Seavo SV1-H612A Series User manual

SV1-H612A Series Motherboard
User Guide
Ver 1.0

Contents
1.
Models and Attentions .........................................................................................................................
2
1.1
Models ...........................................................................................................................................
2
1.2 Attentions ......................................................................................................................................
2
2.
Specification ........................................................................................................................................
3
3.
Data Flow ............................................................................................................................................
4
4.
Jumpers / Headers and Connectors ...................................................................................................
5
5.
Definition of Jumpers / Headers and Connector.................................................................................
7
6.
BIOS setup .........................................................................................................................................
11
7.
GPIO & Watchdog ..............................................................................................................................
11
7.1
Read and write GPIO ...................................................................................................................
11
7.2
Set & Disable WatchDog..............................................................................................................
11
- 1 -

1. Models and Attentions
1.1 Models
This manual is applied to following models:
Model
Chipset
COM
LAN
PCI-E X16
Mini PCI-E
SV1-H612A
H61
10
2
1
1
1.2 Attentions
1) Notes under a table or figure indicate the difference of models, or alternative definition of specific
pin of the header (jumper/connector).
2) How to identify the first pin of a header or jumper
Usually, there is a thick line or a triangle near the header’s or jumper’s pin 1.
Square pad, which you can find on the back of the motherboard, is usually used for pin 1.
- 2 -

2. Specification
Model
SV1-H612A
CPU
Support Intel Pentium/ Celeron/ 2nd and 3rd Generation Core i3/5/7 CPU, LGA1155
Chipset
Intel H61
Memory
Support DDR3 1066/1333 MHz
2
* DIMM Slot，Up to 16 GB Memory Size [1]
Ethernet
2
* Realtek 8111E/8105E PCI-E LAN [2]
Storage
2
* Serial ATA ports
1*mSATA [3]
Serial
10 * RS232 Headers [4]
GPIO
8* GPIO
Graphic
1* VGA DB15 port
1
* HDMI port or 1 * VGA DB15 port（optional）
Audio
Realtek ALC662 5.1 Channel HD Audio Codec
Line-out /MIC Ports and onboard Header
1
* PS/2 port (keyboard)
1
* LPT DB25 port
8
* USB2.0 ports (4 * Rear I/O + 4 * Header)
Other ports
1
* Mini PCI-E (Support mSATA and 3G Devices) [3]
1
* PCI-E X16 slot
1
* SYS_FAN Socket
1
* CPU_FAN Socket
Temperature
Storage: -20~75℃
Operating: 0~60℃
BIOS
AMI UEFI BIOS
Factor
Mini-ITX
Notes:
[1]: Due to the restriction of Windows 32 bit OS, when applied more than 4G memory, 32 bit OS may
detect less than actual size.
[2]: LAN can be customized into single LAN.
[3]: mSATA and Mini PCI-E are using the same interface, so only one function can be used at one time,
if you need the other function, it would need some hardware changes supported.
[4]: COM3 can be RS232 or RS485 by setting jumpers.
- 3 -

3. Data Flow
Intel Pentium/
PCI-E X16
Celeron/
PCI-E X16
nd
2
and 3
rd
Core
Slot
Processor
LGA1155
FDI
DMI
HDMI or
VGA Port
CHANNEL A1
DDRIII
U-DIMM
CHANNEL B1
DDRIII
U-DIMM
VGA Port
Analog Display
USB 2.0
USB*4
4 Ports
USB 2.0
USB*4
Intel® H61
4
Headers
Express Chipset
SATA*1
SATA
SATA
SATA*1
DOM
USB*1
Mini PCI-
E
Slot
PCI-E*1 or SATA*1
LPC
Super I/O 2
Super I/O 1
PCI-E
Realtek
RJ45
8111E/8105E
Port
PCI-E
Realtek
RJ45
8111E/8105E
Port
Audio
Line out/
CODEC
MIC
COM
PS/2
COM
LPT
4 Ports
KB
6 Ports
- 4 -

4. Jumpers / Headers and Connectors
- 5 -

Notes:
[1]: The VGA connector co-lays with a HDMI connector.
Jumpers / Headers and Connectors
1
Front USB Headers
P8
17
ATX2 Power Supply Connector
2
GPIO Header
P8
18
ATX1 Power Supply Connector
3
SATA1 (Pin 7) Power Selection Jumper
P8
19
CPU Socket
4
COM3 Signal selection Jumpers
P8
20
DIMM Slot
5
RS485 Header
P8
21
PCI-E X16 Slot
6
COM2 Header
P9
22
SATA Connectors
7
COM3-6 Headers
P9
23
Mini PCI-E Slot
8
COM7-10 Headers
P10
24
LPT Connector
9
VGA Header
P10
25
COM Connector
10
Front Panel Header
P11
26
LAN Connectors
11
Audio Header
P11
27
Audio Connector
12
CMOS Clear Jumper
P11
28
VGA or HDMI Connector
13
CPU Fan Connector
P11
29
PS/2 Connector
14
System Fan Connector
P11
30
VGA Connector
15
IIC Connector
31
USB Connectors
16
Debug Header
- 6 -

