VIA Technologies P4MA PRO User manual

i
VIA Mainboard
User’s Manual
VIA P4MA PRO
Version 1.0 - August 16th, 2002
P/N 99-51-010811

ii
Copyright
Copyright by VIA Technologies Inc. (“VIA”). No part of this manual may be
reproduced or transmitted in any form without express written authorization
from VIA.
Trademarks
All trademarks are the property of their respective holders.
Data protection
All data should be backed-up prior to the installation of any drive unit or
storage peripheral. VIA will not be responsible for any loss of data resulting
from the use, disuse or misuse of this or any other VIA product.
No Warranty
VIA has made every effort to ensure the accuracy of the content of this
manual. However, it is possible that it may contain technical inaccuracies or
typographical or other errors. VIA will assume no liability for any inaccuracy
found in this publication, nor for damages, direct, indirect, incidental,
consequential or otherwise, that may result from such an inaccuracy, including
without limitation loss of data or profits.
VIA provides this manual “as is”, and does not issue a warranty of any kind,
express or implied, including without limitation implied warranties of
merchantability or fitness for a particular purpose.
The information provided in this manual is subject to change without notice.
VIA reserves the right to alter product designs, layouts or drivers without
notification.

iii
FCC-B Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a class
B digital device, pursuant to part 15 of the FCC rules. These limits are designed
to provide reasonable protection against harmful interference when the equip-
ment is operated in a commercial environment. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accor-
dance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference, in which case the user will be required to correct
the interference at his own expense.
Notice 1
The changes or modifications not expressly approved by the party respon-
sible for compliance could void the user’s authority to operate the equipment.
Notice 2
Shielded interface cables and A.C. power cord, if any, must be used in order to
comply with the emission limits.

iv
TRADEMARKS
All trademarks used in this manual are the property of their respective owners.
Intel and Pentium are registered trademarks of Intel Corporation.
PS/2 and OS/2 are registered trademarks of IBM Corporation.
Windows 95/98/98SE/ME/2000/XP and Windows NT are registered trademarks
of Microsoft.
Netware is a registered trademark of Novell.
Award is a registered trademark of Award Software Inc.
NOTE
1. Always read the safety instructions carefully.
2. Keep this User’s Manual for future reference.
3. Keep this equipment away from humidity.
4. Lay this equipment on a reliable flat surface before setting it up.
5. The openings on the enclosure are for air convection and protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
6. Make sure the voltage of the power source and adjust properly 110/220V
before connecting the equipment to the power inlet.
7. Place the power cord such a way that people cannot step on it. Do not
place anything over the power cord.
8. Always Unplug the Power Cord before inserting any add-on card or mod-
ule.
9. All cautions and warnings on the equipment should be noted.
10. Never pour any liquid into the opening. Doing so could cause damage or
electrical shock.
11. If any of the following situations arises, get the equipment checked by a
service personnel:
* The power cord or plug is damaged
* Liquid has penetrated into the equipment
* The equipment has been exposed to moisture
* The equipment does not work well or does not work according to
the User’s Manual.
* The equipment has dropped or damaged
* The equipment has been visably damaged
12. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT UNCONDI-
TIONED, STORAGE TEMPERATURE ABOVE 600 C (1400F), IT MAY
DAMAGE THE EQUIPMENT.

v
Box Contents
• 1 x VIA Mainboard
• 1 x User’s manual
• 1 x Floppy ribbon cable
• 1 x ATA-66/100/133 IDE ribbon cable
• 1 x 2 Port USB 2.0 Module
• 1 x Driver Utilities CD

vi
Contents
Specifications ........................................................ 1-1
MainboardSpecifications .................................................. 1-2
Mainboard Layout ............................................................ 1-4
Connectors Guide ............................................................. 1-5
Installation ............................................................ 2-1
CPUInstallation ................................................................ 2-2
CPU Installation ............................................................... 2-2
CPU Core Speed.............................................................. 2-3
CPU Fan Installation ........................................................ 2-3
MemoryInstallation ........................................................... 2-5
DDR Module Installation .................................................. 2-6
Power Supply ................................................................... 2-7
ATX 20-Pin Power Connector: ATXPWR....................... 2-7
ATX 12V Power Connector: AUX12V ........................... 2-7
Back Panel ....................................................................... 2-8
Mouse Connector: JMS1 .................................................. 2-8
Keyboard Connector: JKB1 ............................................. 2-8
USB Port Connectors....................................................... 2-9
Parallel Port Connector: LPT1 ......................................... 2-9
Serial Port Connector: COM 1 ....................................... 2-10
MIDI/Game Connector .................................................. 2-10
Audio Port Connectors ................................................... 2-10
RJ45 NIC Port ............................................................... 2-10
VGA Out ........................................................................ 2-10
Connectors ..................................................................... 2-11
Floppy Disk Drive Connector: FDD ................................ 2-11
IrDA Infrared Module Connector: IR ............................. 2-11
Front Panel Audio Connector: F_AUDIO ..................... 2-12
CD-In Connector: CD_IN ............................................. 2-12
Hard Disk Connectors: IDE1 & IDE2 ........................... 2-13
Fan Power Connectors: CPU/SYS FAN ....................... 2-14
Case Connectors: F_PANEL/F_PANEL2 .................... 2-14

