Sealy Reflexion-UP Foundation User manual

A. B. C.
E. F.D.
Installation
Before discarding any packing materials, check the
Reexion®-UP Foundation carton and verify the
following items in the parts list are included:
PARTS LIST
A. Wired Remote Control – hard wired to bed (1)
B. Connection Y-Cable (1) - (Only on Twin Long, and
SplitCAKing)
C. Mattress Retainer Bar (1)*
D. Retainer Bar Plate (2)*
E. Retainer Bar Screw (2)*
F. 9-Volt Batteries (2)
Installation Instructions
*Attached to foundation for shipping.
Appearance of some parts may differ from photos.
11
TEMPUR SEALY CUSTOMER SERVICE DEPARTMENT: 1–800–499–1965

Reflexion®-UP Foundation
STEP 1
Lift carton top off box to reveal the bottom of the
foundation.
STEP 2
Using a power extension cord to reach the
foundation, plug in the foundation’s power cord.
NOTE: Do not uncoil the foundation power cord
which is packaged for shipment.
STEP 3
Slide the cover off the battery compartment on the
power supply and install the provided (2) 9-Volt
Batteries (F). Replace the battery compartment
cover.
NOTE: Do not mix old and new batteries.
STEP 4
Cut the plastic strapping on each Wired Remote
Control from the foundation frame. Ensure that the
wired remote is connected to the foundation.
STEP 5
Power Test Procedure:
Press each of the following buttons long enough to
illuminate the blue LED backlight on the remote
control, and watch/listen for the foundation to
activate. This ensures you will be delivering a
foundation that is fully functional. Test the
foundation by pressing the buttons in the following
sequence.
NOTE: Only press each button long enough
to hear or see the function activate on the
foundation.
1. Head Lift
2. Flat
Pre-Delivery Procedure
STEP 6
Once the warehouse test is successful and complete:
• Unplug the power extension cord
• Place the lid back on the outer carton and secure
for delivery
NOTE: Always keep the foundation in a flat,
horizontal position during transportation and
delivery.
NOTE: To avoid damage to the Reflexion®-UP
Foundation, always open the carton while the
bed is in the flat position.
12
TEMPUR SEALY CUSTOMER SERVICE DEPARTMENT: 1–800–499–1965

Installation
NOTE: Always keep the Reflexion®-UP
Foundation in a flat, horizontal position during
transportation and delivery. Always open the
box in the flat position.
STEP 1
Carefully take the foundation in the carton to the
bedroom and place next to where the customer
wants it set up.
STEP 2
Carefully lift the Reexion-UP Foundation out of
the shipping carton, keeping the unit topside down.
For safety reasons, this should be performed by
twopeople.
NOTE: To avoid damage
to the foundation,
always open the carton
while the bed is in the
flat position.
STEP 3
The products come packed in a cardboard box.
Some components are also sealed in plastic lm.
To unpack, proceed as follows:
STEP 3A
Remove the cardboard and plastic lm from the
components.
STEP 3B
Check the package contents.
STEP 3C
Dispose of the packaging materials.
STEP 3D
Keep the user manual at hand for the operators.
Delivery Procedure
STEP 4
Remove the Wired Remote Control from the frame.
Verify the (2) 9-Volt Batteries were installed into the
battery compartment of the power supply.
NOTE: Do not mix old and new batteries.
STEP 5
Connect the power cord from the power supply to
the surge protector (not included).
STEP 6
NOTE: Aftermarket legs and casters are
available for purchase.
If purchased, attach Reexion-UP Foundation Legs
by following instructions included with accessories.
NOTE: Hand tighten the legs securely to the
frame. DO NOT over tighten. Make sure the legs
are screwed completely into the frame. Legs that
are not securely attached may become unsafe.
DO NOT unscrew a leg to compensate for an
uneven floor.
NOTE: In order to prevent the movement of this
product, all four casters should be in the locked
position.
13
TEMPUR SEALY CUSTOMER SERVICE DEPARTMENT: 1–800–499–1965

Reflexion®-UP Foundation
STEP 7
If this delivery involves dual foundations and/or
split mattresses, see instructions for joining two
foundations on page 15.
STEP 8
Carefully ip the Reexion
®
-UP Foundation(s) over to
the topside up position.
NOTE: Make sure to lift the foundation(s) off the
ground before flipping over. DO NOT use legs as
a leverage point to ensure they do not break.
DO NOT
lean the bed against the
installed legs to flip it over.
ATTENTION ! Improper handling
!
STEP 9
Route the control box cable to your preferred side of
the bed.
STEP 10
Install the Mattress Retainer Bar (C).
STEP 10A
Remove Mattress Retainer Bar (C) from frame.
STEP 10B
Unscrew Retainer Bar Plate (D) and Retainer Bar Screw
(E) from frame with screw driver (not provided).
STEP 10C
Install Mattress Retainer Bar (C) and replace Retainer
Bar Plate (D).
STEP 10D
Tighten Retainer Bar Screw (E) with screw driver.
STEP 11
Place the mattress(es) on the foundation(s).
WARNING: When placing the foundation(s)
within a bed frame, verify the space between
the headboard cross member and the top of the
mattress is no more than 3 inches.
STEP 12
Ensure the power switch on the surge protector is in
the “on” position and that it is plugged into the wall
outlet. Check the system for functionality with the
mattress in place.
14
TEMPUR SEALY CUSTOMER SERVICE DEPARTMENT: 1–800–499–1965

Installation
Instructions For Joining Two Foundations
STEP 4
Plug in the “A” output of the Y-Cable into FrameA
control port.
STEP 5
Plug in the “B” output of the Y-Cable into FrameB
control port.
STEP 6
Plug one of the provided Wired Remote Controls
into the “Control Input” side of the Y-Cable.
ONE WIRED REMOTE CONTROL AND TWO
REFLEXION®-UP FOUNDATIONS
Assembling Split/Dual Foundations (Frame A and
Frame B) to be used together as a single King or CA
King system.
NOTE: The use of “Frame A” and “Frame B” is
for description purposes only and the beds will
not actually be labeled “Frame A” or “Frame B”.
NOTE: Wired Remote Control and Y-Cable are
attached to underside of the Reflexion-UP
Foundation for shipping.
STEP 1
Carefully unplug the Wired Remote Controls from
FrameA and FrameB.
STEP 2
Remove both Wired Remote Controls and set aside.
Place the spare remote control in a safe place for
any future use.
STEP 3
Remove and extend one of the provided Y-Cables
