1.1. ELECTRICAL SAFETY.
p p
WARNING! It is the users responsibility to read, understand and comply with the following:
You must check all electrical equipment and appliances to ensure they are safe before using. You must inspect power supply leads, plugs and
all electrical connections for wear and damage. You must ensure the risk of electric shock is minimised by the installation of appropriate safety
devices. An RCCB (Residual Current Circuit Breaker) should be incorporated in the main distribution board. We also recommend that an RCD
(Residual Current Device) is used with all electrical products. It is particularly important to use an RCD with portable products that are plugged
into an electrical supply not protected by an RCCB. If in doubt consult a qualified electrician. You may obtain a Residual Current Device by
contacting your Sealey dealer. You must also read and understand the following instructions concerning electrical safety.
1.1.1. The Electricity At Work Act 1989 requires all portable electrical appliances, if used on business premises, to be tested by
a qualified electrician, using a Portable Appliance Tester (PAT), at least once a year.
1.1.2. The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for the safe condition of the appliance and the safety of
the appliance operator. If in any doubt about electrical safety, contact a qualified electrician.
1.1.3. Ensure the insulation on all cables and the product itself is safe before connecting to the mains power
supply. See 1.1.1. & 1.1.2. above and use a Portable Appliance Tester (PAT).
1.1.4. Ensure that cables are always protected against short circuit and overload.
1.1.5. Regularly inspect power supply, leads, plugs for wear and damage and all electrical connections
to ensure that none is loose.
1.1.6. Important: Ensure the voltage marked on the product is the same as the electrical power supply
to be used and check that plugs are fitted with the correct capacity fuse. A 13 amp plug may require
a fuse smaller than 13 amps for certain products (subject to 1.1.10. below), see fuse rating at right.
1.1.7. DO NOT pull or carry the powered appliance by its power supply lead.
1.1.8. DO NOT pull power plugs from sockets by the power cable.
1.1.9. DO NOT use worn or damaged leads, plugs or connections. Immediately replace or have repaired by
a qualified electrician. A U.K. 3 pin plug with ASTA/BS approval is fitted. In case of damage, cut off
and fit a new plug according to the following instructions (discard old plug safely).
(UK only - see diagram at right). Ensure the unit is correctly earthed via a three-pin plug.
a) Connect the GREEN/YELLOW earth wire to the earth terminal E.
b) Connect the BROWN live wire to live terminal L.
c) Connect the BLUE neutral wire to the neutral terminal N.
After wiring, check there are no bare wires, that all wires have been correctly connected, that cable outer insulation
extends beyond the cable restraint and that the restraint is tight.
Double insulated products are fitted with live (BROWN) and neutral (BLUE) wires only. Double insulated products are always marked with
this symbol . To re-wire, connect the brown & blue wires as indicated above. DO NOT connect the brown or blue to the earth terminal.
1.1.10. Cable extension reels. When a cable extension reel is used it should be fully unwound before connection. A cable reel with an RCD
fitted is recommended since any product which is plugged into the cable reel will be protected. The section of the cores of the cable
is important. We suggest 1.5mm2section as a minimum but to be absolutely sure that the capacity of the cable reel is
suitable for this product and for others that may be used in the other output sockets, we recommend the use of 2.5mm2section cable.
VARIABLE SPEED SANDER / POLISHER
MODEL: MS800PS
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions
and properly maintained, give you years of trouble free performance.
1. SAFETY INSTRUCTIONS
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS.
USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE
DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
Blue
Neutral
wire
Yellow & Green
Earth wire
FUSE RATING
THIS PRODUCT MUST BE FITTED
WITH A
13 AMP FUSE
Brown
Live
wire
MS800PS - 1 - 120603
INSTRUCTIONS FOR:
1.2 GENERAL SAFETY
pWARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this equipment.
3Familiarise yourself with the application and limitations of the product, as well as the specific potential hazards peculiar to the
sander/polisher.
pWARNING! Disconnect from the mains power and ensure the disc is at a complete standstill before changing accessories, servicing or
performing any maintenance.
3Maintain the sander/polisher in good condition (use an authorised service agent).
3Replace or repair damaged parts. Use genuine parts only. unauthorised parts may be dangerous and will invalidate the warranty.
pWARNING! Keep all guards and holding screws in place, tight and in good working order. Check regularly for damaged parts. A guard or
any other part that is damaged must be repaired/replaced before the tool is next used.
3Locate sander/polisher in a suitable working area, keep area clean and tidy and free from unrelated materials. Ensure there is adequate lighting.
3Keep the sander/polisher clean for best and safest performance.
3Before each use check abrasive attachments for condition. If worn or damaged replace immediately.
3Ensure there are no flammable or combustible materials near the work area.
pWARNING! Wear approved eye safety protection, ear defenders and, if dust is generated, respiratory protection.
Cable
restraint

3. TECHNICAL SPECIFICATIONS
3Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip shoes.
3Remove ill fitting clothing. Remove ties, watches, rings, and other loose jewellery, and contain and/or tie back long hair.
