U-DS90W Creation Station
Assembly Instructions
Contents of Hardware Pack:
[1] Small Wrench [M]
IMPORTANT
If you have difficulty assembling your U-DS90W
Creation Station or need customer service
assistance. Please call:
Martin Universal Design, Inc.
Customer Service Hot Line at
1-313-895-0700.
If you need additional parts,
it is not necessary to contact your dealer,
our Customer Service Rep. will forward them
to you immediately.
Revised June 07- RPI
[1] Allen Wrench [N]
[2] Castors [K]
[1] Large Wrench [L]
[2] Small Wood Screws [I]
[2] Locking Castors [J]
[4] Collars [G]
[4] Male Knobs [H]
[8] M4.2 x 16mm [E]
[8] M4.2 x 12mm [F]
[4] 1/4” x 35mm [C]
[8] 1/4” x 2-1/2” [D]
[8] M6 x 13mm [A]
[4] Nuts [B]
List of Hardware:
Qty Part Description Part Number
[8] M6 x 35mm [A]
[4] Nuts [B]
[4] 1/4” x 35mm [C]
[8] 1/4” x 2-1/2” [D]
[8] M4.2 x 16mm [E]
[8] M4.2 x 12mm [F]
[4] Collars [G]
[4] Male Knobs [H]
[2] Small Wood Screws [I]
[2] Locking Castors [J]
[2] Castors [K]
[1] Large Wrench [L]
[1] Small Wrench [M]
[1] Allen Wrench [N]

4444 Lawton Avenue, Detroit, MI 48208 USA • Tel:[phone]/Fax:[phone]
Email: [email protected] • visit us at www.MartinUniversalDesign.com
U-DS90W Creation Station
Assembly Instructions
Parts List:
IMPORTANT
If you have difficulty assembling your U-DS90W
Creation Station or need customer service
assistance. Please call:
Martin Universal Design, Inc.
Customer Service Hot Line at
1-313-895-0700.
If you need additional parts,
it is not necessary to contact your dealer,
our Customer Service Rep. will forward them
to you immediately.
Revised June 07- RPI
[1 ea.] Pencil Edge [9]
[4 ea.] Drawer Supports
[10]
[1 ea.] Upper Base End
Unit (left) [3]
[1 ea.] 24” x 40” Top [1]
[2 ea.] Lower base End
Unit [2]
List of Parts:
Qty Part Description Part Number
[1] 20” x 40” White Top [1]
[2] Lower Base End Unit [2]
[1] Upper Base End Unit (left) [3]
[1] Upper Base End Unit (right) [4]
[1] Base Cross Support Bar [5]
[1] Top Surface Cross Support [6]
[1] Foot Bar [7]
[2] Tilt Support Mechanisms [8]
[1] Pencil Edge [9]
[4] Drawer Supports [10]
[2] L-Bracket Top Supports [11]
[2] Drawer Units (3 drawers each) [12]
[1 ea.] Upper Base End
Unit (right) [4]
[1 ea.] Base Cross Support
Bar [5]
[1 ea.] Foot Bar
[7]
[1 ea.] Top Surface Cross
Support [6]
[2 ea.] Tilt Support
Mechanisms [8]
[2 ea.] L Bracket Top
Supports [11]
[2 ea.] Drawer Bank of 3
[12]

STEP 1] Assembly Base of table
Assembly Instructions:
STEP 3] Complete Base Assembly
Revised June 07- RPI
Pg. 3
Take the top portion and the lower portion of the base that
was just assembled. Insert the top portion into the lower por-
tion, making sure the top ends slide into the collars that are
on the lower portion of the base. Secure with the [4] male
knobs (part H) tightening them into the collars. As shown
below in FIG 3.
2
2
7
5
D
D
D
D
G
G
J
J
K
K
Begin by taking the [2] Lower Base End units (part #2 and
attach the foot bar (part # 7) and the Base Cross Support bar
(part# 5) to each base end using the 1/4” x 2-1/2” Allen Bolts
(part# D). Secure with Allen Wrench (part N), See FIG 1.
Once the base is assembled continue by adding the [4]
collars (part G) to the ends of the base, as pictured below.
Complete Step 1 by inserting [2] locking castors (part J)
into the front of the base end. Complete by inserting the [2]
remaining castors into the rear of the base.
See picture below.
STEP 2] Assemble upper portion of base
Take each upper Base end (left - part #3) and (right - part #4)
and attach to Top Surface Cross Support (part #6) using [2]
1/4” x 2-1/2” Allen bolts (part D). Secure with Allen Wrench
See FIG 2.
F
FIG 1
4
6
D
3
D
FIG 2
H
G
G
H
STEP 4] Drawer Support Assembly
Attach [2] Drawer Supports (part #10) to each set of draw-
ers (part #12) by sliding one onto each end of the drawers
making sure the hooked end is positioned as pictured below
and the 2 holes are on the bottom side of the drawer unit.
Secure each support using [2] M4.2 x 12mm (part F) in each
support. [4] total for each drawer unit. See FIG 4.
FIG 3
FIG 4
Hooked bent end
F
12
10

6
8
C
C
B
