Sealey SJS700.V2 User manual

INSTRUCTIONS FOR:
JIGSAW VARIABLE SPEED 750W
MODEL No: SJS700.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions and properly
maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS AND CAUTIONS.
USE THIS PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE
AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. RETAIN THESE INSTRUCTIONS FOR FUTURE USE.
1.1 ELECTRICAL SAFETY
 WARNING! It is the responsibility of the owner and the operator to read, understand and comply with the following:
You must check all electrical products, before use, to ensure that they are safe. You must inspect power cables, plugs, sockets and any other con-
nectors for wear or damage. You must ensure that the risk of electric shock is minimised by the installation of appropriate safety devices. A
Residual Current Circuit Breaker (RCCB) should be incorporated in the main distribution board. We also recommend that a Residual Current
Device (RCD) is used. It is particularly important to use an RCD with portable products that are plugged into a supply which is not protected by an
RCCB. If in any doubt consult a qualified electrician. You may obtain a Residual Current Device by contacting your Sealey dealer.
You must also read and understand the following instructions concerning electrical safety.
1.1.1 The Electricity at Work Act 1989 requires that all portable electrical appliances, if used on business premises, are tested by a qualified
electrician, using a Portable Appliance Tester (PAT), at least once a year.
1.1.2 The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for the safe condition of those appliances
and the safety of the appliance operators. If in any doubt about electrical safety, contact a qualified electrician.
1.1.3 Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply. See 1.1.1. and 1.1.2. and
use a Portable Appliance Tester.
1.1.4 Ensure that cables are always protected against short circuit and overload.
1.1.5 Regularly inspect power supply cables and plugs for wear or damage and check all
connections to ensure that none are loose.
1.1.6 Important: Ensure that the voltage marked on the appliance matches the power supply
to be used and that the plug is fitted with the correct fuse - see fuse rating at right.
1.1.7 DO NOT pull or carry the appliance by the power cable.
1.1.8 DO NOT pull the plug from the socket by the cable.
1.1.9 DO NOT use worn or damaged cables, plugs or connectors. Immediately have any faulty
item repaired or replaced by a qualified electrician. When a BS 1363/A UK 3 pin plug is
damaged, cut the cable just above the plug and dispose of the plug safely.
Fit a new plug according to the following instructions (UK only).
a) Connect the GREEN/YELLOW earth wire to the earth terminal ‘E’.
b) Connect the BROWN live wire to the live terminal ‘L’.
c) Connect the BLUE neutral wire to the neutral terminal ‘N’.
d) After wiring, check that there are no bare wires, that all wires have been correctly connected, that the cable outer insulation
extends beyond the cable restraint and that the restraint is tight.
Double insulated products, which are always marked with this symbol , are fitted with live (brown) and neutral (blue) wires only.
To rewire, connect the wires as indicated above - DO NOT connect either wire to the earth terminal.
1.1.10 Products which require more than 13 amps are supplied without a plug. In this case you must contact a qualified electrician to ensure that
a suitably rated supply is available. We recommend that you discuss the installation of an industrial round pin plug and socket with your
electrician.
1.1.11 If an extension reel is used it should be fully unwound before connection. A reel with an RCD fitted is preferred since any appliance
plugged into it will be protected. The cable core section is important and should be at least 1.5mm2, but to be absolutely sure that the
capacity of the reel is suitable for this product and for others which may be used in the other output sockets, we recommend the use of
2.5mm2section cable.
1. SAFETY INSTRUCTIONS
FUSE RATING 5 AMP
Blue
Neutral
Wire
Yellow & Green
Earth Wire
Cable
Restraint
Brown
Live
Wire
1.2 GENERAL SAFETY
 Disconnect the jig saw from the mains power before changing accessories, servicing or performing any maintenance.
 Keep saw in good condition. Check moving parts and alignment, and keep saw blades sharp. If necessary use an authorised service agent.
Replace or repair damaged parts. Use recommended parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
Keep the jig saw clean for best and safest performance.
 Wear approved safety eye protection with side shields, and a dust mask if jig saw generates dust.
Remove ill fitting clothing. Remove ties, watches, rings, other loose jewellry and contain long hair.
Use the jig saw in a suitable working area, keep area clean and tidy and free from unrelated materials, and ensure there is adequate lighting.
Use the correct type of blade for the task, such as cutting wood, resin board, ceramic tiles, plastics, copper tubing and thin metal sheeting.
Prevent body contact with grounded surfaces to avoid electric shock i.e. pipes, radiators, ranges, refrigerators etc.
