Sealey VS0204C4 User manual

Ø45MM BRAKE PRESSURE BLEEDER CAP 90°
CONNECTOR WITH HOSE
MODEL NO: VS0204C4
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURYAND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
instruction
manual
VS0204C4 Issue:1 08/09/22
Original Language Version
© Jack Sealey Limited
Wear eye
protection Wear protective
gloves
1. SAFETY
IMPORTANT! These instructions are provided as a guide only.Always refer to the vehicle manufacturer’s service instructions.
9It is recommended to perform a leak test to ensure if the adaptor is tightly and securely connected on the reservoir.
9Keep this product in good working order and condition, take immediate action to repair or replace damaged parts.
9Use approved parts only. Unapproved parts may be dangerous and will invalidate the warranty.
9Keep children and unauthorised persons away from the work area.
9Keep work area clean and tidy and free from unrelated materials.
9Ensure the work area has adequate lighting.
8DO NOT use the kit to perform a task for which it is not designed.
8DO NOT allow untrained persons to use the kit.
8DO NOT use when tired or under the inuence of drugs, alcohol or intoxicating medication.
9After use, clean equipment and store in a cool, dry, childproof area.
9Dispose of waste liquids in accordance with local authority regulations.
9 Always read and comply with the warnings on the brake uid container.
9 Wear eye protection and keep skin contact to a minimum. If brake uid enters eyes rinse with plenty of water and seek medical
advice. If swallowed seek medical advice immediately.
WARNING! Only use new Brake Fluid, used Brake Fluid or other uids will contaminate the system and possible brake system
failure may result.
WARNING! DO NOT pollute the environment by allowing uncontrolled discharge of uids.
WARNING! Brake uid is ammable - keep away from sources of ignition, including hot surfaces e.g. exhaust manifold.
WARNING! Brake uid will damage paintwork. Any spillage should be ushed with water immediately.
2. INTRODUCTION
Ø45mm Brake and clutch reservoir bleed cap (2001-2022). 90° Connector with hose for use where access is restricted Manufactured
from aluminium, this adaptor is suitable for pressure bleeding work that requires 1-2bar/14-30psi pressure range. Heavy-duty adaptor
covers most vehicles. Compatible with Sealey brake bleeders VS0204, VS0204A, VS0207, VS820, VS821.
3. CONTENTS
CAP4 European, Ford & Nissan
Model No.:.....................................................VS0204C4

VS0204C4 Issue:1 08/09/22
Original Language Version
© Jack Sealey Limited
4. APPLICATIONS
MAKE MODELS YEAR TYPE No.
Alfa Romeo All models All years 4
Audi All models All years 4
BMW All models All years 4
Buick Cascada 2016-2019 1.6L 4
Buick LaCrosse 2010-2016 2.4L, 3.0L, 3.6L 4
Buick Regal 2011-2017 2.0L, 2.4L 4
Buick Verano 2012-2017 2.0L, 2.4L 4
Chevrolet Cruze 2011-2015 1.4L, 1.8L, 2.0L Diesel 4
Chevrolet Cruze Limited 2016-2016 1.4L, 1.8L 4
Chevrolet Malibu 2013-2016 1.8L, 2.0L, 2.4L, 2.5L 4
Chevrolet Malibu Limited 2016-2016 2.5L 4
Citroen All models All years 4
Fiat All models All years 4
Ford C-Max 2013-2018 2.0L 4
Ford Escape 2013-2016 1.5, 1.6L, 2.0L, 2.5L 4
Ford Focus 2012-2018 1.0L, 2.0L, 2.3L 4
Ford Fusion 2013-2014 4
Ford Transit Connect 2014-2020 1.6L, 2.0L, 2.5L 4
Ford Transit-150 2015-2019 3.2L Diesel, 3.5L, 3.7L 4
Ford Transit-250 2015-2019 3.2L Diesel, 3.5L, 3.7L 4
Ford Transit-350 2015-2019 3.2L Diesel, 3.5L, 3.7L 4
Ford Transit-350 HD 2015-2019 3.2L Diesel, 3.5L, 3.7L 4
Jaguar All models All years 4
Land Rover All models All years 4
Mazda CX-7 2007-2012 2.3L, 2.5L 4
Mazda Mazda3 2004-2013 2.0L, 2.3L, 2.5L 4
Mazda Mazda5 2006-2010 2.3L 4
Mazda Mazda5 2012-2015 2.5L 4
Mazda MX-5 Miata 2006-2015 2.0L 4
Mercedes-Benz All models All years 4
Mini All models All years 4
Nissan Europe-made models All years 4
Opel All models All years 4
Peugeot All models All years 4
Renault Almost all models All years 4
Volvo Almost all models All years 4
VW All models All years 4
5. OPERATION
5.1. Remove the master cylinder reservoir cap.
5.2. Pull out the old brake uid as much as possible.
5.3. Fit the adaptor and connect to the reservoir.
5.4. Connect the pressure bleeding tool or machine to the adaptor (g.1).
5.5. Follow the instructions as specied by the pressure bleeding tool or machine manufacturer.
5.6. It is recommended to perform a leak test to ensure if the adaptor is tightly and securely connected on the reservoir.
5.7. Remove the master cylinder reservoir cap (g.2)
5.8. Screw on the adaptor cap.(g.3)
5.9. You are now ready to commence with bleeding the brakes.
6. MAINTENANCE
6.1. Ensure that the unit is de-pressurized before carrying out any maintenance and drain all fluids from the fluid supply tube.
6.2. Clean up any spilled brake fluid and wipe down with a clean cloth.
6.3. Store in a clean, dry and childproof location.
