrical charge.
DO NOTyoperate the tool unless the user’s manual has been read thoroughly
and proper training has been completed.
DO NOTyimmerse the handheld display unit in water. Reduce the risk of
electric shock and damage.
DO NOTyuse the tool if condensation forms inside the imager head. Let the
water evaporate before using again.
DO NOTyuse excessive force to insert or withdraw the cable.
DO NOTyuse the imager head and cable to modify surroundings, clear
pathways or clogged areas.
The handheld display unit is not waterproof. The imager head and its covery
arewaterproof,butnotacid-prooforreproof.Avoidsubmersingtheimager
head into corrosive, oily places and be sure to keep the imager head away
from high temperature objects.
DO NOTyput the imager head and cable into anything or anywhere that may
contain a live electrical charge.
Store idle components out of the reach of children and other untrainedy
persons.
Maintainthetoolwithcare.Properlymaintainedtoolsarelesslikelyto causey
injury.
If the tool is dropped, check for the breakage and any other conditions thaty
may affect its operation.
manufacturer of the tool.y
Dry your hands when operating the tool or replacing batteries.y
Protect against excessive heat. The tool should be kept away from heaty
sources such as radiators, stoves or others that produce heat.
Store the tool in ventilated and dry places.y
