AFi TWIN XL FR-PDA-STO User manual

ASSEMBLY INSTRUCTIONS
Before assembling your bed frame, please read through these
ATTENTION! If you receive a damaged or defective item,
please contact afifurnishings at [email protected] or 1-800-955-3726
instructions carefully and familiarize yourself with the different parts.
Barrel nut - 2 pcs
Wood dowel 10 X 30mm( 1 1/4") - 4 pcs
JCB M6 X 70mm (2 3/4”) - 2 pcs Wood screw(1 1/4”) - 12 pcs
Spare - 1 pc
Spare - 1 pc
Spare - 1 pc
BED FRAME
Page 1 of 2
PARTS LIST HARDWARE
AE
F
B
C
D
FOOT RAIL
LEFT LEG
RIGHT LEG
SIDE RAILS
SLAT KIT
1 PC
1 PC
1 PC
2 PCS
2 SET
1
2
3
4
5
Allen wrench M4 - 1pc
Spare - 1pc
4
4
1
1
D
2
3
B
C
B
C
A
A
B
C
D
A
Attach the legs (2) and (3)
to foot rail (1), using wood dowel
(C) JCB M6 X 100mm (A) and
barrel nut (B).
Tighten with the Allen wrench (F).
Cover holes with wood button (D) as shown.
NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.
Step 1
Step 2
READY
ASSEMBLE
TO
Adult assembly
JCB M6 X 70mm
Barrel nut
Wood dowel
Wood button
TWIN XL
Spare - 1 pc
Wood button - 2 pcs
wood button
Attach the side rails (04) to the headboard and footboard (1) using
the bed hook as shown below.
PO: CODE ITEM
FR-PDA-STO R-21031X
Center set of pins.

Page 2 of 2
Congratulations!
Your bed is now ready for use.
Step 3
Attach slat kit (5) to the bed as shown below. Using wood screw (E) tighten with
Phillips head screwdriver. ( Customer supplied )
We recommend that you periodically recheck that all screws are tight to ensure lasting safety.
TWIN XL
E
Wood screw 1 1/4"
Adult assembly
5
5
E
E
E
E
E
E
E
E
E
E
E
E

Adult assembly
ASSEMBLY INSTRUCTIONS
Before assembling your headboard, please read through these
Page 1 of 2
Step 1
Instructions apply for bed sizes
TWIN > FULL > QUEEN > KING
PARTS LIST HARDWARE
ATTENTION! If you receive a damaged or defective item,
please contact afifurnishings at [email protected] or 1-800-955-3726
READY
ASSEMBLE
TO
instructions carefully and familiarize yourself with the different parts.
HEADBOARD PANEL 1 PC
1
2
3
1 PC
1 PC
LEFT LEG
RIGHT LEG
Split washer - 4 pcs
Flat washer - 4 pcs
JCB M6 X 25mm (1”) - 4 pcs
HARDWARE FOR METAL BED FRAME
Spare - 1 pc
Spare - 1 pc
Spare - 1 pc
E
D
C
Allen wrench - 1pc
Spare - 1pc
If you purchased a wood headboard to attach to metal bed frame, please refer to page 2.
NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.
JCB M6 X 35mm (1 3/8”) - 4 pcs
Spare - 1 pc
B
F
AWooden dowel - 4 pcs
Spare - 1 pc
Attach the legs (2) and (3) to headboard panel (1),
using wooden dowels (A) and JCB (B).
Tighten with the Allen wrench (F).
Adult assembly
1
2
3
A
B
B
A
PO:
HEADBOARD
CODE ITEM ITEM ITEM ITEM
HB-ORL R-28182X R-28183X R-28184X R-28185X

Adult assembly
ASSEMBLY INSTRUCTIONS
Before assembling your bed, please read through these
Metal bed frames are sold separately from wood headboards. The hardware shown on this page
is supplied with your wood headboard for attaching the bed frame to the headboard.
The metal bed frame is supplied with its own assembly instructions and hardware.
instructions carefully and familiarize yourself with the different parts.
Attach the headboard assembly to the metal frame using JCB (C), flat washer (D),
and split washer (E) then tighten with Allen wrench (F), as shown below.
Congratulations!
Allen wrench M4
F
C
C
E
E
D
D
Instructions apply for bed sizes
JCB M6 X 1”
C
Flat washer
Split washer
D
E
Page 2of 2
Your bed is now ready for use.
HEADBOARD
To ensure lasting safety, we recommend that you periodically check
that all screws are tight and all parts are secure.
Step 1
ATTACHING HEADBOARD TO METAL BED FRAME
TWIN > FULL > QUEEN > KING