vii
Digital Audio Connector: SPDIF .................................... 2-16
Chassis Intrusion Connector: CI ..................................... 2-16
USB pin-header: USB3/4 ............................................... 2-17
Wake-On LAN Connector: WOL .................................. 2-17
Wake-On Ring Connector: WOR................................... 2-18
Jumpers .......................................................................... 2-19
Clear CMOS Jumper: CLEAR_CMOS ......................... 2-19
Audio Codec Auto Detect Jumper: OB_CODEC ......... 2-20
Slots ............................................................................... 2-21
AGP (Accelerated Graphics Port) Slot .......................... 2-21
PCI Slots ........................................................................ 2-21
CNR (Communication Network Riser) Slot ................... 2-21
PCI Interrupt Request Routing ....................................... 2-22
BIOS Setup ........................................................... 3-1
Entering Setup ................................................................... 3-2
Control Keys .................................................................... 3-2
Getting Help ...................................................................... 3-3
The Main Menu ................................................................ 3-4
Standard CMOS Features ................................................ 3-6
Advanced BIOS Features ................................................. 3-8
Advanced Chipset Features............................................. 3-11
Integrated Peripherals...................................................... 3-13
Power Management Setup .............................................. 3-17
PNP/PCI Configurations ................................................. 3-22
PC Health Status............................................................. 3-24
Frequency/Voltage Control .............................................. 3-25
Load Fail-Safe Defaults................................................... 3-28
Load Optimized Defaults ................................................. 3-29
Set Supervisor/User Password ........................................ 3-30
Save & Exit Setup........................................................... 3-32
ExitWithoutSaving ......................................................... 3-33

viii
Software Setup ..................................................... 4-1
Driver Utilities CD Content ............................................. 4-2
Getting Started .......................................................... 4-2
Running the Driver Utilities CD .............................. 4-2
CD Content ................................................................ 4-2

1-1
Specifications
Specifications
1
The VIA P4MA PRO mainboard is based around
the VIA ProSavageDDR P4M266 chipset, which brings
support for high-performance DDR266 SDRAM to the
Intel®Pentium® 4 platform. It is a high performance,
cost-effective and energy efficient SMA chipset for
the desktop PC. VIA’s advanced V-Link controller
brings optimal system efficiency by effectively dou-
bling bandwidth between the chipset’s north and south
bridges. P4M266 integrates S3 Graphics’ 128-bit
ProSavage8 graphics accelerator into a single chip,
providing ideal solution for the consumer and entry
level professionals.
This chapter includes the following sections:
Mainboard Specifications 1-2
Mainboard Layout 1-4
Connectors Guide 1-5

1-2
Chapter 1
CPU
•Supports Intel®Pentium®4 Willamette/Northwood and Celeron®processors
in the 478 pin package
•Supports 1.6GHz, 1.7GHz, 1.8GHz, 1.9GHz, 2GHz, 2.2GHz and upwards
Chipset
•VIA P4M266/VT8235 chipset
- Supports Intel®Pentium®4 and Celeron®processors with 400MHz
(100MHz QDR) CPU
Front Side Bus (FSB)
- Integrated ProSavage8 AGP Graphics
- External 4x AGP Bus
- High Bandwidth V-Link Client controller
- Integrated Hardware Sound Blaster/Direct Sound 6 channel AC’97 audio
- Ultra DMA 66/100/133 master mode PCI EIDE controller
- ACPI 1.0B and APM 1.2 compliant
Main Memory
•2 x 184-pin DDR DIMM sockets
•Supports up to 2GB of 2.5v DDR SDRAM (PC2100/PC1600)
Slots
•1 x AGP (Accelerated Graphics Port) 4X slot
•3 x PCI 2.2 32-bit PCI bus slots (supports 3.3v/5v PCI bus interface)
•1 x CNR (Communication Network Riser) slot
Onboard IDE
•Integrated IDE controller provides IDE HDD/CD-ROM with PIO, Bus Mas-
ter and Ultra DMA 66/100/133 operation modes
•Can connect up to 2 channel for 4 IDE devices
Onboard Floppy
•1 x FDD Connector
Onboard LAN
•VIA VT6103 10/100 Base-T Ethernet PHY
Onboard Audio
•VIA VT1616 6 channel AC'97 Codec
Mainboard Specifications

1-3
Specifications
Onboard I/O Connectors
•1 USB connector for 2 additional USB 2.0 ports
•SPDIF ( optical & coaxial ) connector
•Front-panel audio connectors ( Mic and Line Out )
•CD Audio-in connector
•FIR connector
•Wake-on-LAN, Wake-on-Ring
•CPU/System FAN
•System intrusion connector
Back Panel I/O
•1 PS2 mouse port
•1 PS2 keyboard port
•1 Parallel port
•1 game/MIDI port
•1 RJ-45 LAN port
•1 Serial port
•2 USB 2.0 ports
•1 VGA port
•3 audio jacks : line-out, line-in, and mic-in; switched to 6 channel output
during 6 channel operations
BIOS
•Award Plug & Play BIOS
•Desktop Management Interface (DMI) function which records your
mainboard specifications
Dimension
•MicroATX Form Factor
•24.5cmx20.5cm
Mounting
•6 mounting holes

1-4
Chapter 1
Mainboard Layout
VIA P4MA PRO Mainboard
Top: Mouse
Bottom: Keyboard
Top: RJ45
Bottom: USB ports
Top:
Parallel port
Bottom:
COM 1/VGA out
Top: Game port
Bottom:
Line-Out
Line-In
Mic
FDD
F_PANEL
Socket 478
M
BIOS
AUX12V
OB_Codec
AGP Slot
PCI Slot 1
PCI Slot 2
PCI Slot 3
CNR
SPDIF
USB 3/4
SYSFAN
CLEAR_CMOS
WOL
WOR
IR
FDD IDE 1
IDE 2
CI
CD_IN
F_AUDIO
ATXPWR
CPUFAN

1-5
Specifications
Connectors Guide
Connectors Function Reference
ATXPWR ATA 20-pin power connector see p. 2-7
ATX12V ATA 12 V power connector see p. 2-7
JMS1 Mouse connector see p. 2-8
JKB1 Keyboard connector see p. 2-8
USB Port Connectors Connecting to USB devices see p. 2-9
LPT1 Parallel port connector see p. 2-9
COM1 Serial port connector see p. 2-10
MIDI/GameConnector Connecting to joystick orgamepad see p. 2-10
Audio PortConnectors Line-Out/Line-In/Mic-In see p. 2-10
RJ45 NIC Port LAN port see p. 2-10
VGA Out VGA connector see p. 2-10
FDD Floppy disk drive connector see p. 2-11
IR IrDAInfraredModuleconnector see p. 2-11
F_AUDIO Front panel audio connector see p. 2-12
CD-IN CD-In connector see p. 2-12
IDE 1 & IDE2 Hard disk connectors see p. 2-13
CPUFAN/SYSFAN Fan Power connectors see p. 2-14
F_PANEL Case connectors see p. 2-14
SPDIF Digital audio connector see p. 2-16
CI Chassis intrusion connector see p. 2-16
USB 3/4 USB pin-header see p. 2-17
WOL Wake-On LAN connector see p. 2-17
WOR Wake-On Ring connector see p. 2-18
CLEAR_CMOS Clear CMOS jumper see p. 2-19
OB_CODEC Audio Codec Auto Detect jumper see p. 2-20
AGP Slot Connecting to AGP card see p. 2-21
PCI Slot Connecting to PCI cards see p. 2-21
CNR Slot Connecting to CNR card see p. 2-21

Installation
2-1
Installation
This chapter provides you with information
about hardware setup procedures. While installing
the mainboard, carefully hold the components and
closely follow the installation procedures. Some
components may be damaged if they are installed
incorrectly.
It is recommended to use a grounded wrist
strap before handling computer components. Static
electricity can damage some components.
This chapter contains the following sections:
CPU Installation 2-2
Memory Installation 2-5
Power Supply 2-7
BackPanel 2-8
Connectors 2-11
Jumpers 2-19
Slots 2-21
2

Chapter 2
2-2
The VIA P4MA PRO mainboard supports the Intel®Pentium®4 Willamette/
Northwood and Celeron®processors in the 478 pin package (PGA478). When
installing the CPU, ensure the CPU has a large-size heatsink and a cooling
fanattachedon thetopto preventoverheating. If the heatsinkand cooling fan
are not included with the CPU, contact your dealer to purchase and install them
before turning on the computer.
CPU Installation
Overheating will cause serious damage to the CPU
and system. Ensure the cooling fan and heatsink work
properly to protect the CPU from overheating.
WARNING!
1. Pull the lever sideways away
fromthe socket. Then raisethe
lever up to a 90-degree angle.
2. Look for the dot/cut edge. The
dot/cut edge should point to-
wards the lever pivot. The
CPU will only fit in the correct
orientation.
3. Hold the CPU down firmly,
then close the lever shut to
complete the installation.
CPU Installation

