Sealey LEDFLEXG User manual

FLEXI RECHARGEABLE GREEN INSPECTION
LAMP LI-ION 1 COB + 1 LED
MODEL NO: LEDFLEXG
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETYi
1.1. GENERAL
9Ensure the lamp is fully charged before initial use.
8DO NOT turn the lamp on when it is being charged.
8DO NOT shine directly into your, another person’s or an animal’s eyes.
8DO NOT allow children to use the lamp.
8DO NOT use the lamp if you suspect that the battery or the lamp casing is damaged.
8DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery, subsequently
recharge the battery at least once every six months of non-use.
1.2. The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for the safe condition of the appliance and
 thesafetyoftheapplianceoperator.Ifinanydoubtaboutelectricalsafety,contactaqualiedelectrician.
1.3. BATTERY SAFETY
WARNING!Toreducetheriskofburnsorre:
8DO NOT attempt to open, disassemble, modify or service the battery pack.
8DO NOTcrush,puncture,shortexternalcontactsordisposeofinreorwater.
8DO NOT expose to temperatures above 60°C (140°).
9If the electrolyte in the cells gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with cool
water and seek immediate medical attention
2. INTRODUCTION
Unique new 360° design made from high impact materials. High power COB LED produces up to 500 lumens in tight spaces like engine
 compartments.Featuresa160mmstrongheavy-dutyexibleneckwiththeabilitytoholditspositionwhereeveryouneedit.Toplightis
a 3W LED producing up to 120 lumens. Features a sturdy base which means can also be used a desk lamp. Base includes a strong
magnet and 90° folding hook. One switch controls top light, side light and dimmer function. Features LED battery charge level indicator
and charged by a micro USB. Supplied with micro USB lead.
3. SPECIFICATION
Model no:........................................................... LEDFLEXG
Battery: ......................................................3.7V 2.6 Ah Li-ion
LED Qty: ....................................................... 1 COB + 1 LED
Lumen output:............................Side 50 - 500lm / Top 120lm
Operating time: ................................... Side:2-16hr, Top 9.5hr
Overall length:............................................................ 425mm
Weight:........................................................................ 290gm
IP Rating: ........................................................................IP54
LEDFLEXG Issue 1 21/01/19
Original Language Version
© Jack Sealey Limited
Refer to
instruction
manual

4. OPERATION
4.1. CHARGING
4.1.1. LiftrubbercoverandconnectmicroUSBcabletosocketonrearofhandle(g2).
4.1.2. Theunithas3LEDstoindicatechargelevel(g.2).WhilstchargingtheLEDswill
 ash.OncefullychargedallLEDswillbepermanentlylit.
4.2. LIGHTING MODES
4.2.1. Theunithasfourlightingmodes,LED,COB,COBDimmerorO󰀨.ToselectLED
 pressandholdModeSelectorswitch(g.1).TochangetoCOBmodepressandhold
Mode Selector once more. To dim COB mode rotate Mode Selector switch to achieve
 desiredlightlevel.Toturnunito󰀨,pressandholdModeSelectoroncemore.
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
fig.1
fig.2