3Keep children and unauthorised persons away from the working area.
3Secure non-stable workpiece with a clamp, vice or other adequate holding device.
3Remove adjusting keys and wrenches from the machine and its vicinity before turning it on.
7DO NOT use equipment for any purpose other than that for which it is designed.
7DO NOT operate the sander/polisher if any parts are damaged or missing as this may cause failure or possible personal injury.
pWARNING! DO NOT sand any materials containing asbestos.
7DO NOT switch the sander/polisher on whilst the head is in contact with the workpiece and avoid unintentional starting.
7DO NOT get the sander/polisher wet or use in damp or wet locations or areas where there is condensation.
7DO NOT allow untrained persons to operate the sander/polisher.
7DO NOT operate the sander/polisher when you are tired, under the influence of alcohol, drugs or intoxicating medication.
7DO NOT use the sander/polisher where there are flammable liquids, solids or gases such as paint solvents, etc.
7DO NOT leave the sander/polisher operating unattended.
7DO NOT carry the sander/polisher with your finger on the power switch.
7DO NOT pull the cord to remove the plug from the power supply.
3Use a qualified person to lubricate and maintain the sander/polisher.
3When not in use unplug from the mains power supply and store in a safe, dry, childproof area.
Pad Size (mm) 180
Thread Size M14
Motor 1200W/230V
No Load Speed (rpm) 1000-3000rpm
Weight (kg) 2.7
2. INTRODUCTION
The MS800PS is a variable speed sander/polisher with digital rpm read-out. The powerful 1200Watt motor unit is surrounded by a tough
composite housing coupled to an aluminium gear casing. Featuring a stop lock spindle device for simple pad/disc loading and unloading and
supplied with side handle, Ø180mm backing pad and compounding head, the unit is able to operate between 1000rpm and 3000rpm,
accommodating a range of sanding/polishing tasks.
4. CONTENT & ASSEMBLY
4.1. Content
4.1.1. Check the contents of the carton. If any item is missing or damaged contact
your supplier immediately.
4.2. Assembly
p WARNING! Ensure unit is not plugged into mains before attempting
any assembly.
4.2.1. Screw side handle (fig. 1) into chosen hole. Note: there is a mounting hole
on either side and the top of the unit, to suit the application and/or
operator.
4.2.2. To attach a sanding disc (not included) (fig. 2):
Fit rubber backing pad (B) on shaft (C). Engage spindle locking
mechanism and tighten pad fitting. Follow with velcro sanding disc (A)
and press down firmly to affix. Reverse procedure for removal.
4.2.3. To fit an polishing bonnet (not included) e.g. lambswool or compounding
head:
Fit rubber backing pad (B) on shaft (C). Engage spindle locking mechanism
and tighten pad fitting. Follow with a velcro polishing bonnet or
compounding head (fig. 3)(D) and press down firmly. Reverse procedure for
removal.
fig. 2 fig. 3
fig. 1
MS800PS - 1 - 120603

Declaration of Conformity We, the sole importer into the UK, declare that the product
listed here is in conformity with the following standards and directives.
The construction file for this product is held by the Manufacturer and may be inspected by a
national authority upon request to Jack Sealey Ltd.
For Jack Sealey Ltd. Sole importer into the UK of Sealey Power Tools.
Variable Speed Sander & Polisher
Model MS800PS
73/23/EEC Low Voltage Directive
89/336/EEC EMC Directive
98/37/EC Machinery Directive
93/68/EEC CE Marking Directive
Signed by Mark Sweetman 12th June 2003
6. MAINTENANCE
p p
WARNING! Before attempting any maintenance ensure the unit is unplugged from the mains power supply.
6.1. Keep the machine clean and dry. Do not use abrasives to clean the unit. Ensure all external head screws are tight.
6.2. Clean regularly by blowing a jet of compressed air through side vents to ensure motor ventilation is kept clear.
p
p
WARNING! Wear approved safety eye protection and. if necessary, respiratory protection.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
INFORMATION: Call 01284 757525 for our catalogue & promotions. Leave your full name, address & postcode.
Sole UK Distributor,
Sealey Group, Bury St. Edmunds, Suffolk.
5. OPERATION
pWARNING! Ensure you read, understand and apply the
safety instructions in Section 1.
Ensure the power on/off switch (fig 4) is NOT locked
on before plugging into the mains.
5.1. Hold the sander/polisher firmly with one hand on the butt
grip and the other on the side handle. Activate the unit by
selecting 1 with the power on/off switch. To select required
speed, press the speed control increase & decrease
buttons accordingly. RPM is displayed in units of 100,
1000RPM would show as 10 on the LCD display.
i.e. 10=1000rpm - 30=3000rpm.
5.2. To stop the unit, switch the power on/off switch back to 0
Note: As the rubber backing pad is flexible , when sanding
it should not be used head on, but at an angle of
approximately 10 to 20 degrees.
Contact your Sealey Dealer for details of replacement
pads and sanding/polishing discs/heads.
01284 757500 [e-mail] www.sealey.co.uk
01284 703534 e-mail Web
fig 4
