Instructions for:
Glow Plug Removal Set
MODEL No: SX0408.V2
1. SAFETY INSTRUCTIONS
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions and properly
maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS,
WARNINGS AND CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS
INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY.
PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
2. INTRODUCTION
3. SPECIFICATION
WARNING! Ensure Health and Safety, local authority and general workshop practice regulations are adhered to when using tools.
DO NOT use tools if damaged.
Maintain tools in good and clean condition for best and safest performance.
Wear approved eye protection. A full range of personal safety equipment is available from your Sealey dealer.
Wear suitable clothing to avoid snagging. DO NOT wear jewellery and tie back long hair.
DO NOT attempt to start engine or move vehicle whilst tools are fitted and work is in progress.
Ensure any disconnected fuel pipes are plugged to avoid spillage.
Account for all tools and parts being used, DO NOT leave them in or near the engine. Return all parts to the case and store this in a
safe, dry, childproof location.
IMPORTANT: These instructions are provided as a guide only. Always refer to the vehicle manufacturer’s service instructions,
or a proprietary manual, to establish the current procedure and data.
WARNING! The warnings referred to in this guide cannot cover all possible conditions and situations that may occur. It must be understood
that common sense and caution are factors which cannot be built into this product, but must be applied by the operator.
SX0408.V2 Issue No: 1 - 10/09/13
Original Language Version
© Jack Sealey Ltd
● Designedtoremovedamaged/brokenglowplugsfromcylinderheads.
● SuitableforglowplugswithM8x1mmorM10x1mmthread.
● Setincludesallrequiredadaptorsforcentring,drillingandpullingforthesaferemovaloftheglowplug.
● Suppliedinstoragecase.
Model Number:.............................................................. ..SX0408.V2
TapDimensions:.........................¼”-28UNF,M8x1mm,M10x1mm
GlowPlugApplications:................................M8x1mm,M10x1mm
Key to Fig 1:
Number Part No. Description
1................ SX0408.V2-01............................................ Puller Housing
2................ SX0408.V2-02...................................Drill Holding Adaptor
3................ SX0408.V2-03............Puller Adaptor Mandrels (2 pcs/set)
4................ SX0408.V2-04........Pilot Drill Centring Sleeves (2pcs/set)
5................SX0408.V2-05...........................................HexKey(3mm)
6................ SX0408.V2-06........................................Star Socket (E10)
7................ SX0408.V2-07................................Drill Bit (7mm /5.5mm)
8................ SX0408.V2-08................................Drill Bit (9mm/5.5mm)
9................ SX0408.V2-09.............................................Ratchet T- Bar
10............... SX0408.V2-10...................................Pilot Drills (2pcs/set)
11................SX0408.V2-11...........................................Tap(M10x1.0)
12...............SX0408.V2-12.............................................Tap(M8x1.0)
13............... SX0408.V2-13..........................................Tap (¼”-28UNF)
Fig.1:
