Sears 790.32433900 Manual

79032433900.jpg M79032433900.eps B79032432900.eps 318047112.eps
REPAIR
PARTS
LIST
790.32433900
For Parts or Service:
Call
1-800-4-MY-HOME®
(1-800-469-4663)
Or Visit
www.sears.com
36” GAS COOK-TOP
In all orders or correspondence, avoid delays and misunderstandings
by always giving the complete model number shown
All repair parts listed are available for immediate purchase or special
order when you visit your nearest Sears Parts & Repair Center, or the
Service Department at most Sears stores. To order parts by phone, call
the toll-free number listed to the left or visit sears.com.
When requesting service or ordering parts, always provide the following
information:
• Product Type • Part Number
• Model Number • Part Description
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A
Publication number 5995554622

790.32433900
10/09 2
COOK TOP
CAUTION: Use the Kenmore part number to order part, not the illustration number.

790.32433900
# Functional Parts 3 10/09
* Non-Illustrated Parts
COOK TOP
CAUTION: Use the Kenmore part number to order part, not the illustration number.
POS. NO PART NO. DESCRIPTION
16 318279462 Maintop, stainless
20 318279103 Grate, double, black, (2)
20A 318279203 Grate, center, black
21 316264901 Skirt, 14K burner, black
21A 316241901 Skirt, 5K burner, black
21B 316241801 Skirt, 9.5K burner, black
22 316219900 Cap, 14K burner, black
22A 316206600 Cap, 5K burner, black
22B 316213500 Cap, 9.5K burner, black
31 316242000 Seal, 12K/14K burner
31A 316242003 Seal, 5K burner
31B 316242002 Seal, 5K/9.5K burner
39 318144006 Cord, service
43 318921111 Knob, top valve, stainless
46 318279000 Box, burner
* 5303323168 Tape, aluminum, 3" wide
88 318280101 Gasket, cooktop, 21.48", sides, (2)
88A 318280102 Gasket, cooktop, 35.78", front/back, (2)
132 3201437 Strain relief
136 318264301 Support, box, (2)
137 5303285443 Screw, lock bracket, 10-24 x 2.00
* 316136900 Cleaner, stainless steel
* 5995554622 Repair Parts List
* 318203662 Owners Manual
* 318047112 Wiring Diagram
* 318201465 Instructions, installation
* 5303307980 Screw, 8-32 x 0.437, (8)

790.32433900
10/09 4
BURNER
CAUTION: Use the Kenmore part number to order part, not the illustration number.
78
14
24
35
35
35
3
11B 11C
11D
44B 44B
44B
37 37
37
11A 44A
37
B79032432900
10B
10B
11C
11B
10B
11D
77 10A
11A
2B
2B
2A
2B
2C
72
72
72
1
77
77
10
11
77
77
13
8
72
11 44
37

790.32433900
# Functional Parts 5 10/09
* Non-Illustrated Parts
BURNER
CAUTION: Use the Kenmore part number to order part, not the illustration number.
POS. NO PART NO. DESCRIPTION
1 # 318177207 Manifold Pipe
2 # 318233930 Valve, top burner, 14000 BTU
2A # 318233900 Valve, top burner, 5000 BTU
2B # 318233910 Valve, top burner, 9500 BTU
3 # 318232646 Wiring Harness, w/igntr switch
8 318079001 Module, spark
10 # 316223400 Burner, sealed, 14K
10A# 316206401 Burner, sealed, 5K
10B# 316212400 Burner, sealed, 9.5K
11 # 318221344 Ignitor/orifice assy., top burner, right front, 14K, w/holder, tube
11A# 318221343 Ignitor/orifice assy., top burner, right rear, 5K, w/holder, tube
11B# 318221342 Ignitor/orifice assy., top burner, center, 9.5K, w/holder, tube
11C# 318221339 Ignitor/orifice assy., top burner, left rear, 9.5K, w/holder, tube
11D# 318221340 Ignitor/orifice assy., top burner, left front, 9.5K, w/holder, tube
13 318054509 Connector, manifold tube
14 # 318122717 Regulator, pressure
14* 318531900 Clip, (3)
24 318054002 Elbow, fitting
35 318146301 Bushing
37 5304472956 Screw, hex wash, 6-32 x .485
44 316237900 Orifice, top burner, 14K
44A 316237903 Orifice, top burner, 5K
44B 316237902 Orifice, top burner, 9.5K
72 316215600 Screw, valve mtg., 1/4 - 20
77 318192606 Bracket, burner mtg, (4)
* 5303305528 Screw, 8-32 x 1/4
78 318280500 Support, manifold pipe
* # 318127443 LP Conversion Kit, w/instructions
* 318064840 Instruction sheet, LP conversion
* # 318199780 Wiring Harness, ignitor
* 5303307980 Screw, 8-32 x 0.437, (8)
* 5303323140 Screw, ground, 10-32 x 0.375

790.32433900
10/09 6
WIRING DIAGRAM