5. Definition of Jumpers / Headers and Connector
[1] Front USB Headers (5*2 Pin 2.54mm)
Location
Header
Pin
Definition
Pin
Definition
1
+ 5V
2
+ 5V
F_USB1
3
USB0-
4
USB1-
5
USB0+
6
USB1+
F_USB2
7
GND
8
GND
10
N/C
[2] GPIO Header（5*2 Pin 2.00 mm）
Location
Header
Pin
Definition
Pin
Definition
1
GPO68
（
0x548,bit 4
）
2
GPO69（0x548,bit 5）
3
GPO70 （ 0x548,bit 6 ）
4
GPO71（0x548,bit 7）
J_GPIO1
5
GND
6
GPI1 （ 0x50C,bit 1 ）
7
GPI6 （ 0x50C,bit 6 ）
8
GPI7 （ 0x50C,bit 7 ）
9
GPI17（0x50E,bit 1）
10
+ 5V
[3] SATA1 (Pin 7) Power Selection Jumper (3*1 Pin 2.54mm)
Location
Jumper
Setting
Function
SATA_P1
1-2
+ 5V
2-3(Default)
GND
Note: When Pin7 of SATA1 set to +5V (SATA_P1 jumps to 1-2), SATA1 can support SATA DOM.
[4] COM3 Signal selection Jumpers (3*1 Pin 2.0mm)
Location
Jumper
Setting
Function
JP1
1-2
RS232
JP2
2-3
RS485
[5] RS485 Header (COM3, 3*1 Pin 2.54mm)
Location
Header
Pin
Definition
Pin
Definition
J_1
1
RS485-
2
GND
3
RS485+
- 7 -

[6] COM2 Header (5*2 Pin 2.54mm)
Location
Header
Pin
Definition
Pin
Definition
1
DCD
2
DSR
3
RXD
4
RTS
J_COM2
5
TXD
6
CTS
7
DTR
8
RI
9
GND
[7] COM3-6 Headers（20*2 Pin 2.00 mm）
Location
Header
Pin
Definition
Pin
Definition
1
COM3_DCD
2
COM3_RXD
3
COM3_TXD
4
COM3_DTR
5
GND
6
COM3_DSR
7
COM3_RTS
8
COM3_CTS
9
COM3_RI
10
GND
11
COM4_DCD
12
COM4_RXD
13
COM4_TXD
14
COM4_DTR
15
GND
16
COM4_DSR
17
COM4_RTS
18
COM4_CTS
COM3-6
19
COM4_RI
20
21
COM5_DCD
22
COM5_RXD
23
COM5_TXD
24
COM5_DTR
25
GND
26
COM5_DSR
27
COM5_RTS
28
COM5_CTS
29
COM5_RI
30
GND
31
COM6_DCD
32
COM6_RXD
33
COM6_TXD
34
COM6_DTR
35
GND
36
COM6_DSR
37
COM6_RTS
38
COM6_CTS
39
COM6_RI
40
GND
- 8 -

[8] COM7-10Headers（20*2 Pin 2.00 mm）
Location
Header
Pin
Definition
Pin
Definition
1
COM7_DCD
2
COM7_RXD
3
COM7_TXD
4
COM7_DTR
5
GND
6
COM7_DSR
7
COM7_RTS
8
COM7_CTS
9
COM7_RI
10
GND
11
COM8_DCD
12
COM8_RXD
13
COM8_TXD
14
COM8_DTR
15
GND
16
COM8_DSR
17
COM8_RTS
18
COM8_CTS
COM7-10
19
COM8_RI
21
COM9_DCD
22
COM9_RXD
23
COM9_TXD
24
COM9_DTR
25
GND
26
COM9_DSR
27
COM9_RTS
28
COM9_CTS
29
COM9_RI
30
GND
31
COM10_DCD
32
COM10_RXD
33
COM10_TXD
34
COM10_DTR
35
GND
36
COM10_DSR
37
COM10_RTS
38
COM10_CTS
39
COM10_RI
40
GND
[9] VGA Header（12*1 Pin 2.00 mm Wafer）
Location
Header
Pin
Definition
Pin
Definition
1
GND
2
VSYNC
3
HSYNC
4
GND
JVGA1
5
VGA_R
6
GND
7
VGA_G
8
GND
9
VGA_B
10
GND
11
DDCDATA
12
DDCCLK
- 9 -

