Sealey LED013 User manual

Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL
REQUIREMENTS, WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE
PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL
INJURY AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL
Ensure the lamp is fully charged before initial use.
 DO NOT turn the lamp on when it is being charged.
 DO NOT shine directly into your, other person’s or
animal’s eyes.
 DO NOT allow children to use the lamp.
 DO NOT handle or move the lamp whilst it is being
charged.
 DO NOT use the lamp if you suspect that the battery or
the lamp casing is damaged.
DO NOT leave battery in a discharged state, recharge
battery immediately. Before storage, fully recharge the
battery, subsequently recharge the battery at least once
every six months of non-use.
1.2. ELECTRICAL SAFETY FOR USE OF CHARGER.
USE ONLY THE SUPPLIED CHARGER PLUG FOR
CONNECTING TORCH TO THE POWER SUPPLY.
 WARNING! It is the user’s responsibility to read,
understand and comply with the following electrical
instructions:
You must ensure the risk of electric shock is minimised
by the installation of appropriate safety devices.
An RCCB (Residual Current Circuit Breaker) should be
incorporated in the main distribution board. We also
recommend that an RCD (Residual Current Device) is
used with all electrical products, particularly portable
equipment which is plugged into an electrical supply not
protected by an RCCB.
You must also read and understand the following instructions
concerning electrical safety.
1.2.1. The Electricity At Work Act 1989
requires all portable electrical appliances, if used on
business premises, to be tested by a qualified electrician,
using a Portable Appliance Tester (PAT), at least once a
year.
1.2.2. The Health & Safety at Work Act 1974 makes owners
of electrical appliances responsible for the safe condition
of the appliance and the safety of the appliance operator.
If in any doubt about electrical safety, contact a
qualified electrician.
1.2.3. You must ensure that you:
Inspect the charger plug, cable and connector for wear
and damage to ensure items are safe before connecting
to the mains power supply.
If worn or damaged DO NOT use.
Important: Check that the voltage marked on the charger
plug is the same as the power supply to be used.
Uncoil the cable between charger and the lamp.
 DO NOT pull the charger plug from the mains socket by
the lead.
 WARNING! DO NOT use any other type of charger
with this product, other than the supplied mains or
car charger. Failure to observe this warning could
result in injury and or fire and will invalidate the
warranty.
 DO NOT try to take the charger plug apart.
 DO NOT use the charger plug to charge or power any
other electrical item.
 DO NOT get the charger wet, or use in wet, damp
conditions (for indoor use only).
1.3 Battery Safety
 WARNING! To reduce the risk of burns or fire:
 DO NOT Attempt to open, disassemble, modify or
service the battery pack.
 DO NOT Crush, puncture, short external contacts or
dispose of in fire or water.
 DO NOT Expose to temperatures above 60°C (140°).
 Replace only with the battery pack designated for this
product.
 Recycle or dispose of used battery as stipulated by local
regulation.
 If the electrolyte in the cells gets on your skin, thoroughly
wash with soap and water. If it gets in your eyes, rinse
thoroughly with cool water and seek immediate medical
attention.
INSTRUCTION MANUAL FOR:
CORDLESS 36LED RECHARGEABLE
INSPECTION LAMP
MODEL No's. LED013
Original Language Version LED013 Issue: 3 - 22/12/11
Robust inspection lamp with lightweight Lithium-ion battery
suitable for the professional user. Incorporates 36 super bright
LED's ideal for use in engine bays and under-body inspection.
For hands-free applications features both, fold-away 360° swivel
hanging hook and an integral magnet.
Battery: ............................................................. 7.4V / 1Ah Li-ion
Charging Time: .....................................................................4hrs
Operating Time:....................................................................5hrs
Operating Temp:...................................................... -5°C ~ 45°C
Storage Temp: ....................................................... -20°C ~ 40°C
2. INTRODUCTION / SPECIFICATION
3. CHARGING
IMPORTANT WARRANTY INFORMATION:
The battery fitted to this lamp is considered to be a
consumable item and its ability to accept charge will
reduce over time. We will warranty it against mechanical
and electrical defect for a period of one year - this does
not cover fair wear and tear. If the battery is not properly
charged before first use, or regularly conditioned, its
capacity will diminish. Under these circumstances we will
not replace the battery even if it is less than one year old.
3.1 Connect the charger into the charge socket on the
lamp. Plug into power supply and turn on, the red
charge LEDs on the lamp (Fig.1) will light to show
charging has commenced.
3.2 When the battery has fully charged (approx 4hrs) the
red LEDs will go out and green LED's will come
on. Disconnect from mains supply.
3.3 During usage, when the battery is low the red
charging LED's will start to flash. When this happens
switch off the lamp and re-charge.
Note: The Lithium battery does not suffer from memory
effect and once fully charged may be stored for up to
six months without another charge.

4. OPERATION
Note: LED arrays are designed to allow individual LEDs to
cease functioning without causing the entire array to fail.
This could be as a result of shock or impact. Shock or
impact will invalidate warranty.
4.1 Direct the lens away from your eyes before switching on.
Switch the lamp 'ON & OFF' using the push switch on
the handle.
4.2 Suspend the lamp by the hanging hook.
When the light is hanging from its hook it can be rotated
through 360° for more precise positioning.
4.3 You may also use the integral magnet to attach the lamp
to metalwork such as under-bonnet.
Fig.1
On-Off
Switch
Charging
LEDs
Charge
Socket.
Suspension
Magnet.
Rotating Suspension
Hook
Environmental Protection
Recycle unwanted materials instead of disposing
of them as waste. All tools, accessories and
packaging should be sorted, taken to a recycle
centre and disposed of in a manner which is
compatible with the environment.
When the product is no longer required, it must be
disposed of in an environmentally protective way.
Battery Removal
Remove six screws and open casing from front.1.
Clip wires attached to main board and dispose2.
of battery according to local authority
guidelines.
Parts support is available for this product. To obtain parts please email [e-mail]
or phone [phone].
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
INFORMATION: For a copy of our latest catalogue and promotions call us on 01284 757525 and leave your full name and address, including postcode.
01284 757500
01284 703534
[e-mail]
Sole UK Distributor, Sealey Group,
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk,
IP32 7AR
www.sealey.co.uk
Web
email
Original Language Version LED013 Issue: 3 - 22/12/11
Under the Waste Batteries and Accumulators Regulations
2009, Jack Sealey Ltd are required to inform potential
purchasers of products containing batteries (as defined within
these regulations), that they are registered with Valpak’s
registered compliance scheme. Jack Sealey Ltd’s Batteries
Producer Registration Number (BPRN) is BPRN00705
