Sealey SPP01 User manual
INSTRUCTIONS FOR
SOLAR PANELS
MODEL NO: SPP01 12V/1.5W, SPP03 12V 4.8W
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
I
MPORTANT:
PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURYAND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9Observe standard safety procedures when using the SSP01.
▲DANGER! - Beware, lead-acid batteries generate explosive
gases during normal battery operation.
9If the battery terminals are corroded or dirty, clean them before
attaching the clips.
9 Removeillttingclothing.Removeties,watches,ringsand
other loose jewellery. Contain, or tie back, long hair when
working near batteries.
9Keep children and unauthorised persons away from connections.
WARNING! DO NOT use solar panels on any vehicles other than
those with12Volt DC systems.
8DO NOT dis-assemble solar panel. The solar panel must be
checkedbyqualiedservicepersonnelonly.
8DO NOT get solar panel wet or use in damp locations or areas
where there is condensation.
8DO NOT use the solar panel for any purpose other than for which
it is designed.
8DO NOT pull the cables or clips from the battery terminals.
8DO NOT operate the solar panel if damaged.
9When not in use store in a safe, dry, childproof location.
2. INTRODUCTION
Amorphous solar panels convert daylight directly into 12V electricity. Suitable for maintaining charge in a wide range of batteries and power
packs. Ideal for batteries stored in boats and caravans and for batteries in vehicles in long term storage. Advanced technology solar panels
require only daylight to generate power. Supplied with battery clips and vehicle accessory plug.
3. SPECIFICATION
Model no:....................................................................SPP01
Output:................................................................... 12V/1.5W
Dimensions:......................................................340 x 120mm
Model no:....................................................................SPP03
Output:................................................................... 12V/4.8W
Dimensions:......................................................410 x 345mm
4. OPERATION
4.1. Installation.
4.1.1. Insertthesuctioncups(SPPO1only)intothepre-drilledendsofthesolarpanelensuringthattheyaresecurelyxed.
Choose a clean, dry surface, facing the sun, then dampen suction cups and mount to vehicle’s dash or windscreen.
4.2. Connection through vehicle accessory socket
4.2.1. Attach the auxiliary adaptor lead to the solar panel lead. Plug the male-end of the auxiliary adaptor (12V plug) into the female auxiliary
socket (in the vehicle) making sure that both ends are secure and aligned correctly. For optimal charging power, ensure the panel
(solar cell up) is directly facing the sun.
4.3. Battery Connection.
Note: Check the battery is 12VDC. DO NOT use with a 24V battery.
4.3.1. Attach the battery clip lead to the solar panel lead.
4.3.2. Ensure the battery terminals are clean, if necessary clean away any corrosion.
4.3.3. Clip the red (+) crocodile clip to the red (+) terminal post on the battery.
4.3.4. Clip the black (-) crocodile clip to the black (-) terminal post on the battery.
WARNING:Whendisconnectingremovetheblack(-)clipfromthebatteryrstthenremovethered(+)clip.
SPP01, SPP03 | Issue:3(L) 22/08/17
Original Language Version
© Jack Sealey Limited
Refer to
instruction
manual
Connect to any 12V auxiliary
power outlet
Connect directly to battery
using DCcables
4.4. Watertight hardwired terminal connector for SPP01 and SPP03 (not supplied), see below.
4.4.1. Battery terminal connection lead with in-line fuse unit and weatherproof cap to offer protection from water ingress when the connector
is not in use. Can be left on the vehicle and simply connected to SPP01 and SPP03 when required.
WARNING: The clips MUST be placed on to the battery in the aforementioned order, wrong connections may cause sparking or
explosion.
Note: This solar panel has a built-in blocking diode that protects the battery from reverse discharge.
Note: The use of the solar panel is not recommended while the vehicle is in use.
Note: The solar panel is not weatherproofed do not use in wet or use in damp locations.