 Evaluate your working area before using the jig saw i.e. floors and enclosures may contain hidden electrical wires or water piping.
 Maintain correct balance and footing. DO NOT over-reach and ensure the floor is not slippery and wear non skid shoes.
Keep children and unauthorised persons away from the working area.
 Secure non stable work piece with a clamp, vice or other adequate holding device.
 Avoid unintentional starting, and ensure the lock on button is disengaged before use.
 Ensure the power cable is kept to the rear of the saw.
 DO NOT force jig saw but allow the saw to progress normally. Force may break the blade.
 DO NOT secure the saw in a clamp or vice.
 DO NOT use the saw without it’s front guard down and before you have checked blade is secured.
 DO NOT touch the blade and DO NOT point the blade at yourself and/or others.
 DO NOT operate jig saw where there are flammable liquids or gasses.
 DO NOT get the jig saw wet or use in damp or wet locations.
 DO NOT hold unsecured work in your hand.
 DO NOT turn the saw on whilst the blade is in a workpiece.
sDANGER! DO NOT shine laser beam into your or anybody elses eyes.
Original Language Version SJS700.V2 Issue: 2 - 23/11/09

 DO NOT leave the jig saw running whilst laying on it’s side or if unattended.
 DO NOT operate jig saw if any parts are missing or if saw and/or blade is damaged as this may cause failure and/or possible personal injury.
 DO NOT operate jig saw when you are tired, under the influence of alcohol, drugs or intoxicating medication.
 DO NOT carry the jig saw with your finger on the power switch.
When not in use switch jig saw off, remove plug from power supply and store in a safe, dry, childproof area.
2. SPECIFICATION & DESCRIPTION
SPECIFICATION
Length of stroke . . . . . . . . . 27mm
Cutting capacity wood ....100mm
Cutting capacity plastic....20mm
Cutting capacity steel .....10mm
Power input ............230V 750Watt
Stroke per minute........500~3000
Heavy-duty 750Watt electric motor with variable speed control. Features laser guide for accurate cutting. Pendulum cutting action with a maximum
capacity cut of 100mm in wood. Tilting sole-plate allows cutting of bevels up to 45°. Supplied with width cutting gauge, dust extraction outlet and
tted with 2mtr cable and BS approved plug.
fig.2
fig.1
1
1
2
2
3
4
5
6
7
3
Risk of Hand Arm Vibration Injury.
The SJS700.V2 Jigsaw Variable Speed 750W, when operated in accordance with these instructions and tested in accordance with EN 28662-1:
1993 results in the following vibration emission declared in accordance with BS EN12096: 1996.
Measured vibration emission value (Wood): . . . 7.6m/s² Uncertainty: ................. 3.04m/s²
Measured vibration emission value (Metal): . . 11.2m/s²Uncertainty: ................. 4.48m/s²
These values are suitable for comparison with emission levels of other tools that have been subject to the same test.
This tool may cause hand-arm vibration syndrome if its use is inadequately managed.
Recommended Measures to reduce risk of hand-arm vibration syndrome:
For Wood this tool should not be used by an individual regularly for more than 106 minutes in any 8 hour period.
For Metal this tool should not be used by an individual regularly for more than 48 minutes in any 8 hour period.
This duration of use should be reduced if the individual is exposed to hand-arm vibration from other sources.
Net weight .............2.48Kg
Sound pressure level . . . . . 96.3dB(A)
Sound power level .......85.3dB(A)
Vibration Wood ..........7.6m/s2
Vibration Metal . . . . . . . . . . 11.2m/s2
Mitre Cuts ..............± 45º
fig.3
1
2
3. OPERATING INSTRUCTIONS
WARNING! Ensure the jigsaw is switched off and unplugged from the mains power
supply. DO NOT use blunt or damaged blades, and use the correct blade for the
material to be cut.
3.1 Fitting the saw blade.
3.1.1 Take the hex key and loosen the two hex screws (fig.1.1) in the saw head (do not
remove screws).
3.1.2 Insert the saw blade into the centre slot of the saw head as far as it will go. Ensure
the teeth face forwards.
3.1.3 Tighten hex screws and check that the back of the saw blade is in the groove of the
roller guide (fig.3.2).
WARNING! BEFORE USE ENSURE ALL SAFETY INSTRUCTIONS IN CHAPTER 1
ARE STRICTLY FOLLOWED.
3.2 ON/OFF Switch.
3.2.1 Start and stop your jigsaw by depressing and releasing the ON/OFF “trigger” switch
(fig.2.1).