[10] Front Panel Header（5*2 Pin 2.54 mm）
Location
Header
Pin
Definition
Pin
Definition
1
HD LED+
2
Power LED+
3
HD LED-
4
Power LED-
F_PANEL1
5
RESET-
6
PWR+
7
RESET+
8
PWR -
9
N/C
10
[11] Audio Header（5*2 Pin 2.54 mm）
Location
Header
Pin
Definition
Pin
Definition
1
FRONT_MIC_L
2
GND
3
FRONT_MIC_R
4
+ 3.3 V
JP5
5
FRONT_OUT_R
6
GND
7
RRONT_Jack Detect
9
FRONT_OUT_L
10
GND
[12] CMOS Clear Jumper (3*1 Pin 2.54mm)
Location
Jumper
Setting
Function
JCMOS1
1-2(Default)
Normal
2-3
Clear CMOS
[13] CPU Fan Connector (4*1 Pin 2.54 mm)
Location
Connector
Pin
Definition
Pin
Definition
CPU_FAN2
1
GND
2
+12V
3
FAN TAC
4
FAN PWM
[14] System Fan Connector (3*1 Pin 2.54 mm)
Location
Connector
Pin
Definition
Pin
Definition
SYS_FAN2
1
GND
2
+12V
3
FAN TAC
- 10 -

- 11 -
深圳市信步科技有限公司
地址：深圳市福田区车公庙泰然工贸园 210 栋西座 5H T 86-755-88251900 F 86-755-88251910 www.seavo.com

6. BIOS setup
See “SV1-H612A BIOS User Manual” for detail information of BIOS setup.
7. GPIO & Watchdog
7.1 Read and write GPIO
The motherboard provides 8 GPIOs (General Purpose Input and Output register). The GPI
(General Purpose Input register) is a read only register bit. It reflects the incoming logic levels of the I/O
pins, and any writes are ignored. The GPO (General Purpose Output register) is a read and write
register bit. Reads from it reflect the value that is in the flip-flop controlling the output.
The following example shows method to read and write GPIO with Borland C Compile environment
under windows.
void
main(void){ UINT
16 Addr = 0;
UINT8 Bit = 0;
BOOLEN GpioValue1, GpioValue2 = 0;
// read value from gpio<Addr,Bit>.
GpioValue1 = ReadGpio(Addr, Bit);
// write value to gpio<Addr,Bit>.
Status = WriteGpio(Addr, Bit, GpioValue2);
}
UINT8 ReadGpio(UINT8 Addr, UINT8
Bit){ return (inportb(Addr) & (1<<Bit)) >>
Bit;
}
UINT8 WriteGpio(UINT8 Addr, UINT8 Bit, UINT8
Value){ if(Value == 0 || Value == 1){
outportb(Addr, inportb(Addr) & (~(1<<Bit)) | Value<<Bit);
return TRUE;
}
else
return FALSE;
}
7.2 Set & Disable WatchDog
The following example shows method to Set & Disable WatchDog with Borland C Compile
environment under windows.
void main(void){
UINT16 TimeValue = 3;
SetupWDT(TimeValue); //if halted for TimeValue minutes, system will reboot automaticly.

DisableWDT(TimeValue); //used to disable watchdog.
}
void SetupWDT(UINT16 TimeValue){ //Enable
WatchDog Superio_Set_Reg(0x7,0xf1,0x44);
Superio_Set_Reg(0x7,0xf4,0x1e);
Superio_Set_Reg(0x7,0x71,0x00);
Superio_Set_Reg(0x7,0x72,0x90);
Superio_Set_Reg(0x7,0x73,(TimeValue&0xFF));
Superio_Set_Reg(0x7,0x74,(TimeValue>>8));
}
void DisableWDT(UINT16 TimeValue){ //Disable
WatchDog Superio_Set_Reg(0x7,0xf1,0x00);
Superio_Set_Reg(0x7,0xf4,0x00);
Superio_Set_Reg(0x7,0x71,0x00);
Superio_Set_Reg(0x7,0x72,0x20);
}
void Superio_Set_Reg(UINT8 bLDN, UINT8 bReg, UINT8
bValue){ Superio_Enter_Config();
IoWrite8(0x2E,0x07); //Set LDN
IoWrite8(0x2F,bLDN);
IoWrite8(0x2F,bReg);
IoWrite8(0x2F,bValue);
Superio_Exit_Config();
}
void Superio_Enter_Config(void){ //enter superio’s configuration
mode IoWrite8(0x2E,0x87);
IoWrite8(0x2E,0x01);
IoWrite8(0x2E,0x55);
IoWrite8(0x2E,0x55);
Sleep(100);
IoWrite8(0x2E,0x22);
IoWrite8(0x2F,0x80);
}
void Superio_Exit_Config(void){ //exit superio’s configuration mode
IoWrite8(0x2E,0x02);
IoWrite8(0x2F,0x02);
}
【End】
- 12 -