Installation
2-3
CPU Fan Installation
As processor technology pushes to faster speeds and higher performance,
thermal management becomes increasingly important. To dissipate heat, you
MUST attach the CPU cooling fan and heatsink on top of the CPU. Follow the
instructions below to install the Heatsink/Fan:
CPU Core Speed
If CPUClock = 100MHz
Core/Bus ratio = 18
then CPU core speed = CPU Clock x Core/Bus ratio
= 100MHz x 18
= 1.8GHz
2. Position the heatsink and fan onto the
retention mechanism.
1. Locate the CPU and its retention
mechanism on the mainboard.
Retention mechanism
Overclocking
This mainboard is designed to support overclocking. However,
please make sure your components are able to tolerate such abnor-
mal settings, before overclocking. Any attempt to operate beyond
product specifications is not recommended. We do not guarantee the
damages or risks caused by inadequate operation or operation be-
WARNING!

Chapter 2
2-4
5. Connect the fan power cable from the mounted fan to the 3-pin fan power connector
on the mainboard.
3. Mount the fan on top of the heatsink. Press down the fan firmly until its four clips
become wedged in the holes of the retention mechanism.
4. Press the two levers down to secure the fan. Each lever can be pressed down in only
ONE direction.

Installation
2-5
The VIA P4MA PRO mainboard provides 2 sockets for 184-pin, 2.5V DDR
DIMM modules with 4 memory banks. To operate properly, at least one DIMM
module must be installed.
You can install PC1600/PC2100 DDR SDRAM modules on the DDR DIMM
slots (DDR 1~2).
DDR (Double Data Rate) SDRAM is similar to conventional SDRAM, but
doubles the rate of transfer by transfering data twice per cycle. This is achieved
by transfering data on both the rising and falling edges of the clock. Conven-
tional SDRAM only uses the rising edge of the clock to transfer data. Therefore,
conventionalSDRAMiscalledSDR(SingleDataRate)SDRAM.DDRSDRAM
uses 2.5 volts as opposed to 3.3 volts used in SDR SDRAM, and requires 184-
pin DIMM modules rather than 168-pin DIMM modules used by SDR SDRAM.
DDR SDRAM is also known as SDRAM-II, DDR DRAM and DSDRAM
(Double-Speed DRAM). PC2100 running at 133MHz will produce 2.1GB/s
memory bandwidth. High memory bandwidth makes DDR an ideal solution for
high performance PC, workstations and servers.
Memory Installation
Socket 478
M
DDR DIMM Sockets
(DDR 1~2)

Chapter 2
2-6
DDR Module Installation
You can install either single sided or double sided 184-pin DDR DIMM mod-
ules into the DDR DIMM slot, depending on your requirements. Differing from
SDR DIMM, DDR DIMM modules have only one notch on the center of the
module. The number of pins on either side of the breaks are also different. The
memory modules will only fit if placed in the correct orientation.
You can install DDR SDRAM modules in any of the following combinations:
Slot Memory Module TotalMemory
Slot 1
(Bank 0 & Bank 1) 64MB, 128MB, 256MB, 512MB, 1GB 64MB~1GB
Slot 2
(Bank 2 & Bank 3) 64MB, 128MB, 256MB, 512MB, 1GB 64MB~1GB
Maximum System Memory Supported 64MB~2GB
1. The DDR DIMM module has only one notch on the center.
2. Insert the DDR module vertically into the DDR DIMM slot. Make sure the
notch is correctly aligned.
3. The plastic clips at sides of the DIMM slot will automatically close shut.
Notch

Installation
2-7
Power Supply
The VIA P4MA PRO mainboard requires an ATX power supply for powering
the system. Before inserting the power supply connector, always make sure
that all components are installed properly to ensure that no damage will be
caused.
ATX 20-Pin Power Connector: ATXPWR
This connector is for the ATX power supply. To connect to the ATX power
supply, make sure the plugs of the power supply are inserted in the correct
orientation and the pins are properly aligned. Then, push down the plugs
firmly into the connector.
ATX 12V Power Connector: ATX12V
This 12V power connector is used to provide power to the CPU.
PIN SIGNAL
11 3.3V
12 -12V
13 GND
14 PS_ON
15 GND
16 GND
17 GND
18 -5V
19 5V
20 5V
PIN SIGNAL
1 3.3V
2 3.3V
3 GND
45V
5 GND
65V
7 GND
8 PW_OK
9 5V_SB
10 12V
ATXPWR Pin Definition
PIN SIGNAL
1 GND
2 GND
3 12V
4 12V
ATX12V Pin
ATXPWR
AUX12V
13
24
10
1
20
11
Socket 478
M