3.2.2 To lock the switch in the “ON” mode depress the ON/OFF switch and the lock button
(fig.2.2) at the same time, then release the lock button.
3.2.3 To release the lock depress the on/off switch again and the saw will stop.
Original Language Version SJS700.V2 Issue: 2 - 23/11/09

3.3 Speed setting.
A variable speed switch is located in the handle (fig.2.3). Switch
setting 1 is the lowest speed and setting 6 is the highest.
3.4 Cutting: Maximum thickness: Wood 100mm; Metal 10mm
3.4.1 General cutting.
a) Select the correct blade for the material.
b) Check that the base plate is at 90° to the saw blade.
c) Switch on the laser guide (fig.1.2) and maintain the laser beam on
the scribed line on the workpiece throughout the cutting process.
Note: Use a light cutting oil for metals where necessary.
3.4.2 Arc cutting.
To cut small circles or arcs, reduce the speed by using the variable
speed switch.
3.4.3 Centre cutting.
Drill a pilot hole large enough for the blade of the jigsaw into the
centre of the hole to be cut.
3.4.4 Mitre (angle) cutting.
Loosen the two hex screws underneath the base plate (fig.4.1). Slide
the base plate towards the back of the saw and then twist the base to
the required angle using the scale marked on the plate and then slide
the base forward to locate and then re-tighten the hex screws. Ensure
work is adequately clamped, especially when cutting at a 45° angle.
s DANGER! Ensure the jigsaw is switched off and unplugged from
the mains before adjusting base plate.
3.5 Pendulum cutting (fig.5).
Pendulum cutting is performed by adjusting the pendulum switch. This
option will allow the blade to swing, resulting in improved cutting and
the use of a higher speed for certain materials.
a) When the pendulum selector is set at “0” the pendulum mechanism
is off, the blade will operate in a rigid up and down movement.
b) To engage the pendulum option, turn switch to number "1". To
increase the amount of swing, progress to number "2".
3.6 Using the graduated guide (fig.6).
3.6.1 The graduated guide allows a cut to be made parallel to a given edge
of the workpiece, thereby ensuring a straight, accurate cut.
3.6.2 Slide the graduated rule into the base and position as desired.
Tighten the fixing screws to ensure guide does not slip/move out of
position.
3.6.3 Execute cut, ensuring the flat plate of the guide remains in contact
with the edge of the workpiece.
3.7 Dust / chip extraction.
3.7.1 This jigsaw is equipped with a dust/chip extractor outlet which can be
connected to any vacuum cleaner.
3.7.2 Mount the adaptor on the jigsaw and fix it in place by twisting
anti-clockwise (fig.2.7).
3.7.3 Attach the hose of your vacuum cleaner to the adaptor. Note: Should
you require a special adaptor, please contact the manufacturer of your
vacuum cleaner.
3.8 Laser Guide Adjustment.
3.8.1 Switch on the laser guide and check the alignment of the beam, the
beam should run parallel to the centre line of the jigsaw, if adjustment
is required, slacken screw fig.7C and rotate laser fig.7D until the beam
is parallel to the centre line, tighten screw C.
3.8.2 To adjust the vertical alignment (fig.8) place the jigsaw centrally on a
marked line along its length. Depending to the direction of the
adjustment slacken the screw fig.7A or 7B and tighten the opposite
side to move the beam until it is central with the centre line marked
underneath the jigsaw.
DANGER! DO NOT shine laser beam into your own or anybody
elses eyes.
fig.5
fig.4
1
fig.6
fig.7
AB
C
D
fig.8
Original Language Version SJS700.V2 Issue: 2 - 23/11/09

4. MAINTENANCE.
WARNING! Ensure the jig saw is switched off and unplugged from the mains.
4.1 Cleaning
Keep the jigsaw ventilation slots clean and free from obstructions. If available blow compressed air into vents to clear any internal
dust (safety goggles must be worn when undertaking this process). Keep the outer case of the saw clean and free from grease.
DO NOT wash with water or use solvents or abrasives, use a damp cloth.
4.2 Saw Blade
Check blades to ensure they are sharp and not damaged or bent. DO NOT use blunt or damaged blades.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
INFORMATION: For a copy of our latest catalogue and promotions call us on 01284 757525 and leave your full name and address, including postcode.
01284 757500
01284 703534
[e-mail]
Sole UK Distributor, Sealey Group,
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk,
IP32 7AR
www.sealey.co.uk
Web
email
Original Language Version SJS700.V2 Issue: 2 - 23/11/09
